Chef Stand Self-Contained Refrigerated Base model 20000SC
model 20072SC shown
Specifications:
CABINET EXTERIOR: Cabinet body is constructed of all metal. The
top, front, and louver panel are stainless steel. Full length, 12
gauge steel subtop beneath one piece stainless steel top with
1/2" marine edged. Body ends are stainless steel. 6" stainless
steel legs with adjustable bullet feet are mounted to a heavy
gauge steel frame assembly which is integrally welded to bottom
of assembly. Unit totally prewired to junction box. 9' cordset for
115V operation.
CABINET INTERIOR: Interior of cabinet is fully coved to meet
N.S.F. standard #7. The interior is constructed of anodized
aluminum with coved corners for easy clean-up. Drawer opening
frames are A.B.S. and contain magnetic strip for positive seal of
drawer gaskets. Unit insulated with CFC free, foamed in place
polyurethane.
REFRIGERATED DRAWERS: Fully welded, unitized drawer
cartridge assembly - patented. Heavy duty full extension 14
gauge drawer tracks on 1 5/8" heavy duty stainless steel
bearings. Will accommodate (2) 12" x 20" x 4" deep pans per
drawer (pans not included). Quick release allows drawers to be
easily removed for cleaning. Stainless fronts, mounted to drawer
cartridge assembly with easy to grasp drawer handles. Drawers
with press fit magnetic gaskets - (designed for installation &
removal without tools).
REFRIGERATION: CFC free, R-134a refrigeration system to include
condensing unit, Randell blower coil, and thermostatic control for
operator adjustability. Blower coil fitted with expansion valve for
fast recovery. Compressor housing to allow maximum airflow and
includes standard condensate evaporator. Mullion coil, is coated
to resist corrosion, and offers maximum air flow.
Standard Features:
• R-134a self-contained refrigeration system features
expansion valve for fast recovery, and thermostatic
control for operator adjustability
• Hot gas condensate evaporator
• Drawer Cartridge Assemblies are fully removable with
Quick Release feature
• Foamed in place “CFC” free urethane insulation
• Marine edged stainless steel top with 12 gauge steel
subtop to hold the heaviest cooking equipment
• Removable 14 gauge drawer tracks on 1 5/8" heavy
duty stainless steel bearings
• Drawers to accommodate (2) 12"x 20"x 4"pans per drawer
(pans not included)
• 6" high adjustable legs
Description:
32 1/2" deep self-contained refrigerated cooking equipment
stand with reinforced stainless steel top. 12 gauge steel
subtop, and full marine edge. Expansion valve refrigeration
system with thermostatic control for operator adjustability.
R-134a refrigerant is “CFC free”. Unit on 6" high adjustable
legs.
These units feature our Patented Drawer Cartridge Assembly.
A fully welded, unitized drawer cartridge assembly with a
quick release that allows the refrigerated drawers to be
easily removed for cleaning. 3 year warranty on the entire
drawer system.
Options & Accessories:
Heavy duty casters
Flat top
Length modification of: _______
Compressor on left
Randell Chef Stand, Page 1a
PP SPEC0051 Rev. A
Revised 04/07
33°F to 40°F 18°F to 22°F33°F to 41°F
model, 32” Drawer 20048SC-32 20072SC-32 20105SC-32
model, 27” Drawer 20048SC 20072SC 20078SC 20105SC

1055 Mendell Davis Drive, Jackson, MS 39272, 888-994-7636, unifiedbrands.net
Information contained in this document is known to be current and accurate at the time
of printing/creation. Unified Brands recommends referencing our product line websites,
unifiedbrands.net, for the most updated product information and specifications.
Models 20000SC
27” DRAWER SELF-CONTAINED REFRIGERATED MODELS (The load capacity of this equipment stand is rated up to 225 lbs per linear foot)
Model L D H Drawers # of 12x20 Pans HP Volt Amp NEMA Ship Wt.
20048SC 48” 32 1/2” 26” 2 4 1/4 115/60/1 6 5-15P 400
20072SC 72” 32 1/2” 26” 4 8 1/3 115/60/1 7.4 5-15P 530
20078SC 78” 32 1/2” 26” 4 8 1/3 115/60/1 7.4 5-15P 550
20105SC 105” 32 1/2” 26” 6 12 3/8 115/60/1 12 5-15P 675
The Randell Cartridge System! Patented.
• Fully welded 14 gauge unitized Drawer Cartridge assembly.
• 14 gauge drawer tracks on 1 5/8" heavy duty stainless steel bearings.
• Heavy duty full extension tracks to accommodate 12" x 20" x 4" deep pans, two per drawer. Pans by others.
• Quick release allows drawers and liners to be removed without tools.
• Drawers with stainless steel drawer fronts & easy to grasp drawer handles.
