RCA RC5225P User manual

DVD Player
User's a ual
Changing a,n.

Important Information
This symbol indicates that this product
incorporates double insulation between
hazardous mains voltage and user
accessible parts. When servicing use only
identical replacement parts.
This symbol indicates
"dangerous voltage" inside the
product that presents a risk of
electric shock or personal injun/.
,_ This symbol indicates
important instructions
accompanying the product.
FCC NOTE (for U.S.A.):
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or
more of the following measures.
•Reorient or relocate the receiving antenna.
• increase the separation between the equipment and receiver.
• Connect this equipment into an outlet on a circuit different from that to which
the receiver is connected.
•Consult the dealer or an experienced radio/TV technician for help.
This class Bdigital apparatus meets all requirements of the Canadian
Interference--Causing Equipment Regulations.
Product Registration
Please fill out the product registration card and return it immediately. Returning
this card allows us to contact you if needed.
Keep your sales receipt to obtain warranty parts and service and for proof of
purchase. Attach it here and record the serial and model numbers in case you
need them. The numbers are located on the back of the player.
Model No. RC5225P
Serial No.
Purchase Date:
Dealer/Address/Phone:
WARNING
To reduce the risk of fire or shock hazard, do
not expose this DVD player to rain or moisture.
No objects filled with liquids, such as vases,
shall be placed on the apparatus.
CAUTION
THIS PRODUCT UTILIZES A LASER. USE OF
CONTROLS OR ADJUSTMENTS OR
PERFORMANCE OF PROCEDURES OTHER
THAN THOSE SPECIFIED HEREIN MAY
RESULT IN HAZARDOUS RADIATION
EXPOSURE. DO NOT OPEN COVERS AND
DO NOT REPAIR YOURSELF. REFER
SERVICING TO QUALIFIED PERSONNEL.
CAUTION
FCC Regulations state that unauthorized
changes or modifications to this equipment may
void the user's authority to operate it.
Note:
This DVD player is designed and manufactured
to respond to the Region Management
Information. If the Region number of a DVD
disc does not correspond to the Region
number of this DVD player, this DVD player
cannot play the disc. The Region number for
this DVD player is Region No 1,
No_:
This device isprotected by U.S. patent numbers
4,631,603 and 4,577,216 and 4,819,098 and
other intellectual property rights. The use of
Macrovision's copy protection technology in the
device must be authorized by Macrovision and is
intended for home and other limited pay-per-
view uses only, unless otherwise authorized in
writing by Maerovision. Reverse engineering or
disassembly is prohibited.
II
! I
LASER
PRODUCT

Introduction
Introduction
Your DVD player is equipped with some special features. The following information summarizes
some of these features.
The On-Screen Information Display
The Info Display is a menu bar that you can bring up to access certain features while discs are
playing. Icons represent the different features supported by your DVD player. By selecting
different Info Display icons, you can access features including Scene Snip, Repeat, Audio, Subtitles,
Bookmarks and Camera Angle.
Time Search
The Time Search feature lets you go to a point on a disc by entering the elapsed time in the ot"l-
screen time display. For example, if your favorite scene in a movie is one hour and twelve minutes
after the beginning of the movie, you can enter 01:12:00 into the time display and go right to that
point in the movie.
The Bookmarks Feature
You can bookmark a point on a disc that you can go to quickly with the bookmark feature. You
can store up to six bookmarks. For example, if you have a favorite scene in a movie, you can
bookmark it so you can return to it without having to fast forward or reverse to find the exact
scene.
Ratings Limits and Scene Snip
Your DVD player allows you to set ratings limits and passwords. For example, you can set the
DVD player so that any movie with a PG-13 rating or above requires a password to be entered.
You can use Scene Snip to edit out sections of a disc. When this disc is played, you must have the
password to view the original version.
Since not all discs contain ratings, you can also decide if you want to allow free access or require
a password to view unrated discs.
Scene Again TM
When you are watching a DVD disc, by pressing the GO BACK-AGAIN button on the remote'you
can replay ascene instantly. The Scene Again TM feature goes back approximately ten seconds and
replays both video and audio while turning on the subtitles.
(e)lPruSurround
The TmSurround ®option can be used to simulate a six-speaker listening experience through two
speakers.
SRS/TruSurround and the (@) symbol are trademarks of SRSLabs, Inc. in the United States and selected
foreign countries. TruSurround technology is incorporated under license from SRSLabs, Inc.

