Rasilient PS312e2 User manual

RASILIENT CONFIDENTIAL PROPRIETARY INFORMATION
This document contains confidential information that is proprietary to Rasilient or confidential
information which Rasilient has a legal duty to protect from disclosure. The information contained in
this document may not be disclosed without the express written permission of Rasilient Systems Inc.
PS312e2
SAS Expansion Enclosure
User Manual
1/30/2019

Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page
of this document.
About This Manual
Safety Symbols
Environmental Specifications

Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page
of this document.
About This Manual
Safety Symbols
The following symbols are placed on some components of the system to alert the user to
potential hazards,
Safety Symbols
Icon or
Format
Instruction
NOTE: Indicates important information that helps you
make better use of your computer
CAUTION: There is a risk of personal injury and
equipment damage. Follow the instructions.
CAUTION: Hot surface. Avoid contact. Surfaces are hot
and may cause personal injury if touched.
CAUTION: Hazardous voltages are present. To reduce
the risk of electric shock and danger to personal
health, follow the instructions.
WARNING: Indicates a potential for property damage,
personal injury, or death.
italics
Book or document name;
Fill in the content
>
Menu links at all levels
Bold
Menu, Button, Options

Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page
of this document.
Environmental Specification
Temperature and Temperature Gradient
Operating
Ambient
Temperature
5 to 35ºC
Max
Temperature
Gradient
10ºC per hour
Non-Operating Ambient Non-
Operating
-40 to 60 ºC
Humidity
Operating
Ambient
Operating (Non-
condensing)
5 to 85 % R.H
Non-Operating
Ambient Non-
Operating (Non-
condensing)
5 to 90 % R.H
Altitude
Operating 35ºC at 3,000 ft, Meet ASHRAE Class A3
requirement
Non-Operating
25ºC at 40,000 ft

Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page
of this document.
Table of Contents
About This Manual ............................................................................................................................. - 2 -
Safety Symbols................................................................................................................................... - 2 -
1. General Overview ............................................................................................................................1
1.1 Feature Summary ...........................................................................................................1
1.2 System Overview ............................................................................................................1
2. Storage Enclosure Installation.......................................................................................................4
2.1 Safety Instructions .........................................................................................................4
2.1.1 Safety Precautions .................................................................................................4
2.1.2 Power Cord Connection .........................................................................................5
2.1.3 Electro-Static Discharge (ESD) Caution and Warnings........................................5
2.1.4 Protection against moving fan blade ....................................................................6
2.1.5 Rack System Instructions......................................................................................6
2.1.6 Others warnings and cautions ...............................................................................7
2.1.7 Regulatory Information .........................................................................................7
2.2 Necessary Tools..............................................................................................................9
2.3 Safety Instruction.........................................................................................................10
2.4 Check the Installation Environment............................................................................10
2.5 Unpacking.....................................................................................................................11
2.6 Rail Kit ..........................................................................................................................11
2.7 Drive Assembly.............................................................................................................13
2.8 Cabling and Access to electricity.................................................................................15
2.8.1 Connect the system’s power cable(s)..................................................................15
2.8.2Connect the enclosure .........................................................................................16
2.8.3 SAS Cable Connections .......................................................................................17
3. Hardware Overview .......................................................................................................................19
3.1 System Service Indicators............................................................................................19
3.1.1 PS312e2Chassis Front LED.................................................................................19

Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page
of this document.
3.1.2 Rear Indicators.....................................................................................................20
3.2 HDD ...............................................................................................................................22
3.3 PSU (Power Supply Unit) ............................................................................................22
3.3.1 PSU Removal .......................................................................................................22
3.3.2 PSU Installation...................................................................................................23
3.4 Canister .........................................................................................................................23
3.4.1 Canister Removal.................................................................................................24
3.4.2 Canister Installation ............................................................................................24

