USE AND MAINTENANCE MANUAL
Flexi 7
Flexi 9

INFORMATION ON SOLID FUEL HEATING APPLIANCES
According to Regulation (EU) No. 1185/2015
EN
Fuel type Preferred fuel
(only one):
Other
suitable
fuel(s):
ηs
[x%]
Space heating emissions at
nominal heat output(*)
Space heating emissions at
minimum heat output (*) (**)
PM
OGC
CO
NOx
PM
OGC
CO
NOx
[x] mg/Nm3 at 13%O
2
[x] mg/Nm3 at 13%O
2
Wood logs with moisture
content
≤25 % no no
Compressed wood with
moisture
content < 12 % yes no
91,8
15
3
76
96
15
3
221
129
Characteristics when operating with the preferred fuel only
Item
Symbol
Value
Unit
Type of heat output/room temperature control (select one)
Heat output
single stage heat output, no room temperature control
No
Nominal heat output
P
nom
7,1
kW
two or more manual stages, no room temperature control
No
Minimum heat output (indicative)
P
nom
3,3
kW
with mechanic thermostat room temperature control
No
Useful efficiency (NCV as received)
with electronic room temperature control
No
Useful efficiency at nominal heat output
η
th,nom
94,4
%
with electronic room temperature control plus day timer
No
Useful efficiency at minimum heat output (indicative)
η
th,min
95,5
%
with electronic room temperature control plus week timer
Yes
Auxiliary electricity consumption
Other control options (multiple selections possible)
At nominal heat output
el
max
0,035
kW
room temperature control, with open window detection
No
At minimum heat output
el
min
0,010
kW
room temperature control, with presence detection
No
In standby mode
el
SB
0,002
kW
with distance control option
Yes
(*) PM = particulate matter, OGCs = organic gaseous compounds, CO = carbon monoxide, NOx = nitrogen oxides
(**) Only required if correction factors F(2) or F(3) are applied.
Manufacturer
Aico
Aico
Model identifier(s)
Flexi 7
Flexi 7
Brand
Ravelli
Ravelli
Indirect heating functionality
No
No kW
Direct heat output
7,1 kW
12 kW
Indirect heat output
-- kW

INFORMATION ON SOLID FUEL HEATING APPLIANCES
According to Regulation (EU) No. 1185/2015
EN
Fuel type Preferred fuel
(only one):
Other
suitable
fuel(s):
ηs
[x%]
Space heating emissions at
nominal heat output(*)
Space heating emissions at
minimum heat output (*) (**)
PM
OGC
CO
NOx
PM
OGC
CO
NOx
[x] mg/Nm3 at 13%O
2
[x] mg/Nm3 at 13%O
2
Wood logs with moisture
content
≤25 % no no
Compressed wood with
moisture
content < 12 % yes no
91,0
14
3
60
95
15
3
221
129
Characteristics when operating with the preferred fuel only
Item
Symbol
Value
Unit
Type of heat output/room temperature control (select one)
Heat output
single stage heat output, no room temperature control
No
Nominal heat output
P
nom
8,3
kW
two or more manual stages, no room temperature control
No
Minimum heat output (indicative)
P
nom
3,3
kW
with mechanic thermostat room temperature control
No
Useful efficiency (NCV as received)
with electronic room temperature control
No
Useful efficiency at nominal heat output
η
th,nom
93,5
%
with electronic room temperature control plus day timer
No
Useful efficiency at minimum heat output (indicative)
η
th,min
95,5
%
with electronic room temperature control plus week timer
Yes
Auxiliary electricity consumption
Other control options (multiple selections possible)
At nominal heat output
el
max
0,035
kW
room temperature control, with open window detection
No
At minimum heat output
el
min
0,010
kW
room temperature control, with presence detection
No
In standby mode
el
SB
0,002
kW
with distance control option
Yes
(*) PM = particulate matter, OGCs = organic gaseous compounds, CO = carbon monoxide, NOx = nitrogen oxides
(**) Only required if correction factors F(2) or F(3) are applied.
Manufacturer
Aico
Aico
Model identifier(s)
Flexi 9 Decò
Flexi 9 Decò
Brand
Ravelli
Ravelli
Indirect heating functionality
No
No kW
Direct heat output
8,3 kW
12 kW
Indirect heat output
-- kW
Decò, Glass, Steel

Preface
Dear Customer, We would like to thank you for choosing one of our stoves.
We invite you to read this manual carefully, before starting installation and use, so that you are able to benefit from all of its characteris-
tics better and in full safety. It contains all necessary information for correct installation, start-up, operation, cleaning, maintenance, etc.
Keep this manual in a suitable location, do not discard it without reading it.
Incorrect installation, maintenance and improper use of the product relieve the Manufacturer of all liability deriving from use of the stove.
For further information and requirements contact your Ravelli-authorised Technical Assistance Centre.
All rights reserved. No part of this instructions manual can be reproduced or transmitted through any electronic or mechanical means, in-
cluding photocopies, recordings or any other storage system, for other purposes that are not exclusively use by the buyer’s staff, without
the express written consent of the Manufacturer.

