RCA L26HD32D User manual

ATTENTION
If you purchase a universal remote control from your local retailer, please contact the remote manufacturer for the
required programming code.
AIR/CABLE MODE SELECTION
When shipped from the factory, the Signal Type option is set to the “Cable” (Cable Television) mode.
If not using Cable TV, set this menu option to the “Air” position.
Before operating the unit, please read this manual thoroughly.
26/32” TFT LCD DIGITAL TV WITH DVD PLAYER
OWNER’S MANUAL
L26HD32D
L32HD32D
Digital Television Transition Notice
This device contains a digital television tuner, so it should receive digital over the air TV programming, with a
suitable antenna, after the end of full-power analog TV broadcasting in the United States on February 17, 2009.
Some older television receivers, if they rely on a TV antenna, will need a TV Converter to receive over the air digital
programming, but should continue to work as before for other purposes (e.g., for watching low-power TV stations
still broadcasting in analog, watching pre-recorded movies, or playing video games). When a Converter is used
with an older television receiver, a signal splitter might be necessary to continue to receive low-power analog
broadcasts via an antenna. For more information, please see www.DTV.gov. For information on the TV Converter
program, and on government subsidized coupons that may be used toward the purchase of one, see www.
dtv2009.gov, or call the NTIA at 1-888-DTV-2009.
51F0101B_eng.indd 1 4/4/08 10:04:02 AM

2
ANT
ACINPUT
CAUTION
RISKOF ELECTRIC SHOCK
DO NOTOPEN
WARNING:SHOCKHAZARD-DO NOTOPEN.
AVIS:RISQUEDE CHOC ELECTRIQUE-NEPAS OUVRIR
CAUTION:
THIS DIGITAL VIDEO PLAYER EMPLOYS A LASER SYSTEM.
TO ENSURE PROPER USE OF THIS PRODUCT, PLEASE
READ THIS OWNER'S MANUAL CAREFULLY AND RETAIN
FOR FUTURE REFERENCE. SHOULD THE UNIT REQUIRE
MAINTENANCE, CONTACT AN AUTHORIZED SERVICE
LOCATION-SEE SERVICE PROCEDURE.
USE OF CONTROLS, ADJUSTMENTS OR THE
PERFORMANCE OF PROCEDURES OTHER THAN THOSE
SPECIFIED HEREIN MAY RESULT IN HAZARDOUS
RADIATION EXPOSURE.
TO PREVENT DIRECT EXPOSURE TO THE LASER BEAM,
DO NOT TRY TO OPEN THE ENCLOSURE. RADIATION MAY
BE PRESENT WHEN THE ENCLOSURE IS OPENED. DO
NOT STARE INTO THE BEAM.
Location of the required Marking
The rating sheet and the safety caution are
on the rear of the unit.
The lightning flash with arrowhead
symbol, within an equilateral triangle
is intended to alert the user to the
presence of uninsulated dangerous
voltage within the product's enclosure
that may be of sufficient magnitude to
constitute a risk of electric shock.
The exclamation point within an
equilateral triangle is intended to
alert the user to the presence of
important operating and maintenance
(servicing) instructions in the literature
accompanying the appliance.
CAUTION: TO REDUCE THE RISK OF ELECTRIC
SHOCK, DO NOT REMOVE COVER
(OR BACK). NO USER-SERVICEABLE
PARTS INSIDE. REFER SERVICING TO
QUALIFIED SERVICE PERSONNEL.
WARNING: TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS APPLIANCE TO RAIN
OR MOISTURE.
CAUTION: TO PREVENT ELECTRIC SHOCK DO NOT USE THIS POLARIZED PLUG WITH AN EX-
TENSION CORD, RECEPTACLE OR OTHER OUTLET UNLESS THE BLADES CAN BE
FULLY INSERTED TO PREVENT BLADE EXPOSURE.
CERTIFICATION: COMPLIES WITH FDA
RADIATION PERFORMANCE STANDARDS,
21 CFR SUBCHAPTER J.
The lamp(s) within this product contain mercury.
Disposal should be in compliance with local, state or federal laws.
Product Registration
Please fill out the product registration card (packed separately) and return it immediately. For US customers:Your RCA Consumer
Electronics product may also be registered at www.rca.com/television. Registering this product allows us to contact you if needed.
Product Information
Keep your sales receipt to obtain warranty parts and service and for proof of purchase. Attach it here and record the serial and model
numbers in case you need them.These num bers are located on the product.
Model No._____________________ Serial No. __________________________Purchase Date: __________________________
Dealer / Address / Phone: __________________________________________________________________________________
WARNING: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant
to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation.This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference to
radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
CAUTION: Changes or modifications not expressly approved by the partly responsible for compliance with the FCC Rules
could void the user’s authority to operate this equipment.
51F0101A_eng.indd 2 3/10/08 10:56:09 AM

