RAKwireless RAK7249 User manual

22 PAGES
User Manual for
www.RAKwireless.com
Visit our website for more documents.
Version V1.3 | March 2019
DIY Enterprise LoRa Gateway
WisDevice Series
RAK7249

2
RAK7249
2
RAK7249 User Manual V1.3
Table of Contents
1 Overview..................................................................................................................................................... 4
1.1 Introduction......................................................................................................................................... 4
1.2 Main Features.................................................................................................................................... 4
2 DIY Enterprise Gateway..........................................................................................................................5
2.1 Main Board..........................................................................................................................................5
2.2 Enclosure............................................................................................................................................ 6
2.3 Backup Battery...................................................................................................................................6
2.4 Accessories........................................................................................................................................ 6
3 DIY Configuration.....................................................................................................................................7
4 Hardware Interfaces.................................................................................................................................8
5 Product Specifications........................................................................................................................... 9
5.1 Main Specifications............................................................................................................................9
5.2 RF Specifications.............................................................................................................................10
5.2.1 WiFi Radio Specifications.................................................................................................. 10
5.2.2 LoRa Radio Specifications.................................................................................................10
5.3 Software Specifications.................................................................................................................. 11
5.3.1 LoRa......................................................................................................................................11
5.3.2 Network.................................................................................................................................11
5.3.3 Management........................................................................................................................ 11
5.4 Block Diagram..................................................................................................................................12
5.5 Main Board Overview......................................................................................................................12
6 WEB Configuration Guide................................................................................................................... 14
6.1 Connect the Gateway..................................................................................................................... 14
6.2 WEB Management Platform.......................................................................................................... 14
6.2.1 Status Overview.................................................................................................................. 14
6.2.2 LoRaWAN Packet Logger..................................................................................................16
6.2.3 WAN Network Configuration............................................................................................. 17
6.2.4 Cellular Network Configuration......................................................................................... 18
6.2.5 Packet Forwarder Configuration....................................................................................... 18
6.2.6 Network Ping Watchdog.....................................................................................................19
6.2.7 Backup or Upgrade............................................................................................................. 20
7 Contact Information...............................................................................................................................21
8 Revision History..................................................................................................................................... 22
9 Document Summary..............................................................................................................................22

3
RAK7249
3
RAK7249 User Manual V1.3
List of Tables
Table 1 | DIY Configuration.........................................................................................................................7
Table 2 | Main Specifications......................................................................................................................9
Table 3 | WiFi Radio Specifications.........................................................................................................10
Table 4 | LoRa Radio Specifications....................................................................................................... 10
Table 5 | LEDs Status Description...........................................................................................................13
List of Figures
Figure 1 | DIY Enterprise Gateway............................................................................................................ 5
Figure 2 | Hardware Interfaces - Front...................................................................................................... 8
Figure 3 | Hardware Interfaces - Rear.......................................................................................................8
Figure 4 | Block Diagram...........................................................................................................................12
Figure 5 | Circuit Board..............................................................................................................................12
Figure 6 | Status Overview........................................................................................................................15
Figure 7 | LoRaWAN Packet Logger-1................................................................................................... 16
Figure 8 | LoRaWAN Packet Logger-2................................................................................................... 16
Figure 9 | WAN Network Configuration...................................................................................................17
Figure 10 | Cellular Network Configuration............................................................................................ 18
Figure 11 | Packet Forwarder Configuration.......................................................................................... 18
Figure 12 | Radio Configuration............................................................................................................... 19
Figure 13 | Ping Watchdog Interface.......................................................................................................19
Figure 14 | Ping Watchdog Configuration...............................................................................................20
Figure 15 | Backup or Upgrade................................................................................................................ 21

4
RAK7249
4
RAK7249 User Manual V1.3
1Overview
1.1 Introduction
The Enterprise Grade DIY outdoor Gateway is an ideal product for IoT commercial
deployment. It contains the Main Board, Operator-grade waterproof enclosure, backup
battery and mounting accessories. The hardware main board completely integrates the
WIFI, 4G, GPS and PoE main supply with an integrated back-up battery. The firmware
implements a fully featured LoRaWAN™ complinant network base station. The
Gateway has a range of over 15Km line-of-sight and over 2Km in dense urban
environments.
The DIY Gateway brings more flexiblity for the developer to create an enterprise grade
solution: our most important difference is our flexible development support structure,
allowing for faster development and time to market. We offer both a ready to go
firmware image for openWRT based platforms and an open SDK for integration into
hardware to support the needs of each customer.
1.2 Main Features
Enterprise grade network gateway with your own configuration.
LoRaWAN™ Stack Inside and integrate the Web UI for management.
Complete Hardware specification including LoRa concentrator, Cellular, GPS and
WIFI.
Supports Power of Ethernet (PoE) IEEE 802.3af/at-Compliant Class 4, 48V.
Battery Backup sustains operation for 5 hours under typical conditions.
IP67 waterproof enclosure with cable gland.

