RCF HDL 26-A User manual

OWNER MANUAL
ACTIVE
LINE ARRAY MODULE
ACTIVE SUBWOOFER
ARRAY MODULE
HDL 26-A
HDL 35-AS

GENERAL SAFETY INSTRUCTION AND WARNINGS
IMPORTANT NOTE
Before connecting using or rigging the system, please read this instruction manual carefully and keep it on hand for
future reference. The manual is to be considered an integral part of the product and must accompany the system when
it changes ownership as a reference for correct installation and use as well as for the safety precautions. RCF S.p.A. will
not assume any responsibility for the incorrect installation and/or use of the product.
WARNING
• To prevent the risk of fire or electric shock, never expose this equipment to rain or humidity.
• The system HDL line arrays should be rigged and flown by professional riggers or trained personnel under
professional riggers’ supervision.
• Before rigging the system carefully read this manual.
SAFETY PRECAUTIONS
1. All the precautions, in particular the safety ones, must be read with special attention, as they provide important
information.
2. Power supply from mains. The mains voltage is sufficiently high to involve a risk of electrocution; install and connect
this product before plugging it in. Before powering up, make sure that all the connections have been made correctly
and the voltage of your mains corresponds to the voltage shown on the rating plate on the unit, if not, please
contact your RCF dealer. The metallic parts of the unit are earthed through the power cable. An apparatus with
CLASS I construction shall be connected to a mains socket outlet with a protective earthing connection. Protect the
power cable from damage; make sure it is positioned in a way that it cannot be stepped on or crushed by objects. To
prevent the risk of electric shock, never open this product: there are no parts inside that the user needs to access.
3. Make sure that no objects or liquids can get into this product, as this may cause a short circuit. This apparatus
shall not be exposed to dripping or splashing. No objects filled with liquid, such as vases, shall be placed on this
apparatus. No naked sources (such as lighted candles) should be placed on this apparatus.
4. Never attempt to carry out any operations, modifications or repairs that are not expressly described in this manual.
Contact your authorized service centre or qualified personnel should any of the following occur:
- the product does not function (or functions in an anomalous way).
- the power cable has been damaged.
- objects or liquids have got in the unit.
- the product has been subject to a heavy impact.
5. If this product is not used for a long period, disconnect the power cable.
6. If this product begins emitting any strange odours or smoke, switch it off immediately and disconnect the power
cable.
7. Do not connect this product to any equipment or accessories not foreseen.
For suspended installation, only use the dedicated anchoring points and do not try to hang this product by using
elements that are unsuitable or not specific for this purpose. Also check the suitability of the support surface to
which the product is anchored (wall, ceiling, structure, etc.), and the components used for attachment (screw
anchors, screws, brackets not supplied by RCF etc.), which must guarantee the security of the system / installation
over time, also considering, for example, the mechanical vibrations normally generated by transducers.
To prevent the risk of falling equipment, do not stack multiple units of this product unless this possibility is specified
in the user manual.

8. RCF S.p.A. strongly recommends this product is only installed by professional qualified installers (or specialised
firms) who can ensure correct installation and certify it according to the regulations in force.
The entire audio system must comply with the current standards and regulations regarding electrical systems.
9. Supports and trolleys.
The equipment should be only used on trolleys or supports, where necessary, that are recommended by the
manufacturer. The equipment / support / trolley assembly must be moved with extreme caution. Sudden stops,
excessive pushing force and uneven floors may cause the assembly to overturn.
10. There are numerous mechanical and electrical factors to be considered when installing a professional audio system
(in addition to those which are strictly acoustic, such as sound pressure, angles of coverage, frequency response,
etc.).
11. Hearing loss.
Exposure to high sound levels can cause permanent hearing loss. The acoustic pressure level that leads to hearing
loss is different from person to person and depends on the duration of exposure. To prevent potentially dangerous
exposure to high levels of acoustic pressure, anyone who is exposed to these levels should use adequate protection
devices. When a transducer capable of producing high sound levels is being used, it is therefore necessary to wear
ear plugs or protective earphones. See the manual technical specifications to know the maximum sound pressure
level.
To prevent the occurrence of noise on line signal cables, use screened cables only and avoid putting them close to:
- Equipment that produces high-intensity electromagnetic fields.
- Power cables
- Loudspeaker lines.
OPERATING PRECAUTIONS
- Place this product far from any heat sources and always ensure an adequate air circulation around it.
- Do not overload this product for a long time.
- Never force the control elements (keys, knobs, etc.).
- Do not use solvents, alcohol, benzene or other volatile substances for cleaning the external parts of this product.
GENERAL OPERATING PRECAUTIONS
• Do not obstruct the ventilation grilles of the unit. Situate this product far from any heat sources and always ensure
adequate air circulation around the ventilation grilles.
• Do not overload this product for extended periods of time.
• Never force the control elements (keys, knobs, etc. ).
• Do not use solvents, alcohol, benzene or other volatile substances for cleaning the external parts of this product.
CAUTION
To prevent electric shock hazard, do not connect to mains power supply while grille is removed