Table of Contents
Introduction .............................................................................................. 1
Chapter 1: Connections & Setup
Things to Consider Before You Connect ......................................................................... 6
Protect Against Power Surges ................................................................................... 6
Protect Components from Overheating ................................................................... 6
Position Cables Properly to Avoid Audio Interference ............................................ 6
Connection Pictures ................................................................................................... 6
Types of DiscsYour DVD Player will Play .................................................................. 6
Choose Your Connection .................................................................................................. 7
Cables Needed to Connect Components to Your TV ............................................... 7
DVD Player + TV with AudioNideo Input Jacks ....................................................... 8
DVD Player + TV + VCR .............................................................................................. 9
DVD Player + TV + Dolby Pro Logic, Dolby Digital ®or DTS®Receiver ...... i............ 10
DVD Player + TV + 5.1-Channel Audio/Video Receiver .......................................... 12
DVD Player + TV + VCR + Satellite Receiver ............................................................ 14
The Jacks onthe Back of the DVD Player ..................................................................... 16
Install Batteries in the Remote ...................................................................................... 17
Turn on the TV and DVD Player ..................................................................................... 17
How to Find Your TV's Video Input Channel ................................................................ 18
How to Move Around the DVD Player's Menu System ............................................... 19
Set the Menu Language ................................................................................................. 19
Setting Other Options .................................................................................................... 19
A Quick Tour of the Remote .......................................................................................... 20
Component Buttons ................................................................................................. 20
DVD Buttons ............................................................................................................. 20
Chapter 2: Playing DVDs
Regional Coding ............................................................................................................. 24
Using Different Menus ................................................................................................... 24
Loading and Playing Discs ............................................................................................. 24
Using a Disc Menu .......................................................................................................... 25
Using the On-Screen Info Display ................................................................................. 27
Time Display .............................................................................................................. 28
Selecting a Title ........................................................................................................ 28
Selecting a Chapter .................................................................................................. 28
Using Scene Snip Editing ....................................... t................................................. 29
Selecting Subtitles .................................................................................................... 31
Changing the Audio Language ............................................................................... 32
Using the Repeat Feature ........................................................................................ 33
Using Bookmarks ...................................................................................................... 34
Changing the Camera Angle ................................................................................... 35
Manufactured under licensefrom Dolby Laboratories. "Dolby" and the double-D symbol are trademarks of Dolby Laboratories.
Confidential unpubLished works. ©1992-1997 Dolby Laboratories, Inc. All rights reserved.
DTSis a registered trademark of Digital Home Theater Systems, Inc.
•2

Table of Contents
Disc Playback Features Using the Remote ........................................................ _........... 36
Fast Motion Playback (Picture Scan) ....................................................................... 36
Freeze Frame and Frame Advance .......................................................................... 36
Slow Motion Playback .............................................................................................. 36
Chapter Advance ...................................................................................................... 36
Scene Again TM ........................................................................................................... 37
Subtitles .................................................................................................................... 37
Audio Language ....................................................................................................... 37
Camera Angle. .......................................................................................................... 37
Scene Snip Edit ......................................................................................................... 37
Zoom ......................................................................................................................... 38
Chapter 3: Playing Audio CDs
Using the Info Display .................................................................................................... 40
Using the Time Display ............................................................................................. 40
Selecting aSpecific Track ......................................................................................... 40
Selecting a Play Mode .............................................................................................. 41
Using the Program Play Feature .............................................................................. 41
Editing a Playlist................................................................................................. 42
Using the Repeat Feature ....................................................... ................................. 42
Using IntroScan ........................................................................................................ 43
Using Bookmarks ...................................................................................................... 44
Dub Assist ................................................................................................................. 45
Chapter 4: Playing Video CDs
What is a Video CD?................................................................................................. 48
The Video CD Disc Menu .......................................................................................... 48
Video CD Information Display ................................................................................. 49
Selecting a Specific Track ................................................................................... 50
Selecting a Specific Index .................................................................................. 50
Using the Repeat Feature .................................................................................. 50
Changing the Audio Channel Output .............................................................. 51
Skipping Tracks ......................................................................................................... 51
Chapter 5: The DVD Player's Menu System
The DVD PLayerMenu System ................................................................................. 54
Two Types of Menu Items: Path and Action ........................................................... 54
The Play/Resume Play Option .................................................................................. 54
The Play Mode menu ............................................................................................... 55
Selecting a Play Mode ....................................................................................... 55
How to Create a Program ................................................................................. 56
Creating a Program List for an Audio CD ......................................................... 56
Creating a Program List for a DVD Disc............................................................ 57
Editing a Program ........... ................................................................................... 57
Autoplay ............................................................................................................. 58
Dub Assist........................................................................................................... 58
3

