Raleigh PC-14000 Quick start guide

Item Number: PC-14000
Raleigh
Wicker Gazebo
Agora Outdoor LivingTM
Design and Manufacture by
Pacific Currents Inc.
Assembly Instrucons and
Owner’s Manual
(Actual canopy top color may vary)
Dimensions: 12’ W x 12’ L x 11’ H

22012 PC-14000
First, compare the parts in the box with the parts list on the following pages and
make sure that none are missing. If you discover any missing parts, please visit
www.pacificcurrentsinc.com or call [phone].
Save your sales receipt as you
will need this to obtain service.
Choose and measure the final locaƟon where you would like to place the prod-
uct and ensure that it will fit a 12’ x 12’ rectangle with 11’ height clearance. Then,
choose an assembly area as close as possible to this final locaon and large enough
to layout and pre-assemble all the parts for this Gazebo.
It is highly recommended that you cover the work surface with a tarp or other fabric
to prevent scratches to the finish or other damage during assembly.
You will need these addional tools: a ladder and an adjustable wrench.
You may also need these addiontal tools (oponal): work gloves, waterproofing
spray.
Prepare the work area:
General Notes:
Pre-Assembly Steps
Thank you for choosing a Pacific Currents Product.
Please make sure you have carefully read and understood
these assembly instructions before you begin.
1. You will need the help of another person to assemble this product. Please ask a
friend or neighbor for assistance!
2. Once a unit has been pre-assembled in each step, please set it aside unl further
instrucons.
3. For all customers, we highly recommend that you remove your canopy top in
cases of severe inclement weather such as thunderstorms. Damage due to acts of
nature are not covered in the warranty.
4. You do not need to disassemble the gazebo during winter months. However, to
prevent damage to the frame and canvas top due heavy snow loads, remove the
canvas top and store it in a dry locaon unl spring.

PC-14000 2012 3
Parts Idenficaon
A
D
GH
B
E
C
(Note: Not drawn to Scale)
x 4
x 4
x 4 x 4
x 4
x 4
x 4
Column
Left Beam (Short)
Corner Bar (Long)
Column Base
Right Beam (Long)
Corner Bar (Short)
Column Base Cover
Top Connector
Fx 1

42012 PC-14000
Nx 4
Canopy Top Ground Stake
Ballast bag
Ma
x 1 x 16
Lx 12
U Brackets for Canopy Frame
K
Jx 4 x 4
Left Skylight Right Skylight
Ix 8
Center Support Bar

PC-14000 2012 5
***Important***
For missing or defecƟve parts, Do NOT return to the place of purchase.
Call our toll free number below or visit www.pacificcurrents.com.
Please have your sales receipt ready when you call.
[phone]
Bug Screen Sunshade
Addional Parts (Sold Separately)

62012 PC-14000
Hardware Idenficaon
[x 8]
M6 × 28 Bolt
Bolt Set
P
[x 8]
M6 × 20 Bolt
Bolt Set
O
[x 12]
M6 × 10 Bolt
Bolt Set
S
[x 16]
M6 × 40 Bolt
Bolt Set
R
[x 28]
M6 × 35 Bolt
Bolt Set
Q
[x 8]
M6 × 65 Bolt
Bolt Set
T

PC-14000 2012 7
How to use Hardware
Bolt and Washer Assembly
(Part O)
Bolt and Washer Assembly
(Parts Q, R, T)
Snap on Bolt Cover
Washer
Washer Washer

82012 PC-14000
[x 8]
[x 12]
T
S
Assembly Instrucons
Step 1
Assemble main beams.
[x 4] [x 4] [x 8]
D E L
D
E
T
S
S
L
L

PC-14000 2012 9
[x 4]
L
Step 2
Assemble columns.
[x 4] [x 4] [x 4]
A B C
[x 8]
O
[x 12]
S
B
B
L
A
C
S
O
O

10 2012 PC-14000
Step 3
Insert sand bags into columns and
fill with ballast.
[x 4]
N
[x 4] [x 4] [x 4]
aED
Step 4
AƩach beams to columns (and insert stakes if over
soŌsurface).
[x 4]
R
DE
a
N
R
R

PC-14000 2012 11
Step 5
[x 1]
[x 4]
[x 4] [x 4]
F G H
Q
Assemble roof frame corner members to gazebo columns
and center connector.
H
H
G
G
F
Q

12 2012 PC-14000
Step 6
Assemble roof vent frame members to main beams and
center connector.
[x 8]
I
[x 8]
Q
F
I
I
Q

PC-14000 2012 13
Step 7
Assemble roof vent panels.
[x 1] [x 1]
[x 4]
J K
P
J
K
P
P

