Raymarine hsb2 Series User guide

hsb2Series
Fishfinders
Owner’s
Handbook
Documentnumber:81195_1
Date:July2001

hsb2 Series Fishfinders iii
hsb2SeriesFishfinders
Owner’sHandbook
July2001
IntendedUse
Raymarinehsb2Series Fishfinders are intended for recreational fishfinding.
The combined Fishfinder/Chartplotter devices are intended for recreational
fishfinding and course chartplotting.The optional chartplotter function is
intendedas an aid to navigation and should not be reliedupon as a substitute
for official navigation charts.
SAFETYNOTICES
This equipment must beinstalled and operated inaccordance with the
instructions contained in this manual.Failure to do so can resultin personal
injuryand/or navigationalinaccuracies.Inparticular:
1.HIGH VOLTAGE.The LCD display unit contains high voltages.
Adjustments requirespecialized service proceduresand tools onlyavailable
to qualified service technicians – there are nouserserviceable parts or
adjustments. Theoperatorshouldneverremovethedisplayunitcoveror
attempttoservicetheequipment.
2.NAVIGATION AID. The chartplotterunit is only anaid to navigation. Its
accuracycan be affected by manyfactors, including equipment failureor
defects, environmental conditions, andimproperhandling or use.It is the
user’sresponsibility to exercise commonprudence and navigational
judgements.This unit should not be relied uponas a substituteforsuch
prudenceand judgement.
EMCConformance
All Raymarine equipment and accessoriesare designed tothe best industry
standardsfor use in the recreational marine environment.
Thedesignand manufactureof Raymarine equipment and accessories
conform to the appropriate ElectromagneticCompatibility (EMC) standards,
butcorrectinstallationisrequiredtoensurethatperformanceisnot
compromised.

iv hsb2 Series Fishfinders
Preface
This handbook describes the following Raymarine hsb2Series Fishfinders:
•L755RC Plus 7"Monochrome LCD FishfinderDisplay with Chartplotter
•L760 Plus 7" Color LCD Fishfinder Display
•L760RC Plus 7"ColorLCD Fishfinder Display with Chartplotter
•L1250Plus10.4" ColorLCDFishfinderDisplay
•L1250RC Plus10.4" Color LCD Fishfinder Display with Chartplotter
Note:ThecombinedFishfinder/Chartplotterdisplayunitsincludeacartridge
holder assembly whichcontains two slots for C-MAP NTchartcards.
FishfindersystemsrequireanappropriateRaymarinetransducerunitandin-
ter-connecting cable. Detailsfor selecting and installing the transducer are
describedin document number 81196,Transducers forhsb2SeriesFishfind-
ersOwner’sHandbook.
This handbook containsveryimportantinformation on the installation and
operation of your new equipment. Inorder to obtainthe bestresults in
operation and performance, please read this handbookthoroughly.
Raymarine’s Technical Servicesrepresentativesor your local dealerwillbe
available to answerany questions you may have.
TFTLCDDisplays
The colors of thedisplay may seem tovary when viewedagainst a colored
backgroundor in colored light. This is a perfectly normaleffect that willbe
seen withall color LCD displays.
IncommonwithallThinFilmTransistor(TFT)LCDdisplays,thescreenmay
exhibit a few (less than 20) wrongly illuminated pixels. Thesemay appearas
blackpixelsinalightportionofthescreen,orascoloredpixelsinblackareas.
CAUTION:
ToprovideprotectionagainstthedamagingeffectsofUVlight,it is
advisabletoreplacethesuncoverprovidedwhenthecolorLCDdisplayis
notinuse.

hsb2 Series Fishfinders v
RaymarineProductsandServices
Raymarine products aresupported by a network of Authorized Service
Representatives. Forinformation on Raymarine products and services,
contact eitherofthefollowing:
UnitedStates Raymarine,Inc.
22 Cotton Road,Unit D
Nashua, NH 03063-4219
USA
Telephone: [phone]
1-800-539-5539
Fax: [phone]
Europe Raymarine Ltd
AnchoragePark
Portsmouth,Hampshire
England PO3 5TD
Telephone: [phone]
Fax: [phone]
Or, you may contact us on the World Wide Web at www.raymarine.com.
Warranty
Toregisteryourhsb2Series displayunitownership, pleasetakeafewminutes
tofilloutthewarrantyregistrationcardfoundattheendofthishandbook.Itis
very importantthatyoucompletetheownerinformationandreturnthecardto
the factory in order to receive fullwarranty benefits.
TechnicalAccuracy
The technical and graphicalinformation containedin this handbook, to the
best ofour knowledge, was correct as it went to press.However, the
Raymarine policy of continuous improvement and updating may change
product specifications without prior notice. As a result, unavoidable
differences between the product and handbook may occur from time totime,
for which liability cannot beaccepted by Raymarine.

vi hsb2 Series Fishfinders
Raymarine is a registered trademark of Raymarine Limited.
SeaTalkis a registered trademark ofRaymarine Limited.
hsb2is a trademark of Raymarine Limited.
Pathfinder Plus is a trademark of Raymarine Limited.
ThisproductcontainstechnologyprovidedunderlicensebyAcornGroupplc.
The copyright of this intellectual property is acknowledged by Raymarine,
Inc.asareAcorn’strademarksandpatents.Acorn’sworldwidewebaddressis
http://www.acorn.com.
© Raymarine, Inc. 2001

Contents vii
Contents