Table of Contents
The Lock Menu ......................................................................................................... 59
Locking Your DVD Player ................. :................................................................. 59
Unlocking Your DVD Player ............................................................................... 59
Changing Your Password ................................................................................... 59
Editing Your Scene Snip Disc Library ................................................................ 60
Setting the Ratings Limit ................................................................................... 60
How to Set DVD Limits .................................................................................. 60
Changing to a Different Country's Rating System ....................................... 61
Rated Titles ......................................................................................................... 61
Unrated Titles ..................................................................................................... 62
Front Tray Lock ................................................................................................... 62
System Test ......................................................................................................... 62
The Display Menu ..................................................................................................... 63
TV Image ............................................................................................................ 63
Front Display ...................................................................................................... 64
On-Screen Displays ............................................................................................. 64
The Sound Menu ...................................................................................................... 65
Digital Output .................................................................................................... 65
Analog Output ................................................................................................... 66
2-Channel Stereo ........................................................................................... 66
5.1-Channel Out ............................................................................................. 67
Sound Logic ........................................................................................................ 68
The Languages Menu ............................................................................................... 69
Changing the Player Menus Language Preference ......................................... 69
Changing the Disc Menus Language Preference ............................................. 69
Changing the Audio Language Preference ...................................................... 70
Changing the Subtitle Language Preference ................................................... 70
Glossary ..................................................................................................................... 71
Language Code List .................................................................................................. 72
Chapter 6: Other Information
Troubleshooting ....................................................................................................... 74
Handling Cautions ................ :................................................................................... 77
Maintenance of Cabinet .......................................................................................... 77
Formation of Condensation .................................................................................... 77
Handling Discs .......................................................................................................... 77
Cleaning Discs ................................................................................................ ;.......... 77
Universal Remote ..................................................................................................... 78
Program the Remote ......................................................................................... 78
Operate Components after Programming the Remote .................................. 79
Codes .................................................................................................................. 80
Front Panel Controls .......................................................................................... 81
Front Panel Display .................................................................................... _....... 82
Limited Warranty RCA Digital Video Disc (DVD) Player ......................................... 85
Accessories and Order Form .................................................................................... 87
Index .................................. ....................................................................................... 90
4

Chapter 1
Connections & Setup
Chapter Overview:
• Things to Consider Before You Connect
• Choose Your Connection
•The Jacks on the Back of the DVD Player
• Inserting Batteries in the Remote
•How to Find Your TV's Video Input Channel
•How to Move Around the DVD Player's Menu System
•Set the Menu Language
•The Remote Control
Changing Entertainme ,in.
5