1
Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page
of this document.
1. General Overview
This document describes the high-level functional requirements and characteristics for the
Rasilient SBB JBOD Storage Enclosure product which is designed based on 12G SAS. It is a
SBB 2.1 compliant enclosure which houses two enclosure controller units in one single 2U
chassis to 12 3.5 inch hard drives.
1.1 Feature Summary
The following are the major features of the PS312e2storage disk enclosure:
Enclosure
o2U rack-mounted storage enclosure, SBB 2.1 compliant
oDimensions: 2U (H) x 446.8mm (W) x 531mm (L)
Disk Drive
oFront access disk drive
oSupport 12 3.5 inch per enclosure
oDrive power control via pin 3 of the drive connector (Need drive to
support the power control function)
oSAS, NL SAS,SSD and SATA drive support
Power Supply
oRedundant 600W
oSystem input: 100-240VAC, 47Hz-63Hz
oHigh efficiency (80Plus Silver Level)
oHot-pluggable from rear of chassis
o42mm (H) x 215.75mm (W) x 277.2mm (D)
oIntegrated fans for PSU and Canister cooling controlled by internal
microcontroller
oSupport N+1 fan failure
Canister
o1U, SBB 2.1 compliant
oDimensions: 274.5mm (L) x 209.55mm (W) x 38.1mm (H)
oHot-pluggable from rear of chassis
1.2 System Overview
Figure 1-1 ~ Figure 1-3 below, are view of PS312e2.
General Overview

2
Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page
of this document.
Figure 1-1: Trimetric View of PS312e2 Enclosure (3.5 inch drives)
Figure 1-2 PS312e2 Rearview
Figure 1-3 below, is view of the front of PS312e2:
Figure 1-3: PS312e2 Enclosure
As Figure 1-4 below, is view of the rear of PS312e2.

3
Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page
of this document.
Figure 1-4: PS312e2 Enclosure

4
Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page
of this document.
2. Storage Enclosure Installation
These instructions are intended to ensure that the user can use the product correctly to avoid danger or
property loss. Please read this Guide carefully before using the product, and keep it properly for future
reference. If the product cannot work normally or is damaged because the user does not follow the
safety instructions, we shall not assume any responsibility.
2.1 Safety Instructions
This section maybe not applicable to all products, it’s only for reference, and it’s not limited.
Read this section before beginning any procedure. The following text provides safety precautions
to follow when installing the product.
2.1.1 Safety Precautions
For your protection, observe the following safety precautions when setting up your
equipment:
Follow all cautions and instructions marked on the equipment.
Ensure that the voltage and frequency of your power source match the voltage and
frequency inscribed on the equipment’s electrical rating label.
Never push objects of any kind through openings in the equipment. Dangerous
voltages, energy or moving part may be present. Conductive external objects could
produce a short circuit that could cause fire, electric shock, or damage to your
equipment.
Do not block or cover the openings of your product. Never place a product near a
radiator or heat register. Failure to follow these guidelines can cause overheating
and affect the reliability of your product.
Do not operate products without the cover in place. Failure to take this precaution
may result in and system damage.
This product is intended for restricted access whereby access is controlled through
the use of a means of security (for example, key, lock, tool, badge access) and
personnel authorized for access have been instructed on the reasons for the
restrictions and any precautions that need to be taken.
Do not drop the product or subject it to physical shock.
Storage Enclosure
Installation

5
Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page
of this document.
Keep the product away from water or any liquid.
While shipping the product, pack it inside of the qualified package and ship with
pallet.
The equipment should be used in data center or lab.
2.1.2 Power Cord Connection
Installation of this equipment must comply with local and regional electrical
regulations governing the installation of information technology equipment by licensed
electricians. For electrical power ratings on options, refer to the power rating label or
the user documentation supplied with that option.
CAUTION: this product is designed to work with power systems having a grounded neutral
(grounded return for DC-powered products). To reduce the risk of electric shock, do not plug products
into any other type of power system. Contact your facilities manager or a qualified electrician if you are
not sure what type of power is supplied to your building.
CAUTION: Not all power cords have the same current ratings. Do not use the power cord provided
with your equipment for any other products or use. Do not use household extension cords with your
product.
CAUTION: For products with multiple power cords, all power cords must be disconnected to
completely remove power from the system.
Below mark is used when multiple power supplies are installed in a system.
2.1.3 Electro-Static Discharge (ESD) Caution and Warnings
WARNING:
1) In order to maximize overall product quality and eliminate the possibility of damage from electro-
static discharge, please observe ESD handling procedures wherever this symbol occurs during the
system integration.
2) All Employees must attend an ESD training class prior to performing any system or board handling.