27” DRAWER MODELS
1/4 HP COMPRESSOR
CONDENSATE DRAIN 1/2"
115V/60Hz/1Ph/6.0A
JUNCTION BOX 14" AFF
9' LONG CORD SET
HP
J
OC
(NEMA 5-15P)
I.D. VINYL TUBING
MODEL # 20048SC
AFF = ABOVE FIXED FLOOR
LEGEND FOR
CONDENSATE DRAIN 1/2"
I.D. VINYL TUBING
MODEL # 20072SC
AFF = ABOVE FIXED FLOOR
LEGEND FOR
1/3 HP COMPRESSOR
115V/60Hz/1Ph/7.4A
JUNCTION BOX 14" AFF
(NEMA 5-15P)
9' LONG CORD SET
J
OC
HP
AFF = ABOVE FIXED FLOOR
MODEL # 20105SC
J
OC
HP
CONDENSATE DRAIN 1/2"
(NEMA 5-15P)
9' LONG CORD SET
JUNCTION BOX 14" AFF
115V/60Hz/1Ph/12A
I.D. VINYL TUBING
1/2 HP COMPRESSOR
LEGEND FOR
CONDENSATE DRAIN 1/2"
I.D. VINYL TUBING
MODEL # 20078SC
AFF = ABOVE FIXED FLOOR
LEGEND FOR
1/3 HP COMPRESSOR
115V/60Hz/1Ph/7.4A
JUNCTION BOX 14" AFF
(NEMA 5-15P)
9' LONG CORD SET
J
OC
HP
THERMOMETER
27" REFRIG.
27" REFRIG.
(1) SET OF CARTRIDGE STYLE
DRAWERS, EACH DRAWER TO HOLD
(2) 12" X 20" X 4"DP PANS
(PANS NOT PROVIDED)
48"
25"
27" REFRIG.
27" REFRIG.
(2) SETS OF CARTRIDGE STYLE DRAWERS, EACH
DRAWER TO HOLD (2) 12" X 20" X 4"DP PANS
(PANS NOT PROVIDED)
THERMOMETER
27" REFRIG.
27" REFRIG.
72"
25"
(3) SETS OF CARTRIDGE STYLE DRAWERS, EACH
DRAWER TO HOLD (2) 12" X 20" X 4"DP PANS
(PANS NOT PROVIDED)
27" REFRIG.
27" REFRIG.
27" REFRIG.
27" REFRIG. 27" REFRIG.
27" REFRIG.
THERMOMETER
105"
25"
J
OC
HP
27" REFRIG.
27" REFRIG.
(2) SETS OF CARTRIDGE STYLE DRAWERS, EACH
DRAWER TO HOLD (2) 12" X 20" X 4"DP PANS
(PANS NOT PROVIDED)
THERMOMETER
27" REFRIG.
27" REFRIG.
COMPR. HSG.
78"
25"
32.5"
26"
6"

1055 Mendell Davis Drive, Jackson, MS 39272, 888-994-7636, unifiedbrands.net
Information contained in this document is known to be current and accurate at the time
of printing/creation. Unified Brands recommends referencing our product line websites,
unifiedbrands.net, for the most updated product information and specifications.
Models 20000SC-32
The Randell Cartridge System! Patented.
• Fully welded 14 gauge unitized Drawer Cartridge assembly.
• 14 gauge drawer tracks on 1 5/8" heavy duty stainless steel bearings.
• Heavy duty full extension tracks to accommodate 12" x 20" x 4" deep pans, two per drawer. Pans by others.
• Quick release allows drawers and liners to be removed without tools.
• Drawers with stainless steel drawer fronts & easy to grasp drawer handles.
32” DRAWER SELF-CONTAINED REFRIGERATED MODELS (The load capacity of this equipment stand is rated up to 225 lbs per linear foot)
Model L D H Drawers # of 12x20 Pans HP Volt Amp NEMA Ship Wt.
20048SC-32 53” 32 1/2” 26” 2 4 1/4 115/60/1 6 5-15P 400
20072SC-32 82” 32 1/2” 26” 4 8 1/3 115/60/1 7.4 5-15P 530
20105SC-32 120” 32 1/2” 26” 6 12 3/8 115/60/1 12 5-15P 675
1/4 HP COMPRESSOR
CONDENSATE DRAIN 1/2"
115V/60Hz/1Ph/6.0A
JUNCTION BOX 14" AFF
9' LONG CORD SET
HP
J
OC
(NEMA 5-15P)
I.D. VINYL TUBING
MODEL # 20048SC-32
AFF = ABOVE FIXED FLOOR
LEGEND FOR
CONDENSATE DRAIN 1/2"
I.D. VINYL TUBING
MODEL # 20072SC-32
AFF = ABOVE FIXED FLOOR
LEGEND FOR
1/3 HP COMPRESSOR
115V/60Hz/1Ph/7.4A
JUNCTION BOX 14" AFF
(NEMA 5-15P)
9' LONG CORD SET
J
OC
HP
AFF = ABOVE FIXED FLOOR
MODEL # 20105SC-32
J
OC
HP
CONDENSATE DRAIN 1/2"
(NEMA 5-15P)
9' LONG CORD SET
JUNCTION BOX 14" AFF
115V/60Hz/1Ph/12A
I.D. VINYL TUBING
1/2 HP COMPRESSOR
LEGEND FOR
THERMOMETER
32" REFRIG.
32" REFRIG.
(1) SET OF CARTRIDGE STYLE
DRAWERS, EACH DRAWER TO HOLD
(2) 12" X 20" X 4"DP PANS
(PANS NOT PROVIDED)
53"
25"
32" REFRIG.
32" REFRIG.
(2) SETS OF CARTRIDGE STYLE DRAWERS, EACH
DRAWER TO HOLD (2) 12" X 20" X 4"DP PANS
(PANS NOT PROVIDED)
THERMOMETER
32" REFRIG.
32" REFRIG.
82"
25"
(3) SETS OF CARTRIDGE STYLE DRAWERS, EACH
DRAWER TO HOLD (2) 12" X 20" X 4"DP PANS
(PANS NOT PROVIDED)
32" REFRIG.
32" REFRIG.
32" REFRIG.
