RCA LEB356 Installation instructions

Aluminum Foil 5, 18, 22–24, 26
Anti-Tip Device 3, 8, 32
Appliance Registration 2
Care and Cleaning 13, 29–31
Consumer Services 35
Important Phone Numbers 35
Features 6, 7
Model and Serial Numbers 2
Oven 14–28
Baking 17–19
Broiling 24, 25
Lift-Off Oven Door 30
Oven Control Settings 14, 15
Roasting 22, 23
Self-Cleaning 26–28
Shelves 16, 17
Timed Baking 19, 20
Preparation 8
Problem Solver 33, 34
Thermostat Adjustment–
Do It Yourself 21
Removal of Packaging Tape 2
Safety Instructions 3–5
Surface Cooking 8–13
Canning Tips 12
Cooktop Comparison 8
Cookware Tips 10, 11
Surface Cleaning 13
Surface Control Settings 9
Warranty Back Cover
Model
LEB356
Contents
Use and Care
of Your Range
164D1913P082
79-4097
10-95 CG

2
HELP US HELP YOU…
Before using your range, read this guide
carefully.
It is intended to help you operate and maintain your
new range properly.
Keep it handy for answers to your questions.
If you don’t understand something or need more help,
write (include your phone number):
Consumer Affairs
Appliance Park
Louisville, KY 40225
How to Remove Packaging Tape
To assure no damage is done to the finish of the
product, the safest way to remove adhesive left from
packaging tape on new appliances is an application of
a household liquid dishwashing detergent, mineral oil
or cooking oil. Apply with a soft cloth and allow to
soak. Wipe dry and then apply an appliance polish to
thoroughly clean and protect the surface.
NOTE: The plastic tape must be removed from the
chrome trim on range parts. It cannot be removed if
it is baked on.
Write down the model and serial
numbers.
You’ll find them on a label on the front of the range
behind the storage drawer.
These numbers are also on the Consumer Product
Ownership Registration Card that came with your
range. Before sending in this card, please write these
numbers here:
Model Number
Serial Number
Use these numbers in any correspondence or service
calls concerning your range.
If you received a damaged range…
Immediately contact the dealer (or builder) that sold
you the range.
Save time and money.
Before you request service…
Check the Problem Solver in the back of this guide.
It lists causes of minor operating problems that you
can correct yourself.
IF YOU NEED SERVICE…
To obtain service, see the Consumer Services page
in the back of this guide.
We’re proud of our service and want you to be
pleased. If for some reason you are not happy with
the service you receive, here are three steps to follow
for further help.
FIRST, contact the people who serviced your
appliance. Explain why you are not pleased.
In most cases, this will solve the problem.
NEXT, if you are still not pleased, write all the
details—including your phone number—to:
Manager, Consumer Relations
Appliance Park
Louisville, KY 40225
FINALLY, if your problem is still not resolved, write:
Major Appliance Consumer Action Program
20 North Wacker Drive
Chicago, IL 60606

Important Safety Instructions
IMPORTANT SAFETY NOTICE
• The California Safe Drinking Water and Toxic
Enforcement Act requires the Governor of California
to publish a list of substances known to the state
to cause birth defects or other reproductive harm,
and requires businesses to warn customers of
potential exposure to such substances.
• The fiberglass insulation in self-clean ovens
gives off a very small amount of carbon
monoxide during the cleaning cycle. Exposure
can be minimized by venting with an open
window or using a ventilation fan or hood.
When using electrical appliances, basic safety
precautions should be followed, including the
following:
• Use this appliance only for its intended use
as described in this guide.
• Be sure your appliance is properly installed
and grounded by a qualified technician in
accordance with the provided Installation Instructions.
• Do not attempt to repair or replace any part
of your range unless it is specifically
recommended in this guide. All other servicing
should be referred to a qualified technician.
• Have the installer show you the location of the
circuit breaker or fuse. Mark it for easy reference.
• Before performing any service, DISCONNECT
THE RANGE POWER SUPPLY AT THE
HOUSEHOLD DISTRIBUTION PANEL BY
REMOVING THE FUSE OR SWITCHING OFF
THE CIRCUIT BREAKER.
WARNING—All ranges
can tip and injury could result. To
prevent accidental tipping of the
range, attach it to the wall and floor by
installing the Anti-Tip device supplied.
To check if the device is installed and
engaged properly, remove the storage
drawer and inspect the rear leveling leg.
Make sure it fits securely into the slot.
If you pull the range out from the wall for any
reason, make sure the device is properly engaged
when you push the range back against the wall.
If it is not, there is a possible risk of the range
tipping over and causing injury if you or a child
stand, sit or lean on an open door.
Please refer to the Anti-Tip device information
in this guide. Failure to take this precaution could
result in tipping of the range and injury.
• Do not leave children alone—children should
not be left alone or unattended in an area where an
appliance is in use. They should never be allowed
to sit or stand on any part of the appliance.
• CAUTION: ITEMS OF INTEREST TO
CHILDREN SHOULD NOT BE STORED IN
CABINETS ABOVE A RANGE OR ON THE
BACKSPLASH OF A RANGE—CHILDREN
CLIMBING ON THE RANGE TO REACH
ITEMS COULD BE SERIOUSLY INJURED.
• Teach children not to play with the controls
or any other part of the range.
• Never leave the oven door open when you are
not watching the range.
• Always keep combustible wall coverings,
curtains or drapes a safe distance from your
range.
• Do not allow anyone to climb, stand or hang
on the door, drawer or cooktop. They could
damage the range and even tip it over, causing
severe personal injury.
• Never wear loose-fitting or hanging garments
while using the appliance. Be careful when
reaching for items stored in cabinets over the
range. Flammable material could be ignited if
brought in contact with hot surface units or
heating elements and may cause severe burns.
• Use only dry pot holders—moist or
damp pot holders on hot surfaces may
result in burns from steam. Do not let
pot holders touch hot surface units or heating
elements. Do not use a towel or other bulky cloth.
Such cloths can catch fire on a hot surface unit or
heating element.
• Always keep dish towels, dish cloths, pot
holders and other linens a safe distance from
your range.
• Always keep wooden and plastic utensils
and canned food a safe distance away from
your range.
• Do not store flammable materials in an oven or
near the cooktop.
(continued next page)
IMPORTANT SAFETY INSTRUCTIONS
Read all instructions before using this appliance.
3