HDL 26-A
The RCF HDL26-A is an ultra-compact bi-amped 2-way active touring system for small and medium-sized events, both
indoors and outdoors. Because of the advanced transducers’ design and the 2000W Class-D amplifier, among the best
in its class, it is capable of extended bottom end and a pristine sound for a wide range of applications, alone or in a line-
array configuration. It features two 6-inch woofers and an impressive 3-inch titanium compression driver. The proprietary
4PATH waveguide and the impressive 3-inch titanium compression driver create a precise coverage of 100 x 10 degrees
and constant directivity without break up or attenuation. Following the HDL 30-A philosophy, the HDL 26-A shares
the RDNet management network, the composite material cabinet, the zero-degree phase, and ultra-linear amplitude
response. The symmetrical design of the cabinet delivers identical left and right coverage producing excellent playback
clarity up to 133 decibel SPL max.
THE HDL 35-AS
The HDL 35-AS is the ideal flyable bass complement for the HDL 26-A array system. It features a baltic birch plywood
cabinet housing one 4.0” voice coil, 15” Neodymium woofer to handle frequencies from 40 Hz to 140 Hz with the
maximum linearity and lowest distortion. The built-in 2200 watt class-D amplifier delivers excellent playback clarity and
up to 134 decibels SPL max. Due to its RDNet compatibility, the HDL 35-AS is part of the professional HDL System.
POWER REQUIREMENTS AND SET-UP
WARNING
• The system is designed to operate in hostile and demanding situations. Nevertheless it is important to take
extremely care of the AC power supply and set up a proper power distribution.
• The system is designed to be GROUNDED. Always use a grounded connection.
• PowerCon appliance coupler is a AC mains power disconnection device and must be readily accessible during and
after the installation.
CURRENT
The following are the long term and peak current requirement for each HDL 26-A module:
The total current requirement is obtained multiplying the single current requirement by the number of modules.To obtain the best
performances make sure that the total burst current requirement of the system doesn’t create a significant voltage drop on the
cables.
GROUNDING
Make sure that all the system is properly grounded. All the grounding points shall be connected to the same ground
node. This will improve reducing hums in the audio system.
VOLTAGE LONG TERM
230 Volt 3.15 A
115 Volt 6.3 A

POWERCON IN
POWERCON OUT
AC CABLES DAISY CHAINS
POWERING FROM THREE PHASE
When the system is powered from a three phase power distribution it is very important to keep a good balance in the
load of each phase of the AC power. It is very important to include subwoofers and satellites in power distribution
calculation: both subwoofers and satellites shall be distributed between the three phases.
RIGGING THE SYSTEM
RCF has developed a complete procedure to set up and hang an HDL 26-A line array system starting from software data,
enclosures, rigging, accessories, cables, until the final installation.
GENERAL RIGGING WARNINGS AND SAFETY PRECAUTIONS
• Suspending loads should be done with extreme caution.
• When deploying a system always wear protective helmets and footwear.
• Never allow people to pass under the system during the installation process.
• Never leave the system unattended during the installation process.
• Never install the system over areas of public access.
• Never attach other loads to the array system.
• Never climb the system during or after the installation
• Never expose the system to extra loads created from the wind or snow.
WARNING
• The system must be rigged in accordance with the laws and regulations of the Country where the system is used. It
is responsibility of the owner or rigger to make sure that the system is properly rigged in accordance with Country
and local laws and regulations.
• Always check that all the parts of the rigging system that are not provided from RCF are:
- appropriate for the application
- approved, certified and marked
- properly rated
- in perfect condition
• Each cabinet support the full load of the part of the system below. It is very important that each single cabinet of
the system is properly checked
Each HDL 26-A/HDL35-AS module is provided with a Powercon
outlet to daisy chain other modules. The maximum number of
modules that is possible to daisy chain is:
230 VOLT: 6 modules total
115 VOLT: 3 modules total
WARNING - RISK OF FIRE
A superior number of modules in daisy chain will exceed the
Powercon connector maximum ratings and create a potentially
dangerous situation.