32" REFRIG. 32" REFRIG.
32" REFRIG.
THERMOMETER
120"
25"
J
OC
HP
COMPR. HSG.
32.5"
26"
6"
32” DRAWER MODELS
Page 1b

1055 Mendell Davis Drive, Jackson, MS 39272
888-994-7636, unifiedbrands.net
Information contained in this document is known to be current and accurate at the time
of printing/creation. Unified Brands recommends referencing our product line websites,
unifiedbrands.net, for the most updated product information and specifications.
Chef Stand Self-Contained Freezer Base model 20000SCF
model 20072SCF shown
Specifications:
CABINET EXTERIOR: Cabinet body is constructed of all metal. The
top, front, and louver panel are stainless steel. Full length, 12
gauge steel subtop beneath one piece stainless steel top with
1/2" marine edged. Body ends are stainless steel. 6" stainless
steel legs with adjustable bullet feet are mounted to a heavy
gauge steel frame assembly which is integrally welded to bottom
of assembly. Unit totally prewired to junction box. 9' cordset for
115V operation.
CABINET INTERIOR: Interior of cabinet is fully coved to meet N.S.F.
standard #7.The interior is constructed of anodized aluminum with
coved corners for easy clean-up. Drawer opening frames are A.B.S.
and contain magnetic strip for positive seal of drawer gaskets. Unit
insulated with CFC free, foamed in place polyurethane.
REFRIGERATED DRAWERS: Fully welded, unitized drawer
cartridge assembly - patented. Heavy duty full extension 14
gauge drawer tracks on 1 5/8" heavy duty stainless steel
bearings. Will accommodate (2) 12" x 20" x 4" deep pans per
drawer (pans not included). Quick release allows drawers to be
easily removed for cleaning. Stainless fronts, mounted to drawer
cartridge assembly with easy to grasp drawer handles. Provided
with drawer frame heater to prevent gaskets freezing. Drawers
with press fit magnetic gaskets - (designed for installation &
removal without tools).
REFRIGERATION: CFC free, R-404a refrigeration system to include
condensing unit, Randell blower coil, defrost timer, and factory
set pressure control. Blower coil fitted with expansion valve for
fast recovery. Compressor housing to allow maximum airflow and
includes standard condensate evaporator. Mullion coil, is coated
to resist corrosion, and offers maximum air flow.
Standard Features:
• R-404a self-contained refrigeration system features
expansion valve for fast recovery, and thermostatic
control for operator adjustability
• Hot gas condensate evaporator
• Drawer Cartridge Assemblies are fully removable with
Quick Release feature
• Foamed in place “CFC” free urethane insulation
• Marine edged stainless steel top with 12 gauge steel
subtop to hold the heaviest cooking equipment
• Removable 14 gauge drawer tracks on 1 5/8" heavy
duty stainless steel bearings
• Drawers to accommodate (2) 12"x 20"x 4"
pans per drawer (pans not included)
• 6" high adjustable legs
Description:
32 1/2" deep self-contained freezer base cooking equipment
stand with reinforced stainless steel top. 12 gauge steel subtop,
and full marine edge. Expansion valve refrigeration system with
thermostatic control for operator adjustability. R-404a refrigerant
is “CFC free”. Unit on 6" high adjustable legs.
These units feature our Patented Drawer Cartridge Assembly.
A fully welded, unitized drawer cartridge assembly with a
quick release that allows the refrigerated drawers to be
easily removed for cleaning.3 year warranty on the entire
drawer system.
Randell Chef Stand, Page 2a
PP SPEC0052 Rev. A
Revised 04/07
Options & Accessories:
model, 32” Drawer 20048SCF-32 20072SCF-32 20105SCF-32
model, 27” Drawer 20048SCF 20072SCF 20105SCF
33°F to 40°F 18°F to 22°F33°F to 41°F
Heavy duty casters
Flat top
Length modification of: _______
Compressor on left

1055 Mendell Davis Drive, Jackson, MS 39272, 888-994-7636, unifiedbrands.net
Information contained in this document is known to be current and accurate at the time
of printing/creation. Unified Brands recommends referencing our product line websites,
unifiedbrands.net, for the most updated product information and specifications.
Models 20000SCF
DT
1/3 HP COMPRESSOR
CONDENSATE DRAIN 1/2"
115V/60Hz/1Ph/8.7A
JUNCTION BOX 14" AFF
9' LONG CORD SET
HP
J
OC
(NEMA 5-15P)
I.D. VINYL TUBING
MODEL # 20048SCF
AFF = ABOVE FIXED FLOOR
LEGEND FOR
27" FREEZER
27" FREEZER
Digital Control
(1) SET OF CARTRIDGE STYLE DRAWERS, EACH DRAWER
TO HOLD (2) 12" X 20" X 4"DP PANS
(PANS NOT PROVIDED)
48"
25"
J
OC
HP
27" FREEZER
27" FREEZER
(2) SETS OF CARTRIDGE STYLE DRAWERS, EACH DRAWER
TO HOLD (2) 12" X 20" X 4"DP PANS
(PANS NOT PROVIDED)
27" FREEZER
27" FREEZER
COMPR. HSG.
