AnyTone Apollo II User manual

Apollo II
Instruction Manual

This appliance is marked with the symbol for selecve sorng of waste
electrical and electronic equipment. This means that this product must be
removed by means of a selecve collecon system according to European
Direcve 2012/19 / EU either in order to be recycled or dismantled to
reduce any impact on the environment. For more informaon you can
contact your distributor, seller or your local or regional administraon.
Electronic products which have not been subject to selecve collecon
are potenally dangerous to the environment and public health due to
the possible presence of dangerous substances.
Do not dispose of unusable packaging in household waste; dispose of
them in containers intended for recycling.
In order to accomplish with RF exposure requirements for mobile transming
devices, there must be a minimum distance of 20 cm between the antenna
and the people.
This device complies with Direcve 2011/65 / EU (RoHS) of the European Parliament and of the
Council of 8 June 2011 restricng the use of certain hazardous substances in electrical and electronic
equipment.

CONTENTS
FUNCTIONS AND CHARACTERS................................................................... 1
STANDARD ACCESSORIES............................................................................ 2
OPTIONAL ACCESSORIES............................................................................. 2
INSTALLATION................................................................................................. 2
Microphone Connection............................................................................... 2
Antenna Connection .................................................................................... 3
Power Connection ....................................................................................... 3
Fuse Replacement....................................................................................... 3
Intall Microphone Hanger............................................................................. 4
Intall External Speaker................................................................................. 4
GETTING ACQUAINTED.................................................................................. 5
Front Panel .................................................................................................. 5
Rear Panel................................................................................................... 5
Microphone .................................................................................................. 6
KEY FUNCTION OPERATION ......................................................................... 6
BACKGROUND FUNCTION MENU OPERATION......................................... 10
PUBLIC DATA FUNCTION MENU OPERATION ........................................... 14
CHANNEL FUNCTION MENU OPERATION.................................................. 15
DTMF ENCODE SETTING.............................................................................. 16
SELF –DEFINE KEY SETTING ...................................................................... 17
SPECIFICATIONS........................................................................................... 18

There may be some restricons for the use of this equipment in any
country of the European Union. For more informaon consult your dealer
or telecommunicaon authories.

1
1. FUNCTIONS & FEATURES
● FTF LCD display
● 12/24V voltage(4W version only)
● Full alloy body for heat radiation
● Programmable keypad
● CTCSS/DCS (optional)
● Wireless microphone control(optional)
● Cell-phone APP control (optional)
● AM/FM multi norms
● Flexible menu and programming software
● DTMF
● SQ, ASQ
● SQ, ASQ open/close value setting
● RF Gain
● Scan
● Dual watch
● Programmable RB
● CH9/19
● NB
● HI-CUT
● Voltage protection
● 8 memory channel
● TOT
● Backlight control
● Automatic power on
● Keypad lock

2
2. STANDARD ACCESSORIES
3. OPTIONAL ACCESSORIES
4. INSTALLATION
8 ohm speaker
PC cable
Choose a idea location to install the radio.
1. Mark the location for screws by intall racket.
2. Fix the bracket by screws.
3. Fix radio base into install bracket and lock by adjusting knobs.
Radio Screws Microphone Pads
Adjusting screws Microphone Hanger
Install bracket
non-slip mat Fuse(5A 250V)
MIC
P1 FUNC P4
P5
P6
P2
P3

3
4.01 Microphone connection
1. Plug microphone connector into jack.
2. Pull on the dustproof cover for microphone connector.
4.02 Antenna connection
4.03 Power connection
1. Screw on the antenna into antenna jack.
2. To make full use of this radio, it is necessary to locate the antenna in a well
grounded place, and well adjust the SWR.
* Please enquiry the local dealer for choosing and intallation of suitable antenna.
This radio adopt 13.2V power supply.
Connect the red wire to the positive terminal of the battery, and the black wire to the
negative terminal of the battery.
EXTSP
ANT
MIC
P1 FUNC P4
P5
P6
P2
P3
MIC
P1 FUNC P4
P5
P6
P2
P3
»Never press PTT before install the antenna, it might burn the transistor.

4
4.05 Intall Microphone hanger
4.06 Intall external speaker
1. Choose idea location and mark for screw point.
2. Fix the hanger by the srews in accessory list.
This radio adopt 4-8 ohm, 4W external speaker.
1. Install the external speaker in idea location.
2. Plug in the seaker connector into jack.
EXTSP
ANT
4.04 Fuse replacement
This radio adopt 5A, 250V fuse
1. Open the fuse holder
, 250V FUSE
IN-LINE
FUSE HOLDER
2. Replace the fuse and screw on the holder.
FUSE
IN-LINE
FUSE HOLDER
IN-LINE
FUSE HOLDER
IN-LINE
FUSE HOLDER
5A

5
5.01 Front Panel
5.02 Rear Panel
5. GETTING ACQUAINTED
NO. Key Functions
1Power On/Off/Mute
2Programmable Key 1
3Programmable Key 2
4Programmable Key 3
5Programmable Key 4
6Programmable Key 5
7Programmable Key 6
8Function Menu key
9 MIC Microphone Jack
10 Channel Switch/Push key/ Key lock
NO. Functions
11 External Speaker Jack
12 Antenna Jack
25
1
9
8
3 6
10
11
12
47
ANT EXT SP
MIC
P1 FUNC P4
P5
P6
P2
P3

6
5.03 Microphone
6. KEY FUNCTION OPERATION
Channel Down Channel UP
Microphone cable
Mic
PTT
Connector
6.01
1. Short press key, the radio emit a prompt and LCD display on.
2. Power off radio: hold key, until LCD display off.
3. when radio is powered on, short press key, LCD displays
AUDIO: MT, the radio volume will mute.
short press key, LCD displays AUDIO: Esc, radio will recover last volume level.
6.02 Channel switch~PUSH
1. Turn channel switch anti-clockwise to move to down channel, turn it clockwise to up
channel.
2. Fast channel adjust: short press [PUSH] key to adjust channel by 10 steps each push.
3. Key lock: Hold [PUSH] key, LCD displays Key Lock, All keys except [PTT] key are
locked.
Hold [PUSH] key again to unlock the key.