“RCF SHAPE DESIGNER” SOFTWARE AND SAFETY FACTOR
The suspension system is designed to have a proper safety factor (configuration dependent). Using the “RCF Easy
Shape Designer” software it is very easy to understand safety factors and limits for each specific configuration. To
better comprehend in which safety range the mechanics are working a simple introduction is needed: HDL 26-A arrays’
mechanics are built with certified UNI EN 10025 Steel. RCF prediction software calculates forces on every single
stressed part of the assembly and shows the minimum safety factor for every link. Structural steel has a stress-strain (or
equivalent Force-Deformation) curve as in the following:
The curve is characterized by two critical points: the Break Point
and the Yield Point. The tensile ultimate stress is simply the
maximum stress attained. Ultimate tensile stress is commonly
used as a criterion of the strength of the material for structural
design, but it should be recognized that other strength properties
may often be more important. One of these is certainly the Yield
Strength. Stress-strain diagram of structural steel exhibit a sharp
break at a stress below the ultimate strength. At this critical stress,
the material elongates considerably with no apparent change in
stress. The stress at which this occurs is referred to as the Yield
Point. Permanent deformation may be detrimental, and the industry
adopted 0.2% plastic strain as an arbitrary limit that is considered
acceptable by all regulatory agencies. For tension and compression,
the corresponding stress at this offset strain is defined as the yield.
In our prediction software the Safety Factors are calculated considering the Maximum Stress Limit equal to the
Yield Strength, according with many international standards and rules.
The resulting Safety Factor is the minimum of all the calculated safety factors, for each link or pin.
This is where you are working with a SF=7
Depending on local safety regulations and on the situation, the
required safety factor can vary. It is responsibility of the owner or
rigger to make sure that the system is properly rigged in accordance
with Country and local laws and regulations.
The “RCF Shape Designer” software gives detailed information of
the safety factor for each specific configuration.
The results are classified in four classes:
GREEN SAFETY FACTOR > 7 SUGGESTED
YELLOW 4 > SAFETY FACTOR > 7
ORANGE 1.5 > SAFETY FACTOR > 4
RED SAFETY FACTOR > 1.5 NEVER ADMITTED

WARNING
• The safety factor is the result of the forces acting on fly bar’s and system’s front and rear links and pins and depends
on many variables:
- number of cabinets
- fly bar angles
- angles from cabinets to cabinets. If one of the cited variables change the safety factor MUST BE recalculated
using the software before rigging the system.
• In case the fly bar is picked up from 2 motors make sure that the fly bar angle is correct. An angle different from the
angle used in the prediction software can be potentially dangerous. Never allow persons to stay or pass under the
system during the installation process.
• When the fly bar is particularly tilted or the array is very curved the centre of gravity can move out from the rear
links. In this case the front links are in compression and the rear links are supporting the total weight of the system
plus the front compression. Always check very carefully with the “RCF Easy Shape Designer” software all this kind of
situations (even with a small number of cabinets).
PREDICTION SOFTWARE – SHAPE DESIGNER
RCF Easy Shape Designer is a temporary software, useful for the setup of the array, for mechanics and for proper preset
suggestions.
The optimal setting of a loudspeaker array cannot ignore the basics of acoustics and the awareness that many factors
contribute to a sonic result that matches expectations. RCF provides the user with simple instruments that help the
setting of the system in an easy and reliable way.
This software will soon be replaced by a more complete software for multiple arrays and complex venue simulation with
maps and graphs of the results.
RCF recommends this software to be used for each type of HDL 26-A configuration.
System particularly tilted System very curved

SOFTWARE INSTALLATION
The software was developed with Matlab 2015b and requires Matlab programming libraries. At the very first installation
user should refer to the installation package, available from the RCF website, containing the Matlab Runtime (ver. 9) or
the installation package that will download the Runtime from the web. Once the libraries are correctly installed, for all
the following version of the software the user can directly download the application without the Runtime. Two versions,
32-bit and 64-bit, are available for the download.
IMPORTANT: Matlab no longer supports Windows XP and hence RCF EASY Shape Designer (32 bit) doesn’t work with
this OS version.
You may wait a few seconds after the double click on the installer because the software checks if Matlab Libraries are
available. After this step the installation begins. Double-click the last installer (check for the last release in the download
section of our website) and follow the next steps.