72"
25"
(3) SETS OF CARTRIDGE STYLE DRAWERS, EACH DRAWER
TO HOLD (2) 12" X 20" X 4"DP PANS
(PANS NOT PROVIDED)
27" FREEZER
27" FREEZER
27" FREEZER
27" FREEZER 27" FREEZER
27" FREEZER
105"
25"
32.5"
26"
6"
Digital Control Digital Control
DT
DEFROST TIMER
DT
1/3 HP COMPRESSOR
CONDENSATE DRAIN 1/2"
115V/60Hz/1Ph/8.7A
JUNCTION BOX 14" AFF
9' LONG CORD SET
HP
J
OC
(NEMA 5-15P)
I.D. VINYL TUBING
MODEL # 20072SCF
AFF = ABOVE FIXED FLOOR
LEGEND FOR
DEFROST TIMER
DT
1/2 HP COMPRESSOR
CONDENSATE DRAIN 1/2"
115V/60Hz/1Ph/10.9A
DT
1/4 HP COMPRESSOR
CONDENSATE DRAIN 1/2"
115V/60Hz/1Ph/6.0A
JUNCTION BOX 14" AFF
9' LONG CORD SET
HP
J
OC
(NEMA 5-15P)
I.D. VINYL TUBING
MODEL # 20048SCF
AFF = ABOVE FIXED FLOOR
LEGEND FOR
DEFROST TIMER
JUNCTION BOX 14" AFF
9' LONG CORD SET
HP
J
OC
(NEMA 5-15P)
I.D. VINYL TUBING
MODEL # 20105SCF
AFF = ABOVE FIXED FLOOR
LEGEND FOR
DEFROST TIMER
27” DRAWER SELF-CONTAINED FREEZER MODELS (The load capacity of this equipment stand is rated up to 225 lbs per linear foot)
Model L D H Drawers # of 12x20 Pans HP Volt Amp NEMA Ship Wt.
20048SCF 48” 32 1/2” 26” 2 4 1/3 115/60/1 8.7 5-15P 400
20072SCF 72” 32 1/2” 26” 4 8 1/3 115/60/1 8.7 5-15P 530
20105SCF 105” 32 1/2” 26” 6 12 1/2 115/60/1 10.9 5-15P 675
The Randell Cartridge System! Patented.
• Fully welded 14 gauge unitized Drawer Cartridge assembly.
• 14 gauge drawer tracks on 1 5/8" heavy duty stainless steel bearings.
• Heavy duty full extension tracks to accommodate 12" x 20" x 4" deep pans, two per drawer. Pans by others.
• Quick release allows drawers and liners to be removed without tools.
• Drawers with stainless steel drawer fronts & easy to grasp drawer handles.
27” DRAWER MODELS

1055 Mendell Davis Drive, Jackson, MS 39272, 888-994-7636, unifiedbrands.net
Information contained in this document is known to be current and accurate at the time
of printing/creation. Unified Brands recommends referencing our product line websites,
unifiedbrands.net, for the most updated product information and specifications.
Models 20000SCF-32
32” DRAWER SELF-CONTAINED FREEZER MODELS (The load capacity of this equipment stand is rated up to 225 lbs per linear foot)
Model L D H Drawers # of 12x20 Pans HP Volt Amp NEMA Ship Wt.
20048SCF-32 53” 32 1/2” 26” 2 4 1/3 115/60/1 8.7 5-15P 400
20072SCF-32 82” 32 1/2” 26” 4 8 1/3 115/60/1 8.7 5-15P 530
20105SCF-32 120” 32 1/2” 26” 6 12 1/2 115/60/1 10.9 5-15P 675
The Randell Cartridge System! Patented.
• Fully welded 14 gauge unitized Drawer Cartridge assembly.
• 14 gauge drawer tracks on 1 5/8" heavy duty stainless steel bearings.
• Heavy duty full extension tracks to accommodate 12" x 20" x 4" deep pans, two per drawer. Pans by others.
• Quick release allows drawers and liners to be removed without tools.
• Drawers with stainless steel drawer fronts & easy to grasp drawer handles.
DT
1/3 HP COMPRESSOR
CONDENSATE DRAIN 1/2"
115V/60Hz/1Ph/8.7A
JUNCTION BOX 14" AFF
9' LONG CORD SET
HP
J
OC
(NEMA 5-15P)
I.D. VINYL TUBING
AFF = ABOVE FIXED FLOOR
32" FREEZER
32" FREEZER
Digital Control
(1) SET OF CARTRIDGE STYLE DRAWERS, EACH
DRAWER TO HOLD (2) 12" X 20" X 4"DP PANS
(PANS NOT PROVIDED)
53"
25"
J
OC
HP
32" FREEZER
32" FREEZER
(2) SETS OF CARTRIDGE STYLE DRAWERS, EACH DRAWER
TO HOLD (2) 12" X 20" X 4"DP PANS
(PANS NOT PROVIDED)
32" FREEZER
32" FREEZER
COMPR. HSG.
82"
25"
(3) SETS OF CARTRIDGE STYLE DRAWERS, EACH DRAWER
TO HOLD (2) 12" X 20" X 4"DP PANS
(PANS NOT PROVIDED)
32" FREEZER
32" FREEZER
32" FREEZER
32" FREEZER 32" FREEZER
32" FREEZER
120"
25"
32.5"
26"
6"
Digital Control Digital Control
DT
DEFROST TIMER
DT
1/3 HP COMPRESSOR
CONDENSATE DRAIN 1/2"
115V/60Hz/1Ph/8.7A
JUNCTION BOX 14" AFF
9' LONG CORD SET
HP
J
OC
(NEMA 5-15P)
I.D. VINYL TUBING
MODEL # 20072SCF-32
AFF = ABOVE FIXED FLOOR
LEGEND FOR
DEFROST TIMER
DT
1/2 HP COMPRESSOR
CONDENSATE DRAIN 1/2"
115V/60Hz/1Ph/10.9A
MODEL # 20048SCF-32
LEGEND FOR
JUNCTION BOX 14" AFF
9' LONG CORD SET
HP
J
OC
(NEMA 5-15P)
I.D. VINYL TUBING
MODEL # 20105SCF-32
AFF = ABOVE FIXED FLOOR
LEGEND FOR
DEFROST TIMER
32” DRAWER MODELS
Page 2b

1055 Mendell Davis Drive, Jackson, MS 39272
888-994-7636, unifiedbrands.net
Information contained in this document is known to be current and accurate at the time
of printing/creation. Unified Brands recommends referencing our product line websites,
unifiedbrands.net, for the most updated product information and specifications.
