Raycus A6000D User manual

RFL-A6000D~10000D
Fiber Delivered Direct
Diode Lasers
User Guide
Wuhan Raycus Fiber Laser Technologies Co., Ltd.

Wuhan Raycus Fiber Laser Technologies Co., Ltd.
User Guide of RFL-A6000D~10000D
CONTENTS
1. SAFETY INFORMATION.....................................................................................................................1
1.1 SECURITY LABELS.............................................................................................................................................1
1.2 LASER SAFETY GRADE...................................................................................................................................... 2
1.3 OPTICAL SAFETY..............................................................................................................................................2
1.4 ELECTRICAL SAFETY..........................................................................................................................................2
1.5 OTHER SAFETY RULES...................................................................................................................................... 3
2. PRODUCT DESCRIPTION...................................................................................................................3
2.1 FEATURES...................................................................................................................................................... 3
2.2 PACKAGE PARTS..............................................................................................................................................4
2.3 UNPACKING AND INSPECTION............................................................................................................................ 4
2.4 OPERATION ENVIRONMENT...............................................................................................................................5
2.5 ATTENTIONS................................................................................................................................................... 5
2.6 SPECIFICATIONS...............................................................................................................................................6
3. INSTALLATION.....................................................................................................................................7
3.1 DIMENSIONS.................................................................................................................................................. 7
3.2 INSTALLATION RULE....................................................................................................................................... 10
3.3 COOLING REQUIREMENTS............................................................................................................................... 13
4. USING THE PRODUCT...................................................................................................................... 15
4.1 FRONT PANEL...............................................................................................................................................15
4.2 REAR PANEL.................................................................................................................................................16
4.3 POWER CONNECTION.....................................................................................................................................17
4.4 CONTROL INTERFACE DEFINITION.....................................................................................................................19
4.4.1 Safety XP2 Interface....................................................................................................................... 21
4.4.2 Hard Wiring XP1............................................................................................................................. 27
4.4.3 RS232 XP3 Interface....................................................................................................................... 30
4.4.4 Analog Interface XP4...................................................................................................................... 30
4.4.5 INTERNET Interface XP5................................................................................................................. 30
4.5 INTRODUCTION TO SAFETY INTERLOCK.............................................................................................................. 31

Wuhan Raycus Fiber Laser Technologies Co., Ltd.
User Guide of RFL-A6000D~10000D
4.6 SCHEMATIC DIAGRAM OF THE INTERNAL ELECTRICAL CIRCUIT OF THE LASER............................................................. 31
4.7 START OPERATION SEQUENCE.......................................................................................................................... 32
5. CONTROL MODE SELECTION....................................................................................................... 34
5.1 ON MODE....................................................................................................................................................36
5.2AD ENABLE MODE..........................................................................................................................................36
5.2.1EMISSION EXTERNAL CONTROL ENABLE........................................................................................................... 36
5.2.2 RED LIGHT CONTROL................................................................................................................................... 37
5.2.3 PROGRAMMING MODE................................................................................................................................ 37
5.3 REM MODE.................................................................................................................................................. 37
5.3.1 AD enable mode.................................................................................................................................. 37
5.3.2 Emission external control....................................................................................................................38
5.3.3 Red light control.................................................................................................................................. 38
5.3.4 Programming mode............................................................................................................................ 38
6. WIRING DIAGRAM AND OPERATION STEPS............................................................................ 38
6.1 INTERNAL CONTROL IN ON MODE..................................................................................................................... 38
6.2 EMISSION EXTERNAL CONTROL MODE SET BY POWER COMMUNICATION IN ON MODE................................................39
6.3 EMISSION EXTERNAL CONTROL SET BY POWER ANALOG IN ON MODE.....................................................................40
6.4 EMISSION EXTERNAL CONTROL THROUGH PROGRAMMING MODE ON THE ON MODE................................................. 41
6.5 SET THE POWER ANALOG AS EMISSION EXTERNAL CONTROL ON THE REM MODE……………………………………. ……………43
6.6 REM MODE POWER COMMUNICATION SET OUT LIGHT EXTERNAL CONTROL…………………………....…………………………….44
6.7 PROGRAMMING MODE IN REM MODE.............................................................................................................45
7. RS232 AND INTERNET COMMUNICATION COMMAND..........................................................47
7.1 PORT CONFIGURATION....................................................................................................................................47
7.2 LASER COMMUNICATION PROTOCOL (NETWORK PORT & SERIAL PORT)..................................................................48
8. PC SOFTWARE INSTRUCTIONS.....................................................................................................52
8.1 MAIN INTERFACE OF PC SOFTWARE...................................................................................................................52
8.2 MULTI-LASER CONTROL AREA.......................................................................................................................... 53
8.2.1 Add/delete laser.................................................................................................................................. 54
8.2.2 Modify laser IP.....................................................................................................................................55

