Ratio Power box User manual

EV PORTABLE CHARGING CABLE
3-PHASE 16A-32A
Manual
EV PORTABLE CHARGING CABLE 3-PHASE 16A-32A– EV025

www.ratio.nl EV PORTABLE CHARGING CABLE 3-PHASE 16A-32A – EV025
IMPORTANT SAFETY INSTRUCTIONS3
SAFETY INFORMATION4
INSTALLATION 5
OPERATION 6
FRONT PANEL DISPLAY 7
SPECIFICATIONS8
MAINTENANCE 9
FCC INFORMATION9
WARRANTY INFORMATION 10
CONTACT / CUSTOMER SUPPORT 11
CONTACT / CUSTOMER SUPPORT
Ratio Electric B.V.
Ambachtsstraat 12
NL-3861 RH Nijkerk
The Netherlands
Tel. [phone]
[e-mail]
www.ratio.nl
2 11
CONTENTS
www.ratio.nl EV PORTABLE CHARGING CABLE 3-PHASE 16A-32A – EV025
10 [DATUM]
[UITGAVE]
3
Carefully read these instructions and the charging instructions in your vehicle
owner’s handbook before charging your electrical vehicle.
Take special note of all information marked with the following symbols:
IMPORTANT SAFETY INSTRUCTIONS
Caution: This symbol means be careful. You are capable of
doing something that might result in damage to equipment.
Warning: This symbol means danger. You are in a situation
that could cause bodily injury. Before you work on any electrical
equipment, be aware of the hazards involved with electrical
circuitry and standard practices for preventing accidents.
Note:This means pay particular attention. Notes contain helpful suggestions
Safety Guidelines
Use this Portable Charging device to charge electric vehicles equipped
with a conductive charge port only. See the vehicle’s owner’s handbook
to determine if the vehicle is equipped with a conductive charge port.
Make certain the Portable Charging devices’supply cable is positioned
so it will not be stepped on, tripped over, or otherwise subjected to
damage or stress.
There are no user serviceable parts inside. Refer to the Customer
Support section in this manual for service information. Do not attempt to
repair or service the Portable Charging device yourself.
Do not operate your Portable Charging device if it or the supply cable or
housing is visibly damaged. Switch off the MCB in the electrical cabinet
and contact your Service Representative for service immediately. Refer
to the Customer Support section in the manual for information on the
Service Representative in your area.
WARRANTY INFORMATION
Ratio Electric B.V. warrants this product to be free from defects in
material, manufacture and design for a period of one year after the date of
purchase. If this product is defective in materials, manufacture or design
during this warranty period, Ratio Electric B.V. will, at its option, repair or
replace the product.
Repair parts and/or replacement products may be either new or
reconditioned at Ratio Electric B.V. discretion.
This limited warranty does not include service to repair damage from
improper installation, improper connections with peripherals, external
electrical fault, accident, disaster, misuse, vandalism, unauthorized
alteration or repair, abuse or modifications to the product not approved in
writing by Ratio Electric B.V.
Any evidence of an attempt to disassemble the Portable Charging device
will void this warranty.
Any service repair outside the scope of this limited warranty shall be at
applicable rates and terms then in effect.