Note: Specify Refrigerant
Randell supplies R-134a as standard.
Chef Stand Remote Refrigerated Base model 20000R
model 20065R shown
Standard Features:
• R-134a refrigeration system, “CFC free” features thermostatic
control for operator adjustability. Evaporator blower coil with
expansion valve and refrigeration lines provided and installed.
Condensing unit and controls not provided.
• Drawer Cartridge Assemblies are fully removable with
Quick Release feature
• Foamed in place “CFC” free urethane insulation
• Marine edged stainless steel top with 12 gauge steel
subtop to hold the heaviest cooking equipment
• Removable 14 gauge drawer tracks on 1 5/8" heavy duty
stainless steel bearings
• Drawers to accommodate (2)12"x 20"x 4"
pans per drawer (pans not included)
• 6" high adjustable legs
Description:
32 1/2" deep remote refrigerated cooking equipment stand
with reinforced stainless steel top. 12 gauge steel subtop, and
full marine edge. R-134a refrigeration system, with evaporator
blower coil and expansion valve supplied & installed. Condensing
unit not provided. Unit on 6" high adjustable legs.
Specifications:
CABINET EXTERIOR: Cabinet body is constructed of all metal. The
top, front, and louver panel are stainless steel. Full length, 12
gauge steel subtop beneath one piece stainless steel top with
1/2" marine edged. Body ends are stainless steel. 6" stainless
steel legs with adjustable bullet feet are mounted to a heavy
gauge steel frame assembly which is integrally welded to bottom
of assembly. Unit totally prewired to junction box.
CABINET INTERIOR: Interior of cabinet is fully coved to meet
N.S.F. standard #7. The interior is constructed of anodized
aluminum with coved corners for easy clean-up. Drawer opening
frames are A.B.S. and contain magnetic strip for positive seal of
drawer gaskets. Unit insulated with CFC free, foamed in place
polyurethane.
REFRIGERATED DRAWERS: Fully welded, unitized drawer
cartridge assembly - patented. Heavy duty full extension 14
gauge drawer tracks on 1 5/8" heavy duty stainless steel
bearings. Will accommodate (2) 12" x 20" x 4" deep pans per
drawer (pans not included). Quick release allows drawers to be
easily removed for cleaning. Stainless fronts, mounted to drawer
cartridge assembly with easy to grasp drawer handles. Drawers
with press fit magnetic gaskets - (designed for installation &
removal without tools).
REFRIGERATION: CFC free, R-134a refrigeration system to
include Randell blower coil, and thermostatic control for operator
adjustability. Blower coil fitted with expansion valve for fast
recovery. Condensing unit not provided. Mullion coil, is coated to
resist corrosion, and offers maximum air flow.
Options & Accessories:
Heavy duty casters
Flat top
Electric condensate evaporator
Length modification of: _______
Mechanical housing on left
Randell Chef Stand, Page 3a
PP SPEC0053 Rev. A
Revised 04/07
These units feature our Patented Drawer Cartridge Assembly.
A fully welded, unitized drawer cartridge assembly with a
quick release that allows the refrigerated drawers to be
easily removed for cleaning.3 year warranty on the entire
drawer system.
33°F to 40°F 18°F to 22°F33°F to 41°F
model, 32” Drawer 20042R-32 20065R-32 20092R-32
model, 27” Drawer 20042R 20065R 20092R

1055 Mendell Davis Drive, Jackson, MS 39272, 888-994-7636, unifiedbrands.net
Information contained in this document is known to be current and accurate at the time
of printing/creation. Unified Brands recommends referencing our product line websites,
unifiedbrands.net, for the most updated product information and specifications.
Models 20000R
R404 REFRIG.
R-22 REFRIG.
R134A REFRIG.
JUNCTION BOX 14" AFF
CONDENSATE DRAIN 1/2 "
I.D. VINYL TUBING
115V/60Hz/1Ph/6A
CHOOSE REFRIGERANT
J
OC
AFF = ABOVE FIXED FLOOR
MODEL # 20042R
LEGEND FOR LEGEND FOR
R134A REFRIG.
R404 REFRIG.
R-22 REFRIG.
115V/60Hz/1Ph/3A
JUNCTION BOX 14" AFF
MODEL # 20065R
AFF = ABOVE FIXED FLOOR
CONDENSATE DRAIN 1/2"
I.D. VINYL TUBING
CHOOSE REFRIGERANT
J
OC
CHOOSE REFRIGERANT
115V/60Hz/1Ph/4A
AFF = ABOVE FIXED FLOOR
MODEL # 20092R
JUNCTION BOX 14" AFF
LEGEND FOR
I.D. VINYL TUBING
CONDENSATE DRAIN 1/2"
OC
J
R-22 REFRIG.
