Ravaglioli G8945.26 User manual

• For any further information please contact your local dealer or call:
GB
For spare parts drawings refer to the section “ LIST OF COMPONENTS” enclosed to this manual.
INSTRUCTION MANUAL
TRANSLATION FROM THE
ORIGINAL INSTRUCTIONS
- Rev. n. 2 (05/2017)
Technical services: RAVAGLIOLI S.p.A. - Via 1° Maggio, 3 - 40037 Pontecchio Marconi - Bologna Italy
Phone [phone] - Telex 510697 RAV I - Fax [phone] - e-mail: [email protected]
7300-M018-2_R
7300-M018-2_R
G8945.26 - G8945IT.26
G8945V.26 - G8945ITV.26
G8945V.26S - G8945ITV.26S
G8945D.26 - G8945ITD.26
G8945D.26S - G8945ITD.26S

INSTRUCTION, USE AND
MAINTENANCE MANUAL GB
Page 2 of 60
RAVAGLIOLI S.p.A.
7300-M018-2_R
G8945.26 - G8945IT.26 - G8945V.26 - G8945ITV.26 - G8945V.26S - G8945ITV.26S - G8945D.26 - G8945ITD.26 - G8945D.26S - G8945ITD.26S
SUMMARY
SYMBOLS USED IN THE MANUAL AND
ON THE MACHINE_______________________ 5
1.0 GENERAL INTRODUCTION _________ 8
1.1 Introduction ___________________________8
2.0 INTENDED USE ____________________ 8
2.1 Training of personnel__________________8
3.0 SAFETY DEVICES __________________ 9
3.1 Residual risks _________________________9
4.0 GENERAL SAFETY RULES _________ 9
5.0 PACKING AND MOBILIZATION FOR
TRANSPORT ______________________ 10
6.0 UNPACKING _______________________ 11
7.0 MOBILIZATION____________________ 11
8.0 WORKING ENVIRONMENT
CONDITIONS ______________________ 12
8.1 Working position ____________________ 12
8.2 Installation space ___________________ 12
8.3 Lighting _____________________________ 12
9.0 MACHINE ASSEMBLY _____________ 12
9.1 Anchoring system ___________________ 12
9.2 Accessories contained in the packing__ 13
9.3 Assembly procedure _________________ 13
10.0 ELECTRICAL CONNECTION _______ 16
10.1 Direction of rotation of motor
(versions with three phase motor)___ 17
11.0 CONTROLS________________________ 17
11.1 Plus device control unit (only for
G8945V.26S - G8945ITV.26S -
G8945D.26S - G8945ITD.26S
models)______________________________ 17
11.2 Tool control unit _____________________ 18
11.3 Bead-breaking arm control unit _____ 18
11.4 Pedalboard __________________________ 19
12.0 USING THE MACHINE _____________ 20
12.1 Precaution measures during tyre
removal and fitting__________________ 20
12.2 Preliminary operations - Preparing
the wheel ____________________________ 20
12.3 Bead breaking with side vane _______ 20
12.4 Use of the lifting device (only for
G8945V.26S -G8945ITV.26S -
G8945D.26S - G8945ITD.26S models) _ 21
12.5 Wheel clamping______________________ 22
12.5.1 Mandrel height adjustment______ 24
12.5.2 Reverse wheel pan protection
(only for G8945.26 - G8945IT.26
- G8945V.26 - G8945ITV.26 -
G8945V.26S - G8945ITV.26S -
G8945D.26S - G8945ITD.26S
models)__________________________ 24
12.6 Bead breaking through vertical roll _ 24
12.7 Demounting the tyre_________________ 26
12.8 Mounting the tyre____________________ 29
12.8.1 Fitting the tyre upper bead with
entrainer (only for G8945.26 -
G8945IT.26 - G8945V.26 -
G8945ITV.26 - G8945V.26S
- G8945ITV.26S - G8945D.26S -
G8945ITD.26S models) __________ 30
12.9 Tyre inflation with machine without
tubeless inflation____________________ 31
12.10 Tyre inflation with machine with
tubeless inflation____________________ 31
13.0 ROUTINE MAINTENANCE _________ 31
13.1 Lubricants___________________________ 32
14.0 TROUBLESHOOTING TABLE ______ 33
15.0 TECHNICAL DATA_________________ 36
15.1 Technical data_______________________ 36
15.2 Dimensions __________________________ 37
16.0 STORING__________________________ 39
17.0 SCRAPPING _______________________ 39
18.0 REGISTRATION PLATE DATA _____ 39
19.0 FUNCTIONAL DIAGRAMS _________ 39
Table A - Electric diagram
(G8945.26 - G8945IT.26) ________ 40
Table B - Electric diagram
(G8945V.26 - G8945ITV.26
G8945V.26S - G8945ITV.26S) ___ 42
Table C - Electric diagram
(G8945D.26 - G8945ITD.26
G8945D.26S - G8945ITD.26S) __ 43
Table D - Electric diagram (Monophasic
version 110V - 60Hz) ____________ 46

INSTRUCTION, USE AND
MAINTENANCE MANUAL
GB Page 3 of 60 RAVAGLIOLI S.p.A.
7300-M018-2_R
G8945.26 - G8945IT.26 - G8945V.26 - G8945ITV.26 - G8945V.26S - G8945ITV.26S - G8945D.26 - G8945ITD.26 - G8945D.26S - G8945ITD.26S
Table E - Pneumatic diagram
(G8945.26 - G8945D.26 -
G8945V.26) ______________________ 47
Table F - Pneumatic diagram
(G8945IT.26 - G8945ITD.26 -
G8945ITV.26)____________________ 50
Table G - Pneumatic diagram
(G8945V.26S - G8945D.26S) _____ 53
Table H - Pneumatic diagram
(G8945ITV.26S - G8945ITD.26S) _ 56
Table I - Lifting device pneumatic
diagram ________________________ 59
20.0 LIST OF COMPONENTS