5
RAK7249
5
RAK7249 User Manual V1.3
2DIY Enterprise Gateway
Create your own Enterprise Gateway using the supplied building Blocks:
Main Board
Enclosure
Backup Battery
Accessories
Figure 1 | DIY Enterprise Gateway
Note: All the pictures are just for reference, if any discrepancy, please adhere to the actural
product instead.
2.1 Main Board
CPU:RAK634 Module(MT7628 inside)
RAM:128MB DDR2
Flash:16MB
WIFI: 2x2 MIMO 802.11b/g/n
Backup Battery
Accessories
Main Board
Enclosure

6
RAK7249
6
RAK7249 User Manual V1.3
LoRa concentrator
Standard version with 8 channel Gateway and also support Max.16 channel
Gateway.
Tx Power is up to 27dBm and Rx sensitivity is down to -142dBm.
4G Cellular
Quectel EG95 for CAT4 cellular network.
L70 GPS Module
Power-over-Ethernet (PoE)
100M base-T Ethernet with IEEE802.3af/at standard Power-over-Ethernet.
2.2 Enclosure
IP67 waterproof white color.
Interface: 5 x N-Type connectors for Antenna,1 PoE port and 1 reserve port.
Weight (with cable): approximately 70.54oz (2kg).
Dimensions: 220mm x 220mm x 104mm.
Wall thickness: 2mm.
Support up to 70~100 mm diameter pole mount.
2.3 Backup Battery
12V lithium battery, capacity is 5000mAH for more than 5 hours lifetime under
typical operation.
Battery powered real time clock.
Battery Within 140 x 70 x 30mm.
DC 5.5 x 2.1 circular joint with two interfaces, one male and one female.
2.4 Accessories
Mounting Kit
PoE Injector
WiFI Antenna
GPS Antenna
LoRa Antenna
LTE Antenna

7
RAK7249
7
RAK7249 User Manual V1.3
3DIY Configuration
The bellow table shows the main board configurations of the DIY Enterprise Gateway.
Part Number
8 Channel
SX1301
16 channel
SX1301
Cat4 Cellular
GPS
WIFI
Battery Backup
RAK7249-0x-14x
√
√
√
√
RAK7249-1x-14x
√
√
√
√
RAK7249-2x-14x
√
√
√
√
√
RAK7249-3x-14x
√
√
√
√
√
RAK7249-0x
√
√
√
RAK7249-1x
√
√
√
RAK7249-2x
√
√
√
√
RAK7249-3x
√
√
√
√
Table 1 | DIY Configuration

8
RAK7249
8
RAK7249 User Manual V1.3
4Hardware Interfaces
Figure 2 | Hardware Interfaces - Front
Figure 3 | Hardware Interfaces - Rear

9
RAK7249
9
RAK7249 User Manual V1.3
5Product Specifications
5.1 Main Specifications
Feature
Specifications
Computing
MT7628, DDR2RAM 128MB
WIFI Feature
Frequency: 2.400-2.4835GHz(802.11b/g/n)
RX Sensitivity: -95dBm (Min), TX Power: 20dBm (Max)
Operation Channels: 2.4GHz: 1-13
LoRa Feature
SX1301 Mini PCIe card (connects maximum of two),
8Channels (Optional: 16channels)
RX Sensitivity: -142dBm (Min), TX Power: 27dBm (Max)
Frequency: EU433, CN470, EU868, US915
AS920, AS923, AU915, KR920, IN865
Cellular Feature
With EG95: LTE CAT 4
Cellular Variant for Europe
LTE FDD: B1/B3/B7/B8/B20/B28A
WCDMA: B1/B8
GSM: 900/1800MHz
Cellular Variant for North America
LTE FDD: B2/B4/B5/B12/B13
WCDMA: B2/B4/B5
Power Supply
PoE(IEEE 802.3af/at-Compliant), 42~57VDC
Power Consumption
12W (typical)
ETH
RJ45(10/100M)
Antenna
5 N-Type connectors
Ingress Protection
IP67
Enclosure Material
Aluminum
Weight
Approximately 111.11oz (3.15kg)
Dimension
220mm x 220mm x 104mm
Operating Temp.
-30˚C to 65 ˚C
Installation method
Pole or Wall mounting
Table 2 | Main Specifications

