Rain Bird IQ Operation manual

IQ™ Network Communication Cartridge (IQ-NCC)
Installation & User Guide for the IQ™Central Control System

Symbols
b NOTE: Symbol alerts the user to important operating,
functionality, installation or maintenance instructions.
c WARNING: Symbol alerts the user to the presence of
electricity or electromagnetic energy which may constitute
a risk of electric shock, radiation exposure or other hazard.
d CAUTION: Symbol alerts the user to important instructions or conditions that could seriously affect irrigation effectivity
or device operation.
g DIAL: Symbol alerts user of requirement to turn the dial
on the device to an appropriate setting in order to follow
subsequent instructions.
e REPEAT: Symbol indicates that a repetition of previous
steps or actions may be required in order to continue or
complete the process of programming the device.
Rain Bird Support
For technical assistance contact Rain Bird
Technical Services at 1-800-247-3782
Visit us on the web at www.rainbird.com
Or contact Rain Bird Global Support Plan:
U.S. and Canada
1-866-477-9778
[e-mail]
Australia
1800 225 512
[e-mail]
Europe
[phone]
EuropeGSP@ rainbird.fr
International
1-520-434-6216
[e-mail]

I
IQ Network Communication Cartridge
Contents
Introduction .................................................. 1
Welcome to Rain Bird........................................... 1
About This Manual................................................................. 1
ESP-LX Series Controllers.................................................... 1
IQ™Central Control System .................................. 1
IQ™ Network Communication Cartridge .................... 1
Types of IQ™Satellite Controllers .................................... 2
Direct Satellite ..................................................................... 2
Server Satellite..................................................................... 2
Client Satellite...................................................................... 2
Products Covered in this Manual ........................ 2
Figure 1 - IQ™ Network Communication
Cartridge ................................................................................ 3
Installation.................................................... 4
IQ™Network Communication Cartridge
Components......................................................... 4
Network Communication Cartridge ............................. 4
IQ Port Cable or Antenna ................................................... 4
Connection Module (CM)................................................... 4
Connection Module (CM) Port Cable............................ 4
Radio Modem Cable ............................................................. 4
Configuration Options......................................... 4
Figure 2 - Installation Overview .................................. 5
Box Contents ........................................................ 6
Figure 3 - Box Contents................................................... 7
Cartridge Installation .......................................... 8
Access Controller Cabinet.................................................. 8
Remove the Communication Cable Knock-out ...... 9
Install an External Antenna for LXMM........................10
Install the Cartridge.............................................................12
Figure 4 - Installation/ Cable Options ....................13
Complete Cable Connections........................................15
Internal Antenna Installation..........................................18
IQ-NCC Configuration ........................................ 20
Direct Satellite Setup Wizard ..........................................20
Server Satellite Setup Wizard..........................................22
Client Satellite Setup Wizard...........................................24
NCC Configurator Software ............................... 25
Operation.................................................... 26
Controls and Indicators ..................................... 26
Reset Button ...........................................................................26
LED Indicators........................................................................26
Table 1 - IQ Port LED Indicators.................................27
Table 2 - CM Port LED Indicators ..............................28
Table 3 - Radio Port LED Indicators .........................28

II IQ Network Communication Cartridge
Status Menu ....................................................... 29
Direct Satellite Controllers...............................................29
RS-232, Phone or Ethernet...........................................29
GPRS or WiFi........................................................................30
Server Satellite Controllers ..............................................31
RS-232, Phone or Ethernet...........................................31
GPRS or WiFi........................................................................32
Client Satellite Controllers ...............................................33
IQNet Alarms Menu............................................ 34
Appendix ..................................................... 36
Connection Modules.......................................... 36
Connection Module Options..........................................36
Base Module.......................................................................36
Flow Smart Module.........................................................36
IQ Connection Module..................................................37
IQ Flow Smart Connection Module.........................37
Connection Module Installation...................................38
Connect IQ-CM Grounding Wire ..............................40
SIM Card Installation ......................................... 41

1
IQ Network Communication Cartridge
Welcome to Rain Bird
Thank you for purchasing your new state-of-the-art Rain
Bird IQ Network Communication Cartridge (IQ-NCC) for the
IQ Central Control System. For more than seven decades,
Rain Bird has led the irrigation industry in meeting all of your
water management needs by providing the highest quality
products and services available.
About This Manual
This manual is an addendum to ESP-LX Series Controller
Installation & Operations Guides. The instructions in this
manual guide you through installing an IQ-NCC Cartridge
in an ESP-LX Controller (not included), connecting the
communication cables or antenna, and conguring the
cartridge for communication with the IQ computer or IQ
Server Satellite Controller.
ESP-LX Series Controllers
Rain Bird ESP-LXME and ESP-LXD controllers normally
operate as stand-alone irrigation controllers, but can be
upgraded to become eld components of the IQ Central
Control System with the installation of an IQ Network
Communications Cartridge.
IQ™Central Control System
The IQ Central Control System provides remote
communication capability for programming and monitoring
multiple ESP-LXME and ESP-LXD Satellite Controllers from a
single personal computer.
IQ™ Network Communication Cartridge
The addition of an IQ Network Communication Cartridge
(IQ-NCC) turns a new or existing ESP-LXME or ESP-LXD into
an IQ Satellite Controller.
Five types of Network Communication Cartridges are
available to provide communication with the IQ Central
Computer:
l RS-232 (External Modem or Computer Direct Connect-
also used for IQ Client Satellite Communication with an IQ
Server Satellite)
l Phone (Telco)
l Ethernet (Wired LAN Network)
l GPRS (Cellular)
l WiFi (Wireless LAN Network)
Introduction

