Raymarine CP200 User manual

CP100 / CP200
Installation instructions
English
Date: 07-2014
Document number: 87216-1-EN
© 2014 Raymarine UK Limited

Trademarkandpatentsnotice
Raymarine,Tacktick,ClearPulse,Truzoom,HSB,SeaTalk,SeaTalkhs,SeaTalkng,Micronet,Raytech,
GearUp,MarineShield,Seahawk,Autohelm,Automagic,andVisionalityareregisteredorclaimed
trademarksofRaymarineBelgium.
FLIR,DownVision,SideVision,Dragony,Instalert,InfraredEverywhere,andTheWorld’sSixth
SenseareregisteredorclaimedtrademarksofFLIRSystems,Inc.
Allothertrademarks,tradenames,orcompanynamesreferencedhereinareusedforidenticationonly
andarethepropertyoftheirrespectiveowners.
Thisproductisprotectedbypatents,designpatents,patentspending,ordesignpatentspending.
Patentspending
Important:Thisproducthaspatentspending.
FairUseStatement
Youmayprintnomorethanthreecopiesofthismanualforyourownuse.Youmaynotmakeanyfurther
copiesordistributeorusethemanualinanyotherwayincludingwithoutlimitationexploitingthemanual
commerciallyorgivingorsellingcopiestothirdparties.

Chapter1:Importantinformation
CertiedInstallation
Raymarinerecommendscertiedinstallationbya
Raymarineapprovedinstaller.Acertiedinstallation
qualiesforenhancedproductwarrantybenets.
ContactyourRaymarinedealerforfurtherdetails,
andrefertotheseparatewarrantydocumentpacked
withyourproduct.
Warning:Productinstallationand
operation
Thisproductmustbeinstalledand
operatedinaccordancewiththe
instructionsprovided.Failuretodoso
couldresultinpersonalinjury,damage
toyourvesseland/orpoorproduct
performance.
Warning:Potentialignitionsource
ThisproductisNOTapprovedforusein
hazardous/ammableatmospheres.Do
NOTinstallinahazardous/ammable
atmosphere(suchasinanengineroom
ornearfueltanks).
Warning:Productgrounding
Beforeapplyingpowertothisproduct,
ensureithasbeencorrectlygrounded,in
accordancewiththeinstructionsinthis
guide.
Warning:Positivegroundsystems
Donotconnectthisunittoasystemwhich
haspositivegrounding.
Warning:Powersupplyvoltage
Connectingthisproducttoavoltage
supplygreaterthanthespecied
maximumratingmaycausepermanent
damagetotheunit.RefertotheTechnical
specicationsectionforvoltagerating.
Warning:Switchoffpowersupply
Ensurethevessel’spowersupplyis
switchedOFFbeforestartingtoinstallthis
product.DoNOTconnectordisconnect
equipmentwiththepowerswitchedon,
unlessinstructedinthisdocument.
Caution:Powersupplyprotection
Wheninstallingthisproductensurethe
powersourceisadequatelyprotected
bymeansofasuitably-ratedfuseor
automaticcircuitbreaker.
Warning:Ensureallequipmenthas
isolatedpowersupply
Thisproductfeaturesanisolatedpower
supply.Topreventpotentialdamageto
equipment,Raymarinerecommendsthat
anyexternalequipmentconnectedtothis
productalsofeaturesanisolatedpower
supply.
Warning:Highvoltage
Thisproductcontainshighvoltage.
Adjustmentsrequirespecializedservice
proceduresandtoolsonlyavailableto
qualiedservicetechnicians.Thereare
nouserserviceablepartsoradjustments.
Theoperatorshouldneverremovethe
coverorattempttoservicetheproduct.
Warning:Transducercables
Donotremovethetransducercablewhilst
theproductispoweredon,doingsocan
causesparks.Ifthetransducercableis
accidentlyremovedwhilsttheproductis
poweredon,switchtheproduct'spower
off,replacethecableandthenswitchthe
powerbackon.
Warning:Sonaroperation
•NEVERoperatethesonarwiththe
vesseloutofthewater.
•NEVERtouchthetransducerfacewhen
thesonarispoweredon.
•SWITCHOFFthesonarifdiversare
likelytobewithin7.6m(25ft)ofthe
transducer.
Caution:Donotcuttransducer
cables
•Cuttingthetransducercableseverely
reducessonarperformance.Ifthe
cableiscut,itmustbereplaced,it
cannotberepaired.
•Cuttingthetransducercablewill
voidthewarrantyandinvalidatethe
EuropeanCEmark.
Caution:Serviceandmaintenance
Thisproductcontainsnouserserviceable
components.Pleasereferallmaintenance
andrepairtoauthorizedRaymarine
dealers.Unauthorizedrepairmayaffect
yourwarranty.
Importantinformation