INSTRUCTION, USE AND
MAINTENANCE MANUAL GB
Page 4 of 60
FIG. 1
RAVAGLIOLI S.p.A.
7300-M018-2_R
G8945.26 - G8945IT.26 - G8945V.26 - G8945ITV.26 - G8945V.26S - G8945ITV.26S - G8945D.26 - G8945ITD.26 - G8945D.26S - G8945ITD.26S
KEY
1 – Machine base
2 – Bead breaker roll
3 – Column unit
4 – Tool box
5 – Lifting device (only for G8945V.26S - G8945ITV.26S - G8945D.26S - G8945ITD.26S models)
6 – Lateral bead breaker
7 – Locking device
8 – Tool control unit
9 – Bead breaking roll control unit
10 – Plus device control unit (only for G8945V.26S - G8945ITV.26S - G8945D.26S - G8945ITD.26S
models)
11 – Tool arm unlock push button
12 – Tubeless inflation unit (only for G8945IT.26 - G8945ITV.26 - G8945ITV.26S - G8945ITD.26 -
G8945ITD.26S models)
13 – Lever for bead breaker roll lateral opening release
14 – Tyre mounting/demounting tool
15 – Central locking mandrel
16 – Control pedal
17 – Bead breaker roll movement cylinder
18 – Tank unit (only for G8945IT.26 - G8945ITV.26 - G8945ITV.26S - G8945ITD.26 - G8945ITD.26S
models)
19 – Inflation unit with pressure gauge (only for G8945V.26S - G8945D.26S models)
20 – Plus device (only for G8945V.26S - G8945ITV.26S - G8945D.26S - G8945ITD.26S models)

INSTRUCTION, USE AND
MAINTENANCE MANUAL
GB Page 5 of 60
SYMBOLS USED IN THE MANUAL AND ON THE MACHINE
Symbols Description
Read instruction manual.
FORBIDDEN!
Wear work gloves.
Wear work shoes.
Wear safety earcaps.
99990758
Shock hazard.
999911770
Danger! Moving mechanical parts.
Caution: hanging loads.
Mandatory. Operations or jobs to
be performed compulsorily.
Danger! Be particularly careful.
Symbols Description
999911890
Move with fork lift truck or pallet
truck.
Lift from above.
Tyre burst danger.
B4219000
Spindle rotation direction.
B2166000
Hands crushing danger.
B1541000
General danger.
Max inflation pressure rating.
999913060
Inflation pedal.
Wear safety goggles.
Technical assistance necessary.
Do not perform any intervention.
Warning. Be particularly careful
(possible material damages).
Note. Indication and/or useful
information.
RAVAGLIOLI S.p.A.
7300-M018-2_R
G8945.26 - G8945IT.26 - G8945V.26 - G8945ITV.26 - G8945V.26S - G8945ITV.26S - G8945D.26 - G8945ITD.26 - G8945D.26S - G8945ITD.26S

INSTRUCTION, USE AND
MAINTENANCE MANUAL GB
Page 6 of 60
INFORMATION PLATE LOCATION TABLE
RAVAGLIOLI S.p.A.
7300-M018-2_R
G8945.26 - G8945IT.26 - G8945V.26 - G8945ITV.26 - G8945V.26S - G8945ITV.26S - G8945D.26 - G8945ITD.26 - G8945D.26S - G8945ITD.26S

INSTRUCTION, USE AND
MAINTENANCE MANUAL
GB Page 7 of 60 RAVAGLIOLI S.p.A.
7300-M018-2_R
G8945.26 - G8945IT.26 - G8945V.26 - G8945ITV.26 - G8945V.26S - G8945ITV.26S - G8945D.26 - G8945ITD.26 - G8945D.26S - G8945ITD.26S
Code numbers of plates
B1541000 Danger plate
B2166000 Hand crushing danger plate
B2668000 Wheel lifting device danger plate (only for G8945V.26S - G8945ITV.26S - G8945D.26S -
G8945ITD.26S models)
B4219000 Rotation indicating plate
99990758 Electricity danger plate
999910050 Protection device use plate
999910060 Bead breaker danger plate
999910070 Head danger indicating plate
999911770 Unit move indicating plate
999911870 Headphones plate
999911890 Bursting tyre hazard plate
999912460 Supply pressure indicating plate
999912550 110/60/1 voltage table (only for G8945D.26 - G8945ITD.26 - G8945D.26S -
G8945ITD.26S models)
999913060 Inflation pedal plate
999914700 Bead depressing roll controls plate (only for G8945V.26S - G8945ITV.26S - G8945D.26S
- G8945ITD.26S models)
999916011 Motoinverter plate (only for G8945D.26 - G8945ITD.26 - G8945D.26S - G8945ITD.26S
models)
999916311 Rubbish skip label
999916450 Lifting device pedal label (only for G8945V.26S - G8945ITV.26S - G8945D.26S -
G8945ITD.26S models)
999916880 Max. capacity load 80 Kg plate (only for G8945V.26S - G8945ITV.26S - G8945D.26S -
G8945ITD.26S models)
999921000 5 pedals pedalboard plate
999920910 Plate G8945.26-SPEED
♦Voltage label
•Serial number plate
*Manufacturer nameplate
IF ONE OR MORE PLATES DISAPPEARS FROM THE MACHINE OR BECOMES DIFFICULT
TO READ. REPLACE IT AND QUOTE ITS/THEIR CODE NUIMBER/S WHEN REORDERING.

