Preface iii
hsb2PLUS Series LCD Display Owner’s
Handbook
September 2002
INTENDED USE
The display units detailed in this handbook may form part ofnavigational
radar systems intended for light marine use. These displays and radar
systems are only an aid to navigation.
SAFETY NOTICES
This radar equipmentmust beinstalled and operated in accordance with the
instructions contained in this manual. Failure to do so can resultin personal
injuryand/ornavigationalinaccuracies.Inparticular:
1.HIGH VOLTAGE.The LCDdisplayunitandscannerunitcontain
highvoltages.Adjustmentsrequirespecializedserviceproceduresand
toolsonlyavailabletoqualifiedservicetechnicians–thereareno user
serviceablepartsor adjustments.Theoperatorshouldneverremovethe
displayunitcoverorattemptto servicetheequipment.
2.ELECTROMAGNETIC ENERGY.The radar scanner transmits
electromagnetic energy. It is important that the radaris turned off whenever
personnel are required to come closeto the scanner to perform work onthe
scannerassemblyor associatedequipment.
Itisrecommendedthattheradarscannerismountedoutofrangeof personnel
(above head height).
Avoidlookingdirectlyattheantennaasyoureyesarethemostsensitivepartof
thebody toelectromagnetic energy.
Whenproperlyinstalledandoperated,theuseofthisradarwillconformtothe
requirements ofANSI/IEEE C95.1-1992 Standardfor SafetyLevels with
RespecttoHumanExposuretoRadioFrequencyElectromagneticFields,3Hz
to300GHzandNRPB,BoardStatementonRestrictionsonHumanExposure
toStaticandTimeVaryingElectromagneticFieldsandRadiation.DocNRPB,
N0. 5 (1993).
4.NAVIGATIONAID.Thisunitisonlyanaidtonavigation.Itsaccuracycan
be affected by many factors, including equipment failure or defects,
environmentalconditions,andimproperhandlingoruse. Itisthe user’s
responsibilityto exercisecommon prudenceand navigational judgements.
Thisradar unitshouldnotberelieduponasasubstituteforsuchprudenceand
judgement.
81186_3.book Page iii Thursday, August 22, 2002 8:23 AM

iv hsb2PLUS Series LCD Display
Raymarine productsare supported by a network of Authorized Service
Representatives.For informationonour productsand services,contacteither
ofthe following:
UNITEDSTATES RaymarineInc.
22 Cotton Road,Unit D
Nashua, NH 03063-4219
Telephone: [phone]
[phone]
Fax: [phone]
EUROPE RaymarineLimited
AnchoragePark
Portsmouth
HampshirePO35TD
England
Telephone: [phone]
Fax: [phone]
Copyright© Raymarine Ltd.2002
The technical and graphicalinformation contained inthishandbook, to the
bestofourknowledge,wascorrectasitwentto press.However,our policyof
continuousimprovement and updating may change product specifications
withoutpriornotice.Asaresult,unavoidabledifferencesbetweentheproduct
and handbook mayoccur fromtime to time,for which liability cannot be
acceptedby Raymarine.
Raymarine is a registered trademarkof Raymarine Limited.
SeaTalkis a registered trademark ofRaymarineLimited.
hsb2is atrademarkof RaymarineLimited.
Pathfinder Plus is a trademark of Raymarine Limited.
ThisproductcontainstechnologyprovidedunderlicensebyAcornGroupplc.
The copyright ofthisintellectualproperty is acknowledged byRaymarine
Ltd., asare Acorn’s trademarks and patents. Acorn’s world wide webaddress
is http://www.acorn.com.
81186_3.book Page iv Thursday, August 22, 2002 8:23 AM

Preface v
Preface
This handbook describes the radar andchart aspects of thefollowing hsb2
(PLUS) series display systems from Raymarine:
This handbook also describes the useof multi-display systems.
Note:Radar systems are supplied with an appropriate Raymarine scanner
unit andinter-connectingcable. Detailsfor installing thescannerare de-
scribedin thePathfinderRadar Scanner Owner’s Handbook.
The Raychart (RC)display unitsinclude acartridge holderassembly which
containstwo slots for C-MAP NT chart cards.
This handbook contains very important information on theinstallation and
operation of your new equipment. In orderto obtainthe best results in
operation and performance, please readthis handbookthoroughly.
Raymarine’s TechnicalServices representativesor your local dealerwillbe
available to answer any questions you may have.
Warranty
To register your display unit ownership,please take afew minutes to fillout
thewarranty registrationcard found at the end of this handbook. It isvery
important that youcompletethe owner informationand return the card to the
factoryin ordertoreceivefullwarrantybenefits.
EMC Conformance
All Raymarine equipment and accessories aredesigned to the bestindustry
standardsfor use in the recreational marine environment.
Thedesignand manufactureof Raymarineequipmentandaccessories
conform to theappropriate Electromagnetic Compatibility (EMC) standards,
butcorrectinstallation isrequiredtoensurethatperformanceisnot
compromised.
System Display Scanner Chartplotter
Pathfinder Radar RL70 PLUS Yes No
Raychart Chartplotter RC520PLUS No Yes
Combined Pathfinder Radar/Chartplotter RL70RC PLUS Yes Yes
