Ranger Products RD-18G User manual

18 GALLON PORTABLE OIL DRAIN
WITH PUMP AND DRAIN VALVE
Model:
RD-18G
VER B
PLEASE READ THE ENTIRE CONTENTS OF THIS MANUAL PRIOR TO
INSTALLATION AND OPERATION. BY PROCEEDING YOU AGREE THAT
YOU FULLY UNDERSTAND AND COMPREHEND THE FULL CONTENTS OF
THIS MANUAL. FORWARD THIS MANUAL TO ALL OPERATORS. FAILURE TO
OPERATE THIS EQUIPMENT AS DIRECTED MAY CAUSE INJURY OR DEATH.
REV B 09-16-10
pn#5900239
INSTALLATION AND OPERATION MANUAL
SHIPPING DAMAGE CLAIMS
When this equipment is shipped, title passes
to the purchaser upon receipt from the carrier.
Consequently, claims for the material damaged in
shipment must be made by the purchaser against the
transportation company at the time shipment is received.
BE SAFE
Ranger™ Oil Drains are designed and built with
safety in mind. However, proper training and
thoughtful operation on the part of the operator can
increase your overall safety. DO NOT operate or
repair this equipment without reading this manual
and the important safety instructions shown inside.
1645 Lemonwood Dr.
Santa Paula, CA. 93060, USA
Tel: [phone]
Toll Free: 1-800-253-2363
Fax: [phone]
www.rangerproducts.com
Keep this operation manual near the
machine at all times. Make sure that
ALL USERS read this manual.

2
WARRANTY POLICY
Ranger Products™ are backed by over 35 years of
manufacturing experience. Every Oil Drain bearing the
Ranger™ name is sold with the following warranty.
Each Ranger Product™ is warranted to be free
from defects in workmanship and material for a
period of one year from the date of shipment
provided that a written claim for such defect is
made within that time.
This warranty does not cover damage or defects
caused by carelessness of the operator, misuse,
abuse or abnormal use which in any way impairs the
proper functioning of the equipment or by the use or
addition of parts not manufactured by Ranger
Products™ or its suppliers.
THIS WARRANTY IS EXPRESSLY MADE IN LIEU OF
ANY AND ALL OTHER WARRANTIES EXPRESSED
OR IMPLIED INCLUDING THE WARRANTIES OF
MERCHANTABILITY AND FITNESS FOR A
PARTICULAR PURPOSE.
If your Ranger Products™ machine is not functioning
properly, call your Ranger Products™ dealer immediately.
On some occasions, an independent contractor may be
hired to do the repairs. Within the warranty period, a
customer should not hire his own contractor unless it is
authorized in writing by Ranger Products™.
If it is necessary to return equipment for repairs, your
dealer will so advise you. When returning equipment for
repairs, see that machines are properly crated and
protected, and prepay transportation.
Defective parts replaced at no charge must be returned
to your dealer or Ranger Products™ within 60 days of the
date that the replacement parts are shipped; otherwise,
you must pay for the replacement parts at the current
selling price.
SHIPPING DAMAGE
If any damage is found, notify your carrier
immediately and save all packaging materials for the
carrier’s inspector to examine. Failure to promptly
report damage could result in denial of your claim.
A trucking company’s procedure for handling damage is
as follows:
1. Immediately send out an inspector. An inspection
report is filled out on the spot, a copy of which is
given to the customer.
2. The customer has to call the carrier to request a
claim form.
3. The customer mails in the claim form.
4. The claim usually takes two (2) months to process.
If a unit is seriously damaged, your Ranger Products
dealer may be able to intervene, requesting that the
damaged unit be returned and a new unit delivered.
IMPORTANT SAFETY TIPS
ALWAYS MAINTAIN A CLEAN WORK AREA.
KEEP VISITORS AND ESPECIALLY
CHILDREN AWAY FROM WORK AREA.
THIS OIL DRAIN IS TO BE OPERATED BY
PROPERLY TRAINED PERSONNEL ONLY.
OPERATION BY UNTRAINED
PERSONNEL MAY RESULT IN INJURY
AND /OR PROPERTY DAMAGE.
For Parts Or Service Contact:
BendPak Inc. / Ranger Products
1645 Lemonwood Dr.
Santa Paula, CA. 93060
Tel: [phone]
Toll Free: 1-800-253-2363
Fax: [phone]
www.bendpak.com
www.rangerproducts.com

