Raymarine Chart Mode Reference guide

Quick Reference Card: Chart Mode Controls
86067-3
Soft Key Labels:
Change when you press a key.
Default soft key labels are shown.
ROUTE GOTO SCREEN FIND SHIP
Chart
Trackpad
· Controls cursor position and the slider values.
· Hold the trackpad down to move the cursor faster.
CLEAR
· Cancels operation in progress and returns to the
previous display.
· Deletes an object/function under cursor control.
ENTER
· Confirms selection and (if appropriate) clears current
soft key labels. Unit performs the selected task,
accepts changes, or displays more options.
· When cursor text is displayed, takes cursor control
of the object.
· When arrow-head cursor symbol is displayed, drops the
object under cursor control.
POWER
· Press and hold until unit beeps to turn on display.
· Press for 3 seconds to turn off display.
· Press soft key to display desired setup menu.
· Use trackpad to select option and soft key to change option.
· Press ENTER to close menu and CLEAR to to finish.
SYSTEM
SET UP¬
CHART
SET UP¬
TRACK
SET UP¬
GPS
SET UP¬
MENU Provi des access to setup options.
· Press to display soft keys.
· Press soft keys to toggle window ON/OFF and to select
lower window.
· Press ENTER to finish.
SELECT
WINDOWS
WINDOWS
OFF ON
DISPLAY
Controls display mode and windows.
· Press for display mode and soft keys display.
· Press again to toggle through display modes, then ENTER.
· Press and hold for 2 seconds for full screen display.
VRM/EBL
Use to measure range and bearing to/between points.
· Position cursor at start point.
· Press VRM/EBL key to display the Ruler data box.
· Select end point using trackpad
· Press ENTER to fix end position of ruler.
D5562-4
GAIN
Not used in Chart mode.
MULTI
Controls display lighting.
Press and hold MULTI key for brightness to 100%.
· Press to display slider.
RANGE Controls chart scale.
Displayed vertical distances shown in the Status Bar.
· Press top of key to increase the chart distance.
· Press bottom of key to decrease the chart distance.
· Press and hold to change the scale faster.
· Select a slider using the soft key or trackpad.
· Toggle between off/on by pressing the soft key again.
· Adjust slider using trackpad, and press ENTER to finish.
LIGHT
ALARMS
Use to set up the chartplotter alarms.
· Press to display the Alarms set up menu and soft keys.
The soft keys correspond to the selected alarm.
SELECT ARRIVAL
ALARM RADIUS
ALARMS SET UP
OFF COURSE ALARM
ANCHOR ALARM
COUNTDOWN TIMER
ALARM CLOCK
OFF
OFF
00:33:00
OFF
ARRIVAL ALARM 0.01nm
· Use the trackpad to select the alarm.
· Use the softkeys to adjust parameters and/or toggle the alarm on/off.
· Press ENTER to finish.
ON
70%
GROUNDING ALARM 5M/1.0nm
Soft Keys
· Press to select option, or slider.
· Labels change when you press soft/dedicated key.
· Elipses (...) after the text indicate that pressing soft key
leads to another screen of soft key options.
· Press soft key to place waypoint at cursor or vessel, display the
waypoint list, or load/save a C-MAP user card.
· Press ENTER to finish.
MARKS / MOB Controls waypoints and Man Overboard function.
· Press to display waypoint soft keys.
· Press and hold for 2 seconds to activate or cancel MOB.
PLACE WPT
AT CURSOR
PLACE WPT
AT VESSEL
WAYPOINT
LIST
LOAD/SAVE
USER CARD

·Use the softkeys to edit the current route.
· Press UNDO WAYPOINT to remove the last waypoint in a route.
·PLACE waypoint to add a waypoint at the end of the route.
·Press ACCEPT ROUTE to finish.
·Use the soft keys to set up a series of waypoints as a route.
·Use the trackpad to move the cursor
· Press PLACE WAYPOINT and continue until the route is complete .
·Press ACCEPT ROUTE to finish.
MAKE
ROUTE
ROUTE
CLEAR
ROUTE
·Press to clear the current route from the display.
If it is not saved you are prompted to save the route.
EDIT
ROUTE
Status Bar
Vessel Position
Cursor
Selecting chart object
Cursor Positrion Box
Shows the current
cursor position as
either range/bearing
or lat/long. You can
move this box to your
preferred position on
the screen or turn it off.
Waypoint
Object Data Box
For object selected
by cursor
Default Soft Key Labels
These can be turned off. Press any soft key to redisplay them.
Different labels are displayed when you press a key.
Depth Area
Chart Range
Chart Boundary
·Press to navigate to the cursor position.
· When you press GOTO CURSOR, a temporary waypoint is added at the
cursor position and the GOTO is started.
·Press STOP GOTO to cancel.
STOP
GOTO
GOTO
CURSOR
· Use to navigate to a waypoint selected from waypoint database list.
·Use the trackpad to select the waypoint then press the soft key to
start the GOTO.
GOTO
WAYPOINT GOTO
WAYPOINT
FOLLOW
ROUTE GOTO
CURSOR
STOP
FOLLOW
RESTART
XTE
WAYPOINT
ADVANCE
·Press to follow the current route.
· Use the softkeys to cancel the follow or to modify the route while it is
being followed.
GOTO
Text Label
BOX
EBL
FLT
GRD
MRK
SHM
VRM
VRM/EBL
ZMB
Context Sensitive Cursor Control
When the cursor is positioned over special features on the display, a text label appears
to identify the feature. Depending on the feature, you can then move, re-size or delete it.
Feature
Data box (any type)
Electronic Bearing Line
Floating VRM/EBL
Guard zone corner or side
Mark
Ship's Heading Marker
Variable Range Marker
VRM and EBL
Zoom box
Move (for example, an EBL)
Delete (for example, an EBL)
1.
2.
3.
4.
1.
2.
·Use the soft keys to manage the route database list.
·Use trackpad to select a route then press the required
soft key.
ROUTE
LIST
·Use to save and name the current route.
MORE!
·Press to reverse the waypoint order in the current route.
REVERSE
ROUTE
YES NO
NAME ROUTE
SAVE
ROUTE
SHOW
ROUTE
ERASE
ROUTE
ROUTE
INFO NAME
ROUTE
ROUTE
Default Display
Soft Keys Soft Keys
Soft Keys
D6229-1
PLACE
WAYPOINT
UNDO
WAYPOINT
ACCEPT
ROUTE
USE
WPT LIST
PLACE
WAYPOINT
UNDO
WAYPOINT
ACCEPT
ROUTE
USE
WPT LIST
48nm
ROUTE GOTO SCREEN FIND SHIP
CURSOR
Buoy Spec. Purp Pillar Y 'EC2'
Fi(4)Y.15s Racon Whis(2)
282
9.815
R
nm
o
1 Object
CSR 50 11'908N BRG 147 T
POS 001 13'612W RNG 9.82nm
The Needles
S. Catherine's Pt
Isle Of Wight
o
o
.
.
o
age
vil Pt