Wateringress
Wateringressdisclaimer
Althoughthewaterproofratingcapacityofthis
productmeetsthestatedIPXstandard(refertothe
product’sTechnicalSpecication),waterintrusion
andsubsequentequipmentfailuremayoccurifthe
productissubjectedtocommercialhigh-pressure
washing.Raymarinewillnotwarrantproducts
subjectedtohigh-pressurewashing.
Disclaimer
Raymarinedoesnotwarrantthatthisproductis
error-freeorthatitiscompatiblewithproducts
manufacturedbyanypersonorentityotherthan
Raymarine.
Raymarineisnotresponsiblefordamagesorinjuries
causedbyyouruseorinabilitytousetheproduct,
bytheinteractionoftheproductwithproducts
manufacturedbyothers,orbyerrorsininformation
utilizedbytheproductsuppliedbythirdparties.
EMCinstallationguidelines
Raymarineequipmentandaccessoriesconformto
theappropriateElectromagneticCompatibility(EMC)
regulations,tominimizeelectromagneticinterference
betweenequipmentandminimizetheeffectsuch
interferencecouldhaveontheperformanceofyour
system
CorrectinstallationisrequiredtoensurethatEMC
performanceisnotcompromised.
Note:InareasofextremeEMCinterference,
someslightinterferencemaybenoticedonthe
product.Wherethisoccurstheproductandthe
sourceoftheinterferenceshouldbeseparatedby
agreaterdistance.
ForoptimumEMCperformancewerecommend
thatwhereverpossible:
•Raymarineequipmentandcablesconnectedto
itare:
–Atleast1m(3ft)fromanyequipment
transmittingorcablescarryingradiosignalse.g.
VHFradios,cablesandantennas.Inthecase
ofSSBradios,thedistanceshouldbeincreased
to7ft(2m).
–Morethan2m(7ft)fromthepathofaradar
beam.Aradarbeamcannormallybeassumed
tospread20degreesaboveandbelowthe
radiatingelement.
•Theproductissuppliedfromaseparatebattery
fromthatusedforenginestart.Thisisimportantto
preventerraticbehavioranddatalosswhichcan
occuriftheenginestartdoesnothaveaseparate
battery.
•Raymarinespeciedcablesareused.
•Cablesarenotcutorextended,unlessdoingsois
detailedintheinstallationmanual.
Note:Whereconstraintsontheinstallation
preventanyoftheaboverecommendations,
alwaysensurethemaximumpossibleseparation
betweendifferentitemsofelectricalequipment,to
providethebestconditionsforEMCperformance
throughouttheinstallation
Suppressionferrites
Raymarinecablesmaybettedwithsuppression
ferrites.TheseareimportantforcorrectEMC
performance.Ifaferritehastoberemovedforany
purpose(e.g.installationormaintenance),itmustbe
replacedintheoriginalpositionbeforetheproduct
isused.
Useonlyferritesofthecorrecttype,suppliedby
Raymarineauthorizeddealers.
Whereaninstallationrequiresmultipleferritestobe
addedtoacable,additionalcableclipsshouldbe
usedtopreventstressontheconnectorsduetothe
extraweightofthecable.
Connectionstootherequipment
Requirementforferritesonnon-Raymarinecables
IfyourRaymarineequipmentistobeconnected
tootherequipmentusingacablenotsuppliedby
Raymarine,asuppressionferriteMUSTalwaysbe
attachedtothecableneartheRaymarineunit.
CP100/CP200

