Ranger R26EX User manual

MODEL
R26EX
TIRE CHANGER
FOR SERVICING
AUTOMOBILE
AND LIGHT TRUCK
SINGLE PIECE
TIRES / WHEELS
REVISED 12/11/06
INSTALLATION AND OPERATION MANUAL
SHIPPING DAMAGE CLAIMS
When this equipment is shipped, title passes to the
purchaser upon receipt from the carrier.
Consequently, claims for the material damaged in
shipment must be made by the purchaser against the
transportation company at the time shipment is
received.
BE SAFE
Your new Ranger tire changer was designed
and built with safety in mind. However, your
overall safety can be increased by proper train-
ing and thoughtful operation on the part of the
operator. DO NOT operate or repair this equip-
ment without reading this manual and the
important safety instructions shown inside.
1645 Lemonwood Dr.
Santa Paula, CA. 93060, USA
Tel: [phone]
Fax: [phone]
Keep this operation manual near the
machine at all times. Make sure that
ALL USERS read this manual .
PLEASE READ THE ENTIRE CONTENTS OF THIS MANUAL PRIOR TO
INSTALLATION AND OPERATION. BY PROCEEDING YOU AGREE THAT YOU
FULLY UNDERSTAND AND COMPREHEND THE FULL CONTENTS OF THIS
MANUAL. FORWARD THIS MANUAL TO ALL OPERATORS. FAILURE TO
OPERATE THIS EQUIPMENT AS DIRECTED MAY CAUSE INJURY OR DEATH.