Use and maintenance manual Flexi 7 - Flexi 9
Pag.6
Rev.0 01/03/2023
EN
INDEX
Preface........................................................................................................................................................................ 5
IDENTIFICATION .........................................................................................................................8
Stove identication ................................................................................................................................................... 8
Manufacturer identication ...................................................................................................................................... 8
Reference standards................................................................................................................................................. 8
Remote control: Synthetic Declaration of Conformity (DoC)................................................................................ 8
Label ........................................................................................................................................................................... 9
WARRANTY ................................................................................................................................10
Certicate of warranty............................................................................................................................................. 10
Warranty conditions................................................................................................................................................ 10
Registration of warranty ......................................................................................................................................... 10
Info and problems ................................................................................................................................................... 10
GENERAL INFORMATION .........................................................................................................11
Supply and safe-keeping ....................................................................................................................................... 11
Language ................................................................................................................................................................. 11
Symbols used in the manual ................................................................................................................................. 11
SAFETY MEASURES .................................................................................................................11
General safety warnings ........................................................................................................................................ 11
Residual risks ......................................................................................................................................................... 12
DESCRIPTION OF THE APPLIANCE .........................................................................................13
Intended use ........................................................................................................................................................... 13
Reasonably foreseeable incorrect use ................................................................................................................. 13
Obligations and forbidden actions ....................................................................................................................... 14
Characteristics of the fuel ..................................................................................................................................... 15
TECHNICAL CHARACTERISTICS ............................................................................................16
Technical Data ......................................................................................................................................................... 16
Minimum clearances from combustible materials ............................................................................................... 17
Measurements ......................................................................................................................................................... 17
Technical diagram Flexi 7....................................................................................................................................... 17
Technical diagram Flexi 9....................................................................................................................................... 18
Main parts ................................................................................................................................................................ 19
Description of operation......................................................................................................................................... 19
Automatic cleaning system.................................................................................................................................... 19
Recharge the fuel .................................................................................................................................................... 20
Doors opening ......................................................................................................................................................... 20
User training ............................................................................................................................................................ 20
Safety devices.......................................................................................................................................................... 21
The Majolica cladding (if applicable)..................................................................................................................... 22
SHIPPING AND INSTALLATION ...............................................................................................23
Safety warnings for transportation and installation ........................................................................................... 23
Set-ups for the smoke evacuation system ........................................................................................................... 24
Installation ............................................................................................................................................................... 25
CONNECTIONS ..........................................................................................................................28
Connection with external air intake....................................................................................................................... 28
Chimney connection .............................................................................................................................................. 28
Electrical connection .............................................................................................................................................. 28
Ducting ..................................................................................................................................................................... 29
Connection of external probe or thermostat ....................................................................................................... 29
Testing and commissioning .................................................................................................................................. 29
Electric scheme Flexi 7........................................................................................................................................... 30
Electric scheme Flexi 9........................................................................................................................................... 31

