Ravaglioli RAV GTB-16N User manual

1
DO NOT USE THE MACHINE TO BREAK
THE BEAD OF AN INFLATED TIRE.
COMPLETELY DEFLATE THE TIRE FIRST!
PROPER LUBRICATION
OF BOTH BEADS IS CRITICAL.
USE BEAD SAVER ARM
TO REDUCE RISK OF BEAD DAMAGE.
E-Z Operaon
RAV GTB-16N Tubeless Truck Tire Changer
Always consider safety 1st!
• Wear protecve eyewear and clothing.
• Let the machine do the work.
This Machine is Not Designed for Use on Tube Type Tires
• This is a tubeless truck re changer.
Deate the re before aempng break-down procedure!
• Failure to adhere to this rule will result in damage to the machine.
Proper Lubricaon is Crical
• Lubricate the re beads thoroughly before aempng to re-mount.
• Lubricate both sides of both beads.
• Use a quality European type paste for best results. The machine was
shipped with the proper lubricant.
Use Included Alloy Adapters to Avoid Scratching the Back Side
• If you feel your customer is sensive to marring or scratching alloy
wheels use the G108A2 alloy adapters as a prevenve measure.
Use Bead Saver Arm to Reduce Risk of Bead Damage
• Use Bead Saver Arm on Wide Based and Super Duty.
• Use Bead Saver Arm anyme you fear bead damage may result.
Replaceable Plasc Protecon on Bead Saver Arm
• Make certain this plasc pad is in good shape. Replace when needed.
SUMMARY

2
E-Z Operaon
RAV GTB-16N Tubeless Truck Tire Changer
Switching On and O Tire Changer
• Turn on power to the machine using rotary switch.
• When machine is not being used the system is not running.
Operaons of the Control Box
Use Buons on Side for Chucking the Wheel
• Top buon opens the chucking unit.
• Boom buon closes the chucking unit.
Use Top Two Buons to Move Chucking Unit Up/Down
• Lower the unit to start re on the rim.
• Raise the unit all the way to the top to begin mount/
demount process.
Joy Sck at Lower Right Corner Moves Rear Roller Forward/
Backward
• Le to right movement is made by manual hand crank for
safety.
Adjust Rear Roller Le to Right With Hand Crank
• Prevents accidental posion change and resulng wheel/
machine damage.
Outside or front roller arm has inside, outside
In and out moon.
• Allows precise placement of front roller.

3
E-Z Operaon
RAV GTB-16N Tubeless Truck Tire Changer
Demount Instrucons
These steps apply to demounng virtually all re and wheel
combinaons.
I. Preparing to Break the Beads
• Posion wheel against chucking unit with demount side
facing operator.
• Make sure wheel drop center is facing away from the
machine.
• Chucking unit oers several posions for dierent size
wheels and thicknesses.
• Make sure wheel is ed on chucking unit properly.
• Clamp wheel and raise chucking unit all the way to top
unl it stops.
Raise Chucking Unit All the Way to the Top Before Starng
Mounng Demounng Process
• Lower the unit to start re on the rim.
• Raise the unit all the way to the top to begin mount/
demount process.
II. Breaking Outside Bead
Completely Deate the Tire Before Breakdown Procedure or
Damage to the Machine Will Occur!
• Using control box place front roller in proper posion against
the bead and about 1” away from the wheel.
• Rotate the chucking unit to the right (clockwise) and apply
lube to the outer bead...THIS IS CRITICAL.