www.ratio.nl EV PORTABLE CHARGING CABLE 3-PHASE 16A-32A – EV025
10 [DATUM]
[UITGAVE]
3
Carefully read these instructions and the charging instructions in your vehicle
owner’s handbook before charging your electrical vehicle.
Take special note of all information marked with the following symbols:
IMPORTANT SAFETY INSTRUCTIONS
Caution: This symbol means be careful. You are capable of
doing something that might result in damage to equipment.
Warning: This symbol means danger. You are in a situation
that could cause bodily injury. Before you work on any electrical
equipment, be aware of the hazards involved with electrical
circuitry and standard practices for preventing accidents.
Note:This means pay particular attention. Notes contain helpful suggestions
Safety Guidelines
Use this Portable Charging device to charge electric vehicles equipped
with a conductive charge port only. See the vehicle’s owner’s handbook
to determine if the vehicle is equipped with a conductive charge port.
Make certain the Portable Charging devices’supply cable is positioned
so it will not be stepped on, tripped over, or otherwise subjected to
damage or stress.
There are no user serviceable parts inside. Refer to the Customer
Support section in this manual for service information. Do not attempt to
repair or service the Portable Charging device yourself.
Do not operate your Portable Charging device if it or the supply cable or
housing is visibly damaged. Switch off the MCB in the electrical cabinet
and contact your Service Representative for service immediately. Refer
to the Customer Support section in the manual for information on the
Service Representative in your area.
WARRANTY INFORMATION
Ratio Electric B.V. warrants this product to be free from defects in
material, manufacture and design for a period of one year after the date of
purchase. If this product is defective in materials, manufacture or design
during this warranty period, Ratio Electric B.V. will, at its option, repair or
replace the product.
Repair parts and/or replacement products may be either new or
reconditioned at Ratio Electric B.V. discretion.
This limited warranty does not include service to repair damage from
improper installation, improper connections with peripherals, external
electrical fault, accident, disaster, misuse, vandalism, unauthorized
alteration or repair, abuse or modifications to the product not approved in
writing by Ratio Electric B.V.
Any evidence of an attempt to disassemble the Portable Charging device
will void this warranty.
Any service repair outside the scope of this limited warranty shall be at
applicable rates and terms then in effect.

www.ratio.nl EV PORTABLE CHARGING CABLE 3-PHASE 16A-32A – EV025
SAFETY INFORMATION
Warning: When using electric products, basic precautions should
always be followed, including the following:
Read all the safety warnings and instructions before using the product.
Failure to follow the warnings and the instructions may result in electric
shock, fire and / or serious injury.
This device should be supervised when used around children.
Do not put fingers into the electric vehicle connector.
Do not use this product if the flexible power cord or EV cable are frayed,
have broken insulation, or any other signs of damage.
Do not use this product if the enclosure or the EV connector are broken,
cracked, open, or show any other indication of damage.
If the plug provided does not fit the outlet, do not modify the plug,
arrange for a grounded outlet to be installed by an electrician.
The charge cord is provided with a grounding conductor and a groundig
plug. This plug must be plugged into a properly gounded outlet in
compliance with national and local electrical codes.
Warning:If, at any time, you think the equipment is unsafe, switch off
the MCB in your electrical cabinet and immediately contact Customer
Support for service. Do not use your Portable Charging deviceuntil the
problem is identified and corrected.
Caution: Children should not be allowed to use this Portable Charging
device. Do not allow children to play in or around the Portable Charging
device. Close supervision of children is necessary when the Portable
Charging device is used.
Caution: Do not open the enclosure.
4 9
MAINTENANCE
FCC INFORMATION
This device complies with Part 15 of the FCC rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and
(2)This device must accept any interference received, including interference that
may cause undesired operation.
This product has been designed to protect against Radio Frequency Interference
(RFI). However there are some instances where high powered radio signals or
nearby RF-producing equipment (such as digital phones, RF communications
equipment, etc.) could affect operation.
If interference to your charge station is suspected, we suggest the following
steps be taken before consulting your Service Representative for assistance:
1. Reorient or relocate nearby electrical appliances or equipment during
charging.
2. Turn off nearby electrical appliances or equipment during charging.
Caution: Changes or modifications to this product by other than an
authorized service facility may void FCC compliance.
The Portable Charging devicerequires no maintenance other than occasional
cleaning.
Warning: Switch offyour Portable Charging device before cleaning
the unit.
Warning To reduce the risk of electrical shock or equipment damage,
be cautious while cleaning the connectors and case.
Clean the Portable Charging device using a soft cloth lightly moistened with
mild detergent solution. Never use any type of abrasive pad, scouring powder,
or flammable solvents such as alcohol or benzene.
www.ratio.nl EV PORTABLE CHARGING CABLE 3-PHASE 16A-32A – EV025
58
INSTALLATION
Note: This product must be grounded/protective earthed. If it should
malfunction or breakdown, grounding provides a path of least
resistance for electric current to reduce the risk of electric shock. This
product is equipped with a cord having an equipment grounding
conductor and a grounding plug. The plug must be plugged into a red
CEE wall socket 16A/32A that is properly installed and grounded in
accordance with all local codes and ordinances.
Warning: Improper connection of the equipment-grounding conductor is
able to result in a risk of electric shock. Check with a qualified electrician
or serviceman if you are in doubt as to whether the product is properly
grounded. Do not modify the plug provided with the product – if it will not
fit the outlet, have a proper outlet installed by a qualified electrician.
Note: The charge cord used to charge the vehicle is a high-powered electrical
device. The red CEE plug must fit tightly into a red CEE wall socket that
is in good condition.
Warning:Using the charge cord with a wrong or damaged wall socket
may cause burns or start a fire.
Periodically, check the wall plug and charge cord while the vehicle is
charging. If the wall plug feels hot, unplug the charge cord and have the
wall socket replaced by a qualified electrician.
Replace the charge cord if the wall plug or cord are damaged. Do not
use a wall socket that is wrong or damaged.
Warning: Extension Cords, Multi Outlet Power Strips, Surge Protectors
or similar devices should not be used with the charge cord. Use of
Extension Cords, Multi Outlet Power Strips, Surge Protectors or similar
devices may increase the risk of electric shock or other hazards.
SPECIFICATIONS
Charging System IEC 61851 Mode 2
Car Connector IEC 62196 Type 2
Wall Plug IEC 60309 16A/3-phase (red)&32A/3phase (red)
Voltage & Wiring 400V AC 3-phase, 50Hz
Charge Current max. 3-phase 16A or 3-phase 32A (IEC 60309)
Earth leakage protection
Grounding safety
Dimensions
Housing
Weight
Environment
30mA
earth wire detection
320mm x100mm x81mm
Polyester
6 kg (incl. cable) 16A
7kg(incl.cable) 32A
IP54 rain-tight

