RCA RTB1016OM User manual

User Manual
Manuel de l’utilisateur
Manual del usuario
RTB1016
It's important to read this instruction prior to using your new product for the first time.
Il est important de lire ce manuel d’instructions avant d’utiliser votre nouveau produit
pour la première foi.
Es importante que lea este libro de instrucciones antes de usar su nuevo producto por
primera vez.

EN-1
Important Information
THE LIGHTNING FLASH AND ARROWHEAD
WITHIN THE TRIANGLE IS A WARNING SIGN
ALERTING YOU OF “DANGEROUS VOLTAGE”
INSIDE THE PRODUCT.
THE EXCLAMATION POINT WITHIN THE TRI-
ANGLE IS A WARNING SIGN ALERTING YOU OF
IMPORTANT INSTRUCTIONS ACCOMPANYING
THE PRODUCT.
CAUTION: TO REDUCE THE RISK OF ELECTRIC
SHOCK, DO NOT REMOVE COVER (OR BACK). NO
USER SERVICEABLE PARTS INSIDE. REFER SER-
VICING TO QUALIFIED SERVICE PERSONNEL.
WARNING: TO PREVENT FIRE OR ELECTRICAL SHOCK HAZARD, DO NOT EXPOSE THIS PRODUCT TO
RAIN OR MOISTURE.
CAUTION: USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF PROCEDURES OTHER THAN
THOSE SPECIFIED MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.
CAUTION: DANGER OF EXPLOSION IF BATTERY IS INCORRECTLY REPLACED. REPLACE ONLY WITH
THE SAME OR EQUIVALENT TYPE.
WARNING: TO BE COMPLETELY DISCONNECT THE POWER INPUT , THE MAINS PLUG OF APPARATUS
SHALL BE DISCONNECTED FROM THE MAINS. THE MAINS PLUG OF APPARATUS SHOULD NOT BE
OBSTRUCTED OR SHOULD BE EASILY ACCESSED DURING INTENDED USE.
Service Information
This product should be serviced only by those
specially trained in appropriate servicing techniques.
Main plug is used as the disconnect device, it shall
remain operable and should not be obstructed
duringintendeduse.Tobecompletelydisconnected
the apparatus from supply mains, the main plug of
the apparatus shall be disconnected from the mains
socket outlet completely.
Caution
Invisible laser radiation when open and interlocks
defeated. Avoid exposure to beam. Class 1 laser
product.
This system must be opened only by qualified
technicians to prevent accidents caused by the
aser beam.
Copyrights
This product incorporates copyright protection
technology that is protected by methods claims in
certain U. S. Patents and other intellectual property
rights owned by Macrovision Corporation and other
rights owners. Use of this copyright protection
technology must be authorized by Macrovision
Corporation, and is intended for home and
other limited viewing uses only unless otherwise
authorized by Macrovision Corporation. Reverse
engineering or disassembly is prohibited.
SEE MARKING ON BACK OF PRODUCT

EN-2
Important Information
Important Battery Information
• Do not mix different types of batteries or new and
old batteries. Do not use rechargeable batteries.
• In order to avoid any risk of explosion, observe the
polaritiesindicatedinsidethebatterycompartment.
Replaceonlywiththetypeofbatteriesspecified.Do
not dispose of them in a fire or recharge them.
• If you are not using the remote control for a long
period of time, remove the batteries.
Illustrations contained in this document are for rep-
resentation only.
Please respect the environment and
prevailing regulations. Before you dis-
pose of batteries or accumulators, ask
your dealer whether they are subject
to special recycling and if they will ac-
cept them for disposal.
CLASS 1 LASER PRODUCT
APPAREIL À LASERDE CLASSE 1
PRODUCTO LASER DE CLASE 1
WARNING
To reduce the risk of fire or electric shock,
do not expose this product to rain or mois-
ture. No objects filled with liquids, such as
vases, should be placed on the apparatus.
CAUTION:
This product utilizes a laser. Use of controls or
adjustments or performance of procedures other
than those specified may result in hazardous
radiation exposure. Do not open covers and do
not repair yourself. Refer servicing to qualified
personnel.
This Class B digital apparatus complies with
Canadian ICES-003.
Cet appareil numérique de la classe B est
conforme à la norme du NMB-003 du Cana-
da.
This product contains a low
power laser device.
Double insulation when servicing use
only identical replacement parts.

