RAMTONS RM/272 User manual

READ AND SAVE THESE INSTRUCTIONS
Version 1.0 2015
Attention: Pictures in the IM are for reference only.
OWNER’S MANUAL
16" STAND FAN
MODEL: RM/272
3
2
1
0
145x210mm Black

Read Rules for Safe Operation and Instructions Carefully.
CAUTION
1. If the supply cord is damaged, it must be replaced by manufacturer
or its service agent or a similarly qualified person in order to avoid
a hazard.
2. Indoor use only.
3. To protect against the risk of electrical shock, do not immerse the
unit, cord or plug in water or other liquid.
4. This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities, or
lack of experience and knowledge, unless they have been given
supervision or instruction concerning use of the appliance by a
person responsible for their safety. Young children should be
supervised to ensure that they do not play with the appliance.
5. When the appliance is not in use and before cleaning, unplug the
appliance from the outlet.
6. Keep electrical appliances out of reach from Children or infirm
persons. Do not let them use the appliances without supervision.
7. When the fan was assembled, the rotor blade guard shall not be
taken off anymore
- Prior cleaning unplug the fan
- The rotor guard shall not be dissembled/opened to clean the rotor
blades.
- Wipe the fan enclosure and rotor blade guard with a slightly damp
cloth.
WARNING
1. Never insert fingers, pencils, or any other object through the grille
when fan is running.
2. Disconnect fan when moving from one location to another.
3. Be sure fan is on a stable surface when operating to avoid
overturning.
4. DO NOT use fan in window, rain may create electrical hazard.
5. Indoor use only.
RULES FOR SAFE OPERATION
1

PART FIGURE
Base
Note: All the pictures in this manual are for explanation purpose only.
Any discrepancy between the real object and the illustration in the
drawing shall be subject to the real subject.
‘7’finger screw
Front guard Circlip Spinner Plastic nut Rear guard Clutch knob
Motor
housing
Tighten
knob
Internal Pole
Extension
Pole
Height
adjustment
ring
Piano
switch
Motor
shaft
Fan blade
1. Unscrew the “7” finger screw from the Extension Pole. (Fig.1)
2. Insert the extension pole in the base and tighten the “7” Finger screw. (Fig.2)
3. From the extension pole loosen the height adjustment ring and adjust the internal
pipe to the desired height. (Note: If you can’t find the internal pole, it slides inside
the extension pole. You can pull it out from the extension pole.) (Fig.3)
4. To attach the head unit to the extension pole, loosen the thumb screw on the
bottom of the head unit. Place the head unit on the extension pole and tighten the
thumb screw in alignment with the groove on the internal pole. (Fig.4)
CAUTION: Height adjustment ring must be fully fastened before the assembly of the
motor section to the extension pole.
ASSEMBLY OF BASE & COLUMN UNIT
2

3
GUARD & FAN BLADE ASSEMBLY
1. Unscrew the spinner clockwise (or take the spinner out from the bag) and the
plastic nut counter clockwise to remove both of them. Fix the rear guard to the
motor then tighten the plastic nut again. (Fig. 5)
2. Insert the blade into shaft, and make sure the rotor shaft pin is fitted into groove
of the blade. Turn the spinner counter clockwise to tighten the blade. (Fig. 6)
3. Fix the front guard and the rear guard with circlip and then tighten the fan guard
locking screw and nut. (Fig. 7)
Annulargroove
Mountinghole
Thumb screw
Fig.3
Loose
Fig.4
Fig.1Fig.2
Fig.5 Fig.6 Fig.7

3
2
1
0
OPERATING INSTRUCTIONS
1. SPEED CONTROL
Fan speed is controlled by the switch :
0-1-2-3 (Off-Low-Medium-High)
2.OSCILLATION CONTROL
To make the fan oscillate, press the clutch knob located on the top
of the motor housing. To get the directional airflow, pull the clutch
knob up to its initial position.
To adjust the air flow upward or downward, push the guards lightly to the desired
direction.
4.HEIGHT ADJUSTMENT
The height of the fan can be adjusted by loosening the locknut carefully raising or
lowering the fan and firmly re-tightening the locknut.
4
The fan requires little maintenance. Do not try to fix it by yourself. Refer it to
qualified service personnel if service is needed.
1. Before cleaning and assembling, fan must be unplugged.
2. To ensure adequate air circulation to the motor, keep vents at the rear of the
motor free of dust. Do not disassemble the fan to remove dust.
3. Please wipe the exterior parts with a soft cloth soaking a mild detergent.
4. Do not use any abrasive detergent or solvents to avoid scratching the surface.
Do not use any of the following as a cleaner: gasoline, thinner, bending.
5. Do not allow water or any other liquid into the motor housing or interior parts.
MAINTENANCE INSTRUCTION
CLEANING
1. Be sure to unplug from the electrical supply source before cleaning.
2. Plastic parts should be cleaned with a soft cloth moisten with mild soap.
Thoroughly remove soap film with dry cloth.