Connections &Setup
Things to Consider Before You Connect
Protect Against Power Surges
• Connect all components before you plug any of their power cords into the wall outlet.
• Turn off the TV and/or components before you connect or disconnect any cables.
• Make sure all antennas and cables are properly grounded. Refer to the Important Safeguards
sheet packed with your DVD player.
Protect Components from Overheating
• Don't block ventilation holes on any of the components. Arrange the components so that air
can circulate freely.
• Don't stack components.
• When you place components in a stand, make sure you allow adequate ventilation.
• If you connect an audio receiver or amplifier, place it on the top shelf so the heated air from
it won't flow around other components.
Position Cables Properly to Avoid Audio Interference
• Insert each cable firmly into the designated jack.
• If you place components above the TV, route all cables down the side of the back of the TV
instead of straight down the middle of the back of the TV.
• If your antenna uses 300-ohm twin lead cables, do not coil the cables. Also, keep the twin
lead cables away from audio/video cables.
Connection Pictures
Audio/video cables are usually bundled together. For better visibility, the connection pictures in
this book show each cable separately (audio left, audio right, and video).
Types of Discs Your DVD Player will Play
• DVD video discs - DVD video discs contain high quality picture and sound content.
• Audio discs - Audio CDs contain musical or sound content only.
Video CD discs - Like DVD video discs, Video CDs contain picture and sound content. The
difference is the amount of information that can be stored on the disc.
I_MI'AI. AUDIO VIDEOCD
6Chapter 1

Connections Setup
Choose Your Connection
There are several ways to connect your DVD player. Please use the following chart to determine
which connection is best for you. Turn to the appropriate page and connect your DVD player.
Components Cables Needed
• Coaxial
•Audio/video
• S-Video (optional)
•Component video
(optional)
•Coaxial
•Audio/video
•S-Video (optional)
• Component video
(optional)
•Coaxial
•Audio/video
•S-Video (optional)
•Component video
(optional)
•Audio/video
•S-Video (optional)
•Component video
(optional)
_! • Coaxial
•Audio/video
•S-Video (optional)
• Component video
_s_.e__e (optional)
Connection
Title
TV + DVD
TV + DVD + VCR
TV + DVD +
Dolby Digital
TV + DVD +
5,1-Channel
Analog
TV + DVD +
VCR + Satellite
Go to...
page 8
page 9
pages
10-11
pages
12-13
pages
14-15
Cables Needed to Connect Components to Your TV
The pictures below show the cables needed for the connections represented in this book.
Note: Audio/Video cables (A/V cables for short) are usually soM us a bundled set, but the connection pictures in this
book sbow each cable separately for better visibility.
Audio/Video cables
Component Video cables Coaxial cable S-Video cable
Chapter I 7

Connections & Setup
CABLE
OR
OFF-AIR SIGNAL
TV
AUDIO OUT
6'
AUDIO IN
S-VIDEO VIDEO IN
, o
o'o-\K_(
ANT IN
O
I
DVD Player + TV with Audio/Video Input Jacks
1. Connect the audio cables to the AUDIO OUT FRONT L (left - white) and R (right -red) jacks
on the back of your DVD Player, and to the corresponding Audio Input jacks on your TV.
2. Connect the video cable.
• Basic video cormection - Connect the video cable (yellow) to the VIDEO OUT jack on
the back of your DVD Player, and to the Video Input jack on your TV.
OR
• S-Video (optional) - If your TV has an S-Video Input jack, connect the S-Video cable to the
S-VIDEO OUT jack on the back of your DVD Player and to the S-Video jack on your TV. If
your TV doesn't have S-Video, use the basic video connection listed above.
OR
•Component video (optional) - If your TV has component video (Y, P., and P, jacks) use
video-grade cables for the Y, Pu, and PRconnections. Note that it is essential to match the
color-coded connectors with a compatible "IV. If your TV doesn't have component video,
use the basic video connection listed above.
3. Connect the AC power cord to the AC IN jack on the back of your DVD Player, and plug the
other end into an AC outlet.
Note: Your cable or off-air connection to the television should not he affected by this
connection. Connect your cable or off-air antenna to your television as you normally
would. You may need to consult your television manual for details.
Go to page 17
8Chapter I