R134A REFRIG.
R404 REFRIG.
32.5"
26"
6"
(1) SET OF CARTRIDGE STYLE DRAWERS, EACH DRAWER
TO HOLD (2) 12" X 20" X 4"DP PANS
(PANS NOT PROVIDED)
THERMOMETER
27" REFRIG.
27" REFRIG.
42"
25"
J
OC
27" REFRIG.
27" REFRIG.
THERMOMETER
(2) SETS OF CARTRIDGE STYLE DRAWERS, EACH DRAWER
TO HOLD (2) 12" X 20" X 4"DP PANS
(PANS NOT PROVIDED)
27" REFRIG.
27" REFRIG.
MECH. HSG.
65"
25"
(3) SETS OF CARTRIDGE STYLE DRAWERS, EACH DRAWER
TO HOLD (2) 12" X 20" X 4"DP PANS
(PANS NOT PROVIDED)
27" REFRIG.
27" REFRIG.27" REFRIG.
27" REFRIG.
27" REFRIG.
27" REFRIG.
THERMOMETER
92"
25"
Component
27” DRAWER REMOTE REFRIGERATED MODELS (The load capacity of this equipment stand is rated up to 225 lbs per linear foot)
Model L D H Drawers # of 12x20 Pans Volt Amp BTUs Ship Wt.
20042R 42” 32 1/2” 26” 2 4 115/60/1 3 466 330
20065R 65” 32 1/2” 26” 4 8 115/60/1 3 823 460
20092R 92” 32 1/2” 26” 6 12 115/60/1 4 1300 600
The Randell Cartridge System! Patented.
• Fully welded 14 gauge unitized Drawer Cartridge assembly.
• 14 gauge drawer tracks on 1 5/8" heavy duty stainless steel bearings.
• Heavy duty full extension tracks to accommodate 12" x 20" x 4" deep pans, two per drawer. Pans by others.
• Quick release allows drawers and liners to be removed without tools.
• Drawers with stainless steel drawer fronts & easy to grasp drawer handles.
27” DRAWER MODELS

1055 Mendell Davis Drive, Jackson, MS 39272, 888-994-7636, unifiedbrands.net
Information contained in this document is known to be current and accurate at the time
of printing/creation. Unified Brands recommends referencing our product line websites,
unifiedbrands.net, for the most updated product information and specifications.
Models 20000R-32
Component
32” DRAWER REMOTE REFRIGERATED MODELS (The load capacity of this equipment stand is rated up to 225 lbs per linear foot)
Model L D H Drawers # of 12x20 Pans Volt Amp BTUs Ship Wt.
20042R-32 47” 32 1/2” 26” 2 4 115/60/1 3 466 330
20065R-32 75” 32 1/2” 26” 4 8 115/60/1 3 823 460
20092R-32 107” 32 1/2” 26” 6 12 115/60/1 4 1300 600
The Randell Cartridge System! Patented.
• Fully welded 14 gauge unitized Drawer Cartridge assembly.
• 14 gauge drawer tracks on 1 5/8" heavy duty stainless steel bearings.
• Heavy duty full extension tracks to accommodate 12" x 20" x 4" deep pans, two per drawer. Pans by others.
• Quick release allows drawers and liners to be removed without tools.
• Drawers with stainless steel drawer fronts & easy to grasp drawer handles.
R404 REFRIG.
R-22 REFRIG.
R134A REFRIG.
JUNCTION BOX 14" AFF
CONDENSATE DRAIN 1/2 "
I.D. VINYL TUBING
115V/60Hz/1Ph/3A
CHOOSE REFRIGERANT
J
OC
AFF = ABOVE FIXED FLOOR
MODEL # 20042R-32
LEGEND FOR LEGEND FOR
R134A REFRIG.
R404 REFRIG.
R-22 REFRIG.
115V/60Hz/1Ph/3A
JUNCTION BOX 14" AFF
MODEL # 20065R-32
AFF = ABOVE FIXED FLOOR
CONDENSATE DRAIN 1/2"
I.D. VINYL TUBING
CHOOSE REFRIGERANT
J
OC
CHOOSE REFRIGERANT
115V/60Hz/1Ph/4A
AFF = ABOVE FIXED FLOOR
MODEL # 20092R-32
JUNCTION BOX 14" AFF
LEGEND FOR
I.D. VINYL TUBING
CONDENSATE DRAIN 1/2"
OC
J
R-22 REFRIG.
R134A REFRIG.
R404 REFRIG.
32.5"
26"
6"
THERMOMETER
32" REFRIG.
32" REFRIG.
47"
J
OC
32" REFRIG.
32" REFRIG.
THERMOMETER
32" REFRIG.
32" REFRIG.
MECH. HSG.
75"
32" REFRIG.
32" REFRIG.32" REFRIG.
32" REFRIG.
32" REFRIG.
32" REFRIG.
THERMOMETER
107"
(1) SET OF CARTRIDGE STYLE DRAWERS, EACH
DRAWER TO HOLD (2) 12" X 20" X 4"DP PANS
(PANS NOT PROVIDED)
25"
(2) SETS OF CARTRIDGE STYLE DRAWERS, EACH DRAWER
TO HOLD (2) 12" X 20" X 4"DP PANS
(PANS NOT PROVIDED)
25"
(3) SETS OF CARTRIDGE STYLE DRAWERS, EACH DRAWER
TO HOLD (2) 12" X 20" X 4"DP PANS
(PANS NOT PROVIDED)
25"
32” DRAWER MODELS
Page 3b

1055 Mendell Davis Drive, Jackson, MS 39272
888-994-7636, unifiedbrands.net
Information contained in this document is known to be current and accurate at the time
of printing/creation. Unified Brands recommends referencing our product line websites,
unifiedbrands.net, for the most updated product information and specifications.
