Rayvision X11ZS series User manual

4CH/8CH/16CH DVR
Quick Start Guide
1. Packing........................................P. 3
2. Hard Disk Installation................P. 4
3. Front Panel Controls..................P. 6
4. Rear Panel Connectors..............P. 7
5. Live Operations….....................P. 10
6. Playback Operations................P. 13
7. PTZ Operations……...................P.14

2011.07.05 4CH/8CH/16CH-J01(V1.0) Quick Start Guide P.2

2011.07.05 4CH/8CH/16CH-J01(V1.0) Quick Start Guide P.3
1. DVR
2. Quick Start
3. IR Remote Control
4. Battery
5. CD
6. Hard Disk Mount
7. Screws
8. Power Adaptor
9. SATA Cord
Note: Standard shipping products do not include HDD

2011.07.05 4CH/8CH/16CH-J01(V1.0) Quick Start Guide P.4
Step１) Take out the screws as pictures show.
Back panel 3 screws
Step 2) Open the cover follow the arrow direction.

2011.07.05 4CH/8CH/16CH-J01(V1.0) Quick Start Guide P.5
Step３) Connect SATA & Power wire to Hard Disk and put it on the rack mount.
Step 4) Put the cover back and fix it with 3 screws as Step 1 indicated.
Note: After installation, please initialize Hard Disk before starting to record. For more detailed
information, please check out User Manual Utility Setup for reference.

2011.07.05 4CH/8CH/16CH-J01(V1.0) Quick Start Guide P.6
①LED Display
Power: Power is on.
HDD: Hard disk is in use.
LAN: Connected to the internet (in red: Remote user logged in).
REC: Recording.
PLAY: Playing back.
②BACKUP/ESC
In LIVE mode, press to display the BACKUP menu. In SETUP
mode, press to return to previous page.
③PIP
In LIVE mode, display with picture in picture format.
④ZOOM
In LIVE or PLAYBACK mode, enlarge the display of a channel.
⑤PTZ
In LIVE mode, display PTZ menu.
⑥FREEZE
In LIVE mode, freeze the screen.
⑦T-SRH
Display the search menu.
⑧Arrow Keys
：In SETUP mode, press to move cursor up. In PLAYBACK
mode, press to slow down.
：In SETUP mode, press to move cursor down. In PLAYBACK
mode, press to stop playing back.
：
In SETUP mode, press to increase value. In PLAYBACK mode
press to play forwards.
：In SETUP mode, press to reduce value. In PLAYBACK mode,
press to play rewind.
⑨USB 2.0
Port for USB external devices (Rear port for USB mouse device)
⑩MENU
In LIVE mode, press to display menu. In PLAYBACK mode, press
to pause playback.
⑪MUTE
Enable / Disable key tone.
⑫UTILITY
In LIVE mode, display UTILITY menu.
⑬STATUS
In LIVE mode, display STATUS menu.
⑭REC
Start or stop recording.
⑮PLAY
Play back in normal speed.
⑯IR Sensor
Input sensor for the remote control.
⑰ENTER
In SETUP mode, press to enter sub menu. In Live mode, switch to
full screen display.

2011.07.05 4CH/8CH/16CH-J01(V1.0) Quick Start Guide P.7
4CH REAR PANEL CONNECTORS
①HDMI
HDMI port. (Option)
②VIDEO IN
BNC input ports for cameras, 4 in total.
③SPOT
SPOT output.
④AUDIO OUT
RCA output port for audio signal.
⑤AUDIO IN
RCA input port for audio signal.
⑥LAN
Network port.
⑦VGA
VGA port.
⑧MAIN
BNC port for the main monitor.
⑨EXTERNAL I/O
External I/O port.
⑩USB
Port for USB mouse device (Front port for USB external
devices)
⑪IR
IR extension cable jack.
⑫DC 12V
Socket for a DC 12V input.

2011.07.05 4CH/8CH/16CH-J01(V1.0) Quick Start Guide P.8
8CH REAR PANEL CONNECTORS
1 2 3
12
7118 109
4 5 6
①HDMI
HDMI port. (Option)
②VIDEO IN
BNC input ports for cameras, 8 in total.
③SPOT
SPOT output.
④AUDIO OUT
RCA output port for audio signal.
⑤AUDIO IN
RCA input port for audio signal.
⑥LAN
Network port.
⑦VGA
VGA port.
⑧MAIN
BNC port for the main monitor.
⑨EXTERNAL I/O
External I/O port.
⑩USB
Port for USB mouse device (Front port for USB external
devices)
⑪IR
IR extension cable jack.
⑫DC 12V
Socket for a DC 12V input.