EN-3
Important Safety Instructions
Please Read and Save for Future Reference.
Some of the following information may not apply
to your particular product; however, as with any
electronic product, precautions should be observed
during handling and use.
Read these instructions.
•
Keep these instructions.
•
Heed all warnings.
•
Follow all instructions.
•
Do not use this apparatus near water.
•
Clean only with a dry cloth.
•
Do not block any ventilation openings. Install in
•
accordance with the manufacturer’s instructions.
Do not install near any heat sources such
•
as radiators, heat registers, stoves, or other
apparatus (Including amplifiers) that produce
heat.
Only use attachments / accessories specified by
•
the manufacturer.
Do not defeat the safety purpose of the polarized
•
or grounding-type plug. A polarized plug has
two blades with one wider than the other. A
grounding type plug has two blades and a third
grounding prong. The wide blade or the third
prong is provided for your safety. If the provided
plug does not fit into your wall outlet, consult an
electrician for replacement of the obsolete outlet.
Protect the power cord from being walked on
•
or pinched particularly at plugs, convenience
receptacles, and the point where they exit from
the apparatus.
Unplug this apparatus during lightning storms or
•
when unused for long periods of time.
Use only with a cart, stand, tripod,
•
bracket, or table specified by the
manufacturer, or sold with the
apparatus. When a cart is used, use
caution when moving the cart/
apparatus combination to avoid
injury from tip-over.
Refer all servicing to qualified service personnel.
•
Servicing is required when the apparatus has been
damaged in any way, such as the power cord or
plug is damaged, liquid has been spilled or objects
have fallen into the apparatus, the apparatus has
been exposed to rain or moisture, does not operate
normally, or has been dropped.
Additional Safety Information
• The apparatus shall not be exposed to dripping or
splashing and that no objects filled with liquids,
such as vases, shall be placed on the apparatus.
• Always leave sufficient space around the product
forventilation.Donotplaceproduct in or on a bed,
rug, in a bookcase or cabinet that may prevent air
flow through vent openings.
• Donotplace lightedcandles,cigarettes,cigars,etc.
on the product.
• Connect power cord only to AC power source as
marked on the product.
• Care should be taken so that objects do not fall
into the product.
• Do not attempt to disassemble the cabinet. This
product does not contain customer serviceable
components.
If your product operates on batteries, adhere to the
following precautions:
A. Any battery may leak electrolyte if mixed with a
different battery type, if inserted incorrectly, or if
all batteries are not replaced at the same time.
B. Any battery may leak electrolyte or explode if
disposed of in fire or an attempt is made to charge
a battery not intended to be recharged.
C. Discard leaky batteries immediately. Leaking
batteries can cause skin burns or other personal
injury.Whendiscardingbatteries,besuretodispose
of them in the proper manner, according to your
state/provincial and local regulations.
D. Batteryshallnotbe exposedtoexcessiveheat such
as sunshine, fire or the like.
]
Portable Cart
Warning

EN-4
This device complies with part 15 of the FCC
Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any
interference received, including interference that
may cause undesired operation.
This equipment has been tested and found to
comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits
are designed to provide reasonable protection
against harmful interference in a residential
installation. This equipment generates, uses
and can radiate radio frequency energy and, if
not installed and used in accordance with the
instructions, may cause harmful interference to
radio communications.
However, there is no guarantee that interference
will not occur in a particular installation. If this
equipment does cause harmful interference
to radio or television reception, which can be
determined by turning the equipment off and
on, the user is encouraged to try to correct the
interference by one or more of the following
measures:
Reorient or relocate the receiving antenna.
•
Increase the separation between the equipment
•
and receiver.
Connect the equipment into an outlet on a
•
circuit different from that to which the receiver
is connected.
Consult the dealer or an experienced radio / TV
•
technician for help.
WARNING: Changes or modifications to this unit
not expressly approved by the party responsible
for compliance could void the user's authority to
operate the equipment.
FCC Information
chapter J. Applicable at the date of manufacture.
Ventilation
You must adequately ventilate the product. Make
sure there is adequate space around the unit to
provide proper air flow for ventilation. See diagram.
This product complies with DHHS Rules 21 CFR Sub-
For your Safety
The AC power plug is polarized
(one blade is wider than the other)
and only fits into AC power outlets
one way. If the plug won’t go into
the outlet completely, turn the
plug over and try to insert it the
other way.
If it still won’t fit, contact a qualified electrician to
change the outlet, or use a different one. Do not at-
tempt to bypass this safety feature.
Removing the power plug is the only way to com-
pletely remove power from your product. Make
sure the power plug remains easily accessible.
Note:
This unit has been designed to play back BD-video
with region “A” and DVD-video with region “1”. You
cannot play back BD-video or DVD-video that are
labeled for other regions. Look for the symbols on
the right on your BD-video or DVD-video. If these
region symbols do not appear on your BD-video or
DVD-video, you cannot play back the disc in this unit.
The letter or number inside the globe refers to region
of the world. A BD-video or DVD-video labeled for a
specific region can only be played back in the unit
with the same region code.
7 cm
7 cm
10 cm
10 cm
10 cm