Connections Setup
TV
AUDIO _T
S-VNoo cable
Is optional
DVD
PLAYER
VCR
®
DVD Player + TV + VCR
1. Connect the audio cables to the AUDIO OUT FRONT L (left -white) and R (right -red) jacks
on the back of your DVD Player, and to the corresponding Audio Input jacks on your TV.
2. Connect the video cable.
• Basic video connection - Connect the video cable (yellow) to the VIDEO OUT jack on
the back of your DVD Player, and to the Video Input jack on your TV.
OR
•S-Video (optional) - If your TV has an S-Video Input jack, connect the S-Video cable to the
S-VIDEO OUT jack on the back of your DVD Player and to the S-Video jack on your TV. If
your TV doesn't have S-Video, use the basic video connection listed above.
OR
•Component video (optional) - If your TV has component video (Y, PB, and PR jacks) use
video-grade cables for the Y, Pm and PR connections. Note that it is essential to match the
color coded connectors with a compatible "IV. If your TV doesn't have componem video,
use the basic video connection listed above.
3. Connect a coaxial cable to the antenna output jack on the VCR and to the antenna input jack
on the television.
4. Connect the antenna or cable to the Antenna Input jack on the VCR.
5. Insert the AC power cord into the AC IN jack on the back of your player and into an AC outlet.
Go to page 17
Chapter I 9

Connections & Setup
TV
AUDIO OUT
R L
AUDIO IN
S-VIDEO VIDI_O IN L
-!
CABLE OR OFF-AIR SIGNAL
7"-
ANTIN
e
S-Videocable
Isoplional
DVD
PLAYER
®
DOLBY DIGITAL or
DTS RECEIVER
Dolby Digital ®and DTS ®
Both Dolby Digital and DTS are audio formats used to record 5.1-channel audio signals onto the
digital track of film (while the film is being made). Both of these formats provide up to six
separate channels: left, right, center, left rear, right rear, and common subwoofer.
The disc will play 5.1-channel sound only if you've connected a DTS or Dolby Digital receiver or
decoder and if the original movie the disc was recorded from was encoded in the Dolby Digital or
DTS format.
Please Read This Before Using the DIG1TAL AUDIO OUT Jackl
This player's digital output jack is designed for a connection to a Dolby Digital or DTS
receiver or decoder.
Older digital equipment may not be compatible with the Dolby Digital bitstream. Such a
connection can create a high level of noise that may be harmful to your ears, and could
damage headphones or speakers.
It is important to choose the correct Digital Output setting in the DUE) Player's Sound menu,
eapecially when you use the DIGITAL AUDIO OUTjack. For more information, see chapter 5.
Manufactured under license from Dolby Laboratories. "Dolby" and the double-D symbol are trademarks of Dolby
Laboratories. Confidential unpublished works. ©1992-1997 Dolby Laboratories, Inc. All rights reserved.
DTS isa registeredtrademark of Digital Home Theater Systems,Inc.
10 Chapter I

Connections & Setup
DVD Player + TV + Dolby Pro Logic, Dolby Digital
or DTS Receiver
To Connect the DVD Player
1. Connect the left and right audio cables to your audio/video receWer and to the AUDIO OUT
FRONT L (left - white) and R (right - red) jacks on the back of your DVD Player.
2. If you have a Dolby Digital or DTS receiver, insert an optical digital cable (not provided) to the
DIGITAL AUDIO OUT jack on the DVD player to the Digital Input jack on the back of the
receiver. You must also set the Digital Output setting in the Sound menu (see chapter 5).
3. Connect the video cable.
• Basic video connection - Connect the video cable (yellow) to the VIDEO OUT jack on the
back of your DVD Player, and to the Video Input jack on your TV.
OR
•S-Video (optional) _ If your TV has an S-Video Input jack, connect the S-Video cable to the
S-VIDEO OUT jack on the back of your DVD Player and to the S-Video jack on your TV. If
your 'IV doesn't have S-Video, use the basic video connection listed above.
OR
• Component video (optional) - If your "IV has component video (Y, PB, and PR jacks) use
video-grade cables for the Y, Pw and P_ connections. Note that it is essential to match the
color coded connectors with a compatible TV. If your TV doesn't have component video,
use the basic video connection listed above.
4. Connect the AC power cord to the AC IN jack on the back of your DVD Player, and plug the
other end into an AC outlet.
Go to page 17
Chapter I 11

