Rasilient ApplianceStor AS63T User manual

ApplianceStorAS63T
Video Viewing and Administrative Appliance
User Manual

Copyright Notice
All rights, including copyright, in the content of this manual are owned or controlled by
RASILIENT and protected by copyright. No part of this document may be photocopied,
reproduced, or translated into another language without the prior written consent of RASILIENT
Systems, Inc.
Trademarks
All product names or brands mentioned herein are the trademarks of RASILIENT, its
subsidiaries or other respective owners.
Disclaimer
This manual provides information regarding set-up and installation of the product herein.
Nothing herein may be construed as granting any right or license relating to any intellectual
property rights of this manual or product. Unless otherwise provided in the Purchase and Sale
Agreement for this product, manufacturer and distributor of this product will not be liable
whatsoever relating to the distribution and/or use of this product. In addition, manufacturer and
distributor of this product hereby specifically disclaim any express or implied warranties of
merchantability, fitness for a particular purpose, or non-infringement of third party rights in
connection with this product.
Manufacturer of this product has the right to change specifications and product descriptions at
any time without notice.

Contents
About This Manual............................................................................................................................... 2
Conventions........................................................................................................................................ 2
Safety Symbols................................................................................................................................... 3
Safety Precautions.............................................................................................................................. 4
Regulatory and Integration Information.............................................................................................. 6
Regulatory Compliance Identification Numbers............................................................................. 6
Product Regulatory Compliance..................................................................................................... 6
Power Cords ................................................................................................................................... 8
1Introduction................................................................................................................................1-1
1.1 Audience Assumptions .........................................................................................................1-1
1.2 About this Guide...................................................................................................................1-1
1.3 Packing Checklist .................................................................................................................1-1
1.4 Specifications........................................................................................................................1-2
1.5 System Overview..................................................................................................................1-3
1.6 Powerful................................................................................................................................1-4
1.7 Complete solution.................................................................................................................1-5
1.8 SSD Drives ...........................................................................................................................1-5
1.9 Optimized..............................................................................................................................1-5
1.10 System Specification ............................................................................................................1-6
2Component Identification; ........................................................................................................2-8
2.1 Motherboard rear I/O............................................................................................................2-8
2.2 Front I/O................................................................................................................................2-9
2.3 Power Supply......................................................................................................................2-10
2.4 Graphics I/Os......................................................................................................................2-10

List of Figures
Figure 1-1: AS63..........................................................................................................................1-4
Figure 2-1:AS63 Motherboard Rear I/O ......................................................................................2-8
Figure 2-2: AS63 Front I/O...........................................................................................................2-9

List of Tables
Table i European Union Safety Requirements............................................................................. 7
Table 1-1 Introduction of the Manual.........................................................................................1-1
Table 1-2 Packing Checklist......................................................................................................1-1
Table 1-3 Specifications ............................................................................................................1-2

About This Manual
Conventions
Safety Symbols
Safety Precautions
Regulatory and Integration Information

About This Manual
Conventions
To make sure that you perform certain tasks properly, take note of the following symbols used
throughout this manual.
Warning:
Provides Information to prevent injury in the process of completing a
task.
Caution:
Provides Information to prevent damage to the components in the
process of completing a task.
Important:
Provides Information required for completing a task.
Note:
Provides Tips to aid in completing a task.

Safety Symbols
The following symbols are placed on some components of the system to alert the user to
potential hazards,
WARNING: Electric Shock Hazard –To reduce risk of injury from electric
shock hazards, do not open this component.
WARNING: Contains No User or Field Serviceable Parts –To reduce the
risk of injury from electric shock hazards, do not open this component.
WARNING: Hot Surface or Component - To reduce risk of injury from a hot
component; allow the surface to cool before touching.
WARNING: Insert Network Interface Only - Any receptacle (e.g. RJ45)
marked with this symbol indicates a network interface connection. To reduce
the risk of electric shock, fire or damage to equipment, do not plug telephone
or telecommunications connectors into this receptacle
WARNING: This symbol, on power supplies or systems, indicates that the
equipment is supplied by multiple sources of power. To reduce the risk of injury
from electric shock, remove all power cords to completely power down the
system.
Weight in kg
Weight in lb
WARNING: This symbol indicates that the component exceeds the
recommended weight for one individual to handle safely. To reduce the risk
of personal injury or damage to the equipment, observe local occupational
health and safety requirements and guidelines for manual material handling.