6
Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page
of this document.
If you have not been properly trained contact your immediate supervisor to schedule training.
3) Required use of heel straps on both feet and/or wrists strap where applicable to ensure that you
are properly grounded by testing the continuity of the straps at a certified ESD station.
4) If you remove your heel straps or wrist straps for any reason, you must retest to insure proper
grounding.
5) To ensure the policies regarding ESD (Electrostatic discharge) controls for all personnel who work
in the manufacturing departments are enforced.
2.1.4 Protection against moving fan blade
A warning symbol as below or a similar symbol combined with the triangle shaped
warning sign from ISO 3864-2 is required to be placed closely to the moving part and
can be easily found by user during servicing.
CAUTION: Keep fingers and other body parts away from the moving blade. Failure to take this
precaution may result in personal injury.
2.1.5 Rack System Instructions
The following or similar rack-mount instructions are included with the installation
instructions:
Elevated Operating Ambient– If installed in a closed or multi-unit rack assembly,
the operating ambient temperature of the rack environment may be greater than
room ambient. Therefore, consideration should be given to installing the
equipment in an environment compatible with the maximum ambient temperature
(Tma) specified by the manufacturer.
Reduced Air Flow– Installation of the equipment in a rack should be such that the
amount of air flow required for safe operation of the equipment is not
compromised.
Mechanical Loading– Mounting of the equipment in the rack should be such that a
hazardous condition is not achieved due to uneven mechanical loading.
Circuit Overloading– Consideration should be given to the connection of the
equipment to the supply circuit and the effect that overloading of the circuits
might have on over-current protection and supply wiring. Appropriate
consideration of equipment nameplate ratings should be used when addressing
this concern.
Reliable Earthing– Reliable earthing of rack-mounted equipment should be
maintained. Particular attention should be given to supply connections other than
direct connections to the branch circuit (for example, use of power strips).
CAUTION: Rack mounted equipment must not be used as a shelf or workspace.

7
Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page
of this document.
Do not add weight to rack mounted equipment.
The following warnings apply to Racks and Rack Mounted systems:
CAUTION: For safety, equipment should always be loaded from the bottom up. That is, install the
equipment that will be mounted in the lowest space of the rack first, then the next higher space, etc.
CAUTION: To prevent the rack from tipping during equipment installation, the anti-tilt bar on the
rack must be deployed.
2.1.6 Others warnings and cautions
WARNING: This storage is very heavy. To reduce the risk of personal injury or damage to the
equipment:
1) Observe local occupational health and safety requirements and guidelines for manual material
handling.
2) Get help to lift and stabilize the product during installation or removal, especially when the product
is not fastened to the rails. When the storage weighs more than 22.5 kg (50 lb), at least two people
must lift the storage into the rack together. A third person may be required to help align the storage
if the server is installed higher than chest level.
WARNING: The drives and the internal system components maybe too hot to hurt, users should not
touch them before they cool down.
2.1.7 Regulatory Information
FCC (US)
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that
may cause undesired operation.
NOTICE: This equipment has been tested and found to comply with the limits for a Class A digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference when the equipment is operated in a commercial environment.
This equipment generates, uses, and can radiate radio frequency energy, and if it is not installed and
used in accordance with the instruction manual, it may cause harmful interference to radio
communications. Operation of this equipment in a residential area is likely to cause harmful
interference, in which case the user will be required to correct the interference at his/her own expense.

