1) Introduction
The MK-III sensor assembly has been designed to offer improved durability and serviceability.
This sleek new design is 33 inches high and weighs just over 7 pounds. It is the most accurate,
durable, and easiest to install weather station available.
The long range MK-III-LR features a powerful new 2.4 GHz spread spectrum radio that
increases range to 1 mile line of sight. It also features a real time 2 second wind speed and
direction update interval.
2) Getting Started
Congratulations! You are unpacking the ultimate in fine weather watching equipment. RainWise
has been setting industry standards in precision environmental monitoring instrumentation since
1974. The MK series weather station you have just purchased is the result of our years of
expertise.
Before permanently installing your system, set it in the same room as your receiving device, turn
the system on and confirm successful communication.
3) Installation
3.1) Choosing Location
The best location for your weather station is one that is free of obstruction and at an elevation
high enough to prevent interference to the anemometer (wind sensor) from nearby trees or
buildings.
Ideally, the station should be no closer to an obstruction than 10X the obstruction’s height.

5
RainWise MK-III Users Guide
2016Revision
3.2) Mounting Options
The mounting mast included with your sensor assembly has an outside diameter of 1 11/16” and
an inside diameter of 1 5/16”. The length of the mast is 18”. There are many ways to mount the
system utilizing the mast. The RainWise mono mount or tripod are the most common methods
of mounting but the mounting mast can be placed over another pipe, into another pipe, hose-
clamped to a pipe or post, or drilled and through bolted to a surface.
Regardless of how you mount the system the bottom of the electronics enclosure should not
extend more than 12” or less than 7” above the support of the mounting mast. The reason for
this is stability of the tipping bucket rain gauge; unintended movement may cause inaccurate
rainfall counts.
The station should be free of obstructions or heat-absorbing items and should have a clear line-
of-sight between the station and the receiving device.
Mono Mount Tripod Mount
Tripod Mount: Ensure the distance
between the bottom of the control
box and the tripod is no less than 7
inches and no more than 12 inches.

6
RainWise MK-III Users Guide
2016Revision
3.21) Roof Mount
When roof-mounting the sensor assembly the unit should be mounted toward an edge of the roof
(preferably on the prevailing wind side of the building) and it should be installed at least 2-1/2
feet above the roofline. Avoid locating the station near any heat sources such as chimneys or
vents. The anemometer may be separated from the station and mounted separately if necessary to
ensure that it is adequately free from interference. An adapter kit is available through RainWise
called the wind extension kit. 50 feet of cable (maximum length), a support mast, coupling
connector and a cap are supplied in a package. The cost is $50.00.
3.3) Transmitting Installation
The MK-III LR series station can transmit up to 1 mile with a clear line-of-sight between the
weather station and the Oracle display or other RainWise receiving unit. The 418Mhz model can
transmit up to 400 feet with a clean line-of-sight.
Things that may reduce or disable transmission include:
•Metal roofing or siding
•Brick, stone or cement structures
•Trees or dense foliage
400’ clear line-of-sight for (418Mhz model)
1 mile clear line-of-sight for (LR Model)
3.4) Installation Steps
1. Secure the support tube in the desired mounting apparatus as described above. Slide the MK
station down over the necked-down section of the support tube until seated and the slot lines
up with the retaining screw. Tighten the screw.
2. Rotate the station until the solar panel faces TRUE SOUTH in the Northern Hemisphere or
TRUE NORTH in the Southern Hemisphere. Once positioned correctly ensure that the
support tube is secure and unable to rotate.

7
RainWise MK-III Users Guide
2016Revision
3. Adjust the solar panel for optimum performance by tilting it to the appropriate angle and
locking it into place with the bracket located behind it. Use the table in Section 3.5) to
determine your optimum angle.
4. Turn the system on by pulling the switch toward the solar panel.
The system is now transmitting.
3.5) Adjusting Solar Panel
Rotate weather station for panel to face:
• True North in Southern Hemisphere
• True South in Northern Hemisphere
Match the angle of the panel to the latitude of your location using the following chart.
Latitude
Panel Angle
(from Verticle)
0°- 22.5° 60° (Low Hole)
22.5°- 55° 30° (Mid Hole)
55°- 90° 15° (Top Hole)

8
RainWise MK-III Users Guide
2016Revision
4) Maintenance
Depending on the location of your system, the rain gauge may periodically get clogged with dirt,
leaves or other debris. When this happens your rainfall data will appear significantly lower than
other totals in your area or cease to record altogether. Clean the rain gauge as follows:
1. Loosen the 4 screws holding the collector portion onto the base of the rain gauge.
2. Twist the collector counter-clockwise and remove it.
3. Observe the cotter pin holding the plastic screen in place. Straighten the cotter pin
legs to remove it along with the plastic screen.
4. Clear debris from the screen, collector drain, and white dipper assembly.
5. Visually inspect the small circuit board located beneath the white dipping assembly.
If there is evidence of corrosion call RainWise for a replacement switch, which we
will ship with a complete set of installation instructions.
6. Place the screen and cotter pin back in place and bend the cotter pin legs up and
around the inlet as they were before. If they are not bent up and away from the tipper
mechanism they will prevent a complete tip.
7. Replace the collector and tighten the 4 screws.

9
RainWise MK-III Users Guide
2016Revision
5) Troubleshooting
Before calling customer support, check the cable connections to the receiver box and the display.
Make sure the cable is plugged in correctly - it should snap and lock into position on both ends.
If you do call, please have the serial number of your MK-III available, and please have the
display with you near the phone.
5.1) Interference from Nearby RainWise Weather Stations
If your weather station is within signal range of another RainWise weather station, the rainfall
counts on your receiving unit will increase rapidly by 2.36" blocks until it reaches 99.99". This
will occur with or without actual rain. The solution to this problem is to change the station ID
code in your system as outlined below.
5.11) 418Mhz Weather Station
You must call RainWise to request firmware chips to physically swap out with your existing
firmware chips in the outside sensor assembly and display receiving devices. The IP 100 and
CC3000 must be sent to RainWise for reprogramming.
5.12) LR Weather Station
The code may be changed by dip switches located in the upper left corner of the motherboard.
The switches that change the code are #1 and #2.
1. Remove the solar panel cover by loosening the 4 screws in the corners. Carefully pull the
cover away far enough to unplug the solar panel from the motherboard and set aside.
2. Placing switch #1 in the "ON" position changes the code to 1, placing switch #2 in the
"ON" position changes the code to 2. Placing switches #1 and #2 in the "ON" position
changes the code to 3.
3. Plug the solar panel back into the motherboard and secure the solar panel cover to the
enclosure by replacing and tightening the 4 screws.
The code in your receiving devices must match the code set in your sensor assembly. Refer to
the Owner’s Manual of the appropriate receiving device for instructions to change the codes.

European Union (CE)
Southern Hemisphere
418/433 MHz
Hardwire

  N 
oz
10
RainWise MK-III Users Guide
2016Revision
5.13)Dip Switch Chart
The DIP switch is used to select the mode of your device.
Station Coding
Station Coding
2.4 GHz
Everywhere
Except European Union
(Special Radio in Japan)
Northern Hemisphere
