INSTALLATION AND
MAINTENANCE MANUAL
LM CHAIN HOIST
LOADMATE
®
LM05 SERIES II
English
STD-R-KHA-F-CQD-ENG

LM05 SERIES II I&M MANUAL/EN/11.30.2010