Note: Specify Refrigerant
Randell supplies R-404a as standard.
Chef Stand Remote Freezer Base model 20000RF
model 20065RF shown
Standard Features:
• R-404a refrigeration system, “CFC free” features
thermostatic control for operator adjustability. Evaporator
blower coil with expansion valve and refrigeration lines
provided and installed. Condensing unit and controls not provided.
• Drawer Cartridge Assemblies are fully removable with
Quick Release feature
• Foamed in place “CFC” free urethane insulation
• Marine edged stainless steel top with 12 gauge steel
subtop to hold the heaviest cooking equipment
• Removable 14 gauge drawer tracks on 1 5/8" heavy duty
stainless steel bearings
• Drawers to accommodate (2)12"x 20"x 4"
pans per drawer (pans not included)
• 6" high adjustable legs
Description:
32 1/2" deep remote freezer base cooking equipment stand
with reinforced stainless steel top. 12 gauge steel subtop, and
full marine edge. R-404a refrigeration system, with evaporator
blower coil and expansion valve supplied & installed. Condensing
unit not provided. Unit on 6" high adjustable legs.
Specifications:
CABINET EXTERIOR: Cabinet body is constructed of all metal. The
top, front, and louver panel are stainless steel. Full length, 12
gauge steel subtop beneath one piece stainless steel top with
1/2" marine edged. Body ends are stainless steel. 6" stainless
steel legs with adjustable bullet feet are mounted to a heavy
gauge steel frame assembly which is integrally welded to bottom
of assembly. Unit totally prewired to junction box.
CABINET INTERIOR: Interior of cabinet is fully coved to meet
N.S.F. standard #7. The interior is constructed of anodized
aluminum with coved corners for easy clean-up. Drawer opening
frames are A.B.S. and contain magnetic strip for positive seal of
drawer gaskets. Unit insulated with CFC free, foamed in place
polyurethane.
REFRIGERATED DRAWERS: Fully welded, unitized drawer
cartridge assembly -patented. Heavy duty full extension 14
gauge drawer tracks on 1 5/8" heavy duty stainless steel
bearings. Will accommodate (2) 12" x 20" x 4" deep pans per
drawer (pans not included). Quick release allows drawers to be
easily removed for cleaning. Stainless fronts, mounted to drawer
cartridge assembly with easy to grasp drawer handles. Provided
with drawer frame heater to prevent gaskets freezing. Drawers
with press fit magnetic gaskets - (designed for installation &
removal without tools).
REFRIGERATION: CFC free, R-404a refrigeration systems
standard. Includes Randell blower coil, defrost timer, and
thermostatic control for operator adjustability. Blower coil fitted
with expansion valve for fast recovery. Includes solenoid valve &
thermostat, condensing unit not provided. Mullion coil, is coated
to resist corrosion, and offers maximum air flow.
Randell Chef Stand, Page 4a
PP SPEC0054 Rev. A
Revised 04/07
These units feature our Patented Drawer Cartridge Assembly.
A fully welded, unitized drawer cartridge assembly with a
quick release that allows the refrigerated drawers to be
easily removed for cleaning.3 year warranty on the entire
drawer system.
model, 32” Drawer 20042RF-32 20065RF-32 20092RF-32
model, 27” Drawer 20042RF 20065RF 20092RF
33°F to 40°F 18°F to 22°F33°F to 41°F
Options & Accessories:
Heavy duty casters
Flat top
Electric condensate evaporator
Length modification of: _______
Mechanical housing on left

1055 Mendell Davis Drive, Jackson, MS 39272, 888-994-7636, unifiedbrands.net
Information contained in this document is known to be current and accurate at the time
of printing/creation. Unified Brands recommends referencing our product line websites,
unifiedbrands.net, for the most updated product information and specifications.
Models 20000RF
115V/60Hz/1Ph/6A
CHOOSE REFRIGERANT
MODEL # 20092RF
JUNCTION BOX 14" AFF
CONDENSATE DRAIN 1/2"
DEFROST TIMER
AFF = ABOVE FIXED FLOOR
I.D. VINYL TUBING
OC
DT
J
R134A REFRIG.
R404 REFRIG.
R-22 REFRIG.
LEGEND FOR
JUNCTION BOX 14" AFF
115V/60Hz/1Ph/6A
CHOOSE REFRIGERANT
R-22 REFRIG.
R134A REFRIG.
I.D. VINYL TUBING
CONDENSATE DRAIN 1/2 "
DEFROST TIMER
J
DT
R404 REFRIG.
OC
MODEL # 20042RF
AFF = ABOVE FIXED FLOOR
LEGEND FOR
CONDENSATE DRAIN 1/2"
I.D. VINYL TUBING
OC
115V/60Hz/1Ph/6A
CHOOSE REFRIGERANT
R404 REFRIG.
R-22 REFRIG.
R134A REFRIG.