Chapter2:Documentandproductinformation
Chaptercontents
•2.1 Document information
•2.2 Parts supplied
•2.3 Product overview
•2.4 CHIRP Sonar overview
•2.5 CHIRP DownVisionTM overview
•2.6 CHIRP SideVision™ overview
•2.7 Interpreting SideVision™ images
•2.8 CHIRP DownVision™ and CHIRP SideVision™ combined
Documentandproductinformation

2.1Documentinformation
Thisdocumentcontainsimportantinformation
relatedtotheinstallationofyourRaymarineproduct.
Thedocumentincludesinformationtohelpyou:
•planyourinstallationandensureyouhaveallthe
necessaryequipment;
•installandconnectyourproductaspartofawider
systemofconnectedmarineelectronics;
•troubleshootproblemsandobtaintechnical
supportifrequired.
Applicableproducts
Thisdocumentisapplicabletothefollowingproducts:
PartnumberNameDescription
E70204CP1002–channel
CHIRP/
DownVision
sonarmodule
E70205CP100and
CPT-100
2–channel
CHIRP/
DownVision
sonar
moduleand
DownVision
transom
transducer.
E70256CP2002–channel
CHIRP/
SideVision
sonarmodule
E70257CP200and
CPT-200
2–channel
CHIRP/
SideVision
sonar
moduleand
SideVision
transom
transducer.
Documentconventions
Thefollowingconventionsareusedthroughoutthis
documentwhenreferringto:
TypeExampleConvention
Proceduresfor
performingspecic
tasksusinga
multifunction
display.
Select
Transducer
Set-Up.
Theterm“Select”
isusedtorefer
totheaction
ofselectinga
menuoptionon
amultifunction
display,usingthe
touchscreenor
physicalcontrols,
dependingon
displayvariant.
Proceduresfor
navigatingmenu
hierarchieson
amultifunction
display.
Internalsonar
moduleis
turnedofffrom
theFishnder
applicationmenu:
Menu>Set-up>
SounderSet-up>
InternalSounder.
Menuhierarchies
areusedinthis
documentto
provideaquick
summaryon
howtoaccess
aparticular
functiononthe
multifunction
display.
Documentillustrations
Yourproductmaydifferslightlyfromthatshown
intheillustrationsinthisdocument,dependingon
productvariantanddateofmanufacture.
Allimagesareprovidedforillustrationpurposesonly.
Productdocumentation
Thefollowingdocumentationisapplicabletoyour
product:
DescriptionPartnumber
CP100/CP200Installationinstructions
InstallationofaCP100orCP200unitand
connectiontoawidersystemofmarine
electronics.
87216/
88030
CP100/CP200Mountingtemplate
Mountingdiagramforsurfacemountinga
CP100orCP200unit.
87193
CPT–60/CPT–100DownVisiontransom
transducerInstallationinstructions
InstallationofaDownVisiontransom-mount
transducer.
87197/
88024
CPT–200SideVisiontransomtransducer
Installationinstructions
InstallationofaSideVisiontransom-mount
transducer.
87223/
88037
CPT–110/CPT–120Through-hull
transducerInstallationinstructions
InstallationofaDownVisionthrough-hull
transducer.
87201/
88025
CP100/CP200

DescriptionPartnumber
aSeries,cSeries,eSeriesInstallationand
operationinstructions
Detailstheoperationoftheshnder
application(includingDownVisionand
SideVisionoperation)foraSeries,cSeries,
eSeriesmultifunctiondisplays.
81337
gSSeriesInstallationandoperation
instructions
Detailstheoperationoftheshnder
application(includingDownVisionand
SideVisionoperation)forgSSeries
multifunctiondisplays.
81344
Operationinstructions
Fordetailedoperationinstructionsforyourproduct,
refertothedocumentationthataccompaniesyour
display.
Transducerinstallationinstructions
Thisdocumentincludesinstallationinstructionsfor
thesonarmoduleonly.Forinstallationinstructions
foraconnectedtransducer,pleaserefertothe
documentationthataccompaniesthetransducer.
2.2Partssupplied
Partssupplied—CP100/CP200
13
4
2
D12934-1
ItemDescriptionQuantity
1Sonarmodule.1
2Documentationpack.1
3Mountingscrews.4
4Powercable1m
(3.28ft).
1
Documentandproductinformation