10
RAK7249
10
RAK7249 User Manual V1.3
5.2 RF Specifications
5.2.1 WiFi Radio Specifications
Feature
Specifications
Wireless Standard
• IEEE 802.11b/g/n
Operating Frequency
•ISM band: 2.412~2.472(GHz)
Operation Channels
• 2.4GHz: 1-13
Transmit Power
(The max. power may be
different depending on
local regulations)
-per chain
•802.11b
19dBm@ 1Mbps
19dBm@ 11Mbps
•802.11g
18dBm@ 6Mbps
16dBm@ 54Mbps
•802.11n (2.4G)
18dBm@MCS0 (HT20)
16dBm@MCS7 (HT20)
17dBm@MCS0 (HT40)
15dBm@MCS7 (HT40)
Receiver Sensitivity
(Typical)
•802.11b
-95dBm@ 1Mbps
-88dBm @11Mbps
•802.11g
-90dBm @6 Mbps
-75dBm@54Mbps
•802.11n (2.4G)
-89dBm@MCS0 (HT20)
-72dBm @MCS7(HT20)
-86dBm @MCS0(HT40)
-68dBm @MCS7(HT40)
Table 3 | WiFi Radio Specifications
5.2.2 LoRa Radio Specifications
Feature
Specifications
Operating Frequency
• EU433, CN470, EU868, US915
• AS920, AS923, AU915, KR920, IN865
Transmit Power
• 27dBm (Max)
Receiver Sensitivity
• -142dBm (Min)
Table 4 | LoRa Radio Specifications
RF Specifications

11
RAK7249
11
RAK7249 User Manual V1.3
5.3 Software Specifications
5.3.1 LoRa
Supports class A, B & C
Supports LoRaWAN protocol
Supports country code setup
Supports TX power setup
Supports data logger
Supports statistics
Supports location setup
Supports server address & port setup
5.3.2 Network
Supports WiFi AP mode
Supports LTE APN setup
Supports uplink backup
Supports 802.1q
Supports DHCP Server/Client
Supports router module NAT
Supports firewall
5.3.3 Management
Supports WEB Management
Supports SSH2
Supports firmware update
Supports NTP

12
RAK7249
12
RAK7249 User Manual V1.3
5.4 Block Diagram
Figure 4 | Block Diagram
5.5 Main Board Overview
Figure 5 | Circuit Board

13
RAK7249
13
RAK7249 User Manual V1.3
The RAK7249 mainboard provide a Reset key and 6* LEDs for status indication.The
The function of the Reset key is as follows:
Short press: Restart the Gateway;
Long press (5s and above): Restore Factory Settings;
The status of the LEDs is described as below. Please refer to the printing of the LEDs
on the mainboard.
LEDs
Status Indication Description
LED1(PWR)
Power Indicator, Led on when device power on
LED2(ETH)
ON - linkup
OFF - linkdown
Flash - Data Transmitting and Receiving
LED3(LoRa1)
ON - LoRa1 is working
OFF - LoRa1 is not working
Flash - Indicate that LoRa1 Packet
receiving and sending
LED4(LTE)
Slow Flash 1(200ms Bright/1800ms Dark)
- unregistered network (in search)
Slow Flash 2(200ms Dark/1800ms Bright)
- idle status(online)
Flash - Data Transmitting and Receiving
ON - Voice is working
LED5(LoRa2
for 16 channel)
ON - LoRa2 is working
OFF - LoRa2 is not working
Flash - Indicate that LoRa2 Packet
receiving and sending
LED6(WLAN)
AP Mode :
ON - WLAN is working;
Flash - Data Transmitting and Receiving
STA Mode :
Slow Flash(1Hz) - Connection Disconnected;
ON - Connection Successful;
Flash - Data Receiving and Sending;
Table 5 | LEDs Status Description

14
RAK7249
14
RAK7249 User Manual V1.3
6WEB Configuration Guide
6.1 Connect the Gateway
1. Via WiFi
The WiFi of the gateway works in AP mode by default. The default SSID format is
"RAKxxxx_xxxx” such as "RAK7240_D3BD", “D3BD” is the last two bytes of the
gateway MAC address. Connecting to the SSID using your PC, then can automatically
get the IP address. After successful connection, the WEB management platform can be
accessed through the IP address 192.168.230.1 of the gateway LAN interface.
2. Via IP Alias of WAN Port
The WAN interface of the gateway has a static IP (Auto IP Alias) generated
automatically according to the MAC address. The format of the IP address is
169.254.x.x/255.255.0.0. The 3 and 4 bytes of IP correspond to the decimal
representation of the fifth and sixth bytes of the MAC address, respectively. For
example, the MAC address is xx: xx: xx: xx: D3: BD, and the Alias IP is
169.254.211.189/255.255.0.0.
Connecting your PC's Ethernet interface to gateway WAN interface, and adding
169.254.x.x/255.255.0.0 IP address to PC's Ethernet interface, then we can access
gateway's WEB management platform through Alias IP.
3. Via WAN Port DHCP IP
When DHCP Server is in the network where the gateway WAN interface is located, the
WAN interface can automatically get the IP address. After inquiring the IP address of
the gateway through DHCP Server, the WEB management platform of the gateway can
be accessed through the DHCP IP address of WAN interface.
6.2 WEB Management Platform
Open the browser, enter the IP address of the gateway, and open the login page of the
WEB Management Platform. Enter the user name and password (user name and
password default is root) and click login.
6.2.1 Status Overview