Wuhan Raycus Fiber Laser Technologies Co., Ltd.
User Guide of RFL-A6000D~10000D
8.3 MAIN WORKING STATUS DISPLAY...................................................................................................................... 56
8.3.1 Laser’s cumulative operating time display area................................................................................. 57
8.3.2 Laser working status display area.......................................................................................................58
8.3.3 Laser power-up, mode selection, light-out control area.....................................................................59
8.3.4 Programming mode test area.............................................................................................................60
8.3.5 Power slow rise&down parametersettingarea................................................................................... 60
8.3.6 Laser output parameters read the setting area..................................................................................61
8.4 LASER PARAMETER DISPLAY AREA...................................................................................................................... 61
8.5 ALARM TYPE DISPLAY AREA.............................................................................................................................. 62
8.6 PC SOFTWARE OPERATING MODE SELECTION.......................................................................................................62
8.7 LANGUAGE...................................................................................................................................................64
8.8 AUTHORIZATION (TIME-LIMITED LOCKING).........................................................................................................64
8.8.1 Authorization on user mode................................................................................................................64
8.8.2 Authorization on authorization mode.................................................................................................65
8.9 ABOUT......................................................................................................................................................... 66
8.10 XP1 INTERFACE STATUS INDICATION (IN DIAGNOSTIC MODE)............................................................................. 67
8.11 LOG (IN DIAGNOSTIC MODE).......................................................................................................................... 68
8.11.1 Download log.................................................................................................................................... 69
8.11.2 Downloadrecord of historicalfault.................................................................................................... 70
8.11.3 Downloaded file address...................................................................................................................70
8.12 MODULE PARAMETERS (IN DIAGNOSTIC MODE)................................................................................................. 70
8.13 PROGRAMMING SETTINGS (PROGRAMMING EDITING)......................................................................................... 71
8.13.1 View the number of wave bars inside the current laser................................................................... 72
8.13.2 Check programming content.............................................................................................................73
8.13.3 Empty all programmings...................................................................................................................74
8.13.4 Edit Programming............................................................................................................................. 74
8.13.5 Command Explanation...................................................................................................................... 77
9. WARRANTY, REPAIR AND RETURN............................................................................................ 78
9.1 GENERAL WARRANTY......................................................................................................................................78

Wuhan Raycus Fiber Laser Technologies Co., Ltd.
User Guide of RFL-A6000D~10000D
9.2 LIMITATIONS OF WARRANTY............................................................................................................................ 79
9.3 SERVICE AND REPAIR.......................................................................................................................................79

1
1 Safety Information
Thank you for choosing Raycus Fiber Laser. This user manual provides you with important safety,
operation, maintenance and other relevant information. Please read the manual carefully before using this
product. To ensure safe operation and optimum product operation, please carefully review the following
cautions and warnings as well as other information within this manual.
1.1 Security Labels
WARNING: Describes a hazard that leads to severe personal injury or death.
CAUTION: Describes a hazard that leads to general personal injury or damages to
product.
English
Label
Chinese Label
English Label（6000W）
Chinese Label（6000W）
English Label
Chinese Label
1: Fiber Delivery Cable Connector
2: Type 4 Laser Product
3: Class 2 Laser Product Label-1mW
Red Laser
4: CE Authentication
5: ID Label (6kW)
6: Laser Radiation Hazard