2.3Productoverview
CP100productoverview
TheCP100isaCHIRPsonarmodulewith
DownVisioncapabilities.Inconjunctionwitha
compatiblemultifunctiondisplay,theCP100provides
adetailedviewofthewater’sbottomstructure,
enablingyoutoidentifyshandotherobjectsinthe
waterunderneathyourvessel.
D12932-1
TheCP100hasthefollowingfeatures:
•Dual-beamsonar(conicalbeamandfanbeam).
•Typicaldepthperformanceof600ft.
•Watertemperaturesensing.
•Supportfortransomorthrough-hullDownVision
transducers.
•Lowpowerconsumption.
•12Vor24Voperation.
•WaterprooftoIPX6andIPX7.
•Robustandwaterproofhigh-speednetwork
connection.
CP200productoverview
TheCP200isaCHIRPsonarmodulewith
SideVisioncapabilities.Inconjunctionwitha
compatiblemultifunctiondisplay,theCP200provides
adetailedviewofthewater’sbottomstructureon
eachsideofyourvessel,enablingyoutoidentify
bottomfeatures,aswellasshandotherobjects
inthewater.
D12932-1
TheCP200hasthefollowingfeatures:
•Dual-beamsonar(portandstarboardfanbeam).
•Typicalrangeperformanceof300ft.
•Watertemperaturesensing.
•Supportfortransom-mountSideVision
transducers.
•Lowpowerconsumption.
•12Vor24Voperation.
•WaterprooftoIPX6andIPX7.
•Robustandwaterproofhigh-speednetwork
connection.
CP100/CP200

2.4CHIRPSonaroverview
CHIRPsonarproducesaconicalshapedbeam,the
coverageoftheconicalbeamisthewatercolumn
directlybeneaththevessel
Conicalbeam
D12784-2
Sonariseffectiveatarangeofspeeds.Indeeper
waterstheCHIRPbandwidthisautomatically
optimizedtoimprovebottomlockandthedetection
ofmovingobjects(e.g.sh)inthewiderwater
column.
CHIRPsonarscreenexample
2.5CHIRPDownVisionTMoverview
DownVisionTMproducesawide–angleside-to-side
beamandathinfore-to-aftbeam.Thecoverageof
theDownVisionTMbeamisawatercolumndirectly
beneathandtothesidesofthevessel.
DownVisionTMbeam
D12777-2
DownVisionTMiseffectiveatlowervesselspeeds.In
deeperwaterstheCHIRPbandwidthisautomatically
optimizedtoimprovebottomlockandthedetectionof
movingobjects(e.g.sh)inthewiderwatercolumn.
Thewide,thinbeamproducescleartargetreturns.
TheuseofCHIRPprocessingandahigheroperating
frequencyprovideamoredetailedimage,making
iteasiertoidentifybottomstructuresaroundwhich
shmayreside.
CHIRPDownVisionTMscreenexample
Documentandproductinformation

2.6CHIRPSideVision™overview
SideVision™interpretssignalsfromapairof
side-lookingtransducersandbuildsupadetailed
underwaterviewasyourvesselmovesforward.
Thetransducerssendpulsesofsoundwavesinto
thewateroneachsideofyourvessel,andrecord
thesoundwavesthatreectoffthebottom,andoff
objectsonthebottomorsuspendedinthewater
column.Thereceivedechoesareaffectedbythe
bottommaterial(forexamplemud,gravelorrock),
andbyanyotherobjectsintheirpath(forexample
cablesontheseaoor,bridgepiers,wrecks,shoals
orsh).
SideVision™producestwowide–angleside-to-side
beams,eachwithathinfore-to-aftbeam.The
coverageoftheSideVision™beamsisaswathon
eachsideofthevessel.
SideVisionbeams
D#####-1
SideVision™iseffectiveatlowervesselspeeds.
Thewide,thinbeamsproducecleartargetreturns.
Asyourvesselmovesforward,subsequentreturns
builduptoprovideanimageoftheseaooroneach
sideofyourvessel.
TheuseofCHIRPprocessingandahighoperating
frequencyprovideadetailedimage,makingiteasier
toidentifybottomstructuresaroundwhichshmay
reside.Thenarrowanglethebeamsmakewiththe
bottomatlongerrangescanrevealtheshadowsof
structuresthatprotrudefromthebottom.
CHIRPSideVision™screenexample
Note: The “Depth” gure shown in the illustration
above assumes that you have a device in your
system that provides depth data. Please be aware
that not all transducers and / or sonar modules
support depth sensing.
CP100/CP200

