Upright Double Door Dual Temperature model 2020D
Specifications:
CABINET EXTERIOR: Cabinet body is constructed of all metal,
inside & out. The top, bottom, & back are galvanized steel. Front
and sides are available in finishes as listed above. Doors and
louver are stainless steel and are removable without tools. Unit
on 6" casters, front two are locking.
CABINET INTERIOR: Interior of cabinet is fully coved to meet N.S.F.
standard #7.The interior walls, ceiling and door liner are available
in either stainless steel or anodized aluminum as listed above.
Foamed in place, CFC free urethane insulation. Snap-in A.B.S.
breaker strips allow access to condensate heater wires.
DOORS:Stainless front with either anodized aluminum or stainless
steel liner, mounted on heavy duty cam lift hinges with auto-
matic light switch, heavy duty chrome handle, cylinder door lock.
Optional glass doors to be insulated glass with bright extruded
aluminum frames, switch for interior light mounted on exterior of
glass door unit.
REFRIGERATION: Top mounted condensing unit and two separate
evaporator coils utilizing CFC free 404a refrigerant. Refrigerator
sectionutilizesanexpansionvalvesystemwiththermostaticcontrol,
factory tested and balanced to maintain 38˚ F. average interior
temperature. Freezer section uses an expansion valve system
with pressure control, factory tested and balanced to maintain
(0˚ F. to -5˚ F.) average interior temperature. Evaporator coils
are coated to resist corrosion. Unit supplied with master on/off
switch and 8' cord and plug. Access to service points without
tools is standard.
Description:
Randell Series 2000 Upright are built for years of efficient, high
performance service. The top mounted, expansion valve refrig-
eration system offers the highest, most consistent performance
available while maximizing usable interior space.
Standard Features:
• Expansion Valve
• Digital Control
• Exterior LED Temperature Display
• Top mounted Compressor & Evaporator Coils
• C.F.C. Free R-404a Refrigerant
• Efficient Hot Gas Condensate Evaporator
• Automatic Defrost
• 8' Cord & Plug
• Main Power Supply Switch
• Self-Closing Cam Lift Hinges with 120˚ Open Feature (Lifetime Warranty)
• Automatic Interior Light
• 6" Casters - Factory Mounted (Front two Locking)
• Cylinder Door Locks
• Fully Coved Interior Meeting N.S.F. Standard #7
• Polyurethane Insulation
• Condensate Heaters Around Freezer Door Opening
• 3 Baked Epoxy Coated Wire Shelve
With Stainless Steel Support Clips (Adjustable every 1")
• Snap-In Magnetic Door Gaskets
Standard Series Doors/Louver: Stainless steel.
Exterior Sides: Anodized aluminum. Interior: Anodized aluminum
E Series Cabinet interior, exterior sides, fronts,
and doors stainless steel.
Finishes:
Universal Tray Slides (set of two) Qty. Sets
1/2 Doors Solid Glass Qty. Location
6" Legs
Remote (Add Suffix “R”)
Extra Interior Shelves Qty.
(maximum of (23) or (20) additional on 1.5" centers-leaves 1" clear)
Finished Back
Export Voltage(s) Specify Voltage
Prison Package
Options & Accessories:
Randell Upright, Page 9
Revised 08/05

Randell, Unified Brands 888-994-7636, unifiedbrands.net
Information contained in this document is known to be current and accurate at the time
of printing/creation. Unified Brands recommends referencing our product line websites,
unifiedbrands.net, for the most updated product information and specifications.
Model 2020D
SELF-CONTAINED, TWO SECTION, DUAL TEMPERATURE REFRIGERATOR/FREEZER
* Based on 90˚ ambient and +20˚ evaporator for refrigerator. 90˚ ambient and -10˚ evaporator for freezer.
** Includes bottom of each section as one shelf.
Model
2020D two section
L
55”
D
33 1/2"
H
81.25”
Doors
(2) full size
HP
3/4
Volt
115/60/1
Amps
15.4
NEMA
5-20P
BTU Rating
4180*
Ship Wt.
690
Cu./Ft.
44.3
Shelves
8**
Shelves Sq. Ft.
26**
FOR REMOTE MODELS
Use same specifications as self-contained model except for:
Model No. Rec. H.P. Rec. BTU/Hr. Amp. Ship Wt.
2020DR solid door 3/4 4180 7 640
Note: All remote Upright come standard on 6" legs in lieu of casters.
Refrigerator
Some models available for -10˚F applications.
Consult factory.
Freezer
TRAYSLIDE CAPACITIES
Universal Pan Slides .... Model....RIUNIVPS - set of two.
For 12 x 20 food pans or 18 x 26 sheet pans.
Maximum capacity of 12" x 20" food pans per full height section:
(6) 6" deep pans, (8) 4" deep pans, (18) 2" deep pans.
Maximum capacity of 18" x 26" sheet pans with 2" spacing is (22).
3/4hp
HOUSING
DRAIN 1/2 "
9' LONG CORD SET
(NEMA 5-20P)
OC CONDENSATE
DT DEFROST TIMER
EH EVAPORATOR
15.4 Amps
JUNCTION BOX
120V/60Hz/1Ph
COMPRESSOR
HP
J
EVAPORATOR
HOT GAS
CONDENSATE
4180 BTU/Hr
MODEL # 2020D
LEGEND FOR
INDUSTRIESCOMPANY
REFRIGERATOR
FREEZER
INDUSTRIESCOMPANY
J
DT
EH
J
EH
HP
OC OC
(FRONT LOCKING)
(4) 6" CASTERS
REFRIGERATOR
THERMOMETER THERMOMETER
FREEZER
55" 33.5"
26.5"
31.25"
81"
58.25"
33°F to 40°F 18°F to 22°F33°F to 41°F