INSTRUCTION, USE AND
MAINTENANCE MANUAL GB
Page 8 of 60
SOME OF THE PICTURES PRE-
SENT IN THIS MANUAL HAVE
BEEN OBTAINED FROM PICTURES
OF PROTOTYPES, THEREFORE
THE STANDARD PRODUCTION
MACHINES AND ACCESSORIES
CAN BE DIFFERENT IN SOME
COMPONENTS.
1.0 GENERAL INTRODUCTION
This manual is an integral part of the product and
must be retained for the whole operating life of the
machine.
Carefully study the warnings and instructions con-
tained in this manual. It contains important instruc-
tions regarding FUNCTIONING, SAFE USE and
MAINTENANCE.
KEEP THE MANUAL IN A KNOWN,
EASILY ACCESSIBLE PLACE FOR
ALL OPERATORS TO CONSULT IT
WHENEVER IN DOUBT.
THE MANUFACTURER DISCLAIMS
ALL RESPONSIBILITY FOR ANY
DAMAGE OCCURRED WHEN THE
INDICATIONS GIVEN IN THIS
MANUAL ARE NOT RESPECTED:
AS A MATTER OF FACT, THE NON-
COMPLIANCE WITH SUCH INDI-
CATIONS MIGHT LEAD TO EVEN
SERIOUS DANGERS.
1.1 Introduction
Thank you for preferring this tyre-changer. We feel sure
you will not regret your decision.
This machine has been designed for use in profes-
sional workshops and in particular it stands out for
its reliability and easy, safe and rapid operation: with
just a small degree of maintenance and care, this tyre
changer will give you many years of trouble-free service
and lots of satisfaction.
RAVAGLIOLI S.p.A.
7300-M018-2_R
G8945.26 - G8945IT.26 - G8945V.26 - G8945ITV.26 - G8945V.26S - G8945ITV.26S - G8945D.26 - G8945ITD.26 - G8945D.26S - G8945ITD.26S
2.0 INTENDED USE
The machines model “G8945.26” are car tyre
changers intended to be used solely for mounting,
demounting and inflating any type of wheels with
maximum dimensions of 1143 mm/45” and maxi-
mum width of 381 mm/15”.
THIS MACHINE MUST BE USED
STRICTLY FOR THE INTENDED
PURPOSE IT WAS DESIGNED FOR
(AS INDICATED IN THIS MANUAL).
ANY OTHER USE WILL BE CON-
SIDERED IMPROPER USE. IN
PARTICULAR BEAD FITTING AND
INFLATING MUST BE CARRIED
OUT IN A SPECIALLY APPROVED
INFLATION CAGE.
THE MANUFACTURER CANNOT
BE HELD RESPONSIBLE FOR ANY
DAMAGE CAUSED BY IMPROPER,
ERRONEOUS, OR UNACCEPTABLE
USE.
AN INTENSIVE USE OF THE EQUIP-
MENT IN INDUSTRIAL ENVIRON-
MENT IS NOT RECOMMENDED.
2.1 Staff training
The machine may be operated only by suitably
trained and authorized personnel.
Given the complexity of the operations necessary to
manage the machine and to carry out the operations
safely and efficiently, the personnel must be trained
in such a way that they learn all the information
necessary to operate the machine as intended by the
manufacturer.
A CAREFUL READING OF THIS
INSTRUCTION MANUAL FOR
USE AND MAINTENANCE AND A
SHORT PERIOD OF TRAINING
WITH SKILLED PERSONNEL CAN
BE AN ENOUGH PREVENTIVE
PREPARATION.

INSTRUCTION, USE AND
MAINTENANCE MANUAL
GB Page 9 of 60
3.1 Residual risks
The machine was subjected to a complete analysis of
risks according to reference standard EN ISO 12100.
Risks are as reduced as possible in relation with tech-
nology and product functionality.
This manual stresses possible residual risks, also
highlighted in pictograms on the present manual and
adhesive warning signals placed on the machine: their
location is represented in “PLATE LOCATION ON MA-
CHINE INFORMATION TABLE” on page 5.
4.0 GENERAL SAFETY RULES
• Any tampering with or modification to the machine
not previously authorized by the manufacturer ex-
empts the latter from all responsibility for damage
caused by or derived from said actions.
• Removing of or tampering with the safety devices or
with the warning signals placed on the machine leads
to serious dangers and represents a transgression of
European safety rules.
• Use of the machine is only permitted in places free
from explosion or fire hazard and in dry places
under cover.
• Original spare parts and accessories should be used.
THE MANUFACTURER DENIES
ANY RESPONSIBILITY IN CASE
OF DAMAGES CAUSED BY UNAU-
THORIZED MODIFICATIONS OR
BY THE USE OF NON ORIGINAL
COMPONENTS OR EQUIPMENT.
• Installation must be conducted only by qualified
personnel exactly according to the instructions that
are given below.
• Ensure that there are no dangerous situations dur-
ing the machine operating manoeuvres. Immediately
stop the machine if it miss-functions and contact the
assistance service of an authorized dealer.
• In emergency situations and before carrying out any
maintenance or repairs, disconnect all supplies to
the machine by using the main switch.
• The machine electrical supply system must be
equipped with an appropriate earthing, to which
the yellow-green machine protection wire must be
connected.
• Ensure that the work area around the machine is free
of potentially dangerous objects and that there is no
oil since this could damage the tyre. Oil on the floor
is also a potential danger for the operator.
RAVAGLIOLI S.p.A.
7300-M018-2_R
G8945.26 - G8945IT.26 - G8945V.26 - G8945ITV.26 - G8945V.26S - G8945ITV.26S - G8945D.26 - G8945ITD.26 - G8945D.26S - G8945ITD.26S
3.0 SAFETY DEVICES
PERIODICALLY, AT LEAST MONTH-
LY, CHECK THE INTEGRITY AND
THE FUNCTIONALITY OF THE
SAFETY AND PROTECTION DE-
VICES ON THE MACHINE.
All the machines are equipped with:
• “man-operated” controls (immediate stop of opera-
tion when the control is released) for all operating
devices;
• mandrel rotation;
• tool translation;
• bead breaking roller translation;
• side bead breaking;
• lifting device (only for G8945V.26S - G8945ITV.26S
- G8945D.26S - G8945ITD.26S models);
• fixed protections and guards.
The machine is fitted with a number of fixed guards
intended to prevent potential crushing, cutting and
compression risks.
These protections have been realized after risks
evaluation and after all machine operative situations
have been considered.
All protections, specially the rubber ones, have to be
periodically checked in order to evaluate their wear
state.
PERIODICALLY CARRY OUT THE
MAINTENANCE OF THE PROTEC-
TIONS, SHELTERS AND SAFETY
DEVICES IN GENERAL, AS INDI-
CATED IN CHAPTER 13. ROUTINE
MAINTENANCE.
• Motor protection devices (only for G8945D.26
- G8945ITD.26 - G8945D.26S - G8945ITD.26S
models)
The new “Invemotor” motor is equipped with elec-
tronic protection devices. They stop the motor if
working defected conditions appear to avoid that the
motor itself can be damaged and that the operator
safety can be compromised (overvoltage, overload,
overtemperature). For other details, see the chapt.
14 “Fault-Finding”.
• Non-adjustable pressure limiter.
This allows inflation of tyres in reasonable safety.
Inflation of tyres to over 4,2 ± 0,2 bar (60 PSI) is
not allowed.