4
E-Z Operaon
RAV GTB-16N Tubeless Truck Tire Changer
Demount Instrucons Cont.
These steps apply to demounng most re and wheel combinaons.
III. Demounng Outer Bead
• Extend BEAD SAVER arm all the way out and place it at the
12 o’clock posion on the wheel.
• Use re lever to bring outer re bead on top of bead saver
arm.
• With re lever in place rotate re wheel assembly to the
right. (clockwise)
Using Rear Roller to Push the Tire O
• Once outer re bead is removed, return bead saver arm to
its original posion.
• Push rear roller arm against re and keep pushing re unl
you can see the roller... about ½ inch past the front face of
the wheel.
• Rotate chucking unit to the le. (counter-clockwise)
• When dismounng wide-based res be sure and pull out on the front
bead with your hand at the 7 o’clock posion. This helps keep the re
from geng in a bind because of its extreme width.
NOTE POSITION OF
REAR ROLLER AS IT
PUSHES THE TIRE OFF
THE FRONT OF THE
WHEEL.
TIRE IS COMPLETELY
OFF THE WHEEL...NOTE
POSITION OF REAR
ROLLER IN RELATION TO
THE WHEEL.

5
E-Z Operaon
RAV GTB-16N Tubeless Truck Tire Changer
Mounng Instrucons
Alloy Wheels
Lubricate Properly
• Lube the outside of both beads as well as the inside of the
second bead of the re
• Lower clamping unit all the way down and place rst bead
over the rim edge
Raise Clamping Unit All the Way Up
• Tire should stay in place as you raise the clamping unit all the way up.
Inner Bead Mounng
• Push the re on by hand or use front roller to install the rst bead.
Outer Bead Mounng
• Install bead clamp at 6 o’clock.
• Rotate clamping assembly counter-clockwise just past 12
o’clock posion.
• Insert BeadSaver arm between wheel rim and re bead.
With re bar pull re bead on top of Beadsaver arm.
• Move front roller away from the re and then rotate
counter-clockwise unl bead clamp is past the front roller.
• Press re into drop center with front roller and rotate
counter clockwise to nish installing front bead.

6
E-Z Operaon
RAV GTB-16N Tubeless Truck Tire Changer
Mounng Instrucons
Steel Wheels
Lubricate Properly
• Lube the outside of both beads as well as the inside of the
second bead of the re
• Lower clamping unit all the way down and place rst bead
over the rim edge
Raise Clamping Unit All the Way Up
• Tire should stay in place as you raise the clamping unit all the way up.
Inner Bead Mounng
• Push the re on by hand or use front roller to install the rst bead.
Outer Bead Mounng
• Rotate clockwise and move outside roller in ll it is 2” past
rim edge to assist in keeping re in wheel drop center.
• Rotate clockwise while pushing against re with your hand
unl just past 12 o’clock posion.
• Insert BeadSaver Arm between wheel and re bead.
• Pull bead on top of beadsaver arm with re bar.
• Hook the rim edge with re bar below the roller and push
to keep tracon on rim edge.
• Rotate counter clockwise while keeping pressure on
re bar unl outer bead is installed.
•

7
E-Z Operaon
RAV GTB-16N Tubeless Truck Tire Changer
Tire Changer Rules
Do These Always
• Always adhere to company safety rules when operang this machine.
• Always wear eye protecon when operang this machine.
• Always lube every point of the re and wheel that drags on the bead.
• Always let air completely out of re before breaking the bead.
• Always make sure drop center is facing out.
• Always use the Beadsaver Arm when installing a re.
• Always make sure the wheel is clamped rmly with vercal contact on
both sides.
• Always report any bead damage that occurs during the mount or
demount process to your management. This is a denite safety concern.
Never Do These
• Never dismount a re without lubricang rst Never force a re unl it
rips the bead. Never put your ngers between the bead and a roller.
• Never use the Beadsaver Arm without the plasc protecon.
• Never break the bead unl the re is completely deated.
• Never change 10:00-20 on this machine.
• Never change anything other than tubeless over the road truck res on
this machine.
You Must Do This
Machine Prevenve Maintenance
• Your manual includes step by step prevenve maintenance that must be
done weekly and monthly in order to minimize downme and maximize
machine performance and longevity.
BeadSaver Arm Plasc Protecon
• The plasc protecve pad on the end of the BeadSaver Arm is your best
friend and must be replaced when worn. These can be ordered in any
quanty you wish from RAVAmerica.
RavAmerica
800-816-8138 G108A9 BeadSaver Plasc Protecon