After the choice of folders for HDL 26-A Shape Designer software (Figure 2) and Matlab Libraries Runtime the installer
takes a couple of minutes for the installation procedure.

DESIGNING THE SYSTEM
The RCF Easy Shape Designer software is divided into two macro sections: the left part of the interface is dedicated
to project variables and data (size of audiences to cover, height, number of modules, etc.), the right part shows the
processing results.
At first the user should introduce the audience data choosing the proper pop-up menu depending on the size of the
audience and introducing the geometrical data. It is also possible to define the height of the listener.
The second step is the array definition selecting the number of cabinets in the array, the hanging height, the number of
hanging points and the kind of available flybars. When selecting two hanging points consider those points positioned at
the flybar extremes.
The height of the array should be considered referred to the bottom side of the flybar, as shown in the picture below.
After entering all the data input in the left part of the user interface, by pressing the AUTOSPLAY button the software will
perform:
- Hanging point for the shackle with A or B position indicated if a single pickup point is selected, rear and front load if
two pickup points are selected.
- Flybar tilt angle and cabinet splays (angles that we have to set to each cabinet before lifting operations).
- Inclination that each cabinet will take (in case of one pick up point) or will have to take if we were to tilt the cluster
with the use of two engines. (two pick up points).
- Total load and Safety Factor calculation: if the selected setup doesn’t give Safety Factor > 1.5 the text message
shows in red color the failure to meet the minimum conditions of mechanical safety.
The autosplay algorithm was developed for optimum coverage of the audience size. The use of this function is
recommended for the optimization of the array aiming. A recursive algorithm chooses for every cabinet the best angle
available in the mechanics.
HEIGHT
RECOMMENDED WORKFLOW
Pending the official and definitive simulation
software, RCF recommends the use of HDL
26-A Shape Designer together with Ease Focus
3. Because of the need of interaction between
different software, the recommended workflow
assumes the following steps for every array in the
final project:
- Shape Designer: audience and array setup.
Calculation in “autosplay” mode of flybar tilt,
cabinet and splays.
- Focus 3: reports here the angles, tilt of flybar and
presets generated by Shape Designer.
- Shape Designer: manual modify of splay
angles if the simulation in Focus 3 does not give
satisfactory results in order to
check the safety factor.
- Focus 3: reports here the new angles and tilt of
flybar generated by Shape Designer. Repeat the
procedure until good
results are achieved.

HDL 26-A INPUT PANEL
1FEMALE XLR INPUTS (BAL/UNBAL). The system accepts XLR input connectors.
2MALE XLR SIGNAL OUTPUT. The output XLR connector provides a loop through for speakers daisy chaining. The balanced
connector is connected in parallel and can be used to send the audio signal to other amplified speakers, recorders or supplementary
amplifiers.
3SYSTEM VOLUME KNOB
4SIGNAL / LIMITER LED. The LED light is green when a signal is applied to the speaker. It turns RED when the speaker
compressor activates.
5POWER LED. This green led is ON when the speaker is connected to the main power supply.
6LINK LED. This LED turns on when the speaker is connected to RDNet.
7ACTIVE LED.This LED blinks when the speaker is transmitting data over RDNet.
8RDNET DATA INPUT AND DATA LINK. The RDNET IN/OUT PLUG SECTION features etherCON connectors for the RCF RDNet
protocol. This allows the user to completely control the speaker using the RDNet software.
9NEAR / FAR. Use the Near / Far button if you want to apply a Near or a Far Equalization.
10 BYPASS / LOCAL SETUP. When pressed, the setup is loaded from the internal memory that only RDNet can write. Every time
the speaker is turned on, the last stored configuration is applied.
When the button is released, the speaker uses its local setup and will not remember its last RDNet setup when turned on again.
1
2
8
9
10
7
3
64
5