Use and maintenance manual Flexi 7 - Flexi 9
Pag.7
Rev.0 01/03/2023 EN
CONTROLS AND USE.................................................................................................................32
Control panel description....................................................................................................................................... 32
Radio touch remote control initialization ............................................................................................................. 32
Description of the radio touch remote control ..................................................................................................... 33
Description of the display ...................................................................................................................................... 33
Time and date setting ............................................................................................................................................. 34
PROCEDURES FOR USE ...........................................................................................................35
Checks prior to start-up ......................................................................................................................................... 35
Auger loading .......................................................................................................................................................... 35
Switching the appliance on and o ....................................................................................................................... 35
Failed ignition ......................................................................................................................................................... 36
Setting operating temperature and power: .......................................................................................................... 36
OPERATING PHASES OF THE APPLIANCE..............................................................................36
Sequence of ignition phases .......................................................................................................................... 36
Modulation ............................................................................................................................................................... 36
Description of menu functions .............................................................................................................................. 36
Setting ...................................................................................................................................................................... 39
Ventilation menu...................................................................................................................................................... 41
Single ducting ......................................................................................................................................................... 41
Stove phase general layout.................................................................................................................................... 44
Warning Pop -Up ..................................................................................................................................................... 45
Alarms (table with reference codes)...................................................................................................................... 45
INSTALLATION QUICK GUIDE RAVELLI SMART WI-FI...........................................................48
Connect the WiFi module cable ............................................................................................................................. 48
App............................................................................................................................................................................ 48
Connection to the WiFi module.............................................................................................................................. 48
Account registration ............................................................................................................................................... 50
MAINTENANCE ..........................................................................................................................52
Safety warnings for maintenance .......................................................................................................................... 52
Cleaning .................................................................................................................................................................. 52
Extraordinary maintenance .................................................................................................................................... 53
TROUBLESHOOTING .................................................................................................................56
The appliance does not work ................................................................................................................................. 56
Dicult lighting ....................................................................................................................................................... 56
Smoke leakage......................................................................................................................................................... 56
The glass gets dirty easily...................................................................................................................................... 56
Downtime (end of season) ..................................................................................................................................... 56
DISPOSAL AT END OF SERVICE LIFE ......................................................................................56
Warnings for the correct disposal of the product................................................................................................ 56

Use and maintenance manual Flexi 7 - Flexi 9
Pag.8
Rev.0 01/03/2023
EN
IDENTIFICATION
Stove identication
Type of product PELLET STOVE
Trademark Ravelli
Model Flexi 7 - Flexi 9 Déco - Flexi 9 Glass - Flexi 9 Steel
Manufacturer identication
Manufacturer Aico S.p.A.
Via Consorzio Agrario, 3/D - 25032
Chiari (BS) - Italy
T. + 39 030 7402939
[email protected]
www.ravelligroup.it
Reference standards
The Flexi 7 - Flexi 9 stoves that this manual refers to are compliant with the regulation:
305/2011, CONSTRUCTION PRODUCT REGULATION
and the following directives
2014/53/EU (RED)
2011/65/EU 2015/863/EU, 2017/2102/EU, (RoHS)
2009/125/EC (Ecodesign)
And the following harmonised standards and/or technical specications have been applied:
EN 14785; EN 55014-1; EN 55014-2; EN 61000-3-2; EN 61000-3-3; EN 60335-1; EN 60335-2-102; EN 62233; EN 50581; ETSI
EN 300220-1
All local regulations, including those referring to national and European standards, must be respected when installing the appliance.
Remote control: Synthetic Declaration of Conformity (DoC)
The manufacturer Aico S.p.A. declares that the Remote Control, with the Ravelli brand and model PNET00003 (Palm Touch) is in
conformity with the relevant Union harmonisation legislation: 2014/53/EU (RED), and that the following harmonised standards and/
or technical specications have been applied: ETSI EN 301 489-3, ETSI EN 301 489-1, EN 60950-1 A11+A1+A12+AC+A2, EN
62479.
These declarations can be found in full format on the website www.ravelligroup.it.