3
IMPORTANT SAFETY INSTRUCTIONS
1) Read these instructions.
2) Keep these instructions.
3) Heed all warnings.
4) Follow all instructions.
5) Do not use this apparatus near water.
6) Clean only with a clean dry cloth.
7) Do not block any ventilation openings. Install in accordance with the manufacturer's instructions.
8) Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including
amplifiers) that produce heat.
9) Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades
with one wider than the other. A grounding type plug has two blades and a third grounding prong.The
wide blade and the third prong are provided for your safety. If the provided plug does not fit into your outlet,
consult an electrician to replace the obsolete receptacle.
10) Protect the power cord from being walked on or pinched particularly at plug, and the point where it exits
from the apparatus.
11) Only use attachments/accessories specified by the manufacturer.
12) Use only with the cart, stand, tripod, bracket, or table specified by the
manufacturer, or sold with the apparatus. When a cart is used, use caution
when moving the cart/apparatus combination to avoid injury from tip-over.
13) Unplug this apparatus during lightning storms or when unused for long periods
of time.
14) Refer all servicing to qualified service personnel. Servicing is required when the
apparatus has been damaged in any way, such as power-supply cord or plug
damage, liquid has been spilled or objects have fallen into the apparatus, the
apparatus has been exposed to rain or moisture, does not operate normally, or
has been dropped.
15) Apparatus should not be exposed to dripping or splashing, and objects filled with liquids, such as vases,
should not be placed on the apparatus.
16) An outside antenna system should not be located in the vicinity of overhead power lines or other electric
light or power circuits, or where it can fall into such power lines or circuits. When installing an outside
antenna system, extreme care should be taken to keep from touching such power lines or circuits, as
contact with them might be fatal.
17) Do not overload wall outlets and extension cords, as this can result in a risk of fire or electric shock.
18) Do not push objects through any openings in this unit, as they may touch dangerous voltage points or short
out parts that could result in fire or electric shock. Never spill or spray any type of liquid into the unit.
19) If an outside antenna or cable system is connected
to the unit, be sure the antenna or cable system is
grounded to provide some protection against voltage
surges and built-up static charges, Section 810 of the
National Electrical Code, ANSI/NFPA 70, provides
information with respect to proper grounding of the
mast and supporting structure, grounding of the
lead-in wire to an antenna discharge unit, size of
grounding conductors, location of antenna discharge
unit, connection to grounding electrodes, and
requirements for the grounding electrode.
S3126A
PORTABLE CART WARNING
(symbol provided by RETAC)
ANTENNA
DISCHARGE UNIT
(NEC SECTION 810-20)
ANTENNA
LEAD IN WIRE
GROUNDING CONDUCTORS
(NEC SECTION 810-21)
GROUND CLAMPS
POWER SERVICE GROUNDING
ELECTRODE SYSTEM
(NEC ART 250, PART H)
GROUND
CLAMP
ELECTRIC SERVICE
EQUIPMENT
NE
C
-NATI
O
NAL
ELECTRICAL CODE
S2898A
EXAMPLE OF ANTENNA GROUNDING AS PER THE
NATIONAL ELECTRICAL CODE
51F0101A_eng.indd 3 3/5/08 5:05:45 PM