IMPORTANT SAFETY INSTRUCTIONS
(continued)
• For your safety, never use your appliance for
warming or heating the room.
• DO NOT STORE OR USE COMBUSTIBLE
MATERIALS, GASOLINE OR OTHER
FLAMMABLE VAPORS AND LIQUIDS
IN THE VICINITY OF THIS OR ANY
OTHER APPLIANCE.
• Keep hood and grease filters clean to maintain
good venting and to avoid grease fires.
• Do not let cooking grease or other flammable
materials accumulate in or near the range.
• Do not use water on grease fires.
Never pick up a flaming pan.
Turn the controls off. Smother a
flaming pan on a surface unit by covering the
pan completely with a well-fitting lid, cookie
sheet or flat tray. Use a multi-purpose dry
chemical or foam-type fire extinguisher.
Flaming grease outside a pan can be put out
by covering it with baking soda or, if available,
by using a multi-purpose dry chemical or foam-
type fire extinguisher.
Flame in the oven can be smothered completely
by closing the oven door and turning the oven off
or by using a multi-purpose dry chemical or foam-
type fire extinguisher.
• Do not touch the surface units, the heating
elements or the interior surface of the oven.
These surfaces may be hot enough to burn even
though they are dark in color. During and after use,
do not touch, or let clothing or other flammable
materials contact the surface units, areas nearby
the surface units or any interior area of the oven;
allow sufficient time for cooling first.
Potentially hot surfaces include the cooktop and
areas facing the cooktop, the oven vent opening
and surfaces near the opening, crevices around the
oven door, the edges of the door window and
metal trim parts above the door.
Remember: The inside surface of the oven may
be hot when the door is opened.
• When cooking pork, follow the directions
exactly and always cook the meat to an internal
temperature of at least 170°F. This assures that, in
the remote possibility that trichina may be present
in the meat, it will be killed and the meat will be
safe to eat.
Oven
• Stand away from the range when opening the
oven door. Hot air or steam which escapes can
cause burns to hands, face and/or eyes.
• Do not heat unopened food containers.
Pressure could build up and the container could
burst, causing an injury.
• Keep the oven vent duct unobstructed.
• Keep the oven free from grease buildup.
• Place the oven shelf in the desired position
while the oven is cool. If the shelves must be
handled when hot, do not let pot holder contact
the heating elements.
• Pulling out the shelf to the stop-lock is a
convenience in lifting heavy foods. It is also
a precaution against burns from touching the hot
surfaces of the door or oven walls.
• When using cooking or roasting bags in the
oven, follow the manufacturer’s directions.
• Do not use your oven to dry newspapers.
If overheated, they can catch fire.
• Do not use oven for a storage area.
Items stored in an oven can ignite.
• Do not leave paper products, cooking utensils
or food in the oven when not in use.
• After broiling, always take the broiler pan out of
the range and clean it. Leftover grease in the broiler
pan can catch on fire the next time you use the pan.
• Never leave jars or cans of fat drippings on
or near your range.
• Clean only parts listed in this Use and Care
Guide.
• Do not use aluminum foil to line oven bottoms,
except as suggested in this guide. Improper
installation of aluminum foil may result in a risk
of electric shock or fire.
Self-Cleaning Oven
• Do not clean the oven door gasket. The door
gasket is essential for a good seal. Care should be
taken not to rub, damage or move the gasket.
• Do not use oven cleaners. No commercial oven
cleaner or oven liner protective coating of any kind
should be used in or around any part of the oven.
Residue from oven cleaners will damage the inside
of the oven when the self-clean cycle is used.
• Before self-cleaning the oven, remove the broiler
pan, grid and other cookware.
4

Important Safety Instructions
• Be sure to wipe up excess spillage before
starting the self-cleaning operation.
• If the self-cleaning mode malfunctions, turn
the oven off and disconnect the power supply.
Have it serviced by a qualified technician.
Cooktop and Radiant Surface Units
• Use proper pan size—Select
cookware having flat bottoms
large enough to cover the selected
surface unit heating element. The use of
undersized cookware will expose a portion
of the heating element to direct contact and
may result in ignition of clothing. Proper
relationship of cookware to surface units will
also improve efficiency.
• Clean the cooktop with caution. If a wet
sponge or cloth is used to wipe spills on a hot
surface unit, be careful to avoid steam burns.
Some cleansers can produce noxious fumes if
applied to a hot surface. When the cooktop is
cool, use only Cook Top Cleaning Creme brand
cleaner to clean the cooktop.
• Use care when touching the cooktop.
The glass surface of the cooktop will retain heat
after the controls have been turned off.
• Never leave the surface units unattended at
high heat settings. Boilovers cause smoking and
greasy spillovers that may catch on fire.
• Do not operate the radiant surface units if
the glass is broken. Spillovers or cleaning
solution may penetrate a broken cooktop and
create a risk of electrical shock. Contact a
qualified technician immediately should your
glass cooktop become broken.
• Avoid scratching the glass cooktop surface.
The cooktop can be scratched with sharp
instruments, rings or other jewelry and rivets
on clothing.
• Do not stand on the glass cooktop.
• Never use the glass cooktop surface as a
cutting board.
• Do not place or store items on top of the glass
cooktop surface when it is not in use.
• Be careful when placing spoons or other
stirring utensils on the glass cooktop surface
when it is in use. They may become hot and
could cause burns.
• To minimize the possibility of burns, ignition of
flammable materials and spillage, the handle of a
container should be turned toward the center of the
range without extending over nearby surface units.
• Always turn the surface unit controls off before
removing cookware.
• Carefully watch for spillovers or overheating of
foods when frying at high or medium high
temperatures.
• When flaming foods are under the hood, turn
the fan off. The fan, if operating, may spread the
flame.
• Foods for frying should be as dry as possible.
Frost on frozen foods or moisture on fresh foods
can cause hot fat to bubble up and over the sides
of the pan.
• Use little fat for effective shallow or deep-fat
frying. Filling the pan too full of fat can cause
spillovers when food is added.
• If a combination of oils or fats will be used in
frying, stir together before heating, or as fats
melt slowly.
• Always heat fat slowly, and watch as it heats.
• Use a deep fat thermometer whenever
possible to prevent overheating fat beyond the
smoking point.
• Never try to move a pan of hot fat, especially a
deep fat fryer. Wait until the fat is cool.
• To avoid possible damage to the cooking
surface, do not apply Cook Top Cleaning Creme
to the glass surface when it is hot.
• After cleaning, use a dry cloth or paper towel to
remove all Cook Top Cleaning Creme residue.
• Read and follow all instructions and warnings
on Cook Top Cleaning Creme labels.
SAVE THESE
INSTRUCTIONS
5