INSTRUCTION, USE AND
MAINTENANCE MANUAL GB
Page 10 of 60
OPERATORS MUST WEAR SUIT-
ABLE WORK CLOTHES, PROTEC-
TIVE GLASSES AND GLOVES,
AGAINST THE DANGER FROM
THE SPRAYING OF DANGEROUS
DUST, AND POSSIBLY LOWER
BACK SUPPORTS FOR THE LIFT-
ING OF HEAVY PARTS. DANGLING
OBJECTS LIKE BRACELETS MUST
NOT BE WORN, AND LONG HAIR
MUST BE TIED UP. FOOTWEAR
SHOULD BE ADEQUATE FOR THE
TYPE OF OPERATIONS TO BE CAR-
RIED OUT.
• The machine handles and operating grips must be
kept clean and free from oil.
• The workshop must be kept clean, dry and not
exposed to atmospheric agents. Make sure that the
working premises are properly lit.
The machine can be operated by a single operator.
Unauthorized personnel must remain outside the
working area, as shown in Fig. 4.
Avoid any hazardous situations. Do not use air-
operated or electrical equipment when the shop is
damp or the floor slippery and do not expose such
tools to atmospheric agents.
• When operating and servicing this machine, carefully
follow all applicable safety and accident-prevention
precautions.
The machine must not be operated by professionally
unskilled persons.
• During inflation do not lean on the tyre or remain
above it. When beading in the tyre, keep hands away
from tyre and the rim edge.
• Never activate the inflation device (only on models
with tubeless inflation) if the tyre has not been cor-
rectly locked.
• During inflation always stay to the side of the machine
and never in front of it.
IN CASE OF A CHANCE SUPPLY
FAILURE (WHETHER ELECTRICI-
TY OR COMPRESSED AIR), MOVE
THE PEDALS TO THE NEUTRAL
POSITION.
RAVAGLIOLI S.p.A.
7300-M018-2_R
G8945.26 - G8945IT.26 - G8945V.26 - G8945ITV.26 - G8945V.26S - G8945ITV.26S - G8945D.26 - G8945ITD.26 - G8945D.26S - G8945ITD.26S
5.0 PACKING AND MOBILIZATION FOR
TRANSPORT
HAVE THE MACHINE HANDLED BY SKILLED
PERSONNEL ONLY.
THE LIFTING EQUIPMENT MUST WITHSTAND
A MINIMUM RATED LOAD EQUAL TO THE
WEIGHT OF THE PACKED MACHINE (SEE
PARAGRAPH “TECHNICAL SPECIFICATIONS”).
The packed machine is partially assembled in its
main components. The cardboard box containing
it has dimensions of 1410x1310x1995 (for models
G8945.26 - G8945IT.26 - G8945V.26 - G8945ITV.26
- G8945D.26 - G8945ITD.26), 1550x1310x1995 (for
models G8945V.26S - G8945ITV.26S - G8945D.26S -
G8945ITD.26S) and it is fixed on a special reinforced
pallet.
Movement must be by pallet-lift or fork-lift trolley. The
fork lifting points are indicated on the packing.
Fig. 2