EN-5
Things to Consider before You Connect
• Ensure that the mains (AC power) supply in your house complies with that indicated on the identification
sticker located on the back of your unit.
• Installyourunithorizontally,awayfromanysourceof heat (fireplace)orappliancescreatingstrongmagnetic
or electric fields. The components of this unit are sensitive to heat. The maximum ambient temperature
should not exceed 35°C / 95°F.
• Leave enough space around the unit to allow adequate ventilation: 10 cm/4 inches on either side and above
the top, and 5 cm/2 inches at the rear.
• The humidity of the room should not exceed 75%. If you have to use the unit outdoors, do not expose it
to rain or splashing water. The apparatus should not be exposed to dripping or splashing and no objects
filled with liquids, such as vases, should be placed on the apparatus.
• Moving the unit from a cold place to a warm one can cause condensation on some components inside
the unit. Let the condensation disappear on its own before turning the unit on again.
• Before moving the unit, make sure the disc tray is empty.
• Where the mains plug or an appliance coupler is used as a disconnect device, the disconnect device shall
remain readily operable.
• Other important use and cleaning information at the end of the booklet.
Connections and Setup
What’s Included
Subwoofer
One Pig-Tail
antenna wire
Remote control and 2
AAA batteries
Center speaker
Left and right front
speakers Left and right Sur-
round speakers
Features
• Full high-definition video playback at up to 1080p resolution for an amazing viewing experience.
Upconversion of standard definition DVDs for enhanced picture quality at up to 1080p over an HDMI
connection.
• Rich multi-channel surround sound.
• Easy and simple HDTV connection using a single HDMI cable (cable not included).
• Multiple outputs for connecting your home theater system or amplifier.
• PIP functionality that lets you display primary and secondary video at the same time (if available on the
Blu-ray Disc).
• Pop-up menu display without interrupting playback (if available on the Blu-ray Disc).
• HDMI 1080p/60fps output (Blu-ray Disc only) that provides smooth playback of video with a frame rate
of 60 frames per second (TV must be connected with an HDMI cable and be compatible with 1080p 60
frame).
Composite
video cable Main unit (receiver)

EN-6
Connections and Setup
Connecting to your TV
Method 1 (best)
HDMI
• Connect the HDMI OUT jack on the rear of the unit
to the HDMI IN jack on your TV using a HDMI cable
(not included).
• You can select the resolution of the player’s HDMI
output signals (HDMI Auto, 1080p, 1080i, 720p,
480p and 480i) to match your TV’s resolution
capabilities, please see instructions on page 21 for
details.
TV
HD
HD
MI
To HDMI
input
To HDMI
output
HDMI cable
(not supplied)
TV
VIDEO IN
VIDEO IN
Y
P
P
B
R
Video Cable
included
Component
Video Cable
(not supplied)
Green Blue Red
Method 3
Method 2
The FM antenna connects to the FM terminal on the
system’s back panel. It must be hooked up in order
to receive clear reception.
FM antenna
Connecting the Antenna
Notes
• Refer to the owner’s manual of the connected TV
as well.
• HDMI, the HDMI logo and High-Definition
Multimedia Interface are trademarks or registered
trademarks of HDMI licensing LLC.
• If your television is a high definition television
with an HDMI input, we highly recommend you
use the unit’s HDMI output to get the highest
possible video resolution.
Method 2 (good)
Component video jacks (Pr, Pb, Y)
• The component video jacks are color-coded
green, blue and red.
• Additional component video cables (not supplied)
are required. They are usually color-coded green,
blue and red.
• Connect the component video OUT jacks on the
unit to the component video IN jacks on your TV.
Method 3 (basic)
Composite video jack (yellow)
• This video jack is color-coded yellow.
• Use the video cable with yellow plugs (supplied)
for good picture quality.
• Connect the video OUT jack on the unit to the IN
jack on your TV.
Notes
• If one of the devices is not working, check that all
the cables have been inserted properly into the
jacks.
• If your component has only one input for audio
(mono), connect it to the left (white L/Mono)
audio jack on the TV and don’t connect the right
audio part of the cable.
Method 1

EN-7
Connections and Setup
Connecting your player to a wired net-
work router (optional)
Connect an Ethernet cable (CAT5 or better with
RJ45 connector) to the ETHERNET jack on the back
of your player and to an Ethernet jack on a network
hub or broadband router.
Notes:
• Do not connect a modular phone cable to the
ETHERNET jack.
• When plugging or unplugging the cable, hold
the connector on the end of the cable. When
unplugging, do not pull on the cable. Press
down the lock tab and pull the connector out
of the jack.
• Because there are various connection
configurations, follow the instructions from
your Internet service provider.
LAN
LAN cable
(not included)
Connecting AUDIO OUT to an auxilliary
Audio System (optional connection)
This system has AUDIO OUT jacks allowing you to
connect to auxiliary audio systems such as a second
audio amplifierorperhapsawireless audiotransmitter.
Audio System
AUDIO IN
Audio cable
(not included)
Red White
Method 1 (best)
Using Digital Optical Input
Connect components capable of outputting
Dolby digital surround sound (e.g. TV or SAT/Cable
Box) or standard PCM (stereo) format digital signals.
Use a fiber optical cable for this digital audio con-
nection. (Cable not included).
Press OPTICAL button on remote control or
SOURCE button on main unit to select OPTICAL
input.
Connecting AUDIO IN from External
Sources such as TV
Method 2 (good)
Using AUDIO IN Jacks
Connect the AUDIO IN jacks from the unit to the
AUDIO OUT jacks on TV, SAT/Cable Box, VCR or
other component. Press either SOURCE button on
the main unit or AUX button on the remote control
to select AUX mode.
OR
OR
TV SAT/
Cable BoxVCR
AUDIO OUT
Audio cable
(not included)
White
Red
Hub or broadband router