8
Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page
of this document.
NOTICE: Any modifications made to this device that are not approved by Rasilient may void the
authority granted to the user by the FCC to operate this equipment.
ICES-003 (Canada)
This Class A digital apparatus complies with Canadian ICES-003.
Cetappareilnumérique de la classe A estconforme à la norme NMB-003 du Canada.
CE (European Community)
This product conforms to the following European Directive(s) and Standard(s):
Application of Council Directive: 2014/35/EU, 2014/30/EU, 2011/65/EU.
Standards to which Conformity is declared: EN55022, EN55024, EN61000-3-2,
EN61000-3-3, EN60950-1.
This is a class A product.
In a domestic environment this product may cause radio interference in which case
the user may be required to take adequate measures.
Waste Electrical and Electronic Equipment (WEEE)
In accordance with European Directive 2012/19/EU on Waste Electrical and
Electronic Equipment (WEEE), the presence of the above symbol on the product or
on its packaging indicates that this item must not be disposed of in the normal
unsorted municipal waste stream. Instead, it is the user's responsibility to dispose
of this product by returning it to a collection point designated for the recycling of
electrical and electronic equipment waste. Separate collection of this waste helps
to optimize the recovery and recycling of any reclaimable materials and also
reduces the impact on human health and the environment.
For more information concerning the correct disposal of this product, please
contact your local authority or the retailer where this product was purchased.
VCCI (Japan)
This is a Class A product based on the standard of the Voluntary Control Council for
Interference by Information Technology Equipment (VCCI).

9
Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page
of this document.
If this equipment is used in a domestic environment, radio interference may occur,
in which case, the user may be required to take corrective actions.
この装置は、情報処理装置等電波障害自主規制協議会(VCCI)の基準に基づくクラス A
情報技術装置です。
この装置を家庭環境で使用すると電波妨害を引き起こすことがあります。この場合には
使用者が適切な対策を講ずるよう要求されることがあります。
中国环保使用期限标志
此产品环保使用期限是 30 年，在此期限内可安全放心使用，到期后必须进入回收环节。
2.2 Necessary Tools
We recommend the users to prepare and use the following tools for equipment installation:
1) ESD Protection: the users can wrap them around the wrist.
Figure 2-1: ESD Protection
2) Protective gloves:
Figure 2-2: Protective gloves
3) Screw drive:

10
Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page
of this document.
Figure 2-3: Screw drive
2.3 Safety Instruction
Please adopt power supply in the safety voltage range.
If the product does not work properly, please contact your dealer
Do not drop the product or subject it to physical shock.
When cleaning the product, please use a rubber dust blower to remove the
dirt. Never apply any cleanser with ethanol or benzene in it.
Do not expose the product in the environment not defined in the Guide.
Keep the product away from water or any liquid.
While shipping the product, pack it in the factory packing and ship with
pallet.
When it is necessary to replace a part, please contact your dealer in advance
and replace the part with specified model or part of the same features. We
shall not assume any responsibility for problems caused by unauthorized
replacement.
For security reasons, it is recommended that the equipment should be installed as the flow chart as
shows.
Figure 2-4: flow chart
2.4 Check the Installation Environment
Check the cabinet or mounting bracket: ensure that rack or mounting
bracket should be able to hold eight times of the total weight of equipment.
Check the cooling space: ensure thermal dissipation space has been
enough.
Check another installation environment requirements, please refer to the preface of this user
manual.

11
Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page
of this document.
2.5 Unpacking
Follow the following steps to unpack the product:
1) Inspect the package to make sure that it has not been damaged.
If you find damage, contact the local authorized Rasilient agent.
2) Open the package and check whether any item on the packing list is missing.
3) Take all items out of the package and check whether any item is in poor condition.
If you find damage, contact the local authorized Rasilient agent.
After unpacking, please be sure to examine and check the parts in good condition; after the
check, suggest to install equipment or put to the cabinet.
2.6 Rail Kit
This section introduces the PS312e212G chassis install on the rack with rail.
Step 1: Install the rail on the rack and rotate 4 buckles back.
Figure 2-5: Step 1
Step 2: Put the chassis on the rail and push it into the rack.

12
Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page
of this document.
Figure 2-6: Step 2
Step 3: Open the buckles to buckle the ears of chassis rotation, then use screws to fasten the
chassis on the rack.

13
Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page
of this document.
Figure 2-7: Step 3
Step 4: Install the bezel on two sides’ ear.
Figure 2-8: Step 4
2.7 Drive Assembly
This section simply introduces the HDD assemble process which will happen on customer side.
Step 1: Install the HDD with HDD carrier.

14
Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page
of this document.
Figure 2-9: Install the 3.5 HDD with HDD carrier
Step 2: Install the HDD carrier.
Figure 2-10: Install the 3.5 HDD carrier to chassis