INSTRUCTION, USE AND
MAINTENANCE MANUAL
GB Page 11 of 60
7.0 MOBILIZATION
THE LIFTING EQUIPMENT MUST WITHSTAND
A MINIMUM RATED LOAD EQUAL TO THE
WEIGHT OF THE MACHINE (SEE PARAGRAPH
TECHNICAL SPECIFICATIONS). DO NOT AL-
LOW THE LIFTED MACHINE TO SWING.
If the machine has to be moved from its normal work
post, the movement must be conducted following the
instructions listed below.
• Protect the exposed corners with suitable material
(Pluribol/cardboard).
• Do not use metallic cables for lifting.
• Disconnect all machine power supply sources.
• Lift and transport with suitable device with adequate
dimensions.
• Sling with a 100 cm long belt, with a capacity load
greater than 1000 kg as shown in Fig. 3.
Fig. 3
6.0 UNPACKING
DURING UNPACKING, ALWAYS
WEAR GLOVES TO PREVENT ANY
INJURY CAUSED BY CONTACT
WITH PACKAGING MATERIAL
(NAILS, ETC.).
The cardboard box is supported with plastic strapping.
Cut the strapping with suitable scissors. Use a small
knife to cut along the lateral axis of the box and open
it like a fan.
It is also possible to unnail the cardboard box from
the pallet it is fixed to. After removing the packing,
and in the case of the machine packed fully assembled,
check that the machine is complete and that there is
no visible damage.
If the machine is packed dismantled into its principal
parts, after removing the packing, lay the individual
parts on the floor and check them for any missing
components, damage, or irregularity.
If in doubt do not use the machine and refer to pro-
fessionally qualified personnel (to the seller).
The packing (plastic bags, expanded polystyrene, nails,
screws, timber, etc.) should not be left within reach
of children since it is potentially dangerous. These
materials should be deposited in the relevant collec-
tion points if they are pollutants or non biodegradable.
THE BOX CONTAINING THE FIX-
TURES IS CONTAINED IN THE
WRAPPING. DO NOT THROW IT
AWAY WITH THE PACKING.
RAVAGLIOLI S.p.A.
7300-M018-2_R
G8945.26 - G8945IT.26 - G8945V.26 - G8945ITV.26 - G8945V.26S - G8945ITV.26S - G8945D.26 - G8945ITD.26 - G8945D.26S - G8945ITD.26S

INSTRUCTION, USE AND
MAINTENANCE MANUAL GB
Page 12 of 60
8.0 WORKING ENVIRONMENT CONDI-
TIONS
The machine must be operated under proper condi-
tions as follows:
• temperature: 0° + 55° C
• relative humidity: 30 - 95% (dew-free)
• atmospheric pressure: 860 - 1060 hPa (mbar).
The use of the machine in ambient conditions other
than those specified above is only allowed after prior
agreement with and approval of the manufacturer.
8.1 Working position
In Figure 4 it is possible to identify working positions
A and B.
Position A is the main position for wheel fitting and
removal with the mandrel, while position B is ideal to
follow tyre inflation operations.
Working in these positions allows better precision and
speed during operating phases as well as greater safety
for the operator.
8.2 Installation space
Fig. 4
USE THE MACHINE INDOORS OR IN A ROOFED
AREA. PLACE OF INSTALLATION MUST BE
DRY, ADEQUATELY LIT AND IN COMPLIANCE
WITH APPLICABLE SAFETY REGULATIONS.
The location of the machine requires a usable space
as indicated in Fig. 4. The positioning of the machine
must be according to the distances shown. From the
control position the operator is able to observe all the
machine and surrounding area. He must prevent unau-
thorized personnel or objects that could be dangerous
from entering the area.
The machine must be fixed on a flat floor surface,
preferably of cement or tiled. Avoid yielding or irregu-
lar surfaces.
The base floor must be able to support the loads trans-
mitted during operation.
This surface must have a strength of at least 500 kg/m².
The depth of the solid floor must be sufficient to guar-
antee that the anchoring bolts hold.
8.3 Lighting
The machine does not require its own lighting for
normal working operations. However, it must be used
in an adequately lit environment.
In case of poor lighting, use lamps having total power
800/1200 Watt as envisaged by UNI 10380.
9.0 MACHINE ASSEMBLY
After having freed the various components from the
packing check that they are complete, and that there
are no anomalies, then comply with the following in-
structions for the assembly of the components making
use of the attached series of illustrations.
9.1 Anchoring system
The packed machine is fixed to the support pallet
through the holes prearranged on the frame. Such
holes can be used also to fix the machine to the ground,
through floor anchor small blocks (excluded from sup-
ply). Before carrying out the definitive fixing, check that
all the anchor points are laid down flat and correctly
in contact with the fixing surface itself. If not so, insert
shimming profiles between the machine and the fixing
lower surface, as indicated in Fig. 5.
RAVAGLIOLI S.p.A.
7300-M018-2_R
G8945.26 - G8945IT.26 - G8945V.26 - G8945ITV.26 - G8945V.26S - G8945ITV.26S - G8945D.26 - G8945ITD.26 - G8945D.26S - G8945ITD.26S

INSTRUCTION, USE AND
MAINTENANCE MANUAL
GB Page 13 of 60
Fig. 5
a=762 mm
b=525 mm
c=410 mm
• Execute 4 holes with 8 mm diameter on the floor by
the holes on the bottom floor;
• insert the small blocks (excluded from supply) into
the holes;
• fix the machine to the ground with 4 M8x80 mm
screws (excluded from supply) (Fig. 5 ref. 1) (or
with 4 8x80 mm stud bolts (excluded from supply)).
Tighten the screws with an approximate tightening
torque of 70 Nm.
9.2 Fixtures contained in the packing
The packing case contains also the fixtures box. Check
that all the parts listed are there.
Code Description N.
203193 VTE M10x30 4
228012 M10 self-locking nut 4
203074 VTE M12x35 4
237025 Flat washer 12x25x2,5 8
228014 M12 self-locking nut 4
B4064201 Vane 1
140925901 Screw for bead-breaker arm 1
228006 M12 self-locking nut 1
237069 Flat washer 2
903090 Ball knob D. 40 1
253017 Belleville washer 1
730022630 Tank bracket 1
272019 TE M6x16 screw 4
228206 Crated nut M6 4
RAVAGLIOLI S.p.A.
7300-M018-2_R
G8945.26 - G8945IT.26 - G8945V.26 - G8945ITV.26 - G8945V.26S - G8945ITV.26S - G8945D.26 - G8945ITD.26 - G8945D.26S - G8945ITD.26S
9.3 Assembly procedures
Lifting device installation
Only for G8945V.26S - G8945ITV.26S -
G8945D.26S - G8945ITD.26S models)
1. After placing the tyre-changer in the working place
and after making sure it is insulated from its power
supply sources, proceed with the fastening of the
lifting device.
2. Remove the lateral carter (Fig. 6 ref. 1) by unscrew-
ing the relevant screws (Fig. 6 ref. 2).
1
2
2
2
2
Fig. 6
3. Place the lifting device that is assembled next to the
tyre-changer on which it will be installed.
4. Prepare and arrange near the screws and the ac-
cessories, which are necessary for fixing the lifting
device to the tyre-changer.
5. Fix the lifting device (Fig. 7 ref. 1) to the tyre changer
using the screws (Fig. 7 ref. 2) (# 203193) and the
nuts (Fig. 7 ref. 3) (# 228012) on issue.
Fig. 7

