Raygleam FOLDING SOLAR PANEL KIT User manual

FOLDING SOLAR PANEL KIT
USER MANUAL
Accessories:
、
1.Handle 8.Cable
2. Latches 9.Battery clips/Alligator clips
3. Aluminum frame 10.Anderson plug
4. Aluminum support legs 11.Fuse
5.10A EP VS1024BN 12. Storage carry bag
6.Junction box 13.Protect corner
7.Label

Installation
1. Remove solar panel kit from protective/storage carry bag.
2. Unclip the two latches on the side of the unit and fold the two panels outward. Extend the legs to support
the solar panels.
3. Locate in a clear sunlit area free from over hanging branches or obstructions.
4. Place the solar panel kit facing the sun.
Note: To obtain maximum output it is suggested that the panels’ angle be frequently adjusted to track
the suns movement through the day.
5. Fully extend battery lead and connect the battery clips to the + positive (red) & - negative (black) battery
terminals on a 12v battery. Ensure that the connections are secure.
Operation
The connection LED is the LED on the left. BLUE
1. Blue LED flashing on the solar charger controller indicates that the battery leads are connected
correctly to the battery.
2. No LED indicates incorrect connection or no connection to battery.
The charge condition LED is the LED next to the connection LED. (Green, Yellow or Red).
1. The charge LED glowing red, indicates that the battery is over discharged.
2. Yellow LED indicates that the battery is partially charged.
3. Green LED indicates the battery is charged but has not reached full charge.
4. Green LED flashing indicates that the battery has reached full charge.
Warranty:
The life span of the solar panels are more than 20 years, the accessory components’ and regulator warranty
is 1 year. The Solar Panels carry a warranty of 1 year manufacturer defect warranty and 5 years on the solar
cells.
FREQUENTLY ASKED QUESTIONS
Q. What type of batteries can be used with this kit?
A. Any 12V DC battery used for caravans, motor homes, cars, boats, motor cycles, etc.
Q. When will the blue System light illuminate?
A. Only when the solar panels are generating sufficient power to charge the battery and connected correctly
to a battery. (MUST BE CONNECTED TO A BATTERY TO WORK)
Q. Can I extend /lengthen the battery lead?
A. Yes extensions are ok but the longer the length the less efficient the power will be.
Q. Do I need to clean my solar panel?
A. Yes. Dust & dirt should firstly be swept off the panel surface using a soft brush and then use a wet cloth to
wipe the panel surface to remove remaining dirt & grime. It is recommended that any bird droppings be
removed as soon as possible as if left can cause damage to the surface.
Q. Will water damage my solar panel?
A. The solar panels are very well sealed, water should not effect them at all. The regulator even though well
sealed should not be exposed to excessive amounts, water may enter via the wire connections.
Trouble shooting if system does not function
 Check all connections to ensure they are secure and free from moisture & debris.
 Measure the battery voltage, if it is 14.4V or higher, the green light on the solar charger controller
should be illuminated. Check the condition of the battery, ensure it will hold a charge.
 Ensure sufficient light is available. Position your solar panel kit to face towards the sun.
 A battery must be connected to the battery leads before the regulator LEDS will glow.
Folding Solar Panel Kit Specification
Type
Kit Size
Folded
N.W
Specification
Max-Power Max-Power
Voltage
Max-power
Current
Open-Circuit
Voltage
Short-circuit
Current
Module mm Kg W V A V A
2x50W
505*650*30
mm
9.5 100 17.5 5.71 21.6 6.17
Solar Cell: MONO
Technical data on the solar panel kit can be found on the label on the back of the solar panel.