Use and maintenance manual Flexi 7 - Flexi 9
Pag.9
Rev.0 01/03/2023 EN
Label
The following symbols are used on the label:
PIN,nom Heat input power (max) PIN,part Heat input power (min)
Pnom Nominal power Ppart Reduced power
PWnom Nominal water heat output PWpart Reduced water heat
output
PSnom Nominal air heat output PSpart Reduced air heat output
COnom CO at nominal power COpart CO at reduced power
ηnom Efficiency at nominal
power
ηpart Efficiency at reduced
power
pnom Minimum draught at
nominal power
Tnom Flue gas temperature at
nominal power
WElectrical consumption
TW,max Maximum water
temperature
TW,max-set Maximum adjustable
water temperature
pWnom Max working pressure 230 V -
50 Hz
Alimentation
Distance to combustible materials
dS-L Left side dCCeiling
dS-R Right side dFFront
dRRear dBFloor
n.d.: undeclared data
Usare solo il combustibile raccomandato:
Use only reccomended fuel:
Utilizer seulement les combustibles recomandés:
Use solo el combustible recomandado:
Gebruik alleen de aanbevolen brandstof:
Nur empfohlenes Brennmaterial verwenden:
50 Hz
Pellet di legno
7,5 kW 3,4 kW
7,1 kW 3,3 kW
0,018 %0,006 %
95,5 %94,4 %
112 °C
8 Pa 0,08 mbar
320 W
230 V
APPARECCHIO PER IL RISCALDAMENTO DOMESTICO ALIMENTATO A PELLET DI LEGNO
RESIDENTIAL SPACE HEATING APPLIANCE FIRED BY WOOD PELLETS
APPAREIL DE CHAUFFAGE DOMESTIQUE À CONVECTION À GRANULES DE BOIS
APARATO DE CALEFACCION DOMESTICA ALIMENTADO CON PELLETS DE MADERA
HUISHOUDELIJKE RUIMTEVERWARMINGSTOESTELLEN GESTOOKT MET GEPERST HOUT
RAUMHEIZER ZUR VERFEUERUNG VON HOLZPELLETS
Model: FLEXI 7
P
IN,nom
P
IN,part
P
nom
P
part
CO
nom(13%O2)
CO
part(13%O2)
η
nom
η
part
p
nom
T
nom
W
Wood pellet
Granulee de bois
Pellet de madera
Houtpellet
Holzpellets
Ø 6 mm
Leggere le istruzioni d’uso
/ Read and follow the operating manual / Lire et suivre le mode d’emploi / Lea
y respete le manual de operacion / Lees en volg de handleiding voor bediening / Bitte lesen und befolgen
Sie die Montage und Nutzungsanweisungen
Distanza minima da materiali infiammabili
Minimum distance from flammable materials
Distance moindre de matériels inflammables
Distancia minima de materiales inflamables
Minimale afstand van brandbare materialen
Mindestabstand zu brennbaren Materialien
200 mm
200 mm
200 mm
d
S-L
d
S-R
d
R
800 mm
d
C
1000 mm
d
F
0 mm
d
B
D.o.P. n° 317CPR13.07 (Notified Body 0476)
EN 14785:2006
TYP FC62X
Anno di produzione: 2023
AICO S.p.A. - Via Consorzio Agrario, 3/D - 25032 Chiari (BS) - Italy 23
3YR-P-066
C399Q4001
Usare solo il combustibile raccomandato:
Use only reccomended fuel:
Utilizer seulement les combustibles recomandés:
Use solo el combustible recomandado:
Gebruik alleen de aanbevolen brandstof:
Nur empfohlenes Brennmaterial verwenden:
50 Hz
Pellet di legno
8,9 kW 3,4 kW
8,3 kW 3,3 kW
0,018 %0,005 %
95,5 %93,5 %
125 °C
9 Pa 0,09 mbar
320 W
230 V
APPARECCHIO PER IL RISCALDAMENTO DOMESTICO ALIMENTATO A PELLET DI LEGNO
RESIDENTIAL SPACE HEATING APPLIANCE FIRED BY WOOD PELLETS
APPAREIL DE CHAUFFAGE DOMESTIQUE À CONVECTION À GRANULES DE BOIS
APARATO DE CALEFACCION DOMESTICA ALIMENTADO CON PELLETS DE MADERA
HUISHOUDELIJKE RUIMTEVERWARMINGSTOESTELLEN GESTOOKT MET GEPERST HOUT
RAUMHEIZER ZUR VERFEUERUNG VON HOLZPELLETS
Model: Flexi 9 Déco
P
IN,nom
P
IN,part
P
nom
P
part
CO
nom(13%O2)
CO
part(13%O2)
η
nom
η
part
p
nom
T
nom
W
Wood pellet
Granulee de bois
Pellet de madera
Houtpellet
Holzpellets
Ø 6 mm
Leggere le istruzioni d’uso
/ Read and follow the operating manual / Lire et suivre le mode d’emploi / Lea
y respete le manual de operacion / Lees en volg de handleiding voor bediening / Bitte lesen und befolgen
Sie die Montage und Nutzungsanweisungen
Distanza minima da materiali infiammabili
Minimum distance from flammable materials
Distance moindre de matériels inflammables
Distancia minima de materiales inflamables
Minimale afstand van brandbare materialen
Mindestabstand zu brennbaren Materialien
200 mm
200 mm
200 mm
d
S-L
d
S-R
d
R
800 mm
d
C
1000 mm
d
F
0 mm
d
B
D.o.P. n° 318CPR13.07 (Notified Body 0476)
EN 14785:2006
TYP FC62X
Anno di produzione: 2023
AICO S.p.A. - Via Consorzio Agrario, 3/D - 25032 Chiari (BS) - Italy 23
3YR-P-067
C399Q5001