4
IMPORTANT SAFETY INSTRUCTIONS (continued)
20) When replacement parts are required, be sure the service technician uses replacement parts specified by
the manufacturer or those that have the same characteristics as the original part.
Unauthorized substitutions may result in fire, electric shock or other hazards.
21) Upon completion of any service or repairs to this unit, ask the service technician to perform safety checks to
determine that the unit is in proper operating condition.
22) Keep your fingers clear of the disc slot as it is closing. It may cause injury.
23) When you connect the product to other equipment, turn off the power and unplug all of the equipment from
the wall outlet. Failure to do so may cause an electric shock and serious personal injury. Read the owner's
manual of the other equipment carefully and follow the instructions when making any connections.
24) Reduce the volume to the minimum level before you turn on the product. Otherwise, sudden high volume
sound may cause hearing or speaker damage.
25) Do not allow the product to output distorted sound for an extended period of time. It may cause speaker
overheating and fire.
26) When you use the headphones, keep the volume at a moderate level. If you use the headphones
continuously with high volume sound, it may cause hearing damage.
27) Do not look into the opening of the disc slot or ventilation opening of the product to see the source of the
laser beam. It may cause eye damage.
28) Do not use a cracked, deformed, or repaired disc. These discs are easily broken and may cause serious
personal injury and product malfunction.
29) This reminder is provided to call the cable TV system installer’s attention to Article 820-40 of the NEC
that provides guidelines for proper grounding and, in particular, specifies that the cable ground shall be
connected to the grounding system of the building, as close to the point of cable entry as practical.
CONDENSATION
Moisture will form in the operating section of the player if the player is brought from cool surroundings into a warm
room or if the temperature of the room rises suddenly. When this happens, player's performance will be impaired.
To prevent this, let the player stand in its new surroundings for about an hour before switching it on, or make sure
that the room temperature rises gradually.
Condensation may also form during the summer if the player is exposed to the breeze from an air conditioner. In
such cases, change the location of the player.
HOW TO HANDLE THE LCD PANEL
Do not press hard or jolt the LCD panel. It may cause the LCD panel glass to break and injury may occur.
If the LCD panel is broken, make absolutely sure that you do not touch the liquid in the panel. This may cause
skin inflammation.
If the liquid gets in your mouth, immediately gargle and consult with your doctor. Also, if the liquid gets in your
eyes or touches your skin, consult with your doctor after rinsing for at least 15 minutes or longer in clean water.
•
•
51F0101A_eng.indd 4 3/5/08 5:05:46 PM

5
The unit emits heat when in operation. Do not place any covers or blankets on the unit, this may cause
overheating. Do not block ventilation holes, or set up near radiators. Do not place in direct sunshine. When
placing on a shelf leave 10 cm (4 inches) free space around the entire unit.
10cm
10cm
Notes when mounting the LCD TV/DVD on a wall
If the unit is to be mounted on the wall, contact the retailer where you purchased the LCD TV/DVD for advice,
and have the equipment professionally installed. Incomplete or improper installation may cause injury to you,
and/or damage to the LCD TV/DVD.
IMPORTANT NOTICE
Possible Adverse Effects on LCD Panel: If a fixed (non-moving) pattern remains on the LCD Panel for
long periods of time, the image can become permanently engrained in the LCD Panel and cause subtle but
permanent ghost images.This type of damage is NOT COVERED BY YOUR WARRANTY. Never leave your
LCD Panel on for long periods of time while it is displaying the following formats or images:
Fixed Images, such as stock tickers, video game patterns, TV station logos, and websites.
Special Formats that do not use the entire screen. For example, viewing letterbox style (16:9) media on
a normal (4:3) display (black bars at top and bottom of screen); or viewing normal style (4:3) media on a
widescreen (16:9) display (black bars on left and right sides of screen).
The following symptoms are not signs of malfunction but technical limitation. Therefore we disclaim
any responsibility for these symptoms.
LCD Panels are manufactured using an extremely high level of precision technology, however sometimes
parts of the screen may be missing picture elements or have luminous spots.
This is not a sign of a malfunction.
Do not install the LCD Panel near electronic equipment that is susceptible to electromagnetic waves. Some
equipment placed too near this unit may cause interference.
Effect on infrared devices – There may be interference while using infrared devices such as infrared cordless
headphones.
•
•
•
•
•
SAFETY PRECAUTIONS
51F0101A_eng.indd 5 3/5/08 5:05:46 PM