15
RAK7249
15
RAK7249 User Manual V1.3
Figure 6 | Status Overview
Recevied: Shows the total number of LoRa messages received by the LoRa gateway;
Transmittd: Shows the LoRa message sent by the LoRa gateway;
Active Nodes: Shows the number of active LoRa nodes within the LoRa gateway coverage
(nodes that sent messages in 10 minutes)
Busy Nodes: Shows the number of busy nodes within the LoRa gateway coverage (nodes
with an average message spacing of less than 60s)
Dutycycle Of LoRa Channel:
The chart shows the thermodynamic charts of the "duty cycle" of all channels over time over
a period of 12 hours. The longitudinal axis is time and the minimum interval is 60s. The
horizontal axis is the channel frequency. Each value represents the average duty cycle of
the channel within 60s (range is: 0%-100%), green represents the low duty cycle, and red
represents the high duty cycle.
LoRa Traffic:
The chart shows the LoRa packet rate（packet/min）of each spread factor in two hours.
The vertical axis represents the LoRa packet rate, in packet/min, six colors represent six
spread factors, and the total height represents the sum of all the rates of LoRa packet.

16
RAK7249
16
RAK7249 User Manual V1.3
6.2.2 LoRaWAN Packet Logger
Figure 7 | LoRaWAN Packet Logger-1
Figure 8 | LoRaWAN Packet Logger-2
LoRaWAN Packet Logger: Real-time recording and parsing of messages sent and
received by LoRa gateway and can be filtered according to message type and node address.

17
RAK7249
17
RAK7249 User Manual V1.3
Type: Filter by message type. Select ALL as unfiltered and display all messages.
DevAddr: Filter messages based on node addresses.
Hide CRC_ERR packet: When it is selected, no CRC check error message will be
displayed.
Pause/Play: Pause/start message recording.
Clear: Clear the current record.
Download: Save the current record locally in CSV format.
6.2.3 WAN Network Configuration
Figure 9 | WAN Network Configuration
This is for Ethernet uplink network (WAN) configuration. It supports the DHCP/PPPoE/static
IP three protocols.

18
RAK7249
18
RAK7249 User Manual V1.3
6.2.4 Cellular Network Configuration
Figure 10 | Cellular Network Configuration
This is for LTE cellular uplink network (WWAN) configuration. Please fill in
APN/User/Password correctly according to the information provided by the network
operators.
6.2.5 Packet Forwarder Configuration
Figure 11 | Packet Forwarder Configuration
General Setup : LoRa Network Server Configuration
Beacon Setup : Class B / Beacon Configuration
GPS Information ：GPS Location Setup

19
RAK7249
19
RAK7249 User Manual V1.3
Figure 12 | Radio Configuration
Radio Configuration : Rx Setup
Tx Gains ：Tx Power Setup
6.2.6 Network Ping Watchdog
Figure 13 | Ping Watchdog Interface
Ping Watchdog monitors the communication quality of network links by constantly pinging
the specified IP address or domain name on the specified uplink network interface. When
network link failures are found, scheduled measures are taken automatically, such as
<restart interface>/<reduce the priority of this uplink network interface>/<restart the device>.

20
RAK7249
20
RAK7249 User Manual V1.3
Note: Reducing the priority of an uplink interface only works when the LoRa gateway uses
both the Ethernet uplink link and the LTE cellular network uplink link.
WAN interface represents the Ethernet uplink interface and WWAN represents the LTE
cellular network uplink interface. If Ping watchdog is opened on both uplink network
interfaces at the same time and action is set to Increase Gatway Metric, the two uplink links
form backup links and automatically switch to another link when one link fails. The priority of
the two links is determined by the default gatway metric of their respective network
interfaces. The default gatway metric can be set in Network->WAN Network and Network-
>Cellular Network. The lower the gatway metric, the higher the priority of the link.
Figure 14 | Ping Watchdog Configuration
6.2.7 Backup or Upgrade
In Backup/Flash Firmware page, you can backup your configuration or restore your gateway,
and you can upgrade to a new firmware. As shown in the following figure.