14 2012 PC-14000
Step 8
Aach roof vent panels to roof.
[x 16]
Q
Q
Q

PC-14000 2012 15
Step 9
Drape fabric canopy over roof frame. It may help to pull
the peak of the canopy top through the middle of the
roof frame first.
[x 1]
M
M

16 2012 PC-14000
Step 10
Insert ends of roof frame corners into pockets in
the canopy and screw in curtain eback hooks.
[x 8]
U
U

PC-14000 2012 17
FAQ (Frequently Asked QuesƟons)
Q: Will the gazebo frame ever rust?
A: The powder coated finish of the metal frame prevents rusng so long as the metal itself is
not exposed. Exposure of the metal may occur due to accidental scratches or long-term wear
and tear. Occasional touch ups to affected areas with weatherproof paint will ensure many
years of connued enjoyment from your gazebo.
Q: Can I use grills or barbecues inside the gazebo?
A: No, we do not recommend this. While the canopy top is fabricated using a fire resistant
material, our gazebos are not designed to accomodate an open flame. Please refrain from
using your grill inside the gazebo.
Q: Will the gazebo move or blow away in strong winds?
A: Several features of our design were considered to allow the gazebo to remain very stable
across a range of weather condions. The four vents in the canopy top help to allow low to
medium winds to pass through the covering.
However, if you install the gazebo in an area where strong winds are persistent, it is advisable
to take further steps to fasten the gazebo to the ground. If the gazebo is installed over a so
natural surface (grass or dirt), you may drive metal stakes (included) through the holes located
at the boom of the panels and into the ground. If the gazebo is installed over a hard surface
(wooden decks or concrete paos) it will be necessary to separately purchase screws or bolts
and nuts to affix the frame to your installaon surface. Please visit your local Mills Fleet Farm
Store for more opons.
Q: I like being outdoors, but cannot stay for long because of mosquitoes. Are bug screens
available for my gazebo?
A: Yes! Bug screens for all gazebo models are available separately for purchase as an
accessory.
Care Instructions:
Canvas Top:
The polyester top (Canvas Top) can be machine washed using a small amount of detergent. Do not
machine dry or use bleach for the Top. Top may also be spray-rinsed while attached to Gazebo and
lightly scrubbed with a soft broom. DO NOT use any hard abrasives to scrub.
The canvas top is not waterproof. However, a waterproofing spray (not included) may be used to
prevent rain water infiltration.
The canvas top MUST be removed and stored in a dry location in the event of snow fall. Accumulated

18 2012 PC-14000
snow WILL severely damage your gazebo if the canvas top is not removed.
Gazebo Frame:
Any rust on the frame as a result of scratches on the surface can be cleaned with soap and water
and wiped down with a soft cloth. DO NOT use any hard abrasives to scrub. Touch-up paint is not
available but the colors can be matched at your local hardware store.
All metal parts may be sprayed with a clear laquer finish to maintain the attractiveness of your gazebo
over time and allow you to enjoy your gazebo for as long as possible.
Woven Wicker Surfaces:
Please clean regularly with fresh soapy water and dry using a damp soft clean cloth monthly or as
often as necessary
IMPORTANT - Winter storage: If you live in an area that experiences snow in the winter, remove
the canvas top and store it in a location that is dry and free of moisture.
1 Year Limited Warranty:
A. Purchaser assumes all risk in the assembly and use of this unit.
B. *** A claim under our warranty must be submitted by the original purchaser to Pacific Currents Inc.,
via email, website, or fax within 24 hours of the defect occuring and within 12 months of the date of
purchase, validated by providing a copy of the original sales receipt, a photograph of the damaged area
and a brief description. ***
C. All components carry a one year limited warranty from date of purchase against defects in material and
workmanship arising under normal use. This warranty does NOT cover wear and tear, nor weathering due
to climate and other environmental factors, nor does it cover failure resulting from accident, misuse,
neglect , mishandling, modification, or damage that is attributed to acts of nature (high winds, rain, snow,
etc.). This warranty does not cover incidental or consequential damages resulting from use of product, or losses
arising out of any breach of this warranty.
D. Fulfillment of this warranty shall only include direct replacement of damaged parts as described above to be
arranged at the discretion of Pacific Currents Inc. If it is not feasible or practical to replace the damaged part
directly, Pacific Currents Inc. shall arrange a return of merchandise or replacement between the purchaser and
the place of purchase.
Please contact us should you have any questions concerning assembly, care information, warranty
coverage, and missing or defective parts.
Customer Service:
[phone]
Email: info@pacificcurrentsinc.com
Website: www.pacificcurrentsinc.com
Enjoy your new gazebo and thank you for
choosing a Pacific Currents Inc. product!