6
FEATURES OF YOUR RANGE
OFF
H
I
L
O
M
E
D
OFF
H
I
L
O
M
E
D
OFF
H
I
L
O
M
E
D
OFF
H
I
L
O
M
E
D
HOUR MIN.
HR MIN
AUTOMATIC OVEN
COOK
TIME
START
TIME
TIMER
ON/OFF
CLOCK
PREHEATED
OVEN ON
LATCH
DOOR
AUTO
SELF
CLEAN

12 3 25 7
8
9
10
11
12
13
14
15
22
21
20
19
18
17
16
4 6

7
Features of Your Range
Explained
Feature Index on page
1Surface Unit Controls 4, 5, 9, 12, 29
2Surface Unit “ON” Indicator Lights 9
3Oven Light Switch 16, 26
Use the switch on the control
panel to turn the light on and off.
4AUTOMATIC OVEN Light 19, 20
5Clock and Timer 14, 15, 19
6OVEN ON Light 14, 15
AUTO SELF CLEAN Light 14, 27, 28
PREHEATED Light 14, 15
7Oven Temperature Knob 4, 5, 14, 15, 17,
19–22, 24, 27–29
8Oven Vent Duct 4, 31
9Cooktop Surface Units 3–5, 9–13
10 Hot Surface Lights 9
Lights will glow when the cooktop is hot to the touch.
11 Broil Element 4, 24, 29
12 Oven Shelf Supports 4, 16, 17, 22,
Shelf positions are suggested in the 24, 25, 27–29
Baking, Roasting and Broiling sections.
13 Oven Shelf with Stop-Locks 4, 16–20, 22,
24, 26–29
14 Bake Element 4, 29
May be lifted gently for wiping the oven floor.
15 Lift-Off Oven Door with Broil Stop Position 3, 24–26, 30
16 Broiler Pan and Grid 4, 22, 24–26, 30
Do not clean in the self-cleaning oven.
17 Storage Drawer 3, 31
18 Model and Serial Numbers 2
19 Anti-Tip Device 3, 8, 32
20 Oven Interior Light 16, 26, 31
21 Oven Door Latch 17, 19, 22,
Use for self-cleaning only. 24, 26–28
22 Glass Ceramic Cooktop 5, 8–13

PREPARATION
Flooring Under the Range Leveling the Range
Your range, like many other household items, is
heavy and can settle into soft floor coverings such as
cushioned vinyl or carpeting. When moving the
range on this type of flooring, it should be installed on
a 1/4-inch-thick sheet of plywood (or similar material)
as follows: When the floor covering ends at the front
of the range, the area that the range will rest on should
be built up with plywood to the same level or higher
than the floor covering. This will allow the range to be
moved for cleaning or servicing. For complete
information, see the Installation Instructions.
Please check your range to insure all packaging
materials and protective tape covering are removed
from areas, such as the door trim, cooktop frame, end
caps, etc., before using.
Leveling screws are located on each corner of the
base of the range. Remove the bottom drawer and
you can level the range on an uneven floor with the
use of a nutdriver.
To remove drawer, pull the drawer out all the way,
tilt up the front and take it out. To replace drawer,
insert glides at back of drawer beyond stop on range
glides. Lift drawer if necessary to insert easily. Let
front of drawer down, then push in to close.
One of the rear leveling screws will engage the Anti-
Tip device (allow for some side to side adjustment).
Allow a minimum clearance of 1/8″between the range
and the leveling screw that is to be installed into the
Anti-Tip device.
HOW DOES THIS COOKTOP COMPARE
WITH YOUR OLD ONE?
Your new cooktop has a radiant glass ceramic cooktop.
If you are used to cooking with gas burners or electric
surface units, you will notice some differences when
you use the radiant cooktop.
The best types of cookware to use, plus heat-up and
cool-down times, depend upon the type of burner or
surface unit you have.
The following chart will help you to understand the
differences between radiant cooktops and any other
type of cooktop you may have used in the past.
Type of Cooktop Description How It Works
Radiant Electric coils Heat travels to the glass surface and then to the cookware, so pans must be flat on
(Glass Ceramic) under a glass- the bottom for good cooking results. The glass cooktop stays hot enough to
Cooktop ceramic cooktop. continue cooking after it is turned off. Remove the pan from the surface unit if
you want cooking to stop.
Induction High frequency Pans must be made of ferrous metals (metal that attracts a magnet). Heat is
induction coils produced by a magnetic circuit between the coil and the pan. Heats up right away
under a glass and changes heat settings right away, like a gas cooktop. After turning the control
surface. off, the glass cooktop is hot from the heat of the pan, but cooking stops right away.
Electric Coil Flattened metal Heats by direct contact with the pan and by heating the air under the pan. For best
tubing containing cooking results, use good quality pans. Electric coils are more forgiving of
electric resistance warped pans than radiant or solid disks. Heats up quickly but does not change
wire suspended heat settings as quickly as gas or induction. Electric coils stay hot enough to
over a drip pan. continue cooking for a short time after they are turned off.
Solid Disk Solid cast iron Heats by direct contact with the pan, so pans must be flat on the bottom for good
disk sealed to the cooking results. Heats up and cools down more slowly than electric coils. The
cooktop surface. disk stays hot enough to continue cooking after it is turned off. Remove the pan
from the solid disk if you want the cooking to stop.
Gas Burners Regular or sealed Flames heat the pans directly. Pan flatness is not critical to cooking results, but
gas burners use pans should be well balanced. Gas burners heat the pan right away and change
either LP gas heat settings right away. When you turn the control off, cooking stops right away.
or natural gas.
8