EN-8
Connecting the Speakers
Speaker wires are color-coded to match the terminals. Connect the speaker wire from the back of each
speaker to the corresponding color terminal at the back of the unit. Press down the tab to open the terminal
and insert the wire. Release the tab to lock wire in the terminal.
Connections and Setup
Subwoofer
Purple and Black
Green and Black Red and
Black White and Black
Blue and Black
Gray and Black
Rear Speakers
(Surround Sound)
Front Speakers
Right Left
Center Speaker
Insert
Right Left
Press
Release
To adjust each speaker volume level for optimum listening experience.
(1) Press LEVEL button / or on the remote control to select FL (front Left speaker).
(2) Press or buttons to adjust the value up or down (between -10dB and +10dB).
(3) Repeat step (1) and (2) for the other speakers FR, CT, SW, SL, SR.
Speaker gains may be set to levels of up to +10dB, actual max levels may also depend on your Volume
Setting.
Note:
When connecting the speakers, make sure the polarities (“+”speaker wire to“+”on the receiver)
of speaker wires and terminals match. For example, red wire to red terminal on the receiver. If the
cords are reversed, the sound will be distorted. Do not let the speaker wires touch each other, it
will damage the system’s amplifier.

EN-9
Connections and Setup
Note:
Center speaker provided with this unit is
magnetically shielded to protect your TV
set. It is not recommended to place speak-
ers without magnetic shield near the TV
set.
1. Left, Right (Front Speakers)
Front speakers carry primarily music and sound ef-
fects.
2. Center
In surround mode, the center speaker carries most
of the dialog as well as music and effects.
It should be set between the left and right speak-
ers.
3. Surround (Rear Speakers)
The surround speakers’ overall sound balance
should be as close as possible to the front speakers.
Proper placement is vital to establish an evenly dis-
tributed sound field.
4. Subwoofer
A subwoofer is designed to reproduce powerful low
bass effects (explosions, the rumble of spaceships,
etc.).
Courtesy Dolby Laboratories
Front Speaker Placement
For best results, follow the speaker placement
below.
Alignment
Align the center speaker evenly with (A) or slightly
behind (B) (the left and right speakers), but not
ahead of them.
Angle
Place the left and right speakers to form a 45-degree
angle with your favorite viewing position to dupli-
cate the soundtrack mixer’s perspective.
Height
The three front speakers should be as close as pos-
sible to the same height. This often requires placing
the center speaker directly on top (A) or beneath (B)
the TV set.
Positioning Speakers
A
B
1
3
3
1
4
2

EN-10
Connections and Setup
Overview of Controls - Front Panel Controls
Better Surround Placement
Location
If possible, place surround speakers to either side of
the listening area, not behind it.
Height
If space permits, install surround speakers 2-3 feet above
viewers.This helps to minimize localization effects.
Aiming
Aim surround speakers straight across the room,
not down at viewers, to help create a more open,
spacious surround sound field.
Alternative Surround Placement
Rear wall
If rear wall mounting is the only choice, aim the
speakers at each other (A), towards the front (B) or
towards the sidewalls (C, D).
Experiment with placement until sounds seem to
surround you, rather than come from behind you.
No adjacent walls
Surround speakers can go on stands facing each
other to approximate sidewall mounting (A), or to
the sides or rear of the viewing area, aimed upwards;
they can go right on the floor, or preferably, a few
feet offthe floor such as on end tables (B).
Test Tone/Channel Balance
Channel Balance
Your receiver is equipped with a test signal generator
to help balance the audio level for each channel (see
Page 8 for details).
Level Adjustment and Surround Channel Level
Expectation
Even though you adjust the surround channel to be
as loud as the others on the test signal, you may find
that surround channels seems quieter for actual TV
and Movie content. This is because producers use
surround for subtle atmospherics and ambience,
and only rarely for special effects.
Press to open or close
the disc tray.
Adjust the
volume.
Start/pause
playback.
Select the input sources.
Press repeatedly to select:
BD/USB, OPTICAL, AUX,
TUNER.
Connect a USB flash
drive to this port.
Switch the unit
on and off.