Use and maintenance manual Flexi 7 - Flexi 9
Pag.10
Rev.0 01/03/2023
EN
WARRANTY
Certicate of warranty
Ravelli thanks you for the trust granted with the purchase of one of its products and invites the purchaser to:
• read the installation, use and maintenance instructions for the product;
• read the warranty conditions contained below.
Warranty conditions
The warranty for the Customer is acknowledged by the Dealer under the terms of law.
The Dealer acknowledges the warranty only if the product has not been tampered with and only if it has been installed in accordance with
the Manufacturer’s instructions.
The limited warranty covers manufacturing material defects, as long as the product has not broken sue to an incorrect use, negligence,
incorrect connection, tampering, installation errors.
The warranty becomes null and void even if only one requirement in this manual is not complied with.
The following are not covered by warranty:
• the combustion chamber refractory stones;
• the door glass;
• the gaskets;
• the paint job;
• the stainless steel or cast iron combustion grille;
• the resistance;
• the Majolica cladding;
• the aesthetic parts;
• any damages caused by unsuitable installation and/or use of the product and/or shortcomings on the part of the customer.
The use of poor quality pellet or any other unauthorised fuel may damage the product’s components, cause its warranty to be voided and
as a result eliminate the connected manufacturer liability.
It is therefore recommended to use good quality pellet that fulfils the requirements listed in the dedicated chapter.
All damages caused by transportation are not recognised, for this reason it is recommended to carefully check goods upon receipt,
immediately warning the reseller of any damage.
Registration of warranty
To activate the warranty, it is necessary to register the product on the Guarantee Portal on the website
www.ravelligroup.it, by entering your data and the purchase receipt.
Info and problems
Dealers authorised by Ravelli use a trained Technical Service Centre network to meet the Customer’s requirements. For any information
or request for assistance, please contact your Dealer or the Technical Service Centre.

Use and maintenance manual Flexi 7 - Flexi 9
Pag.11
Rev.0 01/03/2023 EN
GENERAL INFORMATION
Supply and safe-keeping
The manual is supplied in printed format.
Keep this manual safe, with the appliance, so that the user can consult it easily.
The manual is an integral part, for safety reasons, therefore:
• it must be kept intact (in full). If it gets lost or ruined it is necessary to immediately ask for a new copy:
• it must be kept with the appliance until demolition (including relocation, sale, rental, lease, etc....).
The Manufacturer will not be held liable for improper use of the appliance and/or damage caused by operations that are not set forth
in the technical documentation.
Language
The original manual was written in Italian.
Any translations into additional languages must be carried out based on the original instructions.
The Manufacturer is liable for the information contained in the original instructions; the translations into di󰀨erent languages cannot be
fully veried therefore if any inconsistency arises it will be necessary to follow the text in the original language or contact our Technical
Documentation O󰀩ce.
Symbols used in the manual
symbol denition
📌This symbol is used to identify particularly important information in the manual. This information also concerns the
safety of users involved in using the appliance.
⚠
This symbol is used to identify important warnings for the safety of the user and/or the appliance.
SAFETY MEASURES
General safety warnings
📌Read this instructions manual carefully before appliance
installation and use. Failure to observe the instructions set
forth herein can void the warranty and/or cause damage to
property and/or people.
⚠ Appliance installation, system verification, operation verification
and initial calibration must be carried out exclusively by qualified
and authorised staff.
⚠ The appliance needs to be connected to a single chimney
that guarantees the draught declared by the Manufacturer
and observes the installation regulations that apply to the
installation site.
⚠ The room where the appliance is installed must have an air
intake.
⚠ The appliance must not be used as an incinerator or differently
from its purpose

Use and maintenance manual Flexi 7 - Flexi 9
Pag.12
Rev.0 01/03/2023
EN
⚠ Do not use any fuel other than fire pellet. It is strictly forbidden
to use liquid fuels.
⚠ It is prohibited to use the appliance with the door or ash drawer
open or the glass broken.
⚠ Do not touch the hot surfaces of the appliance without suitable
protective equipment, to avoid getting burned. When it is
running, the outer surfaces reach hot temperatures to the
touch.
⚠ It is forbidden to make unauthorised changes to the appliance.
⚠ Before using the appliance it is necessary to know the position
and function of the controls.
⚠ If the chimney catches fire you must call the fire brigade.
⚠ Only use original spare parts. Any tampering and/or
replacements that have not been authorised by Ravelli can
pose a danger to the user’s safety.
⚠ In the event of particularly adverse weather conditions, the
safety systems could intervene and switch off the appliance.
In any case, doe not disable the safety systems.
Residual risks
The appliance was designed so as to guarantee the user’s essen-
tial safety requirements.
Safety was integrated into the appliance’s design and construction
as much as possible.
For every residual risk there is a description of the risk and the
zone or part that is applies to (unless the risk applies to the entire
appliance overall). Procedure-related information is also provided
on how to avoid the risk and on the correct use of the personal pro-
tective equipment required by and made compulsory by the Man-
ufacturer.