2.7InterpretingSideVision™images
ThefollowingillustrationshowshowSideVision™imagesonyourmultifunctiondisplayarerelatedtothe
watercolumnandseaoortothesidesofyourvessel.
InterpretingSideVisionimages
POR TS TARBOARD
Ve ssel dire ction
Dis tance =150ft
PORT
Ima ges croll dire ction
STARBOARD
STARBOARD
Ima ge s croll dire ction
Bait ball
Depth
62.9 ft
Vesse l
direction
Distance from
vessel, e.g.
150 ft ( not
depth)
Depth is only displayed if there is a
source of depth data on the network
D
i
D
is
ts
ta
n
a
nc
ec
e
=
=
1
15
0
5
0
f
ft
t
ectio
n
Baitball
VegetationStructure
Water
dire ction
BOA
RD
Dept
62.
9
Wa te r
Ve ge ta tion
Structure
D13166-1
SideVision™imagesareconstructedline-by-line,
similartothewayatelevisionpictureiscomposed
ofmanyhorizontallines.Eachsuccessiveping
fromtheSideVision™transduceraddsanewline
ofimagedatatothetopofyourdisplay.Eachnew
lineshowssonarreturnsfromboththeportand
starboardsidesofyourvessel.
Asnewlinesareaddedwitheachsuccessive
ping,olderdatagraduallyscrollsdownthedisplay,
buildingupadetailedimageofthewatercolumnand
seaoortothesidesofyourvessel.Ifyourvessel
maintainsthesamebearingandspeedforaperiod
oftime,youcaninterprettheimageasaplanofthe
seaooralongyourvessel’scourse.
Theillustrationalsoidentiesexamplesoffeatures
thatmaybevisibleinSideVision™images:
•Water:closetoyourvessel,theSideVision™
sonarbeamsmaynotinteractwithanysolid
objectsinthewatercolumnuntiltheyhitthesea
oor.Thewatercolumnclosetoyourvesselis
displayedasadarkbandintheimage.Theabrupt
changetoalightersectionintheimageindicates
wheretheseaoorisrstdetectedwitheachping.
•Baitball:objectsinthewatercolumnclosetoyour
vesselmaybedetectedbeforetheSideVision™
beamshittheseaoor.Inthisexample,abaitball
isshownwithinthewatercolumn,atadistanceof
approximately30feetfromthevessel.
•Vegetation:objectsincontactwiththeseaoor
thatareclosetoyourvesselmaybeclearlyvisible
intheimageatthepointwheretheSideVision™
beamshittheseaoor.Inthisexample,the
shapesintheimageindicatevegetationattached
totheseaoor.
•Structure:thelighterregionsoftheSideVision™
imagerepresenttheseaoor.Itmaybepossible
todetectdifferencesinthebottommaterial(for
example,whereanareaofmudmeetsanarea
ofgravel)aswellassolidstructuressuchas
pipelinesandpiers.Largersolidstructures,and
seaoorrelief,mayrevealanareaofshadow
directedawayfromyourvessel.
Note:UnlikeDownVision™,SideVision™does
notprovidedirectdepthreadings.Thescale
shownacrossthetopoftheimageindicatesthe
distanceoffeaturesfromyourvessel.
Documentandproductinformation

2.8CHIRPDownVision™andCHIRP
SideVision™combined
ByinstallingandoperatingDownVision™and
SideVision™sonarsystemssimultaneously,you
canachieveafull180degreeviewofthewater
columndirectlybeneathandtothesidesofyour
vessel.
DownVisionandSideVisioncombinedbeams
Note:UsingDownVision™andSideVision™
togetherrequirestwoseparatesoundersinyour
system:
1.ADownVision™sounder:eitheran
internalsounderinaDownVision™
variantmultifunctiondisplay,oranexternal
DownVision™sonarmodule(suchasa
CP100).
2.AnexternalSideVision™sonarmodule(such
asaCP200).
CP100/CP200