EN-11
Overview of Controls
ON/OFF Press to turn on your unit, or put your unit in standby
mode. When your unit is in standby mode, power is
still entering your unit. To disconnect power, unplug
the power cord.
OPEN/CLOSE Press to open or close the disc tray.
R(red),
G(green),
B(blue),
Y(yellow)
When playing a Blu-ray Disc that has a Java application,
press to control playback. For more information, see the
documentation that came with the Blu-ray Disc.
Numbers In playback mode, press GOTO button, then press
the number buttons to enter a title, chapter, track,
or time.
CLEAR Press to clear an input.
GOTO Press to search for a title, chapter, track or time.
VOL+/- Press to increase or decrease the volume.
MUTE Press to turn offsound. Press again to turn the sound
back on.
POP UP During Blu-ray Disc playback, press to open a menu that
lets you control Blu-ray Disc playback.
During DVD playback, press to open the DVD title menu
(if available).
SKIP / Press to go to the next or previous chapter (Blu-ray Disc/
DVD) or track (CD).
In tuner mode, press to go to the next higher /lower
preset station.
,/TUNE
/TUNE ,
Navigate through the menus. The left and right arrows
also tune the radio frequency in the tuner mode.
OK Confirms your selection.
EXIT Press to return to the previous menu.
When in a Menu or file browser window, you can press
this button to move you back to a previous menu level
or folder level.
REV Press to fast reverse.
FWD Press to fast forward.
STOP Press to stop playback.
PLAY Press to start or resume playback.
STEP/ Press once to pause playback.
Press twice, then each time you press this button, the
picture advances one frame.
LEVEL Toggle channels for different level settings. Adjusts the
value using or .
INFO Accesses the Info menu.
MEM/ANGLE Stores a station in tuner mode.
Accesses the camera angle function for Blu-ray or DVD
discs if available.
ZOOM Press to zoom in on the video. Each time you press this
button, the magnification level changes. This button is
only used for DVD discs .
REPEAT Press to repeat the current title, chapter, track, or
repeat all.
A - B Performs point-to-point repeat playback on DVD.

EN-12
Overview of Controls
Note:
Insert the two “AAA” (includ-
ed with this unit) batteries
into the remote control prior
to use.
SETUP Press to access the Dimmer (DIM), Sleep (SLP) and test
tone setting (the settings will be shown of the unit’s
front panel display).
Dimmer Setup
To adjust the brightness of display on front of Blu-ray
disc player.
Press SETUPbut t o n and the“DIM 0 ” a p p e ars, th e n u se
/ buttons to select “DIM 0”,“DIM 1”or “DIM 2”.
Sleep Setup
Press SETUP button and the“DIM 0”appears. Use /
buttonstoselect"SLPOFF",then pressthe /button s
select 30M, 60M, 90M or 120M.
The unit will automatically turn offonceitcountsdown
the sleep time.
Test Tone
Press SETUP button and the“DIM 0”appears. Use /
buttons to select “TEST OFF”, then press / buttons
to select FL (front left speaker), FR (front right speaker),
CT (center speaker), SW (subwoofer), SL (surround left
speaker) or SR (surround right speaker), then press OK
button. You’ll hear a test tone coming from the speaker
you select. Press EXIT button to exit this function.
To adjust the speaker volume levels, press LEVELbut t on
and use / buttons to select the speaker you are
testing, then use or buttons to adjust the value
up or down (between -10dB and +10dB).
PiP Press to turn PiP (picture in picture) mode on or off. This
function is only available by Blu-ray discs if available
on disc.
AUDIO Accesses the audio function. PiP Audio can be selected
through cursor if secondary Audio is available on the
Blu-ray Disc.
SURROUND In AUX/OPTICAL/TUNER mode, press to show current
sound mode
(CH 5.1or STEREO) on the front of Blu-ray disc player
display.
To change the current setting, first press the
SURROUND button, then use / buttons on the
remote control to select STEREO or CH5.1.
SUBWOOFER Press to display current Subwoofer setting (SOFT/
PWRFUL/STRONG/BALANCEl).
To change settings, first press to access the current
Subwoofersetting,thenuse / buttonsontheremote
control to change the current setting.
MENU Accesses the disc menu during playback (on DVD).
SUBTITLE Accesses the subtitle function.
PiP Subtitle can be selected through cursor if secondary
subtitle is available on the Blu-ray Disc.
AUX Press to select AUX input source.
OPTICAL Press to select OPTICAL input source.
TUNER Press to select TUNER mode (FM radio).
BD/USB Press to select the BD/USB mode.

EN-13
Quick Setup
When turned on for the first time or after resetting
it to the factory default, the Quick Setup menu will
pop up as following.
Follow the below steps to make the basic settings for
using the Blu-ray player.
1. Press OK to perform Quick Setup.
• To exit Quick Setup, press button to select
“No”and then press OK.
The display for Player Menu Settings selection
appears.
2. Press or button to select English, French or
Spanish and press OK.
3. Press button to select “Next” and press
OK, then the display for Resolution selection
appears.
Would you like to do Quick Setup?
Yes No
Player Menu Settings
English
French
Spanish
Next Return
Resolution
1080p
1080i
720p
Next Return
HDMI Auto
480p
480i
4. Press or button to select HDMI Auto, 1080p,
1080i , 720p, 480p or 480i and press OK.
(For details about the Resolution, please see page
21.)
6. Press or button to select 16:9 Wide, 16:9
Pillarbox, 4:3 Pan and Scan or 4:3 Letterbox and
press OK.
(FordetailsabouttheTVAspect,pleaseseepage
21.)
7. Press button to select “Next” and press OK.
The display for “Quick Setup complete” appears
and press OK to exit the setup.
5. Press button to select “Next” and press
OK, then the display for TV Aspect selection
appears.
TV Aspect
16:9 Pillarbox
4:3 Pan and Scan
4:3 Letterbox
Next Return
16:9 Wide
Notes
• You can restore the settings to the factory
settings (see page 24).
• You can run Quick Setup again from “Quick
Setup“ in “Settings” (see page 25).