Wuhan Raycus Fiber Laser Technologies Co., Ltd.
User Guide of RFL-A6000D~10000D
2
7: Electrical Hazard
1.2 Laser Safety Grade
This series of lasers are Class 4 laser instruments. The product emits laser radiation at a wavelength
of 915nm or around 915nm, and the average laser power radiated from the fiber delivery cable connector
is 6kW-~10kW (depending on laser model). Direct or Indirect exposure to high power laser radiation
causes damage to the eye or skin. Although the radiation is not visible, the beam will cause irreparable
damage to the retina or cornea, so appropriate and certified laser safety glasses must be worn whenever
the laser is emitting.
WARNING: Users must use appropriate laser goggles when operating this device. The
laser goggles are selected according to the range of wavelength emitted from this product.
Users must select the appropriate laser goggles according to the entire range of laser
wavelengths. Please do not directly view (whether the laser Is emitting or not) the laser
output heads when laser emitting.
1.3 Optical Safety
Any dust on the end of the collimator assembly can damage the crystal of fiber delivery cable
connectoror the entire laser device.
CAUTION: DO NOT emit when the protective cap is not removed, otherwise the lens or
crystal will be damaged.
1.4 Electrical Safety
a) Ensure that the PE line is effectively grounded, and the installation environment is safe and
reliable.

Wuhan Raycus Fiber Laser Technologies Co., Ltd.
User Guide of RFL-A6000D~10000D
3
WARNING: The disconnection of the product grounding will electrify the
outer shell, which may result in personal injury to the operator.
b) Ensure that the AC voltage is supplied normally.
CAUTION: Wrong wiring mode or power supply voltage will cause irreversible
damages to the laser device.
1.5 Other Safety Rules
a) Do not view the fiber delivery cable connector directly when laser is emitting.
b) Do not use fiber lasers in dark or dim environments.
c) If this device is used in a manner not specified in this manual, the protection provided by the
device may be impaired and the warranty will be voided.
d) There are no user serviceable parts, equipment or assemblies inside the product. All service and
maintenance shall be conducted by a certified Raycus engineer. In order to prevent electric shock,
please do not break the seal or uncover the shield. Otherwise, any damage to the device will not
be guaranteed.
2. Product Description
2.1 Features
Fiber delivered direct diode lasers are more compact and ready to use than conventional lasers, with
higher electrical and optical conversion efficiencies, lower power consumption and better beam quality.
Thanks to its flexible laser output ways, it can be easily integrated with system equipment.
Main Features:
High beam quality

Wuhan Raycus Fiber Laser Technologies Co., Ltd.
User Guide of RFL-A6000D~10000D
4
Highly reliable
Maintenance-free operation
High electro-optical conversion efficiency
Convenient control interface
Fast modulation
Product’s main applications:
Industrial cutting and welding
Laser quenching and cladding
Scientific research
2.2 Package Parts
Please refer to package accessories that are in the packing box.
2.3 Unpacking and Inspection
The specially designed packaging materials and cabinets helps Raycus ensures that the lasers are
fully protected during transportation. Nevertheless, in order to prevent unpredictable situations during
transportation, the users still need to carefully check whether the package is correctly placed before
unpacking, and there is no damage from phenomenon such as collision, cracking and flooding on the
outside of the box. Once you find that there is an abnormality in the external cabinet, please inform
Raycus Company in time to deal with it as soon as possible.
Please double check if each listed object is inside the package; and contact Raycus as soon as
possible if there are any issues.
Take extra care when removing the unit from the package and make sure that the fiber optic cable
stays away from any possible collision and vibration. Please do NOT distort, bend or pull the output cable
when unpacking the device; and avoid any collision to the head of laser output.