JUNCTION BOX 14" AFF
MODEL # 20065RF
AFF = ABOVE FIXED FLOOR
LEGEND FOR
J
DT
DEFROST TIMER
32.5"
26"
6"
(1) SET OF CARTRIDGE STYLE DRAWERS, EACH DRAWER
TO HOLD (2) 12" X 20" X 4"DP PANS
(PANS NOT PROVIDED)
25"
(2) SETS OF CARTRIDGE STYLE DRAWERS, EACH DRAWER
TO HOLD (2) 12" X 20" X 4"DP PANS
(PANS NOT PROVIDED)
25"
(3) SETS OF CARTRIDGE STYLE DRAWERS, EACH DRAWER
TO HOLD (2) 12" X 20" X 4"DP PANS
(PANS NOT PROVIDED)
25"
27" FREEZER
27" FREEZER
27" FREEZER
27" FREEZER
27" FREEZER
27" FREEZER
DIGITAL CONTROL
92"
27" FREEZER
27" FREEZER
DIGITAL CONTROL
42"
DT
J
OC
27" FREEZER
27" FREEZER
27" FREEZER
27" FREEZER
MECH. HSG.
DIGITAL CONTROL
65"
Component
27” DRAWER REMOTE FREEZER MODELS (The load capacity of this equipment stand is rated up to 225 lbs per linear foot)
Model L D H Drawers # of 12x20 Pans Volt Amp BTUs Ship Wt.
20042RF 42” 32 1/2” 26” 2 4 115/60/1 6 619 330
20065RF 65” 32 1/2” 26” 4 8 115/60/1 6 1093 460
20092RF 92” 32 1/2” 26” 6 12 115/60/1 8.5 1726 600
The Randell Cartridge System! Patented.
• Fully welded 14 gauge unitized Drawer Cartridge assembly.
• 14 gauge drawer tracks on 1 5/8" heavy duty stainless steel bearings.
• Heavy duty full extension tracks to accommodate 12" x 20" x 4" deep pans, two per drawer. Pans by others.
• Quick release allows drawers and liners to be removed without tools.
• Drawers with stainless steel drawer fronts & easy to grasp drawer handles.
27” DRAWER MODELS

1055 Mendell Davis Drive, Jackson, MS 39272, 888-994-7636, unifiedbrands.net
Information contained in this document is known to be current and accurate at the time
of printing/creation. Unified Brands recommends referencing our product line websites,
unifiedbrands.net, for the most updated product information and specifications.
Models 20000RF-32
Component
32” DRAWER REMOTE FREEZER MODELS (The load capacity of this equipment stand is rated up to 225 lbs per linear foot)
Model L D H Drawers # of 12x20 Pans Volt Amp BTUs Ship Wt.
20042RF-32 47” 32 1/2” 26” 2 4 115/60/1 6 619 330
20065RF-32 75” 32 1/2” 26” 4 8 115/60/1 6 1093 460
20092RF-32 107” 32 1/2” 26” 6 12 115/60/1 8.5 1726 600
The Randell Cartridge System! Patented.
• Fully welded 14 gauge unitized Drawer Cartridge assembly.
• 14 gauge drawer tracks on 1 5/8" heavy duty stainless steel bearings.
• Heavy duty full extension tracks to accommodate 12" x 20" x 4" deep pans, two per drawer. Pans by others.
• Quick release allows drawers and liners to be removed without tools.
• Drawers with stainless steel drawer fronts & easy to grasp drawer handles.
115V/60Hz/1Ph/6A
CHOOSE REFRIGERANT
MODEL # 20092RF-32
JUNCTION BOX 14" AFF
CONDENSATE DRAIN 1/2"
DEFROST TIMER
AFF = ABOVE FIXED FLOOR
I.D. VINYL TUBING
OC
DT
J
R134A REFRIG.
R404 REFRIG.
R-22 REFRIG.
LEGEND FOR
JUNCTION BOX 14" AFF
115V/60Hz/1Ph/6A
CHOOSE REFRIGERANT
R-22 REFRIG.
R134A REFRIG.
I.D. VINYL TUBING
CONDENSATE DRAIN 1/2 "
DEFROST TIMER
J
DT
R404 REFRIG.
OC
MODEL # 20042RF-32
AFF = ABOVE FIXED FLOOR
LEGEND FOR
CONDENSATE DRAIN 1/2"
I.D. VINYL TUBING
OC
115V/60Hz/1Ph/6A
CHOOSE REFRIGERANT
R404 REFRIG.
R-22 REFRIG.
R134A REFRIG.
JUNCTION BOX 14" AFF
MODEL # 20065RF-32
AFF = ABOVE FIXED FLOOR
LEGEND FOR
J
DT
DEFROST TIMER
32.5"
26"
6"
32" FREEZER
32" FREEZER
32" FREEZER
32" FREEZER
32" FREEZER
32" FREEZER
DIGITAL CONTROL
107"
32" FREEZER
32" FREEZER
DIGITAL CONTROL
47"
DT
J
OC
32" FREEZER
32" FREEZER
32" FREEZER
32" FREEZER
MECH. HSG.
DIGITAL CONTROL
75"
(1) SET OF CARTRIDGE STYLE DRAWERS, EACH
DRAWER TO HOLD (2) 12" X 20" X 4"DP PANS
(PANS NOT PROVIDED)
25"
(2) SETS OF CARTRIDGE STYLE DRAWERS, EACH DRAWER
TO HOLD (2) 12" X 20" X 4"DP PANS
(PANS NOT PROVIDED)
25"
(3) SETS OF CARTRIDGE STYLE DRAWERS, EACH DRAWER
TO HOLD (2) 12" X 20" X 4"DP PANS
(PANS NOT PROVIDED)
25"
32” DRAWER MODELS
Page 4b
