RanServe Stainless Steel Ice Cooled Cold Pan models IC
model RAN IC-3 Enclosed Base shown
Description:
Portable, stainless steel ice cooled cold pan serving station. 1"
drain, and perforated strainer plates provided. Available with
enclosed base or open storage. Foamed in place (CFC free)
insulation. Interchangeable stainless steel or laminate body
panels, snap together locking device designed to work with all
other RanServe equipment. (4) swivel casters provided.
Specifications:
UNIT TOP: Top to be one piece of die-formed 16 gauge stainless steel
with 1 1/2", 90˚ nosing on all sides. Unit fitted with 6" deep, ice cooled
display cold pan. Interior of pan to be one piece, continuously welded
construction of 18 gauge stainless steel. Interior fitted with 1" drain
at one end. Drain nipple supplied with ball valve and lever extension to
cabinet exterior on enclosed base units- drain lines run to accessible
area. 1" high perforated, stainless steel bottom strainer plates
provided.
UNIT BODY: Body frame to be all welded construction of steel with
exposed corners to be 1 1/2" stainless steel. All corners welded and
polished. Body ends and panels to be plastic laminate with galvanized
steel backing (specify laminate color). Body ends and panels to be
removable to allow the changing of colors. Cold pan insulated with high
density (CFC free) polyurethane, foamed in place. Unit to be equipped
with 4 swivel casters, (2) locking, that are recessed inside of toe area.
“S” series (Cafeteria style with open base) Same spec as IC series only
“S” series units to have partial stainless steel panel on one side with
undershelf. Undershelf to be 22 gauge stainless steel with integrally
welded steel under-bracing. Ice cooled display pan to have ball valve,
accessible thru storage area.
This equipment is intended for use in rooms having an ambient tem-
perature of 86 ˚F (30˚C) or less.
model RAN IC-2 RAN IC-3 RAN IC-4 RAN IC-5 RAN IC-6
RAN IC-2S RAN IC-3S RAN IC-4S RAN IC-5S RAN IC-6S
model RAN IC-3S Open Base shown
Randell RanServe, Page 11
Revised 09/04
Standard Features:
• Stainless steel ice-cooled cold pan with
one piece interior
• Foamed in place (CFC free) high density
polyurethane insulation
• Interchangeable body panels
• Concealed locking mechanism with easy to use
spring-activated catch
• 1" drain, drain nipple and ball valve
• Stainless steel perforated strainer plates
• Swivel casters - (2) locking
Options & Accessories:
Corian top
Granite top
Laminates
Graphics
Sneeze Guards
Elementary School Height
Canopy
Overshelves
Trayslides
33°F to 40°F 18°F to 22°F33°F to 41°F

Randell, Unified Brands 888-994-7636, unifiedbrands.net
Information contained in this document is known to be current and accurate at the time
of printing/creation. Unified Brands recommends referencing our product line websites,
unifiedbrands.net, for the most updated product information and specifications.
Models IC
Enclosed Base 12" x 20" Pan Coldpan
Model L D H Capacity Interior Dimensions Ship Wt.
RAN IC-2 36” 30" 35" 2 25" x 20" x 6" 140
RAN IC-3 48" 30" 35" 3 38" x 20" x 6" 175
RAN IC-4 60" 30" 35" 4 50.75" x 20" x 6" 215
RAN IC-5 72" 30" 35" 5 63.75" x 20" x 6" 260
RAN IC-6 86" 30" 35" 6 76.5" x 20" x 6" 310
Open Base
RAN IC-2S 36” 30" 35" 2 25" x 20" x 6" 140
RAN IC-3S 48" 30" 35" 3 38" x 20" x 6" 175
RAN IC-4S 60" 30" 35" 4 52" x 20" x 6" 215
RAN IC-5S 72" 30" 35" 5 63.75" x 20" x 6" 260
RAN IC-6S 86" 30" 35" 6 76.5" x 20" x 6" 310
LEGEND FOR
AFF =
ABOVE FIXED FLOOR
RAN IC
UNIT
DELOW BOTTOM OF
LINE EXTENDS TO 1"
1" DIA PVC DRAIN
86"
PANEL
78"
PANEL
60"
PANEL
48"
PANEL
36"
DRAIN HANDLE
PANEL
2.5"
2.5"
DRAIN LINE
35"
30"
PANEL
S/S PANEL
OPEN STORAGE
"S" Model
RAN IC DRAWINGS SHOWN, RAN IC-S FRONT VIEW SHOWN AS REPRESENTATION OF “S” MODELS
Drawings are to be viewed in the same order as the chart