EN-14
Playing a Blu-ray Disc or DVD
Regional Coding
This unit has been designed to play back BD-video
encoded for region “A” and DVD-video encoded for
region “1”. You cannot play back BD-video or DVD-
video that are labeled for other regions. Look for the
symbols on the right on your BD-video or DVD-video.
If these region symbols do not appear on your BD-
video or DVD-video, you cannot play back the disc in
this unit. The letter or number inside the globe refers
to region of the world. A BD-video or DVD-video
labeled for a specific region can only be played back
in the unit with the same region code.
Basic playback (Blu-ray Disc or DVD)
1. Turn on your television set.
2. Press ON/OFF button on the remote control or
ON/STANDBY button located on the unit’s front
panel. Press BD/USB button on the remote
control.
3. Press OPEN/CLOSE button to open the disc
tray.
4. Place a disc onto the disc tray with the label side
up.
5. Press OPEN/CLOSE button again to close the
disc tray.
6. After loading a disc, playback starts automatically,
orthediscmenuappears. Ifthedisc menu appears,
select the Play option and press OK button to
begin playback if “Optical Disc AutoPlay” is set
on. (see page24)
Playback
• To start playback, press button.
Pause
• To pause playback, press button.
• To resume normal playback, press button.
Frame advance
• Press PAUSE twice. “Step Fwd” is displayed.
• Each time you press PAUSE button, the picture
advances one frame.
• Press to resume normal playback.
Stop
• To stop playback, press button. The Settings
menu is displayed.
• To resume playback, press on the remote con-
trol or press or button to select DVD/BD-
ROM, then press OK button. Depending on the
disc, playback starts where it stopped or at the
beginning of the disc.
Accelerated play
• To fast forward or fast reverse, press (fast for-
ward) or (fast reverse).
• Each time you press one of these buttons, the
fast-forward or fast-reverse speed increases from
Fast X2, Fast X4, Fast X8, Fast X16, Fast X32, Fast
X64, to Fast X128. Press to resume normal play-
back.
Changing chapter/track
• Press either the SKIP or button according
to the desired direction.
• Press the SKIP button to skip to the start of the
current chapter or skip to previous chapters.
• Press the SKIP button to skip to the beginning
of the next chapter.
Displaying Blu-ray Disc information
• Press INFO button, your unit displays information
about the Disc, such as type of disc, elapsed time
of the current title, total time of the current title,
total number of chapters.
• Press INFO button again to exit.
Note: The information displayed for discs other
than Blu-ray Discs will be different.

EN-15
Special Functions
Primary video
Secondary video
Notes
• The available options of Audio vary from different
disc format.
• PiP Subtitle is not available for all discs. It only
applies to Blu-ray discs that supports picture-in-
picture features.
• Some discs allow you to turn PiP on/offonly via
the disc menu.
Selecting a play source
• Press SOURCE button on the front panel of the
unit repeatedly to select BD/USB, OPTICAL,
AUX, TUNER.
• Press BD/USB button on the remote control to
select BD/USB mode.
• Press OPTICAL button on the remote control to
select OPTICAL mode.
• Press AUX button on the remote control to select
AUX mode.
• Press TUNER button on the remote control to
select TUNER mode.
Selecting the audio mode
1. Press AUDIO button. Your unit displays audio
channel information, such as 01/03 Eng Dolby
Digital. 01 indicates the currently selected
audio channel. 03 indicates the total number of
audio channels. Eng (English) indicates the audio
language. Dolby Digital describes the currently
selected audio format.
2. Press button and press or button to select
an audio mode, then press OK button.
Selecting the camera angle (Blu-ray Disc and
DVD disc)
Some discs offer different camera angles for specific
scenes. To change the camera angle:
1. Press MEM/ANGLE button on the remote
control. The selected angle will be displayed on
the display bar at the top of the TV screen.
2. Press button and press or button to select
the desired angle, then press OK button. If the
disc was recorded using a single camera angle,
this function is not available.
Using a disc popup menu
1. During Blu-ray or DVD playback, press POP UP
button. The Blu-ray popup menu or the title
menu of DVD disc opens.
2. Press , , or buttons to select an option,
then press OK button.
Selecting subtitles
You can display subtitles on the TV screen and
select a subtitle language from those included on
the DVDs.
1. Press SUBTITLE button on the remote control.
The selected language will be displayed on the
display bar at the top of the TV screen.
2. Press button and press or button to select
your desired language, then press OK button.
PiP Subtitle can be selected through cursor if
secondary subtitle is available on the Blu-ray Disc.
Searching for a title, chapter or elapsed time
1. During playback, press GOTO button one or
more times to select a search mode.
• Press once to select the Goto Title mode.
• Press twice to select the Goto Chapter mode.
• Press three times to select the Goto Time
mode.
2. Press the number buttons to enter the title
number, chapter number or time, then press OK
button. Your unit goes to the title, chapter, or
time you entered.
Repeating a title, chapter or CD track
• Press REPEAT button one or more times to select
a repeat mode.
Using PiP (picture-in-picture) mode
Some Blu-ray Discs are compatible with picture-in-
picture (PiP) mode. In PiP mode, the primary video
is displayed on the full screen, and the secondary
video is displayed in a small window.
• Press PiP button to turn PiP mode on or off.
• Press AUDIO or SUBTITLE button to turn the
audio/subtitle for the video in the PiP window on
or off. Then use cursor buttons and OK button to
select your preferred options.