SURFACE UNIT CONTROLS
At both OFF and HI positions, there is a slight niche so the control “clicks”
at those positions; the word HI marks the highest setting; the lowest setting
is the word LO. In a quiet kitchen you may hear slight “clicking” sounds
during cooking, indicating heat settings selected are being maintained.
Switching to higher heat settings always shows a quicker heat change than
switching to lower settings.
How to Set the Controls Hot Surface Indicator Light
1. Push the control knob in.
2. Turn either clockwise or
counterclockwise to the
desired heat setting.
The control must be pushed in
to set only from the OFF
position. When the control is in any position other
than OFF, it may be turned without pushing it in.
Be sure you turn the control knob to OFF when you
finish cooking.
The left surface unit “on” indicator light will glow
when either surface unit on the left is on. The right
surface unit “on” indicator light will glow when either
surface unit on the right is on.
A “HOT SURFACE”
light will glow brightly
when any radiant element
is hot to the touch, and
will remain lit after the
unit is turned off until the
surface is cool enough to
touch. Each element has
its own “HOT SURFACE”
indicator light.
• It comes on when the
unit is hot to the touch.
• It stays on even after the
unit is turned off.
• It glows brightly until the unit is safe to touch.
OVEN
LIGHT
OFF
HI
LO
MED
OFF
HILO
MED
OFF
HI
LO
MED
OFF
HILO
MED
SURFACE
LIGHT
FRONT REAR REAR FRONT
HOT SURFACE
OVENTEMP
Cooking Guide for Using Heat Settings Special Notes for Glass Cooktops
Appearance may vary.
HI—Quick start for cooking; brings water to a boil.
Medium High—(Setting halfway between HI and
MED) Fast fry, pan broil; maintains a fast boil on
large amounts of food.
MED—Sauté and brown; maintains a slow boil on
large amounts of food.
Medium Low—(Setting halfway between MED and
LO) Cook after starting at HI; cooks with little water
in covered pan.
LO—Steam rice, cereal; maintains serving temperature
of most foods. Slow cooking and simmering. At LO
settings melt chocolate and butter on a small surface unit.
Cooktop temperatures increase with the number of
surface units that are on. With 3 or 4 units turned
on, surface temperatures are high so be careful
when touching the cooktop. The hot surface
indicator light will remain lit after the surface unit
is off and the surface is hot to the touch.
NOTE:
• At HI and Medium High settings never leave food
unattended. Boilovers cause smoking and greasy
spillovers may catch fire.
• When a surface unit is turned on, the unit can be
seen glowing red within a few seconds. The red
glow will turn on and off (cycling) to maintain the
selected heat setting. With poor cookware, you will
see frequent cycling of the unit off and on. Good,
flat cookware will minimize the cycling. See the
Surface Cookware Tips section.
• It is safe to place hot cookware from the oven or
surface on the glass surface when it is cool.
OFF
H
I
L
O
M
E
D
Medium
Low Medium
High
Preparation Cooktop Comparison Surface Unit Controls
9

SURFACE COOKWARE TIPS
Types of Cookware
The following information will help you choose
cookware which will give good performance.
Stainless Steel: highly recommended
Especially good with a sandwich clad bottom. The
sandwich bottom combines the benefits of stainless
steel (appearance, durability, and stability) with the
advantages of aluminum or copper (heat conduction,
even heat distribution).
Aluminum: heavy weight recommended
Good conductivity. Aluminum residue sometimes
appears as scratches on the cooktop, but can be
removed if cleaned immediately. Because of its low
melting point, thin weight aluminum should not be used.
Porcelain/enamel:
Good performance only with a thick, flat, smooth
bottom. Avoid boiling dry, as porcelain can melt and
fuse to the surface.
Copper Bottom: heavy weight recommended
Good performance, but copper may leave a residue
which can appear as scratches. The residue can be
removed, as long as the cooktop is cleaned
immediately. However, do not let these pots boil dry.
Overheated metal can bond to glass cooktops.
An overheated copper pot will leave a residue that
will permanently stain the cooktop.
Glass-ceramic: Usable, but not recommended
Poor performance. May scratch surface.
Stoneware: Usable, but not recommended
Poor performance. May scratch surface.
Cast Iron: Usable, but not recommended
Poor performance. May scratch surface.
How to Check Pan Performance
Use of correct cookware can affect the cooking
performance and cleaning of your cooktop.
The correct cookware reduces the temperature of
the cooktop surface and minimizes the chance of
spillovers burning onto the cooktop.
You must use pans with perfectly flat bottoms.
Some pans may have curved or rounded bottoms or
may be warped. If you are unsure of the flatness of
your pans you may do this quick test.
Turn your pan upside
down on the countertop,
place a ruler flat against
the pan surface. The
bottom of the pan and the
straight edge of the ruler
should fit flush against each other all the way across.
Turn the ruler a full 360 degrees, checking for any
space between the ruler and the bottom of the pan.
Pans with rounded, curved, ridged or warped bottoms
are not recommended.
Another simple test to determine even heat distribution
across the cookware bottom is to put one inch of water
in the pan. Bring the water to a boil and observe the
location of bubbles as the water starts to boil. Good
flat cookware will have an even distribution of bubbles
over the bottom surface area of the pan. Bubbles
localized in only a portion of the bottom indicate
uneven contact of the pan to the surface unit, uneven
heat transfer or an unsuitable pan.
Use pans that match the diameter of the surface unit.
Cooking performance will not be as good if the
cookware is either smaller or larger than the surface unit.
• Place only dry pans on the
surface units. Do not place lids
on the surface units, particularly
wet lids.
• We recommend that you use
only a flat-bottomed wok.
They are available at your
local retail store. The bottom of
the wok should have the same diameter as
the surface unit to insure proper contact.
• Do not use woks that have
support rings. This type of
wok will not heat on radiant
surface units.
• Some special cooking procedures require specific
cookware such as pressure cookers, deep fat fryers,
etc. All cookware must have flat bottoms and be the
correct size. The cookware should also be covered,
if applicable to the cooking process.



































