Rasilient AI68 User manual

AI68 User Manual version 1.1
AI68
Video Analytics Tower
User Manual

AI68 User Manual version 1.1
Copyright Notice
All rights, including copyright, in the content of this manual are owned or controlled by RASILIENT
and protected by copyright. No part of this document may be photocopied, reproduced, or translated
into another language without the prior written consent of RASILIENT Systems, Inc.
Trademarks
All product names or brands mentioned herein are the trademarks of RASILIENT, its subsidiaries or
other respective owners.
Disclaimer
This manual provides information regarding set-up and installation of the product herein. Nothing
herein may be construed as granting any right or license relating to any intellectual property rights of
this manual or product. Unless otherwise provided in the Purchase and Sale Agreement for this
product, manufacturer and distributor of this product will not be liable whatsoever relating to the
distribution and/or use of this product. In addition, manufacturer and distributor of this product hereby
specifically disclaim any express or implied warranties of merchantability, fitness for a particular
purpose, or non-infringement of third party rights in connection with this product.
Manufacturer of this product has the right to change specifications and product descriptions at any
time without notice.

AI68 User Manual version 1.1
Contents
About This Manual.............................................................................................................7
Conventions.......................................................................................................................7
Safety Symbols..................................................................................................................7
Safety Precautions.............................................................................................................8
Regulatory and Integration Information.............................................................................10
Regulatory Compliance Identification Numbers............................................................10
Product Regulatory Compliance....................................................................................10
Power Cords ..................................................................................................................11
1Introduction.................................................................................................................13
Audience Assumptions......................................................................................................13
About this Guide................................................................................................................13
Packing Checklist ..............................................................................................................13
Specifications.....................................................................................................................14
System Overview...............................................................................................................15
Powerful.............................................................................................................................16
Complete solution..............................................................................................................17
SSD Drives........................................................................................................................17
Optimized...........................................................................................................................17
System Specification.........................................................................................................18
2Component Identification;............................................................................................21
Motherboard rear I/O.........................................................................................................21
Front I/O.............................................................................................................................22
Power Supply.....................................................................................................................23

AI68 User Manual version 1.1
List of Figures
Figure 1: AI68....................................................................................................................................16
Figure 2: AI68 Rear IO.......................................................................................................................21
Figure 3: AI68 Front IO......................................................................................................................22
Figure 4: AI68 PSU............................................................................................................................23
Figure 5: AI68 RTX2080 IO ...............................................................................................................24
Figure 6: QRTX4000 (4 DP)..............................................................................................................25

AI68 User Manual version 1.1
List of Tables
Table 1: European Union Safety requirements ..................................................................................11
Table 2: Packing Checklst.................................................................................................................13
Table 3: Specifications.......................................................................................................................14
Table 4: System Specification............................................................................................................18

AI68 User Manual version 1.1
About This Manual
Conventions
Safety Symbols
Safety Precautions
Regulatory and Integration
Information

AI68 User Manual version 1.1
About This Manual
Conventions
To make sure that you perform certain tasks properly, take note of the following symbols used
throughout this manual.
Warning:
Provides Information to prevent injury in the process of completing a
task.
Caution:
Provides Information to prevent damage to the components in the
process of completing a task.
Important:
Provides Information required for completing a task.
Note:
Provides Tips to aid in completing a task.
Safety Symbols
The following symbols are placed on some components of the system to alert the user to potential
hazards,
WARNING: Electric Shock Hazard –To reduce risk of injury from electric
shock hazards, do not open this component.
WARNING: Contains No User or Field Serviceable Parts –To reduce the
risk of injury from electric shock hazards, do not open this component.
WARNING: Hot Surface or Component - To reduce risk of injury from a hot
component; allow the surface to cool before touching.
WARNING: Insert Network Interface Only - Any receptacle (e.g. RJ45)
marked with this symbol indicates a network interface connection. To reduce
the risk of electric shock, fire or damage to equipment, do not plug telephone
or telecommunications connectors into this receptacle
WARNING: This symbol, on power supplies or systems, indicates that the
equipment is supplied by multiple sources of power. To reduce the risk of
injury from electric shock, remove all power cords to completely power down
the system.