6
*This product incorporates copyright protection technology that is protected by U.S. patents and other
intellectual property rights. Use of this copyright protection technology must be authorized by Macrovision,
and is intended for home and other limited viewing uses only unless otherwise authorized by Macrovision.
Reverse engineering or disassembly is prohibited.
*is a trademark of DVD Format/Logo Licensing Corporation.
*Manufactured under license from Dolby Laboratories. Dolby and the double-D symbol are trademarks of
Dolby Laboratories.
*
Manufactured under license under U.S. Patent #: 5,451,942 & other U.S. and worldwide patents issued &
pending. DTS and DTS Digital Out are registered trademarks and the DTS logos and Symbol are trademarks
of DTS, Inc.© 1996-2007 DTS, Inc. All Rights Reserved.
*HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks or registered trademarks of
HDMI Licensing LLC.
Features
LCD color TV With DVD/CD player
Unique space saving design combines a 26/32” LCD color TV and a DVD/CD player.
A DVD disc has much more capacity, but is the same size as an audio CD disc. The Picture/Audio quality of a
DVD exceeds other software. The picture quality is higher than Super VHS video cassettes. The audio quality
is higher than an audio CD. The DVD also has special options; audio language selection, subtitle language
selection, or multi-angle, etc.
The DVD PLAYER can play back both audio CDs and MP3/WMA/JPEG CDs.
Compatible with a wide range of DVD audio outputs
Digital Audio Jack (Coaxial)
When a component with a built-in Dolby Digital decoder is connected, Dolby Digital sound can produce the
effect of being in a movie theater or a concert hall.
Surround standard is different from Dolby Digital.This format is already in use in many theaters. By connecting
this unit to a DTS decoder or an AV amplifier with a built-in DTS decoder, the DTS audio of DVD discs
recorded in this format can be enjoyed. However, audio will not be output from the analog audio output jacks.
By connecting this unit to an AV amplifier with a built-in MPEG decoder, the MPEG audio of DVD discs
recorded in this format can be enjoyed.
The Linear PCM sound of a 48 kHz/24 bit through 96 kHz/24 bit exceeds audio CD sound.
Convenience Features
Direct selection of your desired scenes using Title/Chapter/Time/Track - You can play back from the
desired scene.
Recalling Up to 3 Scenes -
You can program up to 3 scenes in memory and recall the marked scenes.
Frame Advance - The PAUSE/STILL moves one frame at a time.
Slow Motion - The SLOW moves you back and forth through the program by 4 steps of 1/7-1/2 times.
Repeat Playback - You can repeat chapter, track, title, sides or material between two selected points.
Program Playback (Audio CD/MP3/WMA CD) - You can play back tracks in programmed sequences.
Zoom - You can zoom in the selected subject on the screen during playback.
Note: Make sure that discs are suitable for the following functions.
Multi-Language - Maximum 32 language subtitles and maximum 8 language soundtracks can be played back
for movies or programs.
Multi-Angle - Pictures of Sports or a Live Concert are recorded with many cameras. When you play such a disc,
you can change the angles during playback.
Parental Control - You can limit the play back of scenes or sounds of DVD discs that have a rating level
encoded on the disc.
Video Aspect Ratio - You can change the aspect ratio of the screen for your monitor.
TV Features
Integrated Digital Tuner - You can view digital broadcasts without using a Digital TV Set-Top Box.
Closed Caption Decoder With Full Text Mode - Displays text captions or full screen text on the screen for
hearing impaired viewers.
Picture Adjustments Using The Remote Control - The On-Screen display allows precise remote control
adjustment of BRIGHTNESS, CONTRAST, COLOR, TINT and SHARPNESS.
Programmable TV Sleep Timer - Operable from the remote control, the TV can be programmed for up to 120
minutes to turn off automatically.
On-Screen 3 Language Display - You can select one of 3 languages, English, Spanish or French for on-
screen programming.
V-Chip - The V-Chip function can read the rating of a TV program or movie content if the program is encoded
with this information.V-chip will allow you to set a restriction level.
•
•
•
•
51F0101A_eng.indd 6 3/5/08 5:05:46 PM

7
Contents
Before using your unit
IMPORTANT SAFETY INSTRUCTIONS...........3
SAFETY PRECAUTIONS .................................5
IMPORTANT NOTICE.......................................5
Features............................................................6
Contents ...........................................................7
Disc...................................................................8
Location of controls...........................................9
Remote control ...............................................11
Power source ..................................................12
Antenna connections ......................................13
Cable TV connections.....................................14
TV operation
Setting the on-screen language ......................15
Memorizing channels......................................15
TV operation ...................................................16
Labeling channels...........................................17
Labeling video inputs ......................................18
Setting the V-Chip ...........................................18
Closed Caption ...............................................20
CC advanced..................................................20
Adjusting the picture preference .....................21
Picture control adjustment ..............................21
Selecting the color temperature ......................21
Setting the picture size....................................22
Film Mode.......................................................22
Picture control adjustment in the PC mode .....23
DNR................................................................23
Sound control adjustment ...............................23
Selecting Stereo/Second Audio Program
(SAP) ..............................................................23
Selecting the audio language..........................24
Selecting the HDMI audio input source...........24
Turning off the built-in speakers ......................24
Adjusting the back lighting ..............................24
Setting the Auto Shut Off ................................25
Resetting your settings ...................................25
DVD operation
Preparation .....................................................25
Status display of disc ......................................25
Playback procedure ........................................26
Special playback.............................................26
MP3/WMA/JPEG and Audio CD playback......27
Setting the JPEG interval ................................28
Program playback (CD)..................................28
Repeat playback (CD).....................................29
Random playback (CD) ..................................29
Zooming..........................................................29
Locating desired scene...................................29
Repeat playback .............................................30
Marking desired scenes..................................30
Changing soundtrack language ......................30
Subtitles..........................................................31
Changing angles.............................................31
Title selection..................................................31
DVD menu ......................................................31
Setting the language.......................................32
Setting the aspect ratio of TV screen ..............32
Setting on screen display................................32
Setting the picture mode.................................32
Night Mode .....................................................33
Digital Out.......................................................33
Parental control...............................................33
Temporary disabling of rating level
by DVD disc ....................................................34
Additional information
Language code list..........................................35
Connections to other equipment.....................36
Reception disturbances ..................................39
Problems and troubleshooting ........................40
Specifications .................................................42
Limited Warranty.............................................43
51F0101A_eng.indd 7 3/5/08 5:05:47 PM