10

Surface Cookware Tips
SPECIAL CAUTIONS FOR GLASS COOKTOPS
• Never cook directly on the glass.
Always use cookware.
• Always place the pan in the center of
the surface unit you are cooking on.
• Do not slide cookware across the
cooktop because it can scratch
the glass—the glass is scratch
resistant, not scratch proof.
• Do not use the surface as a
cutting board.
• Don’t store heavy items above
the cooktop. If they drop onto
the cooktop, they can cause
damage.







DROPPING







CUTTING







DRAGGINGDRAGGING







OFF CENTER






SURFACE 
COOKING
SURFACE 
COOKING
Deep Fat Frying
Do not overfill cookware with fat that may spill over when adding food.
Frosty foods bubble vigorously. Watch food frying at high temperatures.
Keep the range and hood clean from grease.
General Information About Radiant Surface Units
The radiant cooktop features heating units beneath a
smooth glass surface. The surface units are shown by
outlines on the glass.
Before you use the cooktop for the first time, clean
it with cleaning cream. This helps protect the top
and makes clean-up easier.
NOTE: A slight odor is normal when a new cooktop
is used for the first time. It is caused by the heating of
new parts and insulating materials and will disappear
in a short time.
Use only flat-bottomed cookware. Do not let pots boil
dry. Overheated metal can bond to glass cooktop. An
overheated copper pot will leave a residue that will
permanently stain the glass.
Sliding aluminum cookware across the glass may
leave metal marks. These metal marks will appear as
small scratches. They can be removed with cleaning
cream and a razor scraper.
Avoid sliding pans on the glass cooktop. Pan edges
that are even slightly rough or grit on the cooktop can
cause scratches on the glass.
Even after the surface units are turned off, the glass
cooktop retains enough heat to continue cooking. To
avoid overcooking, remove pans from the surface units
when the food is cooked. Avoid placing anything on the
surface unit until it has cooled completely.
The Hot Surface Lights will stay lit until the cooktop
is safe to touch. It is not unusual for the lights to stay
lit for 30 minutes.
11

Observe the Following Points in Canning
1. Be sure the canner fits over the center of the
surface unit. If your cooktop or its location
does not allow the canner to be centered on the
surface unit, use smaller diameter pots for good
canning results.
2. Flat-bottomed canners must be used. Do not use
canners with flanged or rippled bottoms (often
found in enamelware) because they don’t make
enough contact with the surface units and take
a long time to boil water.
RIGHT WRONG
Flat-bottomed canners are required
for glass cooktops.
3. When canning, use recipes and procedures from
reputable sources. Reliable recipes and procedures
are available from the manufacturer of your canner;
manufacturers of glass jars for canning, such as
Ball and Kerr; and the United States Department of
Agriculture Extension Service.
4. Remember that canning is a process that generates
large amounts of steam. To avoid burns from steam
or heat, be careful when canning.
NOTE: If your house has low voltage, canning may
take longer than expected, even though directions
have been carefully followed.
The process time will be shortened by:
(1) using a pressure canner, and
(2) starting with HOT tap water for fastest
heating of large quantities of water.
CAUTION:
Safe canning requires that harmful microorganisms
are destroyed and that the jars are sealed
completely. When canning foods in a water-bath
canner, a gentle but steady boil must be maintained
for the required time. When canning foods in a
pressure canner, the pressure must be maintained
for the required time.
After you have adjusted the controls, it is very
important to make sure the prescribed boil or
pressure levels are maintained for the required time.
The cooktop surface units have temperature
limiters that prevent the glass cooktop from
getting too hot. If the bottom of your canner is
not flat, the surface unit can overheat, triggering
the temperature limiters to turn the unit off for a
time. This will stop the boil or reduce the pressure
in the canner.
Since you must make sure to process the
canning jars for the prescribed time, with no
interruption in processing time, do not can on any
of the cooktop surface units if your canner is not
flat enough.
What is a Temperature Limiter?
Every radiant surface unit has a Temperature Limiter.
The Temperature Limiter protects the glass-ceramic
surface from getting too hot.
The Temperature Limiter may turn off the
surface units if:
• The pan boils dry.
• The pan bottom is not flat.
• The pan is off center.
• There is no pan on the unit.
HOME CANNING TIPS
Canning should be done on the cooktop only.
Pots that extend beyond 1 inch of the surface unit
circle are not recommended for most surface cooking.
However, when canning with water-bath or pressure
canner, larger-diameter pots may be used. This is
because boiling water temperatures (even under
pressure) are not harmful to the cooktop surfaces
surrounding the surface units.
HOWEVER, DO NOT USE LARGE DIAMETER
CANNERS OR OTHER LARGE DIAMETER POTS
FOR FRYING OR BOILING FOODS OTHER
THAN WATER. Most syrup or sauce mixtures—and
all types of frying—cook at temperatures much higher
than boiling water.
Such temperatures could
eventually
harm the glass cooktop surfaces.
12