Chapter3:Planningtheinstallation
Chaptercontents
•3.1 Installation checklist
•3.2 Required additional components
•3.3 Compatible multifunction displays
•3.4 Software updates
•3.5 Compatible transducers
•3.6 Tools required
•3.7 Typical systems
•3.8 Warnings and cautions
•3.9 General location requirements
•3.10 Product dimensions
Planningtheinstallation

3.1Installationchecklist
Installationincludesthefollowingactivities:
InstallationTask
1Planyoursystem.
2Obtainallrequiredequipmentandtools.
3Siteallequipment.
4Routeallcables.
5Drillcableandmountingholes.
6Makeallconnectionsintoequipment.
7Secureallequipmentinplace.
8Poweronandtestthesystem.
Schematicdiagram
Aschematicdiagramisanessentialpartofplanning
anyinstallation.Itisalsousefulforanyfuture
additionsormaintenanceofthesystem.The
diagramshouldinclude:
•Locationofallcomponents.
•Connectors,cabletypes,routesandlengths.
3.2Requiredadditionalcomponents
Thisproductformspartofasystemofelectronics
andrequiresthefollowingadditionalcomponentsfor
fulloperation.
•Compatible transducer; transom or through-hull
mount. Refer to 3.5 Compatible transducers for
a list of compatible products.
•Compatible Raymarine multifunction display.
Refer to 3.3 Compatible multifunction displays for
a list of compatible products.
•Data cables. Refer to Chapter 4 Cables and
connections for suitable cables. Some installations
may also require extensions to data, power or
transducer cables. Refer to the Chapter 4 Cables
and connections and Chapter 10 Spares and
accessories sections for more information.
CP100/CP200

3.3Compatiblemultifunctiondisplays
Thisproductiscompatiblewiththefollowing
LightHousepoweredRaymarinemultifunction
displays.
•aSeries,cSeries,eSeries.
•gSSeries.
Multifunctiondisplaysoftwarerequirements
Theoperationofthisproductrequiresthatyour
RaymarineLightHousepoweredMFDisrunning
LightHousesoftwareversion11orlater.
3.4Softwareupdates
Thesoftware runningontheproductcanbeupdated.
•Raymarineperiodicallyreleasessoftwareupdates
toimproveproductperformanceandaddnew
features.
•Youcanupdatethesoftwareforyourproductusing
aconnectedandcompatiblemultifunctiondisplay.
•Ifindoubtastothecorrectprocedureforupdating
yourproductsoftware,refertoyourdealeror
Raymarinetechnicalsupport.
Caution:Downloadingsoftware
updates
Thesoftwareupdateprocessiscarried
outatyourownrisk.Beforeinitiatingthe
updateprocessensureyouhavebacked
upanyimportantles.
Ensurethattheunithasareliablepower
supplyandthattheupdateprocessisnot
interrupted.
Damagecausedbyincompleteupdates
arenotcoveredbyRaymarinewarranty.
Bydownloadingthesoftwareupdate
package,youagreetotheseterms.
Planningtheinstallation

3.5Compatibletransducers
CP100compatibletransducers
Thisproductiscompatiblewiththefollowing
Raymarinetransducers.
Part
number
Descrip-
tion
Mounting
Type
Con-
struction
A80270CPT-100
Down-
Vision
trans-
ducer
TransomPlastic
A80277CPT-110
Down-
Vision
trans-
ducer
Through-
hull
Plastic
A80271CPT-120
Down-
Vision
trans-
ducer
Through-
hull
Bronze
CP200compatibletransducers
Thisproductiscompatiblewiththefollowing
Raymarinetransducers.
Part
number
Descrip-
tion
Mounting
Type
Con-
struction
A80281CPT-200
Side-
Vision
trans-
ducer
TransomMarine-
grade
stainless
steel/
plastic
3.6Toolsrequired
Productinstallationrequiresthefollowingtools:
ItemDescriptionQuantity
Powerdrill1
Pozidrivescrewdriver1
Drillbitofappropriatesize*1
Adhesivetape1
Note:*Theappropriatedrillbitsizeisdependent
onthethicknessandmaterialofthemounting
surface.
CP100/CP200