Use and maintenance manual Flexi 7 - Flexi 9
Pag.13
Rev.0 01/03/2023 EN
Residual
risk
Description procedure-related information
Risk of
burns
When the appliance is running, it may reach high
temperatures to the touch, especially on its external
surfaces. Take care to avoid burns and use the specic
tools if necessary.
Use the supplied glove to open pellet cover for loading
operations.
DESCRIPTION OF THE APPLIANCE
Intended use
The appliance in question is intended for:
Operation Allowed fuel Forbidden Setting
Domestic space
heating by
burning:
Pellet Any fuel other
than the
permitted ones.
Residential
or
Commercial
The appliance is designed and built to work safely if:
• it is installed by qualied sta󰀨 according to the specic standards;
• it is used within the limits declared in the contract and herein;
• the operating manual procedures are followed;
• routine maintenance is carried out according to the times and
methods set forth;
• extraordinary maintenance is promptly carried out when needed;
• safety devices are not removed and/or bypassed.
📌This appliance must be intended for the use it was specifically
designed for.
Reasonably foreseeable incorrect use
Reasonably foreseeable incorrect use is listed below:
• using the appliance as an incinerator;
• using the appliance with fuel other than pellet;
• using the appliance with liquid fuels;
• using the appliance with the door open and the ash drawer out.
Any use of the appliance other than intended must be preventively
authorised in writing by the Manufacturer. Without said written
authorisation, the use is considered “improper”. Any contractual
and non-contractual liability of the manufacturer is excluded for
damages to persons, animals or property due to installation and
maintenance adjustment errors and improper use.

Use and maintenance manual Flexi 7 - Flexi 9
Pag.14
Rev.0 01/03/2023
EN
Obligations and forbidden actions
Obligations
The user must:
• read this instructions manual before performing any operation
on the appliance;
• the appliance must not be used by children under the age of 8 or
by people with reduced physical, sensorial or mental capacities
or without experience or without the necessary knowledge, and
always with supervision;
• do not use the appliance improperly, i.e. for uses other than those
described in the “INTENDED USE” paragraph;
• it is strictly forbidden to use liquid fuels;
• keep objects that are not heat and/or ame-resistant at a safe
distance;
• only and exclusively load the appliance with pellet with the
characteristics described herein;
• connect the appliance to a regulation chimney;
• provide a suitable system for the supply of combustion air (air
intake or intake duct for watertight appliances);
• always perform maintenance with the appliance o󰀨 and cold;
• perform cleaning activities at the frequency stated herein;
• use original parts recommended by the Manufacturer.
Forbidden actions
The user must never:
• remove or change the safety devices without authorisation;
• perform operations or manoeuvres of his/her own initiative that
are not part of his/her job description, meaning that he/she might
jeopardise his/her own safety and that of others;
• use fuels other than pellet and those allowed for lighting;
• use the appliance as an incinerator;
• use ammable or explosive substances near the appliance
during operation;
• use the appliance with the door open and/or with the glass ruined
or broken;
• close the combustion air and smoke outlet openings, whatsoever;
• use the appliance to dry laundry;
• replace or change some of the appliance parts.

Use and maintenance manual Flexi 7 - Flexi 9
Pag.15
Rev.0 01/03/2023 EN
Characteristics of the fuel
Wood pellet is a fuel made of pressed wood sawdust, often recovered from processing scraps of carpentries. The material used
cannot contain any extraneous substance such as, for example, glue, lacquer or synthetic substances.
The sawdust, once it has been dried and cleaned from impurities, is pressed using a die with holes: as a result of high pressure, the
sawdust heats up by activating the natural wood binders; this way the pellet maintains its shape even without adding articial
substances.
Wood pellet density varies based on the type of wood and can exceed that of natural wood by 1.5 - 2 times.
The cylinders have a diameter of 6 mm and a variable length between 10 and 40 mm.
Their density is equal to approximately 650 kg/m3. Due to their low water content (< 10%) they have a high energy content.
The UNI EN ISO 17225-2:2014 standard (that replaces the EN PLUS standard) denes pellet quality by specifying three classes: A1,
A2 and B. Maintain fuels and other ammables at a suitable distance.
Ravelli recommends using wood pellet classied A1 and A2 according to the EN ISO 17225-2:2014 standard, or certied DIN PLUS
(more restrictive than the A1 class) or ONORM M 7135. Pellet may be light or dark coloured, it is normally bagged into bags that show
the name of the producer, the main characteristics and classication according to standards.
📌Only use certified pellets. Poor-quality pellets can increase the rate at which dirt builds up on the glass and increase
maintenance work.
📌Using fuel that is not compliant with the above will void the warranty.