SURFACE CLEANING
Glass Ceramic Cooktop Cleaning
Cleaning of glass ceramic cooktops is different from
cleaning a standard porcelain finish. To maintain and
protect the surface of your new glass ceramic cooktop
follow these basic steps.
Before using your cooktop for the first time, clean it
with Cook Top Cleaning Creme. This helps protect
the top and makes clean-up easier.
DAILY CLEANING: Use only Cook Top Cleaning
Creme on Glass Ceramic.
For normal, light soil:
1. Rub a few drops (less is better) of Cook Top
Cleaning Creme onto the soiled area using a damp
paper towel. Wipe until all soil and creme are
removed. Frequent cleaning leaves a protective
coating which is essential in preventing scratches
and abrasions.
2. Clean the surface with Cook Top Cleaning Creme
after each use.
For heavy, burned on soil:
1. Apply a few drops of Cook Top Cleaning Creme to
the (cool) soiled area.
2. Using a damp paper towel, rub creme into the
burned on area. As with any burned on spill, this
may require some effort.
3. Carefully scrape remaining soil with the razor
scraper. Hold the scraper at a 30° angle against the
ceramic surface.
4. If any soil remains, repeat the steps listed above.
For additional protection, after all soil has been
removed, polish the entire surface with the Cook
Top Cleaning Creme.
5. Buff with a dry paper towel.
NOTE:
• Using a razor scraper will not damage the surface
if the 30° angle is maintained.
• Be sure to use a new, sharp razor blade.
Do not use a dull or nicked blade.
• Store the razor blade out of reach of children.
Special Care:
Sugary spillovers (such as jellies, fudge, candy
syrups) or melted plastics can cause pitting of the
surface of your cooktop (not covered by the warranty)
unless the spill is removed while still hot. Special
care should be taken when removing hot
substances. Follow these instructions carefully and
remove the soil while the spill is still hot.
1. Turn off all the surface units affected by the
spillover. Remove hot pans.
2. Wearing an oven mitt, hold the razor
scraper at a 30° angle to the cooktop
and scrape the hot spill to a cool area
outside the surface unit.
3. With the spill in a cool area, use a dry paper towel to
remove any excess. Any spillover remaining should
be left until the surface of the cooktop has cooled.
Do not continue to use the soiled surface unit until all
of the spillover has been removed. Follow the steps
under Heavy Soil to continue the cleaning process.
General Information:
As the Cook Top Cleaning Creme cleans, it
leaves a protective coating on the cooktop surface.
This coating helps to prevent build-up of mineral
deposits (water spots) and will make future cleaning
easier. Dishwashing detergents remove this protective
coating and therefore make the cooktop more
susceptible to staining.
To conveniently order more creme and/or
scrapers for cleaning your radiant range,
please call our toll free number:
National Parts Center 800-626-2002
Creme 10 oz. # WB02X8273
Scraper # WX5X1614
Creme and scraper kit # WB64X5027
PRECAUTIONS
• Most cleaners contain ammonia, chemicals and
abrasives which can damage the surface of your
cooktop. Use only the Cook Top Cleaning Creme
for proper cleaning and protection of your glass
ceramic surface.
• If you slide aluminum or copper cookware across
the surface of your cooktop, they may leave metal
markings which appear as scratches. If this should
happen, use the razor scraper and Cleaning Creme to
remove these markings. Failure to remove these
residues immediately may leave permanent marks.
•
Water stains (mineral deposits) are removable using
Cook Top Cleaning Creme or full strength white vinegar.
• If pots with a thin overlay of aluminum, copper or
enamel are allowed to boil dry, the overlay may bond
with the glass ceramic and leave a black discoloration.
This should be removed immediately before heating
again or the discoloration may be permanent.
• Use of window cleaner may leave an iridescent film
on the cooktop. Cook Top Cleaning Creme will
remove this discoloration.
Read and follow all instructions and warnings
on Cook Top Cleaning Creme labels.
13
Home Canning Tips Surface Cleaning

14
FEATURES OF YOUR OVEN CONTROL
1. COOK TIME. Press this pad and then press the
HOUR and MIN. pads to set the amount of time
you want your food to cook. Turn the Oven
Temperature knob to the desired temperature. The
oven will shut off after the Cook Time has run out.
The COOK TIME indicator light will flash along
with the OVEN ON indicator light at the end of a
timed cooking operation.
2. TIMER ON/OFF. Press this pad to select the
timer feature. The timer does not control oven
operations. The timer can time up to 11 hours and
59 minutes.
To set the timer, first press the TIMER ON/OFF
pad. Press the HOUR and MIN. pads to change
the time.
To cancel the timer, press the TIMER ON/OFF
pad until the display clears.
3. AUTOMATIC OVEN Light. This lights any
time the oven has been programmed for a timed
oven operation.
4. TIME DISPLAY. Shows the time of day and
the times set for the timer on automatic oven
operations.
5. HOUR and MIN. pads. These pads allow you to
set times up to 11 hours and 59 minutes.
6. OVEN ON Light. Glows any time the oven is
heating. The light will flash at the end of a timed
oven operation, reminding you to turn the Oven
Temperature knob to OFF.
7. OVEN TEMPERATURE Knob. Turn this knob
to the temperature or function you want. See the
Baking, Roasting, Broiling and Self-Cleaning
sections.
8. PREHEATED Indicator Light. Glows when
the oven reaches your selected temperature.
9. AUTO SELF CLEAN Light. Glows when the
oven is in the Self-Clean cycle. After the Self-
Clean Cycle, the light will flash. Unlatch the door
and turn the Oven Temperature knob to OFF.
10. CLOCK. Press this pad before setting the clock.
To set the clock, first press the CLOCK pad.
Then press the HOUR and MIN. pads to change
the time of day.
11. START TIME. Press this pad and the HOUR
and MIN. pads to delay the starting of your oven
up to 11 hours and 59 minutes.
If “F–and a number” flash in the display and
the oven control signals, this indicates function
error code. If function error code appears during
the self-cleaning function, check the oven door
latch—the latch handle may have been moved,
even if only slightly, from the latched position.
Make sure handle is to the right as far as it will
go. Turn the Oven Temperature knob to OFF.
Allow the oven to cool for one hour. If function
error code repeats, disconnect power to the range
and call for service.
HOUR MIN.
HR MIN
AUTOMATIC OVEN
COOK
TIME
START
TIME
TIMER
ON/OFF
CLOCK
PREHEATED
OVEN ON
LATCH
DOOR
AUTO
SELF
CLEAN
1 2 3 4 5 6 7
11
10 98