AI68 User Manual version 1.1
Weight in kg
Weight in lb
WARNING: This symbol indicates that the component exceeds the
recommended weight for one individual to handle safely. To reduce the risk
of personal injury or damage to the equipment, observe local occupational
health and safety requirements and guidelines for manual material handling.
Safety Precautions
Technician Notes
Only authorized technicians should attempt to repair this equipment.
Before installing this system, carefully read all the manuals included with the system.
All repair procedures allow only module replacement. Because of the complexity of the individual
boards and sub-assemblies, no one should attempt to make repairs at the component level or make
modifications to any printed wiring board. Improper repairs can create a safety hazard.
To reduce the risk of personal injury from electric shock and hazardous energy levels, do not exceed
the level of repairs specified in these procedures.
The system is designed to be electrically grounded. To ensure proper operation, plug the AC power
cord into a properly grounded AC outlet only.
Electrostatic Discharge Precautions
Electrostatic discharge (ESD) can damage static sensitive devices or micro circuitry. Proper
packaging and grounding techniques are required to prevent damage.
Keep electrostatic-sensitive parts in their containers until they arrive at a static free work area.
Use a wrist strap connected to the work surface as well as properly grounded tools and equipment
Keep the area free of nonconductive materials such as ordinary plastic tools and foam packing.
Avoid touching pins, leads, or circuitry.
Always place drives with printed circuit board (PCB) assembly-side down.
Grasp cards and boards by the edges. Hold drives by the frame. Avoid touching the solder joints or
pins.
If you need to lay the device down while it is out of the antistatic bag, lay it on the antistatic bag.
Before picking it up again, touch the antistatic bag and the metal frame of the system unit at the same
time.
System Warnings
Avoid dust, humidity, and extreme temperatures; place the system on a stable surface.
To reduce the risk of personal injury from hot surfaces, allow the hot-plug disk modules and other
system modules to cool before touching them.
To reduce the risk of electric shock or damage to the equipment, do not disable the power cord
grounding plug. The grounding plug is an important safety feature.
Ensure the power cord is inserted into a grounded electrical outlet that is easily accessible at all times.
Unplug the power cord from the power supply module to shut off power to the equipment
Protect the storage system from power fluctuations and temporary power interruptions with a

AI68 User Manual version 1.1
regulating uninterruptible power supply (UPS). This device protects the hardware from damage
caused by power surges and voltage spikes and keeps the system operational during a power failure.
The storage system must always be operated with all hot plug modules installed or slot covers in
place to ensure proper cooling.
Route power cords so that they will not be walked on or pinched by items placed upon or against
them. Pay particular attention to the plug, electrical outlet, and the point where the cords exit from the
product.

Regulatory and Integration Information
Regulatory Compliance Identification Numbers
For the purpose of regulatory compliance certifications and identification, this system is assigned a
serial number. This system serial number can be found on the product label, along with the required
approval markings and information. When requesting certification information for this product, always
refer to this serial number. This serial number should not be confused with the marketing name or
model number.
Product Regulatory Compliance
Product Safety Compliance
Worldwide Safety approvals can be supplied upon request. Please contact your sales representative
for approvals.
Product EMC Compliance
This product has been assembled from components that comply with the following electromagnetic
compatibility (EMC) regulations.
Communications Commission Notice
Part 15 of the Federal Communications Commission (FCC) Rules and Regulations has established
Radio Frequency (RF) emission limits to provide an interference-free radio frequency spectrum. Many
electronic devices, including computers, generate RF energy incidental to their intended function and
are, therefore, covered by these rules. These rules place computers and related peripheral devices
into two classes, Aand B, depending upon their intended installation. Class Adevices are those that
may reasonably be expected to be installed in a business or commercial environment. Class B devices
are those that may reasonably be expected to be installed in a residential environment (for example,
personal computers). The FCC requires devices in both classes to bear a label indicating the
interference potential of the device, as well as additional operating instructions for the user.
The rating label on the device shows which class (A or B) the equipment falls into. Class A devices do
not have an FCC logo or FCC ID on the label. Class B devices have an FCC logo or FCC ID on the
label. Once the class of the device is determined, refer to the following corresponding statement.
Class A Equipment
This equipment has been assembled with components that comply with the limits for a Class A
AI68 User Manual version 1.1

digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference when the equipment is operated in a commercial environment.
This equipment generates, uses, and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful interference, in which case
the user will be required to correct the interference at personal expense.
Declaration of Conformity for Products Marked with the FCC Logo—United States Only This
device complies with Part 15 of the FCC Rules Operation and is subject to the following two
conditions: (1) this device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation. For questions
regarding your product, please contact your sales representative.
To identify this product, refer to the Part, Series, or Model number found on the product.
European Union Notice
Products with the CE Marking comply with both the EMC Directive (89/336/EEC) and the Low-Voltage
Directive (73/23/EEC) issued by the Commission of the European Community.
Compliance with these directives implies conformity to the following European Norms (items in
brackets are the equivalent international standards):
Table 1: European Union Safety requirements
EN55022 (CISPR 22)
Electromagnetic Interference
EN55024 (IEC61000-4-2,3,4,5,6,8,11)
Electromagnetic Immunity
EN61000-3-2 (IEC61000-3-2)
Power Line Harmonics
EN61000-3-3 (IEC61000-3-3)
Power Line Flicker
EN60950 (IEC950)
Product Safety
Power Cords
The power cord set included in the system meets the requirements for use in the country where the
system was purchased. If this system is to be used in another country, contact your sales
representative to purchase a power cord that is approved for use in that country.
The power cord must be rated for the product and for the voltage and current marked on the product's
electrical ratings label. The voltage and current rating of the cord should be greater than the voltage
and current rating marked on the product. In addition, the cross-sectional area of the wires must be a
minimum of 1.00mm² or 18AWG, and the length of the cords must be between 1.8m (6 feet) and 3.6m
(12 feet). If you have questions about the type of power cord to use, contact your sales
representative.
AI68 User Manual version 1.1