HDL 35-AS INPUT PANEL
1FEMALE XLR INPUTS (BAL/UNBAL). The system accept XLR input connectors.
2MALE XLR SIGNAL OUTPUT. The output XLR connector provides a loop through for speakers daisy chaining. The balanced
connector is connected in parallel and can be used to send the audio signal to other amplified speakers, recorders or supplementary
amplifiers.
3SYSTEM SET UP ENCODER. Push the encoder to select a function (gain reduction, delay, preset). Rotate the encoder to select
a value or a preset.
4GAIN REDUCTION LED. Pushing the encoder once the gain reduction indicator lights green.Then rotate the encoder to reduce
the gain to the right level.
POWER LED. This green led is ON when the speaker is connected to the main power supply.
5DELAY LED. Pushing the encoder twice the delay indicator lights green. Then rotate the encoder to delay the speaker. The delay
is expressed in meters.
SIGNAL LED. The signal indicator lights green if there is audio signal present on the main
6PRESET LED. Pushing the encoder three times the preset indicator lights green.Then rotate the encoder to load the right preset
to the speaker.
LIMITER LED. The amplifier has a built in limiter circuit to prevent clipping of the amplifiers or overdriving the transducers. When
the soft clipping circuit is active the LED blinks RED. It is okay if the limit LED blinks occasionally. If the LED lights continuously, turn
down the signal level.
7SYSTEM SET UP DISPLAY. Display the system setting values. In case of RDNet active connection a rotating segment will light up.
8RDNET LOCAL SETUP/BYPASS. When released the local setup is loaded and RDNet can only monitor the speaker. When
switched the RDNet setup is loaded and bypass any speaker local preset.
9RDNET IN/OUT PLUG SECTION.The RDNET IN/OUT PLUG SECTION features etherCON connectors for the RCF RDNet protocol.
This allows the user to completely control the speaker using the RDNet software.
1
2
8
9
7
3
6
45

RIGGING COMPONENTS
Accessory p/n Description
1 13360360 BARRA SOSPENSIONE HDL 6-A
- up to 16 HDL 26-A
- up to 8 HDL35-AS
- up to 4 HDL35-AS + 8 HDL 26-A
2 13360022 QUICK LOCK PIN
3 13360372 FLY BAR PICK UP HDL 6-A
4CONNECTION BRACKET FOR SECURELY LOCKING THE STACKING CLUSTER ON A SUBWOOFER
5 POLE MOUNT BRACKET
1
5
5
5
2
4
6
3

ACCESSORIES
1 13360129 HOIST SPACING CHAIN. It allows enough space for the hang of most 2 motor chain
containers and avoids any impact on the vertical balance of the array when it is suspended
from a single pick-up point.
2 13360372 FLY BAR PICK UP HDL 6-A
+ 2 QUICK LOCK PIN (SPARE PART P/N 13360022)
3 13360351 AC 2X AZIMUT PLATE. It allows the horizontal aim control of the cluster. The system must
be hooked with 3 motors. 1 frontal and 2 attached to the azimuth plate.
4 13360366 KART WITH WHEELS AC KART HDL 6-A
+ 2 QUICK LOCK PIN (SPARE PART 13360219)
5 13360371 AC TRUSS CLAMP HDL 6-A
+ 1 QUICK LOCK PIN (SPARE PART P/N 13360022)
6 13360377 POLE MOUNT 3X HDL 6-A
+ 1 QUICK LOCK PIN (SPARE PART 13360219)
7 13360375 LINKBAR HDL12 TO HDL 6-A
+ 2 QUICK LOCK PIN (SPARE PART 13360219)
8 13360381 RAIN COVER 06-01
56
12
4
3
500 mm
78

RIGGING PROCEDURE
Installation and setup should only be carried out by qualified and authorized personnel observing the valid national Rules for
the Prevention of Accidents (RPA).
It is the responsibility of the person installing the assembly to ensure that the suspension/fixing points are suitable for the
intended use.
Always carry out a visual and functional inspection of the items before use. In the event of any doubt as to the proper
functioning and safety of the items, these must be withdrawn from use immediately.
WARNING - The steel wires between the locking pins of the cabinets and rigging components are not intended to carry any
load. The cabinet’s weight must only be carried by the Front and Splay/Rear links in conjunction with the front and rear rigging
strands of the loudspeaker cabinets and the Flying frame. Ensure all Locking pins are fully inserted and securely locked before
lifting any load.
In the first instance use the EASY Shape Designer software to calculate the proper set up of the system and to check the safety
factor parameter.
The HDL 6-A flybar allows the suspension of:
- HDL 6-A and HDL12-AS
- HDL 26-A and HDL35-AS

