Raypak VERSA 105 User manual

®
AABBOOVVEE--
GGRROOUUNNDD
PPOOOOLL
HHEEAATTEERR
model 105
•105,000 BTUH
•Natural or propane gas
•Indoor/outdoor
•Standard stackless top
•User-friendly control panel
•High efficiency for economical
operation
•Electronic ignition or millivolt pilot
•Lightweight combustion chamber
•Copper fin tube heat exchanger design
•Completely field serviceable
•Small footprint
•Glass-lined cast iron castings
VVEERRSSAA
Photo courtesy of Ester Williams, Delair Group
The Pool and Spa Heating ExpertsSM

VERSA 105 Above-Ground Pool Heater
42-1/8"
INDOOR
DRAFTHOOD
5"
3-3/8"
2-1/2"
23-7/8"
2-3/4"
ELECTICAL
7-3/4"
GAS
12-3/4"
32-7/8"
STACKLESS
27"
OUTDOOR
STACK
45 3/8"
20-1/8"
3/4" GAS
CONNECTION
Raypak, Inc.
2151 Eastman Ave, Oxnard, CA 93030 • [phone] • Fax [phone]
Raypak Canada Limited
2805 Slough Street, Mississauga, Ontario, Canada L4T IG2 • [phone] • Fax [phone]
www.raypak.com
Litho in U.S.A. ©1999 Raypak, Inc. Catalog No. 6100.25E Effective: 03-15-05 Replaces: 03-01-04 Raypak reserves the right to change these specifications without notice.
Heating Capacity
The table below shows the heating capacity of the VERSA 155 in
temperature rise per hour for a given pool size. For example, the
heater will raise the temperature of a 400-square-foot pool 1 °F per
hour.
Patented Econotherm Heat Exchanger
Your VERSA is equipped with a unique all-copper-fin-tube heat
exchanger, designed for efficient heat transfer, and built to provide
years of trouble-free performance. Both header castings are made
of porcelainized cast iron for durability and resistance to corrosion.
Your VERSA is also available with optional bronze headers for
completely rust-free operation.
Two-Year Limited Warranty against defects in materials and
workmanship (see warranty for details). In addition, every VERSA is
thoroughly tested in simulated conditions before shipment.
Note: Outdoor stack & indoor drafthoods can be supplied but
must be ordered separately.
Fig # 9296
Model
BTUH Input
(000)
Water
Connections Casting
Shipping Weight (lbs.)
Heater w/Stackless Top
C-105 105 1-1/2” Glass-lined
cast iron 113
B-105 105 1-1/2” & 2” Bronze 113
Temp. rise per hour
300 400 500
1-1/4 °F 1 °F 3/4 °F
Specifications
Above-Ground Pool Size (Square Feet)