INSTRUCTION, USE AND
MAINTENANCE MANUAL GB
Page 14 of 60
6. Fix the pneumatic pipes (Fig. 8 ref. 1-2) coming from
the lifting device pedalboard to the lifting cylinder,
as shown in Fig. 8.
BEFORE CONNECTING THE PIPES
(FIG. 8 REF. 1-2), MAKE SURE
THEY PASS THROUGH THE RUB-
BER FAIRLEAD PLACED ON THE
MACHINE BASE AND THE LIFTING
DEVICE FRAME.
Fig. 8
Fig. 9
FASTEN THE PIPES AS SHOWN
IN FIG. 9 IN ORDER TO AVOID
THAT THEY INTERFERE WITH
THE BELT.
RAVAGLIOLI S.p.A.
7300-M018-2_R
G8945.26 - G8945IT.26 - G8945V.26 - G8945ITV.26 - G8945V.26S - G8945ITV.26S - G8945D.26 - G8945ITD.26 - G8945D.26S - G8945ITD.26S
Tubeless inflation tank installation
Only for G8945IT.26 - G8945ITV.26 -
G8945ITV.26S - G8945ITD.26 - G8945ITD.26S
models
7. Fix the bracket (Fig. 10 ref. 1) (# 730022630) with
the two screws (Fig. 10 ref. 2) (# 203193).
Fix the tank (Fig. 10 ref. 3) to the bracket (Fig.
10 ref. 1) using the 4 screws (Fig. 10 ref. 4) (#
272019) and the 4 crated nuts (Fig. 10 ref. 5) (#
228206) on issue.
1
2
3
4
45
Fig. 10
8. Connect the black pipe (Fig. 11 ref. 1) and the blue
pipe (Fig. 11 ref. 2) on the provided quick couplings
as shown in Fig. 11.
1
2
Fig. 11

INSTRUCTION, USE AND
MAINTENANCE MANUAL
GB Page 15 of 60
12. Connect the main pneumatic supply (Fig. 14
ref. 1) by linking connection on the machine filter
unit.
The pressurized pipe coming from the mains must
have a section of 10x19 (see Fig. 14).
Fig. 14
13. Reassemble the lateral carter (Fig. 6 ref. 1)
that was unscrewed before.
IF OTHER PNEUMATIC CONNEC-
TIONS SHOULD BE EXECUED,
REFER TO THE PNEUMATIC DIA-
GRAMS ILLUSTRATED IN CHAPT.
19.
RAVAGLIOLI S.p.A.
7300-M018-2_R
G8945.26 - G8945IT.26 - G8945V.26 - G8945ITV.26 - G8945V.26S - G8945ITV.26S - G8945D.26 - G8945ITD.26 - G8945D.26S - G8945ITD.26S
Installation of Plus device
Only for G8945V.26S - G8945ITV.26S -
G8945D.26S - G8945ITD.26S models
9. Mount the Plus device (Fig. 12 ref. 1) with the
screws (# 203074) (Fig. 12 ref. 2), the washers (#
237025) (Fig. 12 ref. 3) and the nuts (# 228014)
(Fig. 12 ref. 4) on issue.
1
2
2
3
3
3
4
4
Fig. 12
10. Connect the main pneumatic supply to Plus device.
Installation of tool box, pneumatic connection and
bead breaker vane
Valid for all the models
11. Mount the tool box (Fig. 13 ref. 1) using the
screws (# 203193) (Fig. 13 ref. 2) and the nuts
(# 228012) (Fig. 13 ref. 3).
Fig. 13

INSTRUCTION, USE AND
MAINTENANCE MANUAL GB
Page 16 of 60
14. Fix the vane (Fig. 15 ref. 2) onto the bead-breaking
arm using the accessories already in place on the
above-mentioned tool. The Belleville washer must
be positioned inside the tool tongue (see Fig. 15).
7
1
2
3
75
4
6
2
4
5
1
3
Fig. 15
KEY
1 – Bead breaker arm (# 730011591)
2 – Vane (# B4064201)
3 – Screw for bead breaker arm (# 140925901)
4 – M12 Self-locking nut (# 228006)
5 – Flat washer (# 237069)
6 – Ball knob D. 40 (# 903090)
7 – Belleville washer (# 253017)
ONCE THE ASSEMBLY OPERATIONS HAVE
BEEN ENDED, CHECK ALL MACHINE FUNC-
TIONS.
CARRY OUT A DAILY CHECK OF
MAINTAINED-TYPE CONTROLS
CORRECT FUNCTIONING, BEFORE
STARTING MACHINE OPERATION.
10.0 ELECTRICAL CONNECTION
EVEN THE TINIEST PROCEDURE
OF AN ELECTRICAL NATURE
MUST BE CARRIED OUT BY PRO-
FESSIONALLY QUALIFIED STAFF.
BEFORE CONNECTING THE MA-
CHINE MAKE SURE THAT:
• THE MAIN POWER RATING COR-
RESPONDS TO THE MACHINE
RATING AS SHOWN ON THE
MACHINE PLATE;
• ALL MAIN POWER COMPO-
NENTS ARE IN GOOD CONDI-
TION;
• THE ELECTRICAL SYSTEM
IS PROPERLY GROUNDED
(GROUND WIRE MUST BE THE
SAME CROSS-SECTION AREA
AS THE LARGEST POWER SUP-
PLY CABLES OR GREATER);
• MAKE SURE THAT THE ELEC-
TRICAL SYSTEM FEATURES A
CUTOUT WITH DIFFERENTIAL
PROTECTION SET AT 30 mA.
As envisaged by the regulations in force, the machine is
not equipped with a master circuit breaker, but simply
has a plug-socket connection to the electrical mains.
The machine is supplied with 3 m of free cable. A plug
corresponding to the following requirements must be
connected to the cable:
• Conformity to Norm IEC 309
• 230/400 Volt – 16A
• 3P + Ground
• IP 44
Only for versions with inverter
• Conformity to Norm IEC 309
• 220/240 Volt – 32A
• 2P + Ground
• IP 44
RAVAGLIOLI S.p.A.
7300-M018-2_R
G8945.26 - G8945IT.26 - G8945V.26 - G8945ITV.26 - G8945V.26S - G8945ITV.26S - G8945D.26 - G8945ITD.26 - G8945D.26S - G8945ITD.26S