Wuhan Raycus Fiber Laser Technologies Co., Ltd.
User Guide of RFL-A6000D~10000D
5
CAUTION: The fiber optic cable and the fiber delivery cable connector are precise optic
instrument, ANY vibration or impact to the output head, and twist or excessive bend to the
cable will damage the instrument.
2.4 Operation Environment
The operation conditions are listed as the following table:
Table 1: The Operation Environment for the Laser
Model
A6000D
A8000D
A10000D
Supply Voltage(V)
Three-phase four-wire system AC323V～AC437V、50/60Hz（including PE）
Power supply capacity(kVA)
＞20
＞25
＞32
Installation Environment
Flat, no vibration nor impact
Ambient Temperature
10℃～40℃
Relative Humidity
＜70%
Tips: Install the laser in an air-conditioned environment for longer life and better performance.
2.5 Attentions
a) Make sure the product is properly grounded before use.
b) Make sure that the correct voltage of 380VAC is used. Power supply connection failures will
cause irreversible damages the device.
c) It is important to keep the collimating lens clean, otherwise it will cause irreversible damages
the device.
d) When not using the laser, please cover the fiber delivery cable connector protection cap, do not
touch the lens of the output, when necessary, use special dust-free cotton swabs and alcohol to
clean the lens.

Wuhan Raycus Fiber Laser Technologies Co., Ltd.
User Guide of RFL-A6000D~10000D
6
e) Please keep the protective cap of fiber delivery cable connector properly when using the laser.
To avoid dust, make sure to place the protective cap with the opening facing downward.
f) High temperature in summer may cause condensation to form inside the laser, which may
cause permanent damage to the laser, please ensure that the laser is shut down with the water
cooler being stopped at the same time.
g) low temperatures during the winter can cause the laser's internal cooling water to freeze easily,
causing permanent damage to the laser, please ensure that when the laser is in the shutdown
state, the water cooler continuous operation.
h) Failure to follow the instructions above may cause laser power loss, and such loss is not
covered by warranty.
2.6 Specifications
Table 2 Product Specifications
Optical properties
Test Conditions
Model
A6000D
A8000D
A10000D
Output
Power(kW)
6
8
10
/
Operation Mode
CW/Modulated
/
Polarization State
Random
/
Output Power
Tunability
(%)
10～100
/
Emission
Wavelength(
nm)
915±5
Nominal Output Power
Output Power
Instability
＜3%
Nominal Output Power; Duration:
5hrs; Ambient Temp.: 25℃
Modulation
Frequency
(Hz)
50～2k
Nominal Output Power

Wuhan Raycus Fiber Laser Technologies Co., Ltd.
User Guide of RFL-A6000D~10000D
7
Red Guide Laser
Power(mW)
0.5～1
/
Fiber output type
iHQB
QD
/
Fiber core
diameter
(μm)
600
1000
/
Minimum bending
diameter
(μm)
400
600
/
Beam divergence
half-angle
（rad）
≤0.22
Nominal Output Power
Delivery Cable
Length(m)
20
Customizable
Electrical characteristic
Operating Voltage
Three-phase four-wire system AC323V～
AC437V、50/60Hz（Include PE）
/
Maximum power
Consumption
(kW)
15
20
25
Nominal Output power
Way to control
RS232/ Serial communication /AD
/
Other characteristic
/
Dimension（mm）
897×1159×96
8
1199×1159×968
Includes casters and rings, without
warning lights
Weight (kg)
＜360
＜400
＜450
Air conditioning included
Operating
Ambient
Temperature
(°C)
10～40
/
Humidity (%)
＜70
/
Storage
temperature
(°C)
-10～60
/
Cooling method
Water cooling
/

Wuhan Raycus Fiber Laser Technologies Co., Ltd.
User Guide of RFL-A6000D~10000D
8
3 Installation
3.1 Dimensions
The main body dimensions of RFL-A6000D fiber delivered direct diode laser shown in Figure 1.
Figure 1-a Front and rear view of the laser.
Figure 1-b Top and left view of the laser.
Figure 1 the dimensions of RFL-A6000D fiber delivered direct diode laser