2IQ Network Communication Cartridge
Types of IQ™Satellite Controllers
IQ Satellite Controllers are congured as either a Direct,
Server, or Client Satellite. The dierences and capabilities
of each are listed below:
Direct Satellite
Direct Satellites communicate with the IQ Central Computer
through a wired or wireless connection to an IQ-NCC. Direct
Satellites do not communicate with other Satellites.
Server Satellite
Server Satellites communicate with the IQ Central Computer
through a wired or wireless connection with an IQ-NCC.
Communication with up to 149 Client Satellites over the
IQNet is accomplished using a radio modem or a high-speed
communication cable connection. (An optional IQ-FSCM-
LXME or IQ-CM-LXD Connection Module must be installed
to establish a cable connection.)
Client Satellite
Client Satellites communicate with the Server or other
Client Satellites over the IQNet using a radio modem or a
high-speed communication cable connection. (An optional
IQ-FSCM-LXME or IQ-CM-LXD Connection Module must be
installed to establish a cable connection.)
Products Covered in this Manual
This manual describes the installation of the following
Rain Bird IQ™ products:
l RS-232 Network Communication Cartridge (IQ-NCC-RS)
l Phone Network Communication Cartridge (IQ-NCC-PH)
l Ethernet Network Communication Cartridge (IQ-NCC-EN)
l GPRS/Cellular Network Communication Cartridge
(IQ-NCC-GP)
l WiFi Network Communication Cartridge (IQ-NCC-WF)
l GPRS/Cellular External Antenna (IQ-EXTANT-GP)
l WiFi External Antenna (IQ-EXTANT-WF)
l IQ-FSCM-LXME Flow Smart Connection Module
l IQ-CM-LXD Connection Module
b NOTE: The IQ-NCC-GP cartridge requires a SIM card
and GPRS/cellular telemetry service account that is
not provided and must be purchased separately. See
the SIM Card Installation section in the Appendix for
details.

3
IQ Network Communication Cartridge
Figure 1 - IQ™ Network Communication Cartridge
(IQ-NCC-GP shown)

4IQ Network Communication Cartridge
Installation
This section provides instructions for installing and
conguring an IQ Network Communication Cartridge into
an ESP-LXME or ESP-LXD controller.
IQ™Network Communication
Cartridge Components
Network Communication Cartridge
Five types of cartridges are available to communicate with
the IQ Central Computer through a direct cable connection,
external modem, phone line, wired or wireless LAN, or a
GPRS/Cellular network.
IQ Port Cable or Antenna
The IQ Port cable or antenna provides communication with
the IQ Central Computer.
Connection Module (CM)
The Connection Module (CM) installed in your ESP-LX
Controller allows high-speed cable communication between
Server and Client Satellites on the IQNet.
Connection Module (CM) Port Cable
The Connection Module (CM) Port cable provides the
connection between the IQ-NCC and the CM.
Radio Modem Cable
A radio modem can also be connected to the IQ-NCC to
provide wireless radio communication between Server and
Client Satellites on the IQNet.
Configuration Options
Before beginning installation, the following conguration
options need to be determined and/or identied:
l Type of Cartridge (RS, PH, EN, GP, or WF)
l Type of Satellite Controller (Direct, Server, Client)
l Type of communication with other satellites (wireless
connection using a radio modem, wired connection using
an IQNet PE Communication Cable, or none)
l Controller model (ESP-LXME or ESP-LXD)
l Type of connection to the IQ computer (direct cable
connect, external modem, phone cord, Ethernet cable,
cellular or WiFi antenna)

5
IQ Network Communication Cartridge
Figure 2 - Installation Overview
3
A
ESP-LX Controller Front Panel
B
IQ Network Communication
Cartridge (IQ-NCC-EN shown)
C
Connection Module (CM) Cable
(CM Y-Cable shown)
a. To IQNet Radio Modem
b. To Connection Module
D
IQ Port Cable (or Antenna)
E
Ground Wire (to earth ground)
F
IQNet PE Communication
Cable to other Satellites
G
Connection Module
(FSCM-LXME shown)
3
4
5
6
3
7
1
2
b.
a.

6IQ Network Communication Cartridge
Box Contents
The following components are included with each IQ-NCC
and are required for installation.
b NOTE: If anything is missing, please contact your
distributor before proceeding.
1. IQ Network Communication Cartridge
(ONE of the following):
l IQ-NCC-RS (RS-232)
l IQ-NCC-PH (Phone)
l IQ-NCC-EN (Ethernet)
l IQ-NCC-GP (GPRS/Cellular)
l IQ-NCC-WF (WiFi)
2. Cartridge to Connection Module cables
(BOTH of the following):
l CM Y-Cable.
l CM Straight Cable
3. IQ Computer Connection Cable or Antenna
(ONE of the following):
l RS-232 External Modem Cable (IQ-NCC-RS)
l RJ-11 Phone Cord (IQ-NCC-PH)
l RJ-45 Ethernet Cable (IQ-NCC-EN)
l GPRS/Cellular Internal Antenna (IQ-NCC-GP)
l WiFi Internal Antenna (IQ-NCC-WF)
4. Installation & User Guide