EN-16
Playing an audio CD
1. Press ON/OFF button on the remote control or
ON/STANDBY button located on the unit’s front
panel.
2. Press OPEN/CLOSE button to open the disc tray.
3. Place a CD on the disc tray with the label facing
up, then press OPEN/CLOSE button to close
the disc tray. It may take a few seconds for the CD
to load.
4. After loading a disc, playback starts automatically.
5. To eject the CD, press OPEN/CLOSE button.
To control audio CD playback:
• To start playback, press button.
• To pause playback, press button. The sound
is muted when your unit is in pause mode. To
resume normal playback, press button.
• To stop playback completely, press button. To
start playback again, press button. Playback
starts at the beginning of the CD.
• To fast-forward, press button. To resume
normal playback, press button.
• To fast-reverse, press button. To resume
normal playback, press button.
• Press either the or button according to the
desired direction.
Press the button to skip to the start of the
current track or skip to previous tracks. Press the
button to skip to the beginning of the next
track.
• To select a track, press GOTO button once, enter
the track number with the number buttons, then
press OK button.
Playing les on a data disc
Playing les on a data disc
To view JPEG les
1. Press or button to select Pictures, then
press OK button.
2. Press , , or button to select a file (or
a folder) and press OK or button to start
playback. If you selected a folder, the files in this
folder are displayed. Press or button to
select a file and press OK or button to start
playback.
3. Press button to return to the Pictures menu.
4. Press or button to select an option, then
press OK button.
• Settings - This option enables you to define
Slide Show Effects (None, Horizontal Scroll,
Fade and Shutter) and Slide Show Delay (5
Seconds, 2 Seconds, 1 Seconds, No Delay, 10
Seconds, 15 Seconds and 30 Seconds). After
setting, press to highlight OK and then
press OK button to confirm.
• Main Menu - Returns to the main menu.
• Previous folder - Returns to the previous
folder.
• Start Slide Show - This option enables you
to view picture (files) one after another
automatically.
You can play JPEG files that have been recorded on
a CD-R or CD-RW on this unit.
Insert a data disc containing picture files. A seletion
menu appears on the screen:
Settings
Pictures
Connected

EN-17
Watching Movies with Netix
To use Netflix service, connect this player to your
network, and configure the network settings if they
are not finished yet. (See “Network Setting” section
on page 24).
Launching Netix movie
1. In home menu, press or button to select
Connected.
2. Press button and then press OK button to
enter.
Creating Netix account
If you are not a Netflix Member: Select “no”. Read
the instructions displayed on the TV screen, and
visit http://www.netflix.com from your PC. Sign
up to create your account, then select “I’m now a
member”.
If you are a Netflix Member: Select “Yes”.
Activating Netix player
To play streaming video via Netflix service, Netflix
player needs to be activated. Read the instructions
displayed on the TV screen, and visit http://www.
netflix.com/activate on your PC. Sign in to your
Netflix account, if necessary. Enter the activation
code displayed on the TV screen.
Playing USB ash (“thumb”) drive
Insert a USB thumb drive containing picture into
your unit. A selection menu appears on the screen:
Press or button to select Pictures, then press
OK button.
(To play pictures, please see Playing les on a data
disc for details.)
If an optical disc containing picture files is inserted
at the same time, the system will enter the source
selection screen and you can press or button
to choose Optical Disc or USB .
If you choose Optical Disc option, please follow the
operation instructions in “Playing files on a data
disc” .
Using a USB device Watching movies with Netix
Notes
• It is recommended to plug the USB flash
drive when the unit is off.
• It does not support USB hard disc mass
storage device, multi-card reader and other
USB computer peripheral.
• Do not disconnect the USB flashdrive when
you are playing it, it may corrupt the data.
• If you cannot easily insert the USB device,
you may have inserted it incorrectly. Try to
turnover the device and then insert again.
Settings
Pictures
Connected