2011.07.05 4CH/8CH/16CH-J01(V1.0) Quick Start Guide P.9
16CH REAR PANEL CONNECTORS
①MAIN
BNC port for the main monitor.
②VIDEO IN
BNC input ports for cameras, 16 in total.
③AUDIO IN
RCA input port for audio signal.
④LAN
Network port.
⑤AUDIO OUT
RCA output port for audio signal.
⑥SPOT
SPOT output.
⑦EXTERNAL I/O
External I/O port.
⑧eSATA
External SATAhard disks port for expanding recording space.
⑨VGA
VGA port.
⑩USB
Port for USB mouse device (Front port for USB external
devices)
⑪IR
IR extension cable jack.
⑫DC 12V
Socket for a DC 12V input.

2011.07.05 4CH/8CH/16CH-J01(V1.0) Quick Start Guide P.10
You can monitor all the channels, listen to audio signal and have some related operations under
LIVE mode. This paragraph describes the IR remote control, mouse operation and on screen
graphical icons under LIVE mode.
Table 5-1 Functions of remote control under LIVE mode
Button
Description
REC
Start/Stop recording.
PLAY
Start playing back the most recently recorded segment.
ENTER／MODE
Switch to full screen or multi split display.
MENU／
Enable/ Disable setup Menu.
BK-UP
Enable/ Disable backup menu.
ESC
Return last menu.

2011.07.05 4CH/8CH/16CH-J01(V1.0) Quick Start Guide P.11
Table 5-2 Graphical icons that will display after right-clicking your mouse under LIVE
mode
Icon
Description
Resting the cursor on this icon will bring up the following
four menu icons.
Main menu.
Search menu.
Backup menu.
PTZ mode.
Turn on/off recording.
Playback.
Resting the cursor on this icon will bring up the following
five display icons.
FREEZE.
PIP.
ZOOM, double the screen size.
AUTO-sequence.
LOCK, activate the key lock.
Full screen display.
Quad display.
9 display
16 display

2011.07.05 4CH/8CH/16CH-J01(V1.0) Quick Start Guide P.12
Table 5-3 Description of on screen graphical icons in LIVE mode
圖示
說明
Recording is on
Live Audio is on
Live Audio is off
Motion detected on the channel
Video loss detected on the channel
USB device detected
Connected to the LAN cable.
AUTO-seq is on
Freeze is on, screen is frozen
LOCK is on
PTZ control is on
Shows the current hard disk space has been used
(99% mean used 99%, remain 1%)
Lower right of each CH will show the current time
Icon
Description
/
Image quality (High/Low)
/
Full screen
Record
Snapshot
Record and snap shot file saving path setup
Enable / Disable Shortcut Toolbar

2011.07.05 4CH/8CH/16CH-J01(V1.0) Quick Start Guide P.13
Switch to PLAYBACK mode by pressing “PLAY” under the LIVE mode, the graphical icon
will show up on the upper center of the screen and the operation panel ( see below picture) will
show up at right lower corner of the screen. You can drag the panel by mouse to place it on any
location of your screen.
Table 6-1 Remote control functions under the PLAYBACK mode
Button
Description
ENTER/ MODE
Switch to full screen, quad
MENU /
Turn on/off PAUSE.
PLAY
Play back at normal speed.
/ SLOW
Play back at slower speed. The speed will be slowed to 1/2, 1/4, 1/8, by
each pressing of the button till the slowest limitation of the normal speed.
/
Fast rewind. Each press increases the speed to the next level. There are
six speeds: 2x, 4X, 8X, 16x, 32X and 64X.
/
Fast forward. Each press increases the speed to the next level. There
are six speeds: 2x, 4X, 8X, 16x, 32X and 64X.
/
Stop playback.
Table 6-2 The mouse operation under the PLAYBACK mode
Icon
Description
「/ 」Fast rewind
「/ 」Fast forward
/
Play/pause
「▲/ SLOW」， slow playback
「▼/ ■」stop playback
Playback step by step
Full screen display
Quad display
9 screen display
16 screen display
Zoom-in display
If you want to monitor single channel, please choose a channel and click left
button of mouse two times.

2011.07.05 4CH/8CH/16CH-J01(V1.0) Quick Start Guide P.14
Switch to the PTZ mode by pressing “PTZ” button under the LIVE mode. The PTZ icon
will appear on upper left side of screen and the control panel will appear on the down right side
of screen.
Table 7-1 Mouse operation under the PTZ mode
Icon
Description
Leave PTZ Mode，back to the LIVE mode
Pre-set number N. (0~255)
Go to pre-set number N.
Set current PTZ location at pre-set number N.
「TOUR」， press to activate pre-set tour＊
「PIP」， Set current PTZ location as the start of line-scan. ＊
「FREEZE」， Activate line-scan. ＊
「ZOOM」， Set current PTZ location as the end of line-scan. ＊
To move PTZ in 360°
PTZ zoom in; PTZ zoom out
PTZ focus in; PTZ focus out.
PTZ IRIS open, PTZ IRIS close.
Below functions need support from specific PTZ manufacturer.
Please check user manual of your PTZ for more detail.
to
AUX 1~8,「AUTO」Key ＋Number key「1~8」
「Backup」, Customized function。
＊PTZ communication protocols from different brands aren’t compatible 100%
sometimes. Therefore, some of these functions may be unavailable.