8
Playable discs
Disc type and logo mark content
DVD Video
Audio
+
Video
(moving
pictures)
CD-DA Audio
The following discs are also available.
DVD-R/RW discs of DVD video format.
CD-R/RW discs of MP3/WMA/JPEG.
•
•
Disc
CAUTION:
Only the left types of discs can be played on this
unit. DVD-ROM, CD-ROM, SVCD, CVD, VCD, etc.
cannot be played.
8cm discs can be played directly. If an 8cm disc
adapter is used it will cause errors.
If you insert an irregular shaped disc, it may get
stuck and cause a malfunction.
The use of a ring protector or other disc
accessories will cause errors.
This unit is to be used exclusively with the NTSC
color system. PAL and SECAM system discs cannot
be used with this unit.
Some CD-R/RWs and DVD-R/RW can not be
played back depending on the recording conditions.
•
•
•
•
•
•
Region Number
Region number (Regional restriction code) is built-in to the unit and DVD video discs.
Region number “1” or “ALL” of DVD video discs can be used on this unit.
Title
When two or more movies are recorded on a disc, the disc
is divided into two or more sections. Each section is called
a “TITLE”.
Chapter
The titles can be subdivided into many sections.
Each section is called a “CHAPTER”.
Track
An Audio CD can contain several items.
These are assigned to the tracks.
Removing Disc from Case
Be sure to hold the edge of disc. Do not touch the surface of the disc.
Pick up the disc gently from the case.
Do not scratch the disc.
Do not get dirt on the surface of the disc.
Do not stick a label or adhesive tape on the disc.
Do not drop or bend the disc.
Storing Disc
Store the disc in the case to avoid risk of scratches, dirt or damage.
Do not leave disc exposed to direct sunlight or in hot or humid places.
Cleaning Disc
Wipe the disc with a clean, dry cloth from center to edge.
Do not wipe the disc in a circular motion.
Do not use liquid or aerosol cleaners.
•
•
•
•
•
•
•
•
1ALL
CHAPTER 1
TITLE 1 TITLE 2
DVD DISC
CHAPTER 2 CHAPTER 2 CHAPTER 3CHAPTER 1
TRACK 1 TRACK 2 TRACK 3 TRACK 4 TRACK 5
Audio - CD
51F0101A_eng.indd 8 3/5/08 5:05:47 PM

9
Location of controls
Front
To display the menu screen.
Press MENU button to display the menu screen.
CHANNEL / buttons, VOLUME +/– buttons and INPUT/ENTER button can be used to select the desired
setting during the menu screen operations.
POWER button
INPUT/ENTER button
VOLUME +/– buttons
CHANNEL /1 (PLAY) button
MENU button
Remote sensor
POWER indicator
EJECT button
Left side
CHANNEL /3(STOP) button
DISC slot
51F0101A_eng.indd 9 3/5/08 5:05:48 PM

10
Location of controls (continued)
Rear side
COMPONENT IN jacks
PC/DVI AUDIO IN jack RF (ANT)IN jack
LINE 1 IN jacks
(VIDEO/S-VIDEO/AUDIO(L/R))
AUDIO (L/R) jacks
(for COMPONENT IN and LINE 2 VIDEO IN)
LINE 2 VIDEO
IN jack
AC INPUT jack
ANT
ACINPUT
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
WARNING:SHOCK HAZARD-DO NOT OPEN.
AVIS:RISQUE DE CHOC ELECTRIQUE-NE PAS OUVRIR
ANT
AC INPUT
HDMI 1/DVI IN jack
HDMI 2 IN jack
PC MONITOR IN jack
VAR (VARIABLE) AUDIO OUT jacks
COAXIAL DIGITAL AUDIO OUT jack
51F0101A_eng.indd 10 3/10/08 10:56:10 AM