Connections & Setup
TV
AUDIO OUT
RL
AUDIO IN
S-VIDEO VIDEO IN ANT IN
RL
i
mI
S-Videocable
isoptional
DVD
PLAYER
CABLE
OR
OFF-AIR SIGNAL
AUDIO/VIDEO
RECEIVER
5.1-Channel Out Analog Audio
The 5,1-Channel Out Analog Audio feature lets you connect front, center, subwoofer, and/or
surround speakers to your DVD player. You can setup each speaker individually using the
5.1-Channel Setup option of the Sound menu (see chapter 5),
Note: You must change the analog ouq)ut to 5.1-channel to use the 5.1-channel analog
ou_uts.
The disc will play 5.1-Channel sound only if you've Connected the corresponding speakers and the
original movie the disc was recorded from was encoded with 5.1-Channel audio.
12 Chapter I

Connections & Setup
DVD Player + TV + 5.1-Channel Audio/Video
Receiver
To Connect the DVD Player
1, Connect the audio cables from the AUDIO OUT FRONT Rand L, SURROUND Rand L, SUB
(subwoof;er), and/or CENTER jacks on your DVD player to the corresponding Audio Input jacks
on your audio/video receiver. Set up the speakers using the Speaker menu of the Analog Output
option of the Sound menu (see chapter 5).
2. Connect the video cable.
•Basic video connection - Connect the video cable (yellow) to the VIDEO OUT jack on the
back of your DVD Player, and to the Video Input jack on your TV.
OR
• S-Video (optional) -If your TV has an S-Video Input jack, connect the S-Video cable to the S-
VIDEO OUT jack on the back of your DVD Player and to the S-Video jack on your TV. If your
TV doesn't have S-Video, use the basic video connection listed above.
OR
•Component video (optional) -If your TV has component video (Y, Pu, and PR jacks) use
video-grade cables for the Y, Pu, and PRconnections. Note that it is essential to match the
color coded connectors with a compatible TV. If your TV doesn't have component video, use
the basic video connection listed above.
3. Connect the AC power cord to the AC IN jack on the back of your DVD Player, and plug the
other end into an AC outlet
Go to page 17
Chapter I 13

Connections &Setup
TV
AUDIO OUT
RL
ANT IN
@
S-Videocable
isoptional
DVD
PLAYER
@ O
AUDIO IN
S-VIDEO VIDEO IN R L
-1o
To AC OuIJet
VCR
@
VIDEO
@
OUT TO TV
IN FROM ANT
SATELLITE
RECEIVER
OUT
S-VIDEO VIDEO R L
OUT TO TV
SATELLITE
SIGNAL
II CABLE
OR
OFF-AIR
SIGNAL
14 Chapter I

Connections & Setup
DVD Player + TV + VCR +Satellite Receiver
1. Connect the audio cables to the AUDIO OUT FRONT L(left - white) and R (right - red) jacks
on the back of your DVD Player, and to the corresponding Audio Input jacks on your TV.
2. Connect the video cable.
*Basic video connection - Connect the video cable (yellow) to the VIDEO OUT jack on
the back of your DVD Player, and to the Video Input jack on your TV.
OR
•S-Video (optional) - If your TV has an S-Video Input jack, connect the S-Video cable to the
S-VIDEO OUT jack on the back of your DVD Player and to the S-Video jack on your TV. If
your "IV doesn't have S-Video, use the basic video connection listed above.
OR
• Component video (optional) - If your TV has component video (Y, Pu, and PR jacks) use
video-grade cables for the Y, PB, and PRconnections. Note that it is essential to match the
color coded connectors with a compatible "IV.If your TV doesn't have component video,
use the basic video connection listed above.
3. Use a coaxial cable to connect the antenna output on the satellite receiver to the antenna input
on the VCR.
4. Insert the AC power cord into the AC IN jack on the back of your player and into an AC outlet.
Go to page 17
Chapter I 15