To Reset the Timer To Cancel the Timer
Power Outage Oven Temperature Knob
If the display is still showing the time remaining, you
may change it by pressing the HOUR and MIN. pads
until the time you want appears in the display.
If the remaining time is not in the display, recall the
remaining time by pressing the TIMER ON/OFF pad
and then pressing the HOUR and MIN. pads until the
new time you want shows on the display.
To cancel the timer, the remaining time must be in
the display. To recall the time remaining, press the
TIMER ON/OFF pad once. To cancel the timer press
the TIMER ON/OFF pad again.
The clock must be set for the
automatic oven timing functions to
work properly. The time of day
cannot be changed during a Timed
Baking or Self-Cleaning cycle.
1. Press the CLOCK
pad. The display
will flash.
2. Press the HOUR and MIN. pads
to set the correct time of day.
3. Press the CLOCK pad for an
immediate start.
1. Press the CLOCK pad, the
display will be blank. Press the
CLOCK pad again, the display
will flash.
2. Press the HOUR and MIN. pads
to set the correct time of day.
3. Press the CLOCK pad again for
an immediate start.
CLOCK
When the power is restored the display will flash
the time of day until a pad is pressed or the knob
is turned. Reset the clock to the correct time of day.
If your oven was set for a timed oven operation
when the power outage occurred, the clock and all
programmed functions must be reset. To reset them,
first turn the Oven Temperature knob back to OFF
and then reset the clock, functions and knob back to
the way they were before the power outage.
The oven temperature
knob maintains the
temperature you set
from WARM to 550°F.
It also has an OFF,
BROIL and an AUTO
SELF CLEAN
setting.
The PREHEATED light glows when the oven
reaches your selected temperature.
The OVEN ON light will glow any time the Oven
Temperature knob is not in the OFF position and is
set on a temperature or a function.
PREHEATED
OVEN ON
LATCH
DOOR
AUTO
SELF
CLEAN
OVEN CONTROL, CLOCK AND TIMER
Automatic Clock To Set the Clock To Reset the Clock
Features of Your Oven Control Oven Control, Clock and Timer
To Blank Out the Clock Timer To Set the Timer
If you have several clocks in your
kitchen, you may wish to blank the
time of day display of your range.
If so, press the CLOCK pad.
Although you cannot see it, the
clock maintains the correct time of
day. It will reappear for the
duration of any function that
displays a Start Time or Cook
Time. Press the CLOCK pad again
to bring back the display.
The timer is a minute timer and
does not control oven operations.
The maximum setting on the timer
is 11 hours and 59 minutes.
1. Press the TIMER
ON/OFF pad.
2. Press the HOUR
and MIN. pads
until the amount of time you
want shows in the display. The
timer will start automatically
within a few seconds of
releasing the pad.
When the countdown is finished
the control will beep until the
TIMER ON/OFF pad is pressed.
TIMER
ON/OFF
15

16
Automatic Oven Shut Off Oven Light
As a safety feature, this oven will automatically shut
itself off if it has been left on for more than 12 hours. Use the switch on the control panel to turn the oven light on and off.
Shelf Positions
The oven has four shelf supports identified in this
illustration as A (bottom), B, C and D (top). Shelf
positions for cooking are suggested in the Baking,
Roasting and Broiling sections.
A
B
C
D
USING YOUR OVEN
Before Using Your Oven
1. Look at the controls. Be sure you understand how
to set them properly.
2. Check the oven interior. Look at the shelves.
Take a practice run at removing and replacing
them properly to give sure, sturdy support.
3. Read over the information and tips that follow.
4. Keep this guide handy so you can refer to it,
especially during the first weeks of using
your new range.
NOTE: You may notice a “burning” or “oily” smell
the first few times you turn your oven on. This is
normal in a new oven and will disappear in a short
time. See the Operating the Self-Cleaning Oven section.
Oven Shelves
The shelves are designed with
stop-locks so when placed
correctly on the shelf supports,
they will stop before coming
completely out of the oven and
will not tilt when you are
removing food from them or
placing food on them.
When placing cookware on a shelf,
pull the shelf out to the bump on
the shelf support. Place the cookware
on the shelf, then slide the shelf
back into the oven. This will
eliminate reaching into the hot oven.
To remove the shelves from the
oven, pull them toward you, tilt
front end upward and pull them out.
To replace, place the shelf on the
shelf support with the stop-locks
(curved extension of the shelf)
facing up and toward the rear of
the oven. Tilt up front and push
the shelf toward the back of the
oven until it goes past the bump
on the shelf support. Then lower
the front of the shelf and push it all
the way back.
Bump

17
BAKING
Do not lock the oven door with the latch during
baking. The latch is used for self-cleaning only.
Your oven temperature is controlled very accurately
using an oven control system. We recommend that
you operate the range for a number of weeks using the
time given on recipes as a guide to become familiar
with your new oven’s performance.
If you think an adjustment is necessary, see the Adjust
the Oven Thermostat section. It lists easy Do It
Yourself instructions on how to adjust the thermostat.
NOTE: When the oven is hot, the top and outside
surfaces of the range get hot too.
How to Set Your Range for Baking
To avoid possible burns, place the shelves in the
correct position before you turn the oven on.
1. Turn the Oven Temperature knob to the desired
temperature. The OVEN ON indicator light will glow.
2. When the temperature inside the oven reaches your
preset temperature, a tone will sound and the
PREHEATED indicator light will glow. Place the
foods in the oven.
3. Check food for doneness at minimum time on
recipe. Cook longer if necessary.
4. Turn the Oven Temperature knob to OFF.
Oven Shelves
Arrange the oven
shelf or shelves in
the desired locations
while the oven is
cool. The correct
shelf position
depends on the kind
of food and the
browning desired.
As a general rule,
place most foods in the middle of the oven, on either
shelf position B or C. See the chart for suggested shelf
positions.
Type of Food Shelf Position
Angel food cake A
Biscuits or muffins B or C
Cookies or cupcakes B or C
Brownies B or C
Layer cakes B or C
Bundt or pound cakes A or B
Pies or pie shells B or C
Frozen pies A (on cookie sheet)
Casseroles B or C
Roasting A or B
D
C
B
A
Preheating
Preheating is necessary for good results when baking
cakes, cookies, pastry and breads. For most casseroles
and roasts, preheating is not necessary. For ovens
without a preheat indicator light or tone, preheat 10
minutes. After the oven is preheated, place the food
in the oven as quickly as possible to prevent heat
from escaping.
Preheat the oven if the recipe calls for it. Preheat means
bringing the oven up to the specified temperature
before putting the food in the oven. To preheat, set the
oven at the correct temperature—selecting a higher
temperature does not shorten preheat time.
(continued next page)
Using Your Oven Baking