Wuhan Raycus Fiber Laser Technologies Co., Ltd.
User Guide of RFL-A6000D~10000D
9
The RFL-A6000D fiber delivered direct diode laser uses RFL- iHQB fiber delivery cable, and its form
factor is shown in Figure 2
Figure 2 External dimensions of the RFL-HPQ fiber delivery cable connector
RFL-A8000D/A10000D The main body dimensions of RFL-A6000D fiber delivered direct diode
laser shown in Figure 3.
a) Front and rear view of the laser.

Wuhan Raycus Fiber Laser Technologies Co., Ltd.
User Guide of RFL-A6000D~10000D
10
b) Top and left view of the laser.
Figure 3 The dimensions of RFL-A8000D/A10000D fiber delivered direct diode laser
RFL-A8000D/A10000D fiber delivered direct diode laser uses RFL- QD fiber delivery cable, and its
form factor is shown in Figure 4
Figure 4 External dimensions of the RFL-QD fiber delivery cable connector
Note: The dimensions in the above diagram are in the unit of mm.
Before the laser works, make sure that the two copper contacts (Interlock pins) on the fiber delivery
cable connector are shorted, otherwise the laser will not work properly. Before installing the output cable
into the processing head, the lens of the output cable must be inspected. If the output cable lens is dirty,
the lens must be cleaned. It is forbidden to disassemble the output lens by anyone other than staffs from
Raycus, otherwise the warranty will be invalidated.

Wuhan Raycus Fiber Laser Technologies Co., Ltd.
User Guide of RFL-A6000D~10000D
11
3.2 Installation rules
a) Place the laser horizontally in a suitable position and ground it, as necessary.
b) Before the laser is powered on, please check if the power supply has the correct voltage
(380VAC±10%, 50/60Hz, See Table 2 Product Technical Data Sheet for details.), and check
whether the grounding line is well grounded.
c) Connect the power cable and control cable to the product when power supply is OFF.
d) Connect the cooling system to the laser and fiber delivery cable connector according to the
water inlet and outlet signs.
e) Please check the fiber delivery cable connector and make sure to clean it before installing it in
the equipment.
f) Do not step on, squeeze or excessively bend the protective tube during the installation of the
fiber delivery cable connector to avoid damage to the optical fiber.
g) In the process of installing the optical cable output head, ensure the cleanliness of the
surrounding environment (do not use electric fans to dissipate heat when it is hot in summer to
avoid large dust in the air).
h) The minimum bending diameter of the laser transmission cable in non-working conditions such
as transportation and storage shall not be less than 40cm.
i) Customers can use the four lifting rings at the top of the product or the four casters at the
bottom to lift or move the product. Before lifting the laser source, make sure that the four lifting
rings are installed firmly and reliably. When lifting the laser source, be sure to use the four
lifting rings; when pushing the laser source, please make sure that the support block at the
bottom of the horizontal adjustment caster is off the ground. After the laser source is positioned,
adjust the support block to make it contact the ground to avoid displacement of the laser source.
As shown in Figure 5.

Wuhan Raycus Fiber Laser Technologies Co., Ltd.
User Guide of RFL-A6000D~10000D
12
a) Lifting ring
b) Leveling casters
Figure 5 Laser top lifting ring and bottom level adjustment caster.
CAUTION: All the cables can only be connected when power supply is off. Hot plug
may damage the device.
CAUTION:
(1) The placement of the laser output cable should be as natural as possible, and the
output cable should not be twisted.
(2) If the coil diameter of the fiber delivery cable connector is too small, it will damage
the laser.
Lifting ring
Lifting ring
Leveling casters
Leveling casters