www.ratio.nl EV PORTABLE CHARGING CABLE 3-PHASE 16A-32A – EV025
58
INSTALLATION
Note: This product must be grounded/protective earthed. If it should
malfunction or breakdown, grounding provides a path of least
resistance for electric current to reduce the risk of electric shock. This
product is equipped with a cord having an equipment grounding
conductor and a grounding plug. The plug must be plugged into a red
CEE wall socket 16A/32A that is properly installed and grounded in
accordance with all local codes and ordinances.
Warning: Improper connection of the equipment-grounding conductor is
able to result in a risk of electric shock. Check with a qualified electrician
or serviceman if you are in doubt as to whether the product is properly
grounded. Do not modify the plug provided with the product – if it will not
fit the outlet, have a proper outlet installed by a qualified electrician.
Note: The charge cord used to charge the vehicle is a high-powered electrical
device. The red CEE plug must fit tightly into a red CEE wall socket that
is in good condition.
Warning:Using the charge cord with a wrong or damaged wall socket
may cause burns or start a fire.
Periodically, check the wall plug and charge cord while the vehicle is
charging. If the wall plug feels hot, unplug the charge cord and have the
wall socket replaced by a qualified electrician.
Replace the charge cord if the wall plug or cord are damaged. Do not
use a wall socket that is wrong or damaged.
Warning: Extension Cords, Multi Outlet Power Strips, Surge Protectors
or similar devices should not be used with the charge cord. Use of
Extension Cords, Multi Outlet Power Strips, Surge Protectors or similar
devices may increase the risk of electric shock or other hazards.
SPECIFICATIONS
Charging System IEC 61851 Mode 2
Car Connector IEC 62196 Type 2
Wall Plug IEC 60309 16A/3-phase (red)&32A/3phase (red)
Voltage & Wiring 400V AC 3-phase, 50Hz
Charge Current max. 3-phase 16A or 3-phase 32A (IEC 60309)
Earth leakage protection
Grounding safety
Dimensions
Housing
Weight
Environment
30mA
earth wire detection
320mm x100mm x81mm
Polyester
6 kg (incl. cable) 16A
7kg(incl.cable) 32A
IP54 rain-tight