INSTRUCTION, USE AND
MAINTENANCE MANUAL
GB Page 17 of 60 RAVAGLIOLI S.p.A.
7300-M018-2_R
G8945.26 - G8945IT.26 - G8945V.26 - G8945ITV.26 - G8945V.26S - G8945ITV.26S - G8945D.26 - G8945ITD.26 - G8945D.26S - G8945ITD.26S
11.0 CONTROLS
11.1 Plus device control unit (only for
G8945V.26S - G8945ITV.26S -
G8945D.26S - G8945ITD.26S models)
It is made up of an handle control (Fig. 16 ref. 1),
positioned on the device. This handle control allows
to operate the vertical translation of the pressor roll.
Lift the lever (Fig. 16 ref. 2) to operate the upwards
translation, and lower the lever (Fig. 16 ref. 2) to
perform the downwards translation.
The device positioning next to the tyre is a completely
manual operation.
1
2
Fig. 16
Only for 110V - 60Hz monophasic version
The machine is supplied with bipolar cable of 2 m,
CSA certified. A plug corresponding to the following
requirements must be connected to the cable:
• Conformity to Norm UL/CSA
• 110V - 60Hz – 32A
• 1P + N + Ground
• Protection degree IP 44 or equivalent
On delivery, the machines are preset to operate at a
three-phase voltage of 230/400 V - 50/60 Hz, with a
monophasic voltage of 220/240 V - 50/60 Hz (for the
versions with inverter) or with a monophasic voltage of
110V 60Hz (on demand for G8945V.26 - G8945ITV.26
- G8945V.26S - G8945ITV.26S models).
For any other type of power supply, ask the manufac-
turer at the time of purchase: a machine functioning
under the required voltage conditions will be prepared.
FIT A TYPE-APPROVED PLUG
TO THE MACHINE CABLE (THE
GROUND WIRE IS YELLOW/GREEN
AND MUST NEVER BE CONNECTED
TO ONE OF THE PHASE LEADS).
MAKE SURE THAT THE ELECTRI-
CAL SYSTEM IS COMPATIBLE
WITH THE RATED POWER AB-
SORPTION SPECIFIED IN THIS
MANUAL AND APT TO ENSURE
THAT VOLTAGE DROP UNDER
FULL LOAD WILL NOT EXCEED
4% OF RATED VOLTAGE (10%
UPON START-UP).
10.1 Direction of rotation of motor (versions
with three phase motor)
Once all power connections have been made, make
sure that the mandrel is rotating in the right direction
(pedal lowered, clockwise rotation). If the direction of
rotation is wrong, swap two phase wires in the plug.
FAILURE TO OBSERVE THE ABOVE
INSTRUCTIONS WILL IMMEDIATE-
LY INVALIDATE THE WARRANTY.

INSTRUCTION, USE AND
MAINTENANCE MANUAL GB
Page 18 of 60
11.2 Tool control unit
It is made up of:
It is made up of an handle control (Fig. 17 ref. 1),
positioned on the tool arm. Through this handle
control you can control the vertical translation for
the tool introduction and bead coupling. Lift the lever
(Fig. 17 ref. 2) to operate the upwards translation,
and lower the lever (Fig. 17 ref. 2) to perform the
downwards translation;
- a control with two push-buttons: press the button
(Fig. 17 ref. 3) to unlock the vertical translation and
to move upwards the tool arm, by pressing the push-
button (Fig. 17 ref. 4) you can unlock the horizontal
translation and move downwards the tool arm;
CONTROLS (FIG. 17 REF. 3-4) (IN
ORDER TO PREVENT THE WRONG
USE OF THE TYRE CHANGER)
ARE OPERATIVE ONLY IF THE
TOOL (FIG. 17 REF. 7) IS IN
COMPLETELY LIFTED POSITION.
OPERATE LEVER (FIG. 17 REF. 2),
BY SHIFTING IT UPWARDS, IN
ORDER TO MOVE THE TOOL TO
SUCH POSITION.
- a handle control (Fig. 17 ref. 5) through a thrust
and return movement, together with (Fig. 17 ref. 6)
unlocking push button, enables tools setting on wheel
diameter (only horizzontally).
Fig. 17
11.3 Bead-breaking arm control unit
It is made up of an handle control (Fig. 18 ref. 1),
positioned on the device. This handle control allows
to operate the vertical translation of the bead breaker
arm . Lift the lever (Fig. 18 ref. 2) to operate the up-
wards translation, and lower the lever (Fig. 18 ref. 2)
to perform the downwards translation.
Pull the rear lever (Fig. 18 ref. 3) to operate the bead-
ing roll progress. The present control is a maintained
operative control. When the lever is released the bead
roll returns to rest position.
The bead breaking arm is equipped with an unlock-
ing push button (Fig. 18 ref. 4) that must be pressed
before gripping the handle (Fig. 18 ref. 5) to place
the bead breaking roll on the rim edge. Releasing the
push button, the roll locks itself into the set position.
THE PUSH-BUTTON (Fig. 18 ref. 4)
MUST BE PRESSED BEFORE AC-
TIVATING THE HANDLE (Fig. 18
ref. 5)OTHERWISE THE HANDLE
DOES NOT ALLOW ANY MOVE-
MENT.
1
2
3
4
5
Fig. 18
RAVAGLIOLI S.p.A.
7300-M018-2_R
G8945.26 - G8945IT.26 - G8945V.26 - G8945ITV.26 - G8945V.26S - G8945ITV.26S - G8945D.26 - G8945ITD.26 - G8945D.26S - G8945ITD.26S