Wuhan Raycus Fiber Laser Technologies Co., Ltd.
User Guide of RFL-A6000D~10000D
13
CAUTION:
(1) During the process of installation and disassembly, please handle the fiber delivery
cable connector gently, and avoid vibration.
(2) Before assembling the laser output head, ensure that the optical lens and cutting head
cavity are clean and free of pollution.
3.3 Cooling Requirements
Table 3 Cooling Requirements
Model
Cooling
Capacity
（kW）
Minimum
Flow
（L/min）
Input
Pressure
（Bar）
Hose inner
Diameter
（mm）
Cooling water
Temperature
（℃）
RFL-A6000D
≥18
＞52
4～6
Φ25
25±0.5
RFL-A8000D
≥20
＞68
4～6
Φ32
25±0.5
RFL-A10000D
≥24
＞84
4～6
Φ32
25±0.5
Requirements of Cooling Water:
a) Cooling water needs to be pure water;
b) In order to prevent the water in the water cooler from growing mold and causing pipeline
blockage, it is recommended to add alcohol when filling pure water, and the amount of alcohol
added is 10% of pure water;
c) When the ambient temperature of the equipment is between -10 ℃and 0 ℃, the glycol
solution with a volume ratio of 30% must be used and replaced every two months;
d) If ambient temperature is below -10℃, the chiller with both heating and cooling functions must
be used and kept in full-time operation.
Water cooling requirements for output optical cables:
a) Water flow requirements: iHQB fiber delivery cable connector water flow rate greater than
1.5L/min; QD fiber delivery cable connector water flow rate greater than 2.5L/min.

Wuhan Raycus Fiber Laser Technologies Co., Ltd.
User Guide of RFL-A6000D~10000D
14
b) Water cooling pressure:4～6 Bar at the water inlet;
c) Water inlet and outlet connector type: iHQB output fiber optic cable ϕ6 quick release connector;
QD output fiber optic cable ϕ8 quick release connector.
d) Water pipe type: iHQB fiber delivery cable connector outer diameter ϕ6 inner diameter ϕ4; QD
fiber delivery cable connector outer diameter ϕ8 inner diameter ϕ5.5
e) Cooling water quality: deionized water, distilled water, purified water; it is recommended to
replace the water once a month, and the replacement period should not exceed two months.
f) PH value of cooling water: 5.5～9;
g) The water cooler needs to be equipped with a filter element whose filter particle size is less than
100um; the filter element needs to be cleaned once a month.
h) Maximum cooling water temperature: 35℃;
i) The lowest cooling water temperature: 5℃greater than the saturated dew point temperature;
j) Additives in cooling water: meet the above PH value and solid particle size requirements;
Other requirements:
a) When starting the cooling system for the first time, check the entire water system and joint for
water leakage.
b) If the laser is not used for a long time, the cooling water inside the cooling system and the laser
inside should be drained, otherwise the laser equipment will be damaged.
c) Please use compressed gas below 0.5MPa when emptying water from the device. Failure to do
so may cause permanent equipment damage to cooling system.
CAUTION:
(1) Set the water temperature of the cooling system correctly according to the ambient
temperature. Setting the water temperature too high will result in the laser not working
properly. Setting the water temperature too low will cause condensation inside the laser or the
laser output head, which will cause damage to the laser;

Wuhan Raycus Fiber Laser Technologies Co., Ltd.
User Guide of RFL-A6000D~10000D
15
①
②
③
④
⑤
⑥
(2) Before turning on the laser, the cooling system must be working properly, and the water
temperature should be suitable for the temperature.
4 Using the Product
Please log in to the official website of Raycus to download the new PC software and the
PC software user manual. Website: http://www.raycuslaser.com
4.1 Front Panel
Figure 6 shows the front panel.
Figure 6 Front view of the panel
REM/OFF/ON: The key switch is the main control switch of the laser. Insert the key and turn it to
the "ON" position, the main control part of the laser is powered on, and the POWER light is on, Rotate to
the "REM" position, you need to close the Pin8 and Pin9 of the XP1 interface on the rear panel to achieve
remote power-on, and rotate to REM to activate the hard-wired control mode of the laser.