Use and maintenance manual Flexi 7 - Flexi 9
Pag.16
Rev.0 01/03/2023
EN
TECHNICAL CHARACTERISTICS
Technical Data
Units of
measurement Flexi 7 Flexi 9
Energy efficiency class - - A++ A++
Heating input reduced - nominal kW 3,4 - 7,5 3,4 - 8,9
Heating output reduced - nominal kW 3,3 - 7,1 3,3 - 8,3
Red. - Nom. Yield % 95,5 - 94,4 95,5 - 93,5
Hourly consumption kg/h 0,71 - 1,56 0,71 - 1,83
Loading interval h 11 - 24 9 - 24
Heating volume* m3 125 - 200 150 - 235
CO at 13% of O2
% 0,018 - 0,006 0,018 - 0,005
mg/m3 221 - 76 221 - 60
OGC at 13% of O2mg/m3 3 - 3 3 - 3
NOXat 13% of O2mg/m3 129 - 96 129 - 95
PM at 13% of O2mg/m3 15,0 - 15,0 15,0 - 14,0
Smoke temperature °C 73 - 112 73 - 125
Smoke ow g/s 3,0 - 3,7 3,0 - 4,4
Minimum draft Pa - mbar
8 - 10
0,08 - 0,1
9 - 10
0,09 - 0,1
Electrical connection Hz - V 50- 230 50- 230
Electrical power consumption max. W 320 320
Electrical power consumption reduced - nominal W 10 - 35 10 - 35
Stand-by electrical consumption W 1,6 1,6
smoke air inlet Ø mm 50 50
smoke outlet pipe Ø mm 80 80
Hopper capacity kg 17 17
Seasonal energy e󰀩ciency % 91,8 91,0
Type of room temperature control with electronic room temperature control plus week timer
Other control options with distance control option
The data shown here is provided as a guideline and is not binding, and may change based on what type and quality of wood is used.
Ravelli reserves the right to make any changes in order to improve product performance.
* Heatable volume based on the requested power equal to 35 W/m³ and 55 W/m³

Use and maintenance manual Flexi 7 - Flexi 9
Pag.17
Rev.0 01/03/2023 EN
Minimum clearances from combustible materials
Units of
measurement Flexi 7 Flexi 9
R Right side mm 200 200
L Left side mm 200 200
B Rear mm 200 200
A Front mm 1000 1000
Measurements
Unit of
measurement Flexi 7 Flexi 9 Déco Flexi 9 Glass Flexi 9 Steel
Height mm 1050 1050 1050 1050
Width mm 530 530 530 530
Depth mm 574 574 574 574
Weight kg 190 200 190 190
Technical diagram Flexi 7
530
1050
530
574
574
395
50 AIR INLET
130
192
80 SMOKE OUTLET
L
AR B

Use and maintenance manual Flexi 7 - Flexi 9
Pag.18
Rev.0 01/03/2023
EN
Technical diagram Flexi 9
530
1050
530
574
574
80 CANALIZATION
395
50 AIR INLET
130
80 SMOKE OUTLET
192
305
72,5