3
THIS OPERATING MANUAL CONTAINS
IMPORTANT DETAILS CONCERNING THE
SAFE OPERATION OF THIS EQUIPMENT.
THE USER MUST READ AND UNDERSTAND
THESE DETAILS BEFORE ANY USE OF THE
EQUIPMENT. THIS MANUAL MUST BE
RETAINED FOR FUTURE REFERENCE.
OWNER/OPERATOR
RESPONSIBILITY:
The owner and/or operator shall study the product
instructions and retain them for future reference.
The owner and/or operator shall have an understanding
of the product operating instructions and warnings before
operating the equipment.
Warning information shall be emphasized and
understood. If the operator is not uent in English, the
product instructions and warnings shall be read to and
discussed with the operator in the operator’s native
language by the purchaser/ owner or his designee,
making sure that the operator comprehends its contents.
INSPECTION
Visual inspection should be made before each use of
the Oil Drain. This inspection should check for abnormal
conditions such as cracked welds, leaks, and damaged,
loose or missing parts.
Any product that appears to be damaged in any way,
is found to be worn or operated abnormally, must be
removed from service immediately.
Any product that operates abnormally shall be removed
from service until repaired by a qualied repair service
center.
If the product is accidentally subjected to an abnormal
load or shock, it must be taken out of service immediately
and be inspected by a qualied repair or service center.
It is recommended that an annual inspection is performed
on the Oil Drain and that any damaged or worn parts,
decals or warning labels be replaced with manufacturer’s
specied parts.
ALTERATIONS
Because of potential hazards associated with this type of
equipment, no alterations shall be made to the product.
FOR YOUR SAFETY AND TO PREVENT INJURY:
WARNING!
DO NOT EXCEED RATED CAPACITY.
OVERLOADING CAN CAUSE DAMAGE TO
OR FAILURE OF THE OIL DRAIN.
KEEP HANDS AND BODY CLEAR
OF ALL PINCH POINTS.
THIS OIL DRAIN IS DESIGNED FOR USE ONLY ON
HARD LEVEL SURFACES CAPABLE OF SUSTAINING
THE LOAD. USE ON OTHER THAN HARD LEVEL
SURFACES CAN RESULT IN INSTABILITY AND
POSSIBLE LOSS OF LOAD.
NO ALTERATIONS TO THE OIL
DRAIN SHALL BE MADE.
READ, STUDY AND UNDERSTAND THE OPERATING
MANUAL PACKED WITH THIS EQUIPMENT
BEFORE OPERATING.
FAILURE TO HEED THESE WARNINGS MAY RESULT
IN LOSS OF LOAD, DAMAGE , AND/OR FAILURE
RESULTING IN PROPERTY DAMAGE,
PERSONAL OR FATAL INJURY.
DISPOSE OF USED OIL AND OTHER AUTOMOTIVE
FLUIDS IN COMPLIANCE WITH LOCAL,
STATE AND FEDERAL ENVIRONMENTAL
LAWS AND REGULATIONS.

4
ASSEMBLY INSTRUCTIONS
1. Assemble the Oil Drain using the illustration below as a guide.
Funnel Diameter Capacity Adjustable Shipping Weight Shipping Dimensions
18”
457mm
18 Gallons
68 liters
37” - 71”
940mm -1,800mm
32 lbs
15 kg
19” x 19”x 30”
483mm x 483mm x 762mm
PARTS BREAKDOWN
SPECIFICATIONS

5

Brand:Ranger
Model:RP20FC
Description:OilFilter/CanCrusher

TheRangerRP20FCoilfiltercrusherisanindustrialcrusherthat
convenientlyreducesthesizeofusedoilfilterstoonefourthoftheiroriginal
size.Anintegratedcollectionchamberandcollectordownspouttubeallows
quickrecoveryoftheoilforeasydisposaltoadrumorbulkcontainer.Ideal
forcrushingautomotiveandlightdutytruckoilfilterseventhepopular,8”
tallfiltersforCumminsandPowerstrokedieselpoweredvehicles

FEATURES
xSaveondisposalcostsandstoragespace.
xFulfilsEPAandothermandatedenvironmentalstandards.
xNomessdesignoperatescleanandefficientlylessenspillhazards.
xSinglecontrolvalveoperation.
xExclusiveXshapedbevelinpressheadprealignsfiltersforabsolute
verticalpress.
xWeldedsteelplateconstruction.
x121/2”diametercylinderprovides20,000lbs.crushingat175PSI.
x20secondcycletime.
xReducesfiltersto25%oftheiroriginalsize.
xRemovesupto95%oftheoil.
x100%Airoperatedverylowmaintenance.
xAutomaticsafetydoorstopsoperationwhendoorisopen.
xSeethroughdoorforconvenientviewingofoperation.
xComesstandardwithpressureregulatorandairmoistureseparator.
xOptionalstandaccommodates5,16and55gallondrumsfor
efficientfluidhandling.

SPECIFICATIONS
xOverallHeight:291/2”/749mm.
xOverallWidth:17”/432mm.
xOverallDepth:17”/432mm.
xChamberOpeningHeight:11”/279mm.
xChamberOpeningWidth:8”/203mm.
xChamberOpeningDepth:11”/279mm.
xAveragecycletime:1520seconds
xAirinput:125175PSI
xUnitWeight:228lbs./103kg.


6
For Parts Or Service
Contact:
BendPak Inc. / Ranger Products
1645 Lemonwood Dr.
Santa Paula, CA. 93060
Tel: [phone]
Toll Free: 1-800-253-2363
Fax: [phone]
www.bendpak.com
www.rangerproducts.com
pn#5900239