Safety Precautions
Technician Notes
Only authorized technicians should attempt to repair this equipment.
Before installing this system, carefully read all the manuals included with the system.
All repair procedures allow only module replacement. Because of the complexity of the
individual boards and sub-assemblies, no one should attempt to make repairs at the
component level or make modifications to any printed wiring board. Improper repairs can
create a safety hazard.
To reduce the risk of personal injury from electric shock and hazardous energy levels, do
not exceed the level of repairs specified in these procedures.
The system is designed to be electrically grounded. To ensure proper operation, plug the
AC power cord into a properly grounded AC outlet only.
Electrostatic Discharge Precautions
Electrostatic discharge (ESD) can damage static sensitive devices or micro circuitry. Proper
packaging and grounding techniques are required to prevent damage.
Keep electrostatic-sensitive parts in their containers until they arrive at a static free work
area.
Use a wrist strap connected to the work surface as well as properly grounded tools and
equipment
Keep the area free of nonconductive materials such as ordinary plastic tools and foam
packing.
Avoid touching pins, leads, or circuitry.
Always place drives with printed circuit board (PCB) assembly-side down.
Grasp cards and boards by the edges. Hold drives by the frame. Avoid touching the solder
joints or pins.
If you need to lay the device down while it is out of the antistatic bag, lay it on the antistatic
bag. Before picking it up again, touch the antistatic bag and the metal frame of the system
unit at the same time.
System Warnings
Avoid dust, humidity, and extreme temperatures; place the system on a stable surface.
To reduce the risk of personal injury from hot surfaces, allow the hot-plug disk modules and
other system modules to cool before touching them.

To reduce the risk of electric shock or damage to the equipment, do not disable the power
cord grounding plug. The grounding plug is an important safety feature.
Ensure the power cord is inserted into a grounded electrical outlet that is easily accessible
at all times. Unplug the power cord from the power supply module to shut off power to the
equipment
Protect the storage system from power fluctuations and temporary power interruptions with
a regulating uninterruptible power supply (UPS). This device protects the hardware from
damage caused by power surges and voltage spikes and keeps the system operational
during a power failure.
The storage system must always be operated with all hot plug modules installed or slot
covers in place to ensure proper cooling.
Route power cords so that they will not be walked on or pinched by items placed upon or
against them. Pay particular attention to the plug, electrical outlet, and the point where the
cords exit from the product.

Regulatory and Integration Information
Regulatory Compliance Identification Numbers
For the purpose of regulatory compliance certifications and identification, this system is
assigned a serial number. This system serial number can be found on the product label, along
with the required approval markings and information. When requesting certification information
for this product, always refer to this serial number. This serial number should not be confused
with the marketing name or model number.
Product Regulatory Compliance
Product Safety Compliance
Worldwide Safety approvals can be supplied upon request. Please contact your sales
representative for approvals.
Product EMC Compliance
This product has been assembled from components that comply with the following
electromagnetic compatibility (EMC) regulations.
Communications Commission Notice
Part 15 of the Federal Communications Commission (FCC) Rules and Regulations has
established Radio Frequency (RF) emission limits to provide an interference-free radio
frequency spectrum. Many electronic devices, including computers, generate RF energy
incidental to their intended function and are, therefore, covered by these rules. These rules
place computers and related peripheral devices into two classes,A and B, depending upon their
intended installation. ClassAdevices are those that may reasonably be expected to be installed
in a business or commercial environment. Class B devices are those that may reasonably be
expected to be installed in a residential environment (for example, personal computers). The
FCC requires devices in both classes to bear a label indicating the interference potential of the
device, as well as additional operating instructions for the user.
The rating label on the device shows which class (A or B) the equipment falls into. Class A
devices do not have an FCC logo or FCC ID on the label. Class B devices have an FCC logo or
FCC ID on the label. Once the class of the device is determined, refer to the following
corresponding statement.
Class A Equipment
This equipment has been assembled with components that comply with the limits for a ClassA

digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when the equipment is operated in a
commercial environment. This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. Operation of this equipment in a residential area is likely
to cause harmful interference, in which case the user will be required to correct the interference
at personal expense.
Declaration of Conformity for Products Marked with the FCC Logo—United States Only
This device complies with Part 15 of the FCC Rules Operation and is subject to the following
two conditions: (1) this device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause undesired operation.
For questions regarding your product, please contact your sales representative.
To identify this product, refer to the Part, Series, or Model number found on the product.
European Union Notice
Products with the CE Marking comply with both the EMC Directive (89/336/EEC) and the
Low-Voltage Directive (73/23/EEC) issued by the Commission of the European Community.
Compliance with these directives implies conformity to the following European Norms (items in
brackets are the equivalent international standards):
Table i European Union Safety Requirements
EN55022 (CISPR 22)
Electromagnetic Interference
EN55024 (IEC61000-4-2,3,4,5,6,8,11)
Electromagnetic Immunity
EN61000-3-2 (IEC61000-3-2)
Power Line Harmonics
EN61000-3-3 (IEC61000-3-3)
Power Line Flicker
EN60950 (IEC950)
Product Safety

Power Cords
The power cord set included in the system meets the requirements for use in the country where
the system was purchased. If this system is to be used in another country, contact your sales
representative to purchase a power cord that is approved for use in that country.
The power cord must be rated for the product and for the voltage and current marked on the
product's electrical ratings label. The voltage and current rating of the cord should be greater
than the voltage and current rating marked on the product. In addition, the cross-sectional area
of the wires must be a minimum of 1.00mm² or 18AWG, and the length of the cords must be
between 1.8m (6 feet) and 3.6m (12 feet). If you have questions about the type of power cord to
use, contact your sales representative.

Audience Assumptions
About This Guide
Packing Checklist
Specifications
System Overview
Chapter 1
Introduction

AS63 User Manual
1-1
1Introduction
1.1 Audience Assumptions
This manual assumes that you are a service technician or network administrator familiar with
computer hardware, data storage and network administration terminology and tasks.
1.2 About this Guide
AS63 comes with appropriate hardware installed. User only needs to configure IP addresses,
install appropriate VMS software to administer and view the cameras. This manual is generally
organized as follows:
Table 
1-1 Introduction of the Manual
Introduction
General introduction to theAS63 and its components.
1.3 Packing Checklist
Make sure you have all the components shipped with your system. If any item is damaged or
missing, please contact your sales representative for replacement. The AS63 is shipped with the
following:
Table  1-2 Packing Checklist
Chassis
Mid Tower Enclosure
Graphics Adapter
One or two Video GraphicsAdapters depending on the configuration
Power Cords
One Power Cord

AS63 User Manual
1-2
1.4 Specifications
The table below is the technical specification for the AS63.
Table 
1-3 Specifications
Dimensions
Height: 16.7" / 425mm
Width: 7.8" / 198mm
Depth: 19.1" / 485mm
Weight
Max-weight: 25 lbs / 11.3 kg ±5%
Temperature
Operating System: +10ºC~+35ºC
Non-operating System: -40ºC~+70ºC
Humidity
Operating System: 20%~80%
Non-operating System: 10%~95%
Power
100--240Vac input, 50/60Hz
600 watts
Current
Typical - 5/2.5Amax 8.6A