Use and maintenance manual Flexi 7 - Flexi 9
Pag.19
Rev.0 01/03/2023 EN
Main parts
A Grid for air passage
B Combustion chamber door
C Ashes drawer
D Pellet cover
E Control panel
F Combustion chamber
G Grid for ashes
H Slide for ashes
I Reset thermostat
L Air passage gap
Description of operation
Ravelli pellet stoves of the Flexi 7 and Flexi 9 family are home heating appliances powered by wood pellets with automatic loading. They
are suitable for use as a secondary heating system or as a support for the main heating system.
The heat generated by pellet combustion is diffused in the installation room by radiation and natural convection. It is possible to choose
whether to activate the front fan or keep the stove in operation by natural convection. In addition, in the Flexi 9 versions it is possible to
activate the ducting to heat another room, subject to activation by the installer.
The stove is controlled by an electronic control unit that manages the start-up, operation and shutdown phases and also includes many
other functions for control, programming and safety.
The user can choose the operating power from 5 levels, or set the temperature to be maintained in the room. In this case the stove will
manage the power to ensure maximum comfort. Among the functions of the electronic control unit there is also that of being able to pro-
gram the start-up and shutdown of the stove, setting the weekly chronothermostat.
All this can be done comfortably from the sofa using the handheld remote control.
Ravelli’s patented cleaning system minimises maintenance by the user. There is no longer any need to clean the brazier before each
lighting and all maintenance operations.
This stove has been designed for hermetic installations, so it can be installed in the traditional way, or by taking air directly from outside.
Automatic cleaning system
The stove is equipped with atuomatic brazier cleaning system. This means that there is no need to carry out daily manual cleaning of the
brazier or every time the stove is lit. The automatic cleaning system is activated every time the stove is lit and after 6 hours of continuous
operation. The cleaning cycle, which involves shutting down, automatic cleaning and restarting the stove, takes about 10 minutes. During
this period the heating is guaranteed by the heat accumulated by the appliance itself.
Note: the times indicated are those set by default by the Manufacturer.
C
A
A A
B B
C C
D D
E E
F F
G G
H H
J J
K K
L L
M M
N N
P P
R R
T T
24
24
23
23
22
22
21
21
20
20
19
19
18
18
17
17
16
16
15
15
14
14
13
13
12
12
11
11
10
10
9
9
8
8
7
7
6
6
5
5
4
4
3
3
2
2
1
1
DISEG.
VERIF.
APPR.
FABB.
Qual.
SE NON SPECIFICATO:
QUOTE IN MILLIMETRI
FINITURA SUPERFICIE:
TOLLERANZE:
LINEARE:
ANGOLARE:
FINITURA:
INTERRUZIONE
BORDI NETTI
NOME
FIRMA
DATA
MATERIALE:
NON SCALARE DISEGNO
REVISIONE
TITOLO:
N. DISEGNO
SCALA:1:5 FOGLIO 1 DI 1
A0
PESO:
80016CR01
A A
B B
C C
D D
E E
F F
G G
H H
J J
K K
L L
M M
N N
P P
R R
T T
24
24
23
23
22
22
21
21
20
20
19
19
18
18
17
17
16
16
15
15
14
14
13
13
12
12
11
11
10
10
9
9
8
8
7
7
6
6
5
5
4
4
3
3
2
2
1
1
DISEG.
VERIF.
APPR.
FABB.
Qual.
SE NON SPECIFICATO:
QUOTE IN MILLIMETRI
FINITURA SUPERFICIE:
TOLLERANZE:
LINEARE:
ANGOLARE:
FINITURA:
INTERRUZIONE
BORDI NETTI
NOME
FIRMA
DATA
MATERIALE:
NON SCALARE DISEGNO
REVISIONE
TITOLO:
N. DISEGNO
SCALA:1:5 FOGLIO 1 DI 1
A0
PESO:
80016CR01
E
F
H
G
B
D
I
L

Use and maintenance manual Flexi 7 - Flexi 9
Pag.20
Rev.0 01/03/2023
EN
Recharge the fuel
⚠ Use only wood pellets, the characteristics shown in this manual.
⚠ During pellet loading prevent the pellet bag from coming into contact with hot surfaces.
📌It is not recommended to empty the pellet bag directly into the hopper to avoid depositing wood sawdust on the bottom of
the hopper.
To load the pellets inside the hopper, proceed as described below:
Step Action
1 Open the pellet hopper cover
2 Lift the slide
3 Pour the pellets into the hopper
4 Close the pellet hopper cover
Doors opening
The combustion chamber door, the pellet hopper lid and the ash drawer can only be opened when the stove is in the OFF state.
If one of them is not closed, the pellet supply is interrupted, the control unit emits an acoustic warning signal, while the symbol appears on
the display:
In this condition, by touching the CONFIRM button you can read the detail of the warning: “doors and ash pan open”. If the combustion
chamber door, the pellet hopper lid and / or the ash drawer are not closed within 1 minute, the stove switches off signaling ALARM 07.
Opening the doors also interrupts the automatic cleaning phase of the brazier. In the event of a prolonged interruption of the cleaning
phase, ALARM 19 may appear.
Remember that in the presence of an alarm the stove will have to be restarted manually.
User training
Once installation is complete, the user must always be fully trained in the functions and characteristics of the stove by the technician au-
thorized by Ravelli to ensure optimal and safe use.
The training should cover the following topics:
• Description of the stove, its operation and basic settings
• How to turn the stove on and off safely
• Fuel storage and refilling
• What to do in the event of an alarm, in particular that of “no ignition”
• How to clean the stove correctly and the importance of performing it on a regular basis
• It is advisable to schedule the first annual maintenance