18
Baking Pans Pan Placement
Use the proper baking pan. The type of finish on the
pan determines the amount of browning that will occur.
• Dark, rough or dull pans absorb heat resulting in a
browner, crisper crust. Use this type for pies.
• Shiny, bright and smooth pans reflect heat, resulting
in a lighter, more delicate browning. Cakes and
cookies require this type of pan.
• Glass baking dishes also absorb heat. When baking
in glass baking dishes, the temperature may need to
be reduced by 25°F.
• If you are using dark non-stick pans, you may find
that you need to reduce the oven temperature 25°F.
to prevent browning.
For even cooking and proper browning, there must be
enough room for air circulation in the oven. Baking
results will be better if baking pans are centered as
much as possible rather than being placed to the front
or to the back of the oven.
Pans should not touch each other or the walls of
the oven. Allow 1- to 11⁄2-inch space between pans
as well as from the back of the oven, the door and
the sides. If you need to use two shelves, stagger the
pans so one is not directly above the other.
Baking Guides
When using prepared baking mixes, follow package recipe or instructions
for the best baking results.
Cookies Aluminum Foil
When baking cookies,
flat cookie sheets
(without sides) produce
better-looking cookies.
Cookies baked in a
jelly roll pan (short
sides all around) may
have darker edges and
pale or light browning
may occur.
Do not use a cookie sheet so large that it touches the
walls or the door of the oven. Never entirely cover
a shelf with a large cookie sheet.
For best results, use only one cookie sheet in the
oven at a time.
Never entirely cover
a shelf with aluminum
foil. This will disturb
the heat circulation
and result in poor
baking. A smaller
sheet of foil may be
used to catch a
spillover by placing
it on a lower shelf
several inches below the food.
BAKING
(continued)
Pies Cakes
For best results, bake pies in dark, rough or dull pans
to produce a browner, crisper crust. Frozen pies in foil
pans should be placed on an aluminum cookie sheet
for baking since the shiny foil pan reflects heat away
from the pie crust; the cookie sheet helps retain it.
When baking cakes, warped or bent pans will cause
uneven baking results and poorly shaped products.
A cake baked in a pan larger than the recipe
recommends will usually be crisper, thinner and
drier than it should be. If baked in a pan smaller than
recommended, it may be undercooked and batter may
overflow. Check the recipe to make sure the pan size
used is the one recommended.

Baking Timed Baking
19
Don’t Peek
Set the timer for the estimated cooking time and do
not open the door to look at your food. Most recipes
provide minimum and maximum baking times such
as “bake 30-40 minutes.”
DO NOT open the door to check until the minimum
time. Opening the oven door frequently during
cooking allows heat to escape and makes baking times
longer. Your baking results may also be affected.
To avoid possible burns, place the shelves in the
correct position before you turn the oven on.
The oven will turn on immediately and cook for
a selected length of time. At the end of Cook Time,
the oven will turn off automatically.
1. Press the COOK TIME pad. The
COOK TIME and AUTOMATIC
OVEN indicator lights will glow
and the OVEN ON indicator light
will flash.
2. Press the HOUR
and MIN. pads until
the desired length of
baking time appears in
the display.
3. Turn the Oven Temperature knob to the desired
temperature. The OVEN ON indicator light will glow.
4. The oven will turn on. When the temperature inside
the oven reaches your preset temperature, a tone
will sound and the PREHEATED indicator light
will glow.
5. When the oven automatically turns off, the OVEN
ON and COOK TIME indicator lights will flash
and the Oven Control will beep continuously until
the Oven Temperature knob is turned to OFF.
6. Remove the food from the oven. Remember, foods
that are left in the oven continue cooking after the
controls are off.
NOTE: Foods that spoil easily such as milk, eggs,
fish, stuffings, poultry and pork should not be allowed
to sit for more than one hour before or after cooking.
Room temperature promotes the growth of harmful
bacteria. Be sure that the oven light is off because heat
from the bulb will speed harmful bacteria growth.
(continued next page)
HOUR MIN.
COOK
TIME
How to Set Immediate Start and Automatic Stop
TIMED BAKING
(on some models)
How to Time Bake
Do not lock the oven door with the latch during
timed baking. The latch is used for self-cleaning only.
The oven control allows you to turn the oven on or off
automatically at specific times that you set. Examples
of Immediate Start (oven turns on now and you set it to
turn off automatically) and Delay Start (setting the
oven to turn on automatically at a later time and turn
off automatically) will be described.
NOTE: Before beginning, make sure the oven clock
shows the correct time of day.
To set the clock, first press the
CLOCK pad. Then press the HOUR
and MIN. pads until the correct time
of day is displayed.
CLOCK

20
TIMED BAKING
(continued)
To avoid possible burns, place the shelves in the
correct position before you program the oven.
You can set the oven control to delay-start the
oven, cook for a specific length of time and then
turn off automatically.
1. Press the COOK TIME pad. The
COOK TIME and AUTOMATIC
OVEN indicator lights will glow
and the OVEN ON indicator light
will flash.
2. Press the HOUR and
MIN. pads until the
desired length of baking
time appears in the
display.
3. Press the START TIME pad.
The START TIME indicator light
will glow.
4. Press the HOUR and MIN. pads until the desired
Start Time appears in the display.
5. Turn the Oven Temperature knob to the desired
temperature. The OVEN ON indicator light will glow.
6. The oven will turn on automatically at the time you
set and cook for the length of time you set. When
the oven automatically turns off the COOK TIME
and OVEN ON indicator lights will flash and the
control will beep continuously until the Oven
Temperature knob is turned to OFF.
7. Remove the food from the oven. Remember,
even though the oven shuts off automatically,
foods continue cooking after controls are off.
NOTE:
• The low temperature zone of this range (between
WARM and 200°F.) is available to keep hot cooked
foods warm. Food kept in the oven longer than
2 hours at these low temperatures may spoil.
• Foods that spoil easily such as milk, eggs, fish,
stuffings, poultry and pork should not be allowed to
sit for more than one hour before or after cooking.
Room temperature promotes the growth of harmful
bacteria. Be sure that the oven light is off because heat
from the bulb will speed harmful bacteria growth.
START
TIME
HOUR MIN.
COOK
TIME
Easy Steps:
1. Press the COOK TIME pad.
2. Press the HOUR and MIN. pads to set the
desired length of baking time.
3. Press the START TIME pad.
4. Press the HOUR and MIN. pads until the
desired Start Time appears in the display.
5. Turn the Oven Temperature knob to the
desired temperature.
How to Set Delay Start and Automatic Stop
Questions and Answers
Q. Can I use the minute timer during oven
cooking?
A. The minute timer can be used during any
cooking function.
Q. Can I change the time of day on the clock while
I’m Time Baking in the oven?
A. The time of day on the clock should not be
changed during any program that uses the oven
timer. You must either stop those programs or wait
until they are finished before changing the time.
