Upright Pass-Thru Triple Door Refrigerator models 2030P
Specifications:
CABINET EXTERIOR: Cabinet body is constructed of all metal,
inside & out. The top and bottom are galvanized steel. Fronts and
sides are available in finishes as listed above. Doors and louvers
are stainless steel and are removable without tools. Unit on 6"
casters, front two are locking.
CABINET INTERIOR: Interior of cabinet is fully coved to meet N.S.F.
standard #7.The interior walls, ceiling and door liner are available
in either stainless steel or anodized aluminum as listed above.
Foamed in place, CFC free urethane insulation. Snap-in A.B.S.
breaker strips allow access to condensate heater wires.
DOORS: Stainless steel fronts with either anodized aluminum
or stainless steel liner, mounted on heavy duty cam lift hinges
with automatic light switch, heavy duty chrome handle, cylinder
door lock. Glass doors to be insulated glass with bright extruded
aluminum frames, switch for interior light mounted on exterior of
glass door unit.
REFRIGERATION:Topmountedcondensingunitandevaporatorcoil,
expansion valve system with thermostatic control, factory tested
and balanced to maintain 38˚ F.average interior temperature utiliz-
ing CFC free 134a refrigerant. Evaporator coil is coated to resist
corrosion. Unit supplied with master on/off switch and 8' cord and
plug. Access to service points without tools is standard.
Description:
Randell Series 2000 Three Section, pass-thru Upright are built
for years of efficient, high performance service.The top mounted,
expansion valve refrigeration system offers the highest,most con-
sistent performance available while maximizing usable interior
space.
Standard Features Continued:
• Automatic Defrost
• 8' Cord & Plug
• Main Power Supply Switch
• Self-Closing Cam Lift Hinges with 120˚ Open Feature (Lifetime Warranty)
• Automatic Interior Light
• 6" Casters - Factory Mounted (Front two Locking)
• Cylinder Door Locks
• Fully Coved Interior Meeting N.S.F. Standard #7
• Polyurethane Insulation
• 3 Baked Epoxy Coated Wire Shelves Per Section With
Stainless Steel Support Clips (Adjustable every 1")
• Snap-In Magnetic Door Gaskets
Standard Series Doors/Louver: Stainless steel.
Exterior Sides: Anodized aluminum. Interior: Anodized aluminum
E Series Cabinet interior, exterior sides, fronts,
and doors stainless steel.
Finishes:
Randell Upright, Page 12
Revised 08/05
Universal Tray Slides (set of two) Qty. Sets
*1/2 Doors Solid Glass Qty. Location
6" Legs
Remote (Add Suffix “R”)
Extra Interior Shelves Qty.
(maximum of (23) or (20) additional on 1.5" centers-leaves 1" clear)
Finished Back
Export Voltage(s) Specify Voltage
Prison Package
*Split glass door option available on model 2031P only.
Options & Accessories:
Standard Features:
• Expansion Valve
• Exterior LED Temperature Display
• Top mounted Compressor & Evaporator Coil
• C.F.C. Free R-134a Refrigerant
• Efficient Hot Gas Condensate Evaporator
model 2030P (Stainless Steel Doors) 2031P (Glass Doors)
33°F to 40°F 18°F to 22°F33°F to 41°F

Randell, Unified Brands 888-994-7636, unifiedbrands.net
Information contained in this document is known to be current and accurate at the time
of printing/creation. Unified Brands recommends referencing our product line websites,
unifiedbrands.net, for the most updated product information and specifications.
SELF-CONTAINED THREE SECTION PASS-THRU REFRIGERATOR
* Based on 90˚ ambient and +20˚ evaporator.
Model 2030P
TRAYSLIDE CAPACITIES
Universal Pan Slides .... Model....RIUNIVPS - set of two.
For 12 x 20 food pans or 18 x 26 sheet pans.
Maximum capacity of 12" x 20" food pans per full height section:
(6) 6" deep pans, (8) 4" deep pans, (18) 2" deep pans.
Maximum capacity of 18" x 26" sheet pans with 2" spacing is (22).
FOR REMOTE MODELS
Use same specifications as self-contained model except for:
Model No. Rec. H.P. Rec. BTU/Hr. Amp. Ship Wt.
2030P 1/2 4400 5 750
Note: All remote Upright come standard on 6" legs in lieu of casters.
4400 BTU/Hr
9' LONG CORD SET
(NEMA 5-15P)
115V/60Hz/1Ph
JUNCTION BOX
MODEL # 2030P
LEGEND FOR
11.7 Amps
OC CONDENSATE DRAIN 1/2"
EH EVAPORATOR HOUSING
1/2hp COMPRESSOR
J
HP
EVAPORATOR
CONDENSATE
HOT GAS
INDUSTRIESCOMPANY
OC
EH
HP
J
83"
26.5"
35.75"
26.5"
31.25"
81"
Model
2030P solid doors
2031P glass doors
L
83”
83”
D
35 3/4"
35 3/4"
H
81.25”
81.25”
Doors
6
6
HP
1/2
1/2
Volt
115/60/1
115/60/1
Amps
11.7
11.7
NEMA
5-15P
5-15P
BTU Rating
4400*
4400*
Ship Wt.
800
800
Cu./Ft.
77.16
77.16
Shelves
9
9
Shelves Sq. Ft.
39
39