Connections & Setup
The Jacks on the Back of theDVD Player
When connecting, make sure you connect Output jacks to Input jacks, Video to Video, Right Audio to Right Audio, etc.
fAC IN
Insert the AC power
cord into the DVD
Player and plug the
other end into an AC
outlet.
fAUDIO OUT
2-Channel Output: Insert audio cables (left and
right) from the FRONT R and L jacks on your DVD
player to the corresponding Audio Input jacks (left
and right) on your TV or receiver.
5.1-Channel Output: Insert audio cables from the
FRONT R and L, SURROUND R and L, SUB
(subwoofer), and/or CENTER jacks on your DVD
player to the corresponding Audio Input jacks on
your TV or receiver.
Note.. To use 5.1-channel output, you must change the
analog output setttng to 5.1 channel (see the Sound
menu in chapter 5).
o'oLo
'O O []
f
DIGITAL AUDIO OUT
Use a digital optical cable
(not provided) to connect
your DVD Player to a
compatible Dolby Digital or
DTS receiver or decoder.
V.
f
Y' PB'PR
(Component Video Ou_out)
Use these jacks to connect to
aTV with Component video
input jacks. Unlike asingle
video input, component
video maintains the video
signal as three separate
signals through these three
jacks. This connection
provides optimum quali W.
To ensure maximum picture
qualiw, use three video-
grade cables for the Y, Pw
and PR connections. Note
that it is essential to match
the color-coded connectors
with a compatible TV.
S-VIDEO
If your TV has an
S-Video jack, you can
connect an S-Video
cable for increased
video quail W. The
S-Video cable only
carries the picture
signal; remember to
connect the left and
right audio cables.
/
rVIDEO OUT
(Composite Video Output)
Connect avideo
cable to this jack and
to the Video Input
jack on your TV.
16 Chapter 1

Connections & Setup
Install Batteries in the Remote
1. Remove the battery compartment cover on the back of the remote.
2. Insert new batteries. Match the polarities (+ and -) on the batteries
with the diagram on the remote.
3. Put the battery compartment cover back on the remote.
Important Battery Information
If you're not going to use the remote for a month or more, be sure
to remove the batteries because they can leak and cause damage.
• Dispose of batteries in the proper manner, according to federal,
state, and local regulations.
Any battery may leak electrolyte if mixed with a different battery
type, if inserted incorrectly, if all batteries are not replaced at the
same time, if disposed of in fire, or if an attempt is made to charge a
battery not intended to be recharged.
• Discard leaky batteries immediately. Leaking batteries can cause skin
burns or other personal injury.
Point the Remote in the Right Direction
When you want the remote to operate the DVD Player, point the remote
at the DVD Player, not the TV. The remote has to be pointed in the
correct direction and toward the correct component in order for the
remote's signal to communicate with the sensor on the component.
Make sure there is a clear path between the remote and the component
you want to operate so the signal isn't blocked.
Turn on the TV and DVD Player
1. Turn on your TV and tune to the correct video input channel (see
following page).
2. Press the DVD button on the DVD remote or the ON,OFF button on
the DVD player.
Chapter I 17

Connections &Setup
How to Find Your TV's Video Input Channel
You need to tune your TV to the Video Input Channel (or S-Video Channel if you connected the
S-Video cable to your TV and to your DVD Player) to see the DVD Player's menu and to see the
content that's on a disc. The video channel on TVs varies for different brands and different models.
In order for your DVD remote to work, your TV must be set on the correct video input channel.
Below are some things to try.
• If your TV brand is RCA, GE, or PROSCAN, press the TV button on the remote that came with
your TV (not the DVD remote). Then press the INPUT button on the remote.
* If you have another brand, consult your TV's Owner's Manual.
If those options don't work, try one of the following options.
• Press a button on the TV remote (see table below).
• Select it from the TV's menu system.
• Tune directly to the DVD input channel by pressing a specific number (see table below).
• Go through all the channels in the channel list by pressing the channel up/down buttons on
the "IV.
Some common scenarios are listed in the following table:
Video Input Channel Variations
Button/Switch Button on the Channel #
on the TV TV Remote
VIDEO VID 1 00
SIGNAL LINE 90
VID 1 VID 91
VID 2 VIDEO 92
S-VID S-VID 93
S-VIDEO INPUT VID 1
S-VIDEO VID 2
SOURCE
AUX
18 Chapter 1