AS63 User Manual
1-3
1.5 System Overview
The ApplianceStor 63 Tower Video Viewing Appliance offers a high performance standalone
video viewing, monitoring and administration appliance that is cost effective. It supports monitors
with 8K resolution and 3D display. It offers standard HDMI, Display Port, VGAand DVI video
ports (three usable). Optional support for up to two DisplayPorts, two DVI and six HDMI for total
of up to eleven high resolution HD monitors for complete and cost effective surveillance viewing
and administration. The AS63T is the proven high performance video surveillance view and
administration solution.
The AS63T video viewing appliance comes in a tower chassis ideally suited for security
operations centers (SOCs). Installation and setup is a breeze. The server comes custom built
and configured with a complete product test. Most popular VMS client viewing software can also
be preinstalled on request. This allows the AS63T to be up and running in less than 15 minutes
after it is unpacked from the box. The AS63T Video Viewing Appliance is the ultimate viewing
center appliance specifically designed for mission-critical video surveillance.

AS63 User Manual
1-4
Figure 1-1: AS63
.
1.6 Powerful
The AS63T is a high performance server appliance, built around Intel® Xeon E3-1245 v5
quad-core eight thread server class processors with up to 3.9GHz clock speed and 8GB of 2133
MHz DDR4 ECC memory. The AS63Toffers high performance and bandwidth connectivity to
meet the requirements of the most demanding megapixel camera viewing and administration
SOC environments. The AS63T comes standard with two GbE ports for LAN connectivity.

AS63 User Manual
1-5
1.7 Complete solution
Rasilient provides a complete physical security solution. We offer all necessary components,
including high performance recording, viewing/monitoring and administration servers, and our
high performance storage products for a complete solution. We provide the right solutions for
small to the large video surveillance deployments. There is no longer a need to worry if your VMS
and cameras will work on your storage server. We prequalify and certify most major VMS
software for our solutions.
1.8 SSD Drives
SSD drives are designed to deliver reliable 24×7 operation and optimized for power consumption,
quiet operation, and video. This ensures the highest video storage performance, with
enterprise-class reliability and a significant system cost savings.
1.9 Optimized
The AS63T is optimized for the video surveillance market. It has the performance and capacity
required for the most demanding surveillance monitoring installations

AS63 User Manual
1-6
1.10 System Specification
Core Technology
CPU Type
Intel Skylake Xeon E3-1245v5 3.5GHz
Socket
LGA1151
Core Logic
Intel® 236 Chipset
Bench Mark/Clock speed
10291/3.50GHz
Memory size
8GB
Memory type
DDR4 2133 ECC DIMM
Expansion
Expansion Slot :
4
Slot Type:
1 x PCIe 3.0/2.0 x16 (x16/x8)
1 x PCIe 3.0/2.0 x16 (x8 mode) (switched from x16)
1 x PCIe 3.0/2.0 x16 (x4 mode)
1 x PCIe 3.0/2.0 x16 (x4 mode)
Storage
Drive support
240GB SSD
Removable Storage
1 x Optical DVD-RW
Networking
Data Ports
2 x GbE
Display Outputs
Up to 11 total HD ports
Onboard graphics
Intel® HD Graphics 530, 1xDVI, 2xHDMI
Onboard graphics
performance
985
Optional HD Graphics
Cards (x2)
GeForce GTX 1050 4GB up to 8 ports (2xDVI-D, 6x
HDMI &2xDP)
Opt Graphic performance
6300
Up to 11 HD total ports
Maximum supported
resolution
4096 x 2160(HDMI, DVI),
7680x4320 (Display Port),
I/O Ports
6 x USB 3.0 ports (2 front and 4 rear)
2 x USB 3.1 port(s) (rear, Type-A + Type-C)
1 x DVI, DP, VGA and HDMI ports (3 usable)
1 x PS/2 combo mouse port & keyboard port
Compliance PSU
Safety
US/Canada (UL1950-CSA950)