3.7Typicalsystems
Note:Thefollowingillustrationsshowthevarious
productsthatcanbeconnectedinatypicalsystem.
•SystemsthatincludeaCP200sonarmodule
canuseaSideVisiontransducerinplaceofthe
illustratedDownVisiontransducer.
•Forinformationonhowtoconnecttheproducts,
refer to the Chapter 4 Cables and connections
section.
•For information on available cables and
accessories, refer to the Chapter 10 Spares and
accessories section.
Example:basicsonarsystemfeaturing
multifunctiondisplay
D12937-1
1
4
2
3
ItemDescription
1Multifunctiondisplay
2Sonarmodule
3RayNetcable
4DownVisiontransducer
Example:expandedsonarsystemfeaturing
autopilotsystemandmultifunctiondisplay
SeaTalkng
D12938-1
SeaTalkng
RayNet
1
3
4
5
67
910
22
8
RayNet
ItemDescription
1Sonarmodule
2RayNetcables
3RayNetnetworkswitch
4Radarscanner
5Multifunctiondisplay
6DownVisiontransducer
7EvolutionACU
8SeaTalkngspurcable
9EvolutionEV
10Pilotheadcontroller
Planningtheinstallation

3.8Warningsandcautions
Important: Before proceeding, ensure that you
have read and understood the warnings and
cautions provided in the Chapter 1 Important
information section of this document.
3.9Generallocationrequirements
Importantconsiderationswhenchoosingasuitable
locationforyourproduct.
Thisproductissuitableformountingaboveorbelow
decks.
Theproductshouldbemountedwhereitwillbe:
•protectedfromphysicaldamageandexcessive
vibration.
•wellventilatedandawayfromheatsources.
•awayfromanypotentialignitionsourcesuchasan
engineroom,nearfueltanksoragaslocker.
Whenchoosingalocationfortheproduct,
considerthefollowingpointstoensurereliableand
trouble-freeoperation:
•Access—theremustbesufcientspaceto
enablecableconnectionstotheproduct,avoiding
tightbendsinthecable.
•Diagnostics—theproductmustbemountedin
alocationwherethediagnosticsLEDiseasily
visible.
Note: Not all products include a diagnostics
LED. Refer to the Chapter 6 System checks
and troubleshooting for more information.
•Electricalinterference—theproductshouldbe
mountedfarenoughawayfromanyequipment
thatmaycauseinterferencesuchasmotors,
generatorsandradiotransmitters/receivers.
•Magneticcompass—refertotheCompass
safedistancesectioninthisdocumentforadvice
onmaintainingasuitabledistancebetweenthis
productandanycompassesonyourvessel.
•Power—tokeepcablerunstoaminimum,the
productmustbelocatedascloseaspossibleto
thevessel’sdcpowersupply.
•Mountingsurface—ensuretheproductis
adequatelysupportedonasecuresurface.Refer
totheweightinformationprovidedintheTechnical
specicationforthisproductandensurethatthe
intendedmountingsurfaceissuitableforbearing
theproductweight.DoNOTmountunitsorcut
holesinplaceswhichmaydamagethestructure
ofthevessel.
Compasssafedistance
Topreventpotentialinterferencewiththevessel's
magneticcompasses,ensureanadequatedistance
ismaintainedfromtheproduct.
Whenchoosingasuitablelocationfortheproduct
youshouldaimtomaintainthemaximumpossible
distancefromanycompasses.Typicallythisdistance
shouldbeatleast1m(3ft)inalldirections.However
forsomesmallervesselsitmaynotbepossibleto
locatetheproductthisfarawayfromacompass.In
thissituation,whenchoosingtheinstallationlocation
foryourproduct,ensurethatthecompassisnot
affectedbytheproductwhenitisinapoweredstate.
CP100/CP200

3.10Productdimensions
162 mm (6.4 in) 171 mm (6.7 in)
72 mm (2.8 in)
225 mm (8.9 in)
205 mm (8.1 in)
D12941-1
Planningtheinstallation

Chapter4:Cablesandconnections
Chaptercontents
•4.1 General cabling guidance
•4.2 Connections overview
•4.3 Power connection
•4.4 Transducer connections
•4.5 Network connection
Cablesandconnections