1. FLYBAR SETUP
The HDL 6-A flybar allows to set the central bar in two different configurations “A” e “B”.
Configuration “B” allows a better upper inclination of the cluster.
This accessory is provided in “A” configuration.
To set it in “B” configuration:
1. Remove the cotter pins “R”, pull out the linchpins “X” and
the quick lock pins “S”
2. Lift the central bar then re-position it making the “B”
indication on the label and the holes “S” match together.
3. Re-assemble the flybar repositioning the pins “S”, the
linchpins “X” and the cotter pins “R”.
X
S
S
R
X
S
S
R
X
S
S
R
FLYBAR
WITH CENTRAL BAR
IN “A” POSITION
FLYBAR
WITH CENTRAL BAR
IN “B” POSITION
1.1 SET THE CENTRAL BAR IN “B” POSITION
CENTRAL BRACKET LABEL

PICK UP POINT
“A” POSITION
PICK UP POINT
“B” POSITION
PICK UP POINT
“B” POSITION
PICK UP POINT
“A” POSITION
PICK UP POINT
“A” POSITION
PICK UP POINT
“B” POSITION PICK UP POINT
“B” POSITION
PICK UP POINT
“A” POSITION
PICK UP POINT
“A” POSITION
PICK UP POINT
“B” POSITION PICK UP POINT
“B” POSITION
PICK UP POINT
“B” POSITION
PICK UP POINT
“A” POSITION
PICK UP POINT
“B” POSITION
PICK UP POINT
“A” POSITION
PICK UP POINT
“B” POSITION
PICK UP POINT
“B” POSITION
PICK UP POINT
“A” POSITION
PICK UP POINT
“B” POSITION
PICK UP POINT
“B” POSITION
PICK UP POINT
“A” POSITION
PICK UP POINT
“A” POSITION
PICK UP POINT
“B” POSITION
PICK UP POINT
“B” POSITION
PICK UP POINT
“A” POSITION
PICK UP POINT
“B” POSITION
PICK UP POINT
“B” POSITION
PICK UP POINT
“A” POSITION
PICK UP POINT
“A” POSITION
PICK UP POINT
“B” POSITION
PICK UP POINT
“B” POSITION
PICK UP POINT
POSITION
1.2 PICK UP POINT POSITION
2. SYSTEM SUSPENSION PROCEDURE
SINGLE PICK UP POINT
DUAL PICK UP POINT
Position the flybar pick-up point as shown in the software, respecting the position “A” or “B”.
Allows to lift the cluster with two pulleys adding an optional pick up point (pn 13360372).

2.1 SECURING THE FLYBAR TO THE FIRST HDL 26-A SPEAKER
2.2 SECURING THE SECOND HDL 26-A SPEAKER TO THE FIRST (AND CONSECUTIVE)
1. Insert the frontal quick lock pins “F”
2. Rotate the rear bracket and secure it to the flybar with the rear quick lock pin “S” to the HDL 26-A Link Point hole
1. Secure the frontal quick lock pins “F”
2. Rotate the rear bracket and and secure it to the first speaker using the rear quick lock pin “P”,
selecting the inclination angle as shown on the software.
F
S
F
F
S
F
F
P
F
S
F
F
S
F
F
P
F
S
F
F
S
F
F
P
HDL6-A REAR
BRACKET LABEL

2.3 SECURING THE FLYBAR TO THE FIRST HDL35-AS SPEAKER
2.4 SECURING THE SECOND HDL35-AS SPEAKER TO THE FIRST (AND CONSECUTIVE):
1. Insert the frontal quick lock pins “F”
2. Rotate the rear bracket and secure it to the flybar with the rear quick lock pin “S” on the HDL12 Link Point hole.
1. Pull out the frontal bracket “A”
2. Secure the frontal quick lock pins “F”
3. Rotate the rear bracket and secure it to the first speaker using the rear quick lock pin “P”.
FF
S
F
S
FF
P