EN-18
Note
Resolution of video streamed from Netflix
varies depending on communication speed or
bitrate of each content, etc.
Preparing Instant Queue
To play streaming video via Netflix service, Netflix
service, you must have an appropriate Netflix
subscription and the player needs to be registered
for Netflix service. See previous section for details
on how to activate.
Now you can view Netix streaming video.
After having activated Netflix player and prepared
Instant Queue, movies and TV episodes in your
Instant Queue appear on the TV screen. Select
your desired one using the remote control of the
player. You can control Netflix streaming video with
the following buttons of the remote control of this
player:
(Play) To start playing movie.
To pause playback while in PLAY mode.
(Stop) To stop playing and return to a list of
movie titles.
(Pause) To pause playing movie.
To start playing while in PAUSE mode.
(Right) To pause playing and open a list of
scenes. Pressing further proceeds to
the next scene.
(Left) To pause playing and open a list of
scenes. Pressing further proceeds to
the previous scene.
(Up) To stop playing and return to a list of
movie titles.
(FWD) To pause playing and open a list of
scenes. Fast forward play starts.
(REV) To pause playing and open a list of
scenes. Fast reverse play starts.
OK Allows you to enter or exit“trick play
mode”. Trick Play mode allows you
to skip to a specific scene in a movie
quickly
Watching movies with Netix
Pandora is personalized internet radio that is
designed to help you discover new music you’ll love
mixed in with music you already know.
To use the Pandora service, please ensure your unit
is successfully connected to a network with internet
access. (See“Network Setting”section on page 24).
For users that already have a Pandora account,
skip to step 4.
Step 1:
Creating an activation code on the player
a. In home menu, press or button to select
Connected, and then press button to choose
Pandora.
b. Select“I am new to Pandora”from option list and
press OK button.
c. You will be given an activation code, then use
this activation code to generate a new account
on your PC (See Step 2).
Step 2:
Creating a new Pandora account on your PC
a. Go to http://www.pandora.com/rca and enter
the activation code.
b. Follow the instructions to create an new
account.
Step 3:
Now that you’ve successfully created a Pandora
account on your PC, log in using your player.
Step 4:
Using an existing Pandora account
a. In home menu, press or button to select
Connected, and then press button to choose
Pandora.
b. Select “I have a Pandora account” from the
option list and press OK button.
c. Sign in with your Pandora account.
Enjoying music with Pandora

EN-19
Some BD-ROMs contains BD-Live features that
can be downloaded to the external memory (local
storage) for enjoyment.
In order to access BD-Live functions, the Blu-ray
disc player must be properly configured for BD-
Live internet access, and it must be equipped with
additional memory (USB Flash Drive).
1. Insert a USB Flash Drive of at at least 1GB capacity
(not supplied) into the USB jack on the front
panel of the Blu-ray disc player.
• The USB device is used as the local storage.
• Make sure that the USB device is properly
inserted into the Blu-ray disc player.
• If there is not at least 100Mbyte of free space
on the USB device, you should choose “Erase
Blu-ray Storage” from the BD-Live settings
(see page 25).
2. Connect the Blu-ray disc player to a network
(see page 7).
3. Turn the Blu-ray disc player on.
4. Set “BD-Live Internet Acces” to “Limit Access” or
“Always Allow Access” in BD-Live Settings
(see page 25).
5. Insert a BD-ROM with BD-Live and select the BD-
Live selection following the instructions on the
disc menu.
• The operation method differs depending on
your BD-ROM. Please refer to the instructions
coming with the disc.
Enjoying BD-Live
Notes
• Do not remove the USB device when using the
BD-Live function.
• Depending on your connection environment, it
may take time to connect to the Internet or the
Internet may not be connected.
IMPORTANT!
Many BD-Live compatible discs require content
to be downloaded onto USB flash drive in order
to access the available BD-Live features.
A USB flash drive with at least 1GB of free space
needs to be inserted prior to inserting the BD-
Live compatible disc.
AUX/OPTICAL
You can connect Audio or Audio-Video devices such
as a TV, Game System, VCR, Satellite or Cable Box
to this unit using the AUDIO IN jacks at the back of
the unit. The AUX input provides an analog audio
connection especially suitable for older devices. The
OPTICAL input provides a digital audio connection
which will allow you to experience true digital
surround sound, if the connected device is capable
of providing Dolby digital surround signals. This
unit will take the audio from the connected device
and play the audio through the speakers.
Connecting Auxiliary Components
Refer to Connecting AUDIO IN from external
sources such as TV for details on connecting the
auxiliary components to the unit (see page7).
Selecting AUX/OPTICAL Mode
Press either the SOURCE button on the main unit
or AUX/OPTICAL button on the remote control to
select AUX or OPTICAL input.
Sound Output in AUX or OPTICAL
Mode
• You may change the Surround Sound setting
to STEREO mode if you like (see instructions
under Overview of Controls). However, we
recommend you leave the system in full surround
(“CH 5.1”) mode
• If the auxiliary audio signal is mono, there will be
no output from some speakers in full surround
mode.
Note: Optical input cannot decode DTS signals.
