RCA L42FHD2X48 User manual

l42FHD2X48
42"class Full HD 120Hz 1080p LCD
DIAGONALLY MEASURED: 41.9" | WITH STAND W-40" x H-27.8" x D-10.6" | WITHOUT STAND W-40" x H-26" x D-4.4"
FEATURES AND BENEFITS
RCA Scenium stands for the best consumer televisions the RCA brand has to offer. This year’s lineup is no exception.
The RCA Scenium line of 120Hz Full HD 1080p televisions incorporate the latest technologies (including HDMI™
and SRS TruSurround XT®) and provide the best in picture performance. Additional features like ARC2™ video
processing enable smoother motion when viewing movies or fast-action sports. The 48 Series also features HDMI-
CEC (Consumer Electronics Control) compliance, Dynamic Contrast Enhancement and USB Input. Wrap all this
performance in a sleek high gloss piano black finish and you have the pinnacle of RCA performance and design.
RCA products are designed with the environment in mind. The Intuilight™ Light Sensor detects ambient room light
and automatically adjusts contrast on the screen. The result is more energy-efficiency that is perfectly balanced for
your room’s environment — night or day. The RCA Scenium 48 Series is ENERGY STAR®compliant.

REAR JACK PANEl
SIDE JACK
PANEl
l42FHD2X48
SPECIFICATIONS
SIGNAl FORMAT CAPABIlITY
RF Tuning Capability . . . . . . . . . . . . . . . . . ATSC/NTSC/QAM
RefreshRate ........................120Hz
Analog Video Formats (NTSC/480i) . .
Composite, S-Vid, Component
Video Formats (480p, 720p, 1080i) . . . Component, RGB, HDMI
Video Formats (1080p). . . . . . . . . . . . . . . HDMI
DISPlAY SIZE
Display Aspect Ratio . . . . . . . . . . . . . . . . 16x9
Display Resolution . . . . . . . . . . . . . . . . . . . 1920x1080
Brightness (cd/m2) . . . . . . . . . . . . . . . . . . 420
Panel Contrast Ratio . . . . . . . . . . . . . . . . . 5000:1
Viewing Angle Horizontal/Vertical . . . . 176/176
Response Time (Gray to Gray) . . . . . . . . 8.5ms
VIDEO
Video Processing - Marketing . . . . . . . . . ARC2
BitDepth ...........................10bit
Adjustable Color Temperature . . . . . . . . Yes
Adjustable Picture Control (bright,
cont, sharp, color, tint). . . . . . . . . . . . . . Yes
FormatControl......................Yes
Dynamic Backlight. . . . . . . . . . . . . . . . . . . Yes
Dynamic Contrast Ratio . . . . . . . . . . . . . . 25000:1
Dynamic Light Sensor. . . . . . . . . . . . . . . . Yes
CombFilter .........................3DY/C
HD De-interlacing. . . . . . . . . . . . . . . . . . . . Yes
Reverse 3:2 Pull Down (Film Mode). . . . Yes
NoiseReduction.....................3D
AUDIO
Audio Power (Watts)
FrontSpeakers......................8W/CHx2
Treble, Bass, Balance, Volume,
Mute Control. . . . . . . . . . . . . . . . . . . . . . . Yes
Equalizer............................Yes
Broadcast Stereo . . . . . . . . . . . . . . . . . . . . MTS Stereo
Second Audio Program (SAP) . . . . . . . . Yes
Dolby Processing . . . . . . . . . . . . . . . . . . . . Yes
Premium Sound . . . . . . . . . . . . . . . . . . . . . SRS TruSurround XT
CONVENIENCE
Control Buttons. . . . . . . . . . . . . . . . . . . . . . Power, CH +/–, Vol +/–, Menu
ProgramGuide......................Yes
Auto Tune (one-button launch) . . . . . . . Yes
Auto Channel Search. . . . . . . . . . . . . . . . . Yes
Multilingual On–Screen–Display . . . . . . . English/French/Spanish
Channel Labelling. . . . . . . . . . . . . . . . . . . . Yes
Closed Caption Capability . . . . . . . . . . . . Yes
Energy Star . . . . . . . . . . . . . . . . . . . . . . . . . Version 3.0 Compliant
Parental Control (V–Chip) . . . . . . . . . . . . USA & Canada
Downloadable Ratings . . . . . . . . . . . . . . . Yes
PictureReset........................Yes
Picture Memory Presets . . . . . . . . . . . . . . Yes
Clock...............................Yes
SleepTimer .........................Yes
PC Compatibility. . . . . . . . . . . . . . . . . . . . . Yes (via RGB & DVI)
HDMI-CEC Compliant . . . . . . . . . . . . . . . . Yes
JPEG Viewing/MP3 Playback for USB . Yes
CONNECTIONS — REAR INPUTS/OUTPUTS
RF Input (ATSC/NTSC). . . . . . . . . . . . . . . 1
Composite Video Input. . . . . . . . . . . . . . . 1
S-VideoInput........................1
Audio Input for Composite . . . . . . . . . . . 1 L/R
RGBInput...........................1
Audio Input for RGB . . . . . . . . . . . . . . . . . 1 - 3.5mm PC Audio
Component Video Input
(YCrCb/YPrPb) . . . . . . . . . . . . . . . . . . . . 1
Audio Input for Component Video . . . . 1 L/R
HDMI Inputs (1080p capable) . . . . . . . . . 3 V1.3 (1 DVI compatible)
Audio Input for DVI . . . . . . . . . . . . . . . . . . 1 L/R
AudioOutput .......................1L/R(Fixed)
Digital Audio Output (SPDIF) . . . . . . . . . 1 - Optical
CONNECTIONS — SIDE INPUTS/OUTPUTS
Composite Video Input. . . . . . . . . . . . . . . 1
Audio Input for Composite . . . . . . . . . . . 1 L/R
HDMI Input (1080p capable) . . . . . . . . . . 1 V1.3
USBInput...........................1V2.0(SWUpgrade
& Player)
Headphone Jack Output . . . . . . . . . . . . . Yes
REMOTE CONTROl
Remote Model Number . . . . . . . . . . . . . . RC2254701
Universal Remote . . . . . . . . . . . . . . . . . . . . Yes
Remote Finder (Fetch) . . . . . . . . . . . . . . . Yes
ACCESSORIES (INClUDED)
IB (English/French/Spanish). . . . . . . . . . Yes
PowerCord .........................Yes
PACKAGE & PRODUCT INFORMATION
Package Size (WxHxD) (inches) . . . . . . 45.2 x 32.1 x 15.1
Package/Product Weight (lbs). . . . . . . . 54 / 41.9
ENERGY STAR and the ENERGY STAR mark are registered U.S. marks.
Dolby is a registered trademark of Dolby Laboratories.
HDMI, the HDMI logo and High-Definition Multimedia Interface are
trademarks or registered trademarks of HDMI Licensing LLC.
Product features, definitions and physical specifications are subject to change without notice. RCA
and associated marks are trademarks of THOMSON S.A. used under license to TTE CORPORATION.
TTE Technology, Inc.
101 West 103rd Street
Indianapolis, IN U.S.A 46290
rca.com/television
