Rage Jetpack Commander User manual

INSTRUCTION MANUAL
Width (Diagonal Shaft to Shaft):2 9/16” (65mm)
Total Width: 3 5/8” (92mm)
Total Depth: 3 5/8” (92mm)
Height: 2 3/4” (70mm)
Weight: 1 oz. (27g)
Charger: USB type charger
Transmitter: 4-channel, 2.4GHz
Flight Time: 5 to 6 minutes

1. Plug the USB charger into a 5V USB power source, such as a laptop.
on a full charge.
4. After charging, unplug the USB charging cable. Do not attempt to
overcharge the battery.
• Use only the supplied lithium battery. Using any
• Only use the included USB charging cable to
Charging the Jetpack Battery
Caution:
charge the Jetpack battery.
other battery may damage the Jetpack.
On/Off
Charge port
2. Plug other end into the charge port on the back of the Jetpack (see photo).
The charger will show a red LED light when charging the battery. When the
red LED turns off, the battery is fully charged.
around the house. The built-in 6-axis gyro control system provides amazing stability. Features like Auto
Take-Off and Landing and Altitude Hold assist in learning to control the Jetpack Commander. The Dual
Rate feature enables you to increase the speed and agility of the aircraft as your skills progress and you
landings. You can even use the included sticker sheets to customize the Jetpack Commander and make
it your own.
The Jetpack Commander is RTF (Ready-To-Fly) aircraft, so it arrives factory-assembled with everything
, it also
. Simply
the house within minutes of opening the box!

Use a screwdriver to open the battery compartment. Then insert
three AAA batteries, matching the polarities (+ and -) marked
inside. Use alkaline batteries for optimal performance. Replace
the cover and screw it in place.
Installing the Transmitter Batteries
Transmitter Instructions
1. Press the On/Off button on the transmitter to turn it on. Press and hold the power button on the Jetpack
(see drawing above for location of the on/off switch) until the LED lights are blinking. Move the left stick
up till you hear a beep, then move it all the way down until you hear another beep. The transmitter is now
paired with the Jetpack and the lights will turn solid.
2. After pairing, with the Jetpack on the ground, press the Take Off/Land button or move the left stick up to
take off. To avoid ground effect turbulence, ascend to at least 12” (30cm) from the ground. Press the Take
Off/Land button again and the Jetpack will slowly descend, land and turn the motors off.
3. Push the left stick up to ascend, push the left stick down to descend. Push the left stick left/right to
rotate.
4. Push the right stick up to move forward, push the right stick down to move backward. Push the right
stick left/right to move left or right.
5. Forward/Backward Trim: If the Jetpack tends to move forward, press the Backward Trim button several
times until the Jetpack no longer moves forward on its own. Press the Forward
backward on its own.
6. Left/Right Trim: If the Jetpack drifts right, press the left trim button; if it drifts left, press the right trim
button.
7. Dual Rates: Press the button on the right top of the transmitter to change from low to high rate. The
controller will beep twice. High rates increases the sensitivity for increased manueverability. Press the
rates until they are comfortable with the controls.
pressed, a series of beeps indicates the mode is active. Move the right stick in one of the four directions to
360°
Flip
High/Low
Rates

Landing Pad Assembly
1
2
3
Tape the four arch segments together
Unfold the landing pad
Tape the arch to the
landing pad
Aerial Combat Streamers
Tape a streamer to the back of each rear motor
Two or more Jetpack Commanders can
engage in aerial combat. The goal is to
cut your opponents streamer with the
propeller of your Jetpack Commander.
to cutting your own streamer.
If ribbon becomes entangled
in a prop, immediately re-
duce the throttle to off. Care-
fully untangle the streamer

Calibration Instructions
2. Place the Jetpack on level ground, turn it on and pair with the
transmitter.
3. Move the left stick all the way down and the right stick all the way up.
Hold them there until the LED lights on the Jetpack stop blinking
and remain solid.
4. The calibration process is now complete and the Jetpack is ready
to take off.
Battery Notes
•
• Do not leave batteries in hot places such as an automobile in direct sunlight.
• Do not mix new and used batteries, or install used batteries in other equipment.
• Do not mix Alkaline, Standard (Carbon-Zinc), or Rechargeable (Nickel Cadmium) or
• (Nickel Metal Hydride) batteries.
• Do not reverse the polarity (positive and negative terminals) of batteries.
• For best results use type AAA batteries.
• Install only new batteries of the same type in your product.
• Batteries should be recycled or disposed of per state and local guidelines.
Replacement Parts
Warning:
Small parts，not for
children under 3 years old.
.ragerc.com or
call 800 622-7223 M-F 9:00-5:00 mountain time.
A
A
B
B
Propeller Replacement
1. The 4 propellers are not identical. Each propeller is labeled with an A
or B.
2. When replacing a prop, refer to the drawing to the right for correct prop
placement.
that it inhibits movement.
Item Number Description
RGR4510
Propeller Set (4) Black
RGR4511
Propeller Set (4) White
RGR4512
Replacement Motor (CW)
RGR4513
Replacement Motor (CCW)
RGR4514
2.4GHz Transmitter, Red
RGR4515
2.4GHz Transmitter, White
RGR4516
Combat Streamer Set (20)
RGR4517
Landing Pad
RGR4518
Stunt Hoop
RGR4519
USB Type Charger

Look for these additional great products from Rage R/C at your local retailer
or visit hobbyrecreationproducts.com
RGRB1205 Black Marlin Brushless R/C Boat RGRA1108 X-FLY RTF VTOL Aircraft
RGRC1800 R18MT 1/18 Scale Monster Truck
RGRB1300 Eclipse 1M RTR Sailboat

Limited Warranty
Warranty Period: Rage R/C warrants that the Jetpack Commander (“Product”) will be free from
original factory defects in materials and workmanship upon purchase (“Warranty Period”).
damage, (b) damage due to acts of God, accident, misuse, abuse, negligence, commercial use,
or (e) Product not purchased from an authorized Rage R/C dealer.
OTHER THAN THE EXPRESS WARRANTY ABOVE, RAGE R/C MAKES NO OTHER WARRANTY OR
REPRESENTATION, AND THEREFORE DISCLAIMS ANY AND ALL IMPLIED WARRANTIES, INCLUD-
ING, WITHOUT LIMITATION, THE IMPLIED WARRANTIES OF NON-INFRINGEMENT,
MERCHANTABILITY AND SUITABILITY FOR A PARTICULAR PURPOSE. THE PURCHASER
ACKNOWLEDGES THAT THEY ALONE HAVE DETERMINED THAT THE PRODUCT WILL MEET THE
REQUIREMENTS OF THEIR INTENDED USE.
Product(s) involved in a warranty claim. Service or replacement decisions are at the sole
SERVICE OR REPLACEMENT AS PROVIDED UNDER THIS WARRANTY IS THE PURCHASER’S SOLE
AND EXCLUSIVE REMEDY.
CONSEQUENTIAL DAMAGES, LOSS OF PROFITS OR PRODUCTION OR COMMERCIAL LOSS IN ANY
WAY, REGARDLESS OF WHETHER SUCH CLAIM IS BASED IN CONTRACT, WARRANTY, TORT,
NEGLIGENCE, STRICT LIABILITY OR ANY OTHER THEORY OF LIABILITY, EVEN IF RAGE R/C HAS
BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.
Further, in no event shall the liability of Rage R/C exceed the individual price of the Product on
purchaser or user are not prepared to accept the liability associated with the use of the
to the place of purchase.
Rage R/C, an exclusive brand of:
2034 South 3850 West
Salt Lake City, Utah 84104 Printed in China
