RC JEEP 2020 JT User manual

Thank you for choosing Rough Country for all your vehicle needs.
Please read instructions before beginning installation. Check the kit hardware against the kit contents shown below. Be
sure you have all needed parts and know where they go.
If question exist, please call us @1-800-222-7023. We will be happy to answer any questions concerning this product.
Check all fasteners for proper torque. Check to ensure for adequate clearance between all components.
Periodically check all hardware for tightness.
KIT CONTENTS:
Tire Carrier x1
Gusset x1
Wheel Adapter Mount x1
Adapter Mount x1
2.5” Washers x4
Gaskets x4
TOOLS NEEDED:
9/16 wrench and socket
3/4 wrench and socket
Ratchet
Torque Wrench
13/32 Bit
Drill Motor
Painters Tape
Pen
Tape Measure
Width of Tire Straight Edge
HARDWARE INCLUDED:
3/8-16 x 1 Hex Head Bolts x8
3/8-16 x 1-1/4 Hex Head Bolts x4
3/8 Flat Washers x24
3/8 Lock Washer x4
3/8-16 Lock Nuts x8
3/8-16 Nuts x4
1/2-13 x 1-1/4 Hex Head Bolts x3
1/2” Flat Washers x6
1/2-13 Nylock Nut x3
M14x1.5 Lug Nuts x3
Splined Socket Key x1
Torque Specs:
Size Grade 5 Grade 8 Size Class 8.8 Class 10.9
5/16” 15 ft/lbs 20ft/lbs 6MM 5ft/lbs 9ft/lbs
3/8” 30 ft/lbs 35ft/lbs 8MM 18ft/lbs 23ft/lbs
7/16” 45 ft/lbs 60ft/lbs 10MM 32ft/lbs 45ft/lbs
1/2” 65 ft/lbs 90ft/lbs 12MM 55ft/lbs 75ft/lbs
9/16” 95 ft/lbs 130ft/lbs 14MM 85ft/lbs 120ft/lbs
5/8” 135ft/lbs 175ft/lbs 16MM 130ft/lbs 165ft/lbs
3/4” 185ft/lbs 280ft/lbs 18MM 170ft/lbs 240ft/lbs
JEEP 2020 JT Bed Mount Tire Carrier
921105440

1. Install the gusset to the inside of the tire carrier using 4 of the supplied 3/8-16 x 1 hex head bolts (8) 3/8 flat washers
and (4) 3/8-16 nylock nuts. See Photo 1 and 2.
2. Torque the 3/8 hardware to 35 ft-lbs. using a 9/16 wrench and socket. See Photo 3.
3. Install the adapter mount onto the front side of the carrier using 4 of the supplied 3/8-16 x 1 hex head bolts (8) 3/8
flat washers and (4) 3/8-16 nylock nuts. Torque to 35 ft-lbs. using a 9/16 wrench and socket. See Photo 4.
4. Install the wheel mount into the installed adapter mount using 3 of the supplied 1/2-13 x 1-1/4 hex head bolts (6) 1/2”
flat washers and (3) 1/2-13 nylock nuts. See Photo 5. Do not tighten at this time.
5. Measure the wheel and tire that will be installed onto the mount. Laying a straight edge on the tire, take a measure-
ment of the tire height from the mounting flange of the wheel. Take measurement . See Photo 6.
Photo 1 Photo 2
Photo 3 Photo 4
Photo 5 Photo 6
Install the gusset into the carrier. Install the 3/8 hardware.
Tighten the installed hardware. Install the adapter mount.
Install the adapter mount. Take measurement of wheel and tire height.
INSTALLATION INSTRUCTONS

6. Use a tape measure to set the recorded dept of the wheel mount. Torque the hardware to 90 ft-lbs. using a 3/4”
wrench and socket. See Photos 7 and 8.
7. Locate the 4 gaskets. See Photo 9.
8. Install 1 of the gaskets onto each mount on the bottom of the tire carrier mount. See Photo 10.
9. Apply painters tape onto the bed floor of the vehicle. See Photo 11.
10. Set the tire carrier on the tape in the bed of the vehicle. See Photo 12.
Photo 7 Photo 8
Photo 9 Photo 10
Photo 11 Photo 12
Set the recorded depth of the wheel mount. Tighten the installed hardware.
Locate the 4 gaskets. Install the gaskets on the mounts.
Apply painters tape onto the bed floor. Set the tire carrier on the tape in the bed.

11. Temporarily install the wheel and tire onto the tire carrier. Set the carrier in the desired position. Double check clear-
ances in-between the tire and the tire carrier. See Photo 13.
12. Use a pen to mark the 4 mounting locations onto the painters tape. See Photo 14.
13. Check clearances under the bed before drilling. Use a 13/32 bit to center drill the marked holes
through the bed floor. See Photo 15.
14. Remove the painters tape, clean the surface and any drilled shavings.
15. Install the tire carrier into the bed over the drilled holes. Secure the tire carrier using 4 of the supplied 3/8-16 x 1-1/4
hex head bolts (4) 3/8 flat washers. See Photo 16.
16. Install the 4 supplied 2.5” round washers under the bed onto the 3/8 bolts from the top with (4) 3/8 flat washers, (4)
3/8 lock washers and (4) 3/8-16 nuts. Torque to 35 ft-lbs. using a 9/16 wrench and socket. See Photo 17.
17. Install the wheel and tire onto the carrier secure using the supplied lug nuts. See Photo 18.
Photo 13 Photo 14
Photo 15 Photo 16
Photo 17 Photo 18
Set the tire carrier position. Mark the position of the carrier.
Drill the 4 marked holes. Install the supplied hardware.
Install the 2.5” washer with the 3/8 hardware. Install the wheel and tire.