INSTRUCTION, USE AND
MAINTENANCE MANUAL
GB Page 19 of 60
Fig. 19
RAVAGLIOLI S.p.A.
7300-M018-2_R
G8945.26 - G8945IT.26 - G8945V.26 - G8945ITV.26 - G8945V.26S - G8945ITV.26S - G8945D.26 - G8945ITD.26 - G8945D.26S - G8945ITD.26S
11.4 Pedalboard
The pedal (Fig. 19 ref. 1) (only for G8945V.26S -
G8945ITV.26S - G8945D.26S - G8945ITD.26S models)
has a maintained control position and operates the
handling of the wheel lifting device.
Pulling the pedal downwards the lifting device starts its
rise while , on the contrary pulling the pedal upwards
the lifting device starts descending.
Releasing the pedal at any time will provoke the lifting
devices top.
The pedal (Fig. 19 ref. 2) operates the vertical trans-
lation of the tool arm (disengagement).
Pulling the pedal downwards the tool arm in working
position starts its descent. Press it again to obtain the
tool arm rise in disengagement position.
The pedal (Fig. 19 ref. 3) has two maintained control
operative positions. When it is pushed downwards it
controls mandrel motor clockwise rotary movement.
When the pedal is lifted upwards it operates the op-
posite movement.
The pedal (Fig. 19 ref. 4) has a maintained control
operative position. When pressed down, it operates
the bead breaker arm closing. Releasing the pedal, the
arm returns to rest position.
The inflation pedal (Fig. 19 ref. 5) has a different
function according to the version present on the ma-
chine.
Version with inflation with pressure gauge
The inflation pedal in this version has only one
function. A continuous pressure supplies air at a
controlled pressure (max 4.2 ± 0,2 bar 60 PSI).
Version with tubeless inflation
The inflation pedal has two functions. The supply of
air at a controlled pressure as in the previous version,
and a second function of a jet of air from the inflation
nozzle to assist the beading in of the tyre.
DO NOT CHANGE THE SET OP-
ERATING PRESSURE VALUE BY
MEANS OF THE MAXIMUM PRES-
SURE VALVES. THE MANUFAC-
TURER SHALL NOT BE RESPON-
SIBLE FOR INJURY OR DAMAGE
ARISING FROM UNAUTHORISED
CHANGES.

INSTRUCTION, USE AND
MAINTENANCE MANUAL GB
Page 20 of 60
12.0 USING THE MACHINE
12.1 Precaution measures during tyre re-
moval and fitting
Before fitting a tyre, observe the following safety rules:
• always use clean, dry and in good condition rims
and tyres; in particular, if necessary, clean the rims
after all the balancing weights (as well as the adhesive
weights on the inner side) have been removed, and
make sure that:
- neither the bead nor the tread of the tyre are dam-
aged.
- the rim does not produce dents and/or deformation
(especially for alloy rims, dents can cause internal
micro-fractures, that pass unobserved at visual
inspection, and can compromise the solidity of the
rim and constitute danger even during inflation);
• adequately lubricate the contact surface of rim and
tyre bead. Use specific tyre lubricants only.
• replace the inner tube valve with a new valve. If the
tyre tube has a metal valve, replace the grommet.
• make sure that the tyre is the right size for the rim.
Never fit a tyre unless you are sure it is the right size
(the rated size of the rim and tyre is usually printed
directly on each of them).
• do not use compressed air or water jets to clean the
wheels on the machine.
12.2 Preliminary operations - Preparing the
wheel
• Remove the wheel balancing weights from both sides
of the wheel.
REMOVE THE VALVE STEM AND
ALLOW THE TYRE TO COMPLETE-
LY DEFLATE.
• Establish from which side the tyre should be de-
mounted, checking the position of the groove.
• Find the rim locking point.
• Try to establish the special types of wheels, such as
“TD” and “AH”, in order to improve locking, bead
breaking, assembly and disassembly performances.
12.3 Bead breaking with side vane
After preparing the wheel as described in the previous
point, follow the instructions given below to carry out
the bead breaking procedure:
1. Position the wheel as indicated in Fig. 20 and move
the bead breaker tool toward the edge of the rim.
Fig. 20
2. Press the pedal (Fig. 19 ref. 4) and activate the
bead breaker tool to remove the bead. If the bead
does not detach the first time, repeat the operation,
on different points of the wheel, until it has come
away completely.
3. Reverse the position of the wheel and repeat the
operation on the other side.
4. Lubricate the tyre carefully along the entire circum-
ference of the bead on both sides.
FAILURE TO LUBRICATE MIGHT
CAUSE FRICTION BETWEEN THE
MOUNTING TOOL AND THE TYRE,
AND WOULD CAUSE DAMAGE TO
THE TYRE AND/OR THE BEAD.