AI68 User Manual version 1.1
Audience Assumptions
About This Guide
Packing Checklist
Specifications
System Overview
Chapter 1
Introduction

AI68 User Manual version 1.1
1Introduction
Audience Assumptions
This manual assumes that you are a service technician or network administrator familiar with
computer hardware, data storage and network administration terminology and tasks.
About this Guide
AI68 comes with appropriate hardware installed. User only needs to configure IP addresses, install
appropriate VMS software to administer and view the cameras. This manual is generally organized as
follows:
Introduction of the Manual
Introduction General introduction to the AI68 and itscomponents.
Packing Checklist
Make sure you have all the components shipped with your system. If any item is damaged or missing,
please contact your sales representative for replacement. The AI68 is shipped with the following:
Table 2: Packing Checklst
Chassis
Full TowerEnclosure
Graphics Adapter
Up to 6 Video Graphics Adapters depending on the
configuration
Power Cords
One Power Cord

AI68 User Manual version 1.1
Specifications
The table below is the technical specification for the AI68.
Table 3: Specifications
Dimensions
Height: 22" / 560mm
Width: 9.13" / 232mm
Depth: 22" / 560mm
Weight
Max-weight: 40 lbs / 18 kg ±5%
Temperature
Operating System: +10ºC~+35ºC
Non-operating System: -40ºC~+70ºC
Humidity
Operating System: 20%~80%
Non-operating System: 10%~95%
Power
100--240Vac input, 50/60Hz
1200 watts
Current
13A(110VAC)

AI68 User Manual version 1.1
System Overview
The AI68 Video Analytics Server The AI68T is optimized for Analytic/Machine Learning Video
Surveillance applications. The AI68Tcomes fully integrated and tested with industry leading video
analytic software, offering a turnkey platform for Artificial Intelligence, Machine learning and Heuristic
Analytic applications.
The AI68T Video Analytics Server comes in a tower chassis ideally suited for security operations
centers (SOCs). Installation and setup is a breeze. The server comes custom built and configured
with a complete product test. Most popular VMS client viewing software can also be preinstalled on
request. This allows the AI68T to be up and running in less than 15 minutes after it is unpacked from
the box.

AI68 User Manual version 1.1
Figure 1: AI68
Powerful
The AI68Tis a high performance analytics server appliance, built around Intel® Dual Xeon
Scalable CPUs and 384GB of 2666 MHz DDR4 memory. It can be configured with up to 6
Nvidia GPU cards.
Multiple CPU and GPU configurations available to create the most efficient and cost-effective
analytics solutions. The AI68T offers high performance and bandwidth connectivity to meet the
requirements of the most demanding video analytics requirements. The AI68T comes standard with
two GbE ports for LAN connectivity.

AI68 User Manual version 1.1
Complete solution
Rasilient provides a complete physical security solution. We offer all necessary components, including
high performance recording, analytics servers, viewing/monitoring and administration servers, and our
high performance storage products for a complete solution. We provide the right solutions for small to
the large video surveillance deployments. There is no longer a need to worry if your VMS and cameras
will work on your storage server. We prequalify and certify most major VMS software for our solutions.
SSD Drives
SSD drives are designed to deliver reliable 24×7 operation and optimized for power consumption,
quiet operation, and video. This ensures the highest video storage performance, with enterprise-class
reliability and a significant system cost savings.
Optimized
The AI68T is optimized for the video analytics market. It has the performance and capacity required
for the most demanding video analytics requirements.

AI68 User Manual version 1.1
System Specification
Table 4: System Specification
Core Technology
CPU Type
Dual Intel Xeon Scalable
Socket
LGA3647
Core Logic
Intel® C621 Chipset
Memory size
up to 384GB
Memory type
DDR4 2666 DIMM
Expansion
Expansion Slot :
7
Slot Type:
(4) PCI-E Gen3 x16 slots / (3) PCI-E Gen3 x8 slots
Storage
Drive support
256GB/512GB/1TB SSD for OS
Networking
Data Ports
2 x GbE
Display Outputs
1x VGA. Additional based on GPU cards
Onboard graphics
Aspeed AST2500
I/O Ports
6 x USB 3.0 ports (2 front and 4 rear)
2 x USB 2.0 port (front)
1 x VGA (D-sub)
Compliance PSU
Safety
US/Canada (UL1950-CSA950)

AI68 User Manual version 1.1
Europe (CE, EN55022 compliance to EU Directive
89/366/EEC)
EMI
US (FCC, CFR47 Part 15, Class A)
Europe (CE, EN55022 & EN55024)
Physical Characteristics
Dimensions (in /mm)
9.13”x 22”x 22”/232 x 560 x 560 mm
Weight
40 lbs / 18 kg ±5%
Power
Single
Voltage
100/220V AC
Watts
1200 Watts
Operating Environment
Designed for 24x7x365 Operation
Operation temperature
10℃ ~ 35℃
Non operation
temperature
-40℃ ~ 70℃
Humidity:
20% ~ 90% ( Non condensing)
Operating altitude
0 to 10,000’/0 to 3000m

AI68 User Manual version 1.1
Chapter 2
AI68 Component Identification
