Sony SA-VE215 User manual

AEP Model
UK Model
E Model
Australian Model
Chinese Model
SERVICE MANUAL
SPEAKER SYSTEM
SPECIFICATIONS
•The SA-VE215 system consists of one unit
ofSA-WMS215andfiveunitsofSS-MS215.
•Thisset is theSpeakersectionin HT-K170/
K215.
SA-VE215/WMS215/
SS-MS215
Photo: SA-WMS215 Photo: SS-MS215
SS-MS215 Front, center and rear speakers
Speaker system Full range, magnetically
shielded
Speaker units 5 cm cone type
Enclosure type Bass reflex
Rated impedance 8 ohms
Power handling 60 watts
capacity
(Maximum input
power)
Sensitivity level 84 dB (1W, 1m)
Frequency range 150 Hz - 20,000 Hz
Dimensions (w/h/d) Approx. 76 ×100 ×86 mm
including front grille
Mass Approx. 425 g
SA-WMS215 Subwoofer
System Active subwoofer,
Speaker system magnetically shielded
Speaker unit Woofer : 16 cm cone type
Enclosure type Acoustically Loaded Bass Reflex
Continuous RMS 50 W
power output
(8 ohms, 20 - 250 Hz)
Reproduction 32 Hz - 250 Hz
frequency range
High frequency 250 Hz
cut-off frequency
Input
LINE IN (input pin jack)
General
Power requirements 220 - 230 V AC, 50/60 Hz
Power consumptions 45 W
Dimensions (w/h/d) Approx. 240 ×285 ×355 mm
including front panel
Mass Approx. 8 kg
Design and specifications are subject to change without
notice
Ver 1.1 2003. 05
Sony Corporation
Home Audio Company
Published by Sony Engineering Corporation
9-929-500-12
2003E16-1
© 2003.05

2
SAFETY-RELATED COMPONENT WARNING!!
COMPONENTS IDENTIFIED BY MARK 0OR DOTTED LINEWITH
MARK 0ON THE SCHEMATIC DIAGRAMS AND INTHE PARTS
LIST ARE CRITICAL TO SAFE OPERATION. REPLACE THESE
COMPONENTS WITH SONY PARTS WHOSE PART NUMBERS
APPEAR AS SHOWN IN THIS MANUAL OR IN SUPPLEMENTS
PUBLISHED BY SONY.
Notes on chip component replacement
• Never reuse a disconnected chip component.
• Notice that the minus side of a tantalum capacitor may be
damaged by heat.
Flexible Circuit Board Repairing
• Keep the temperature of soldering iron around 270˚C
during repairing.
• Do not touch the soldering iron on the same conductor of the
circuit board (within 3 times).
• Be careful not to apply force on the conductor when soldering
or unsoldering.

33
SECTION 1
DIAGRAMS
1-1. NOTE FOR PRINTED WIRING BOARDS AND SCHEMATIC DIAGRAMS
Note on PrintedWiring Board:
•X: parts extracted from the component side.
•b: Pattern from the side which enables seeing.
•Indication of transistor.
B
These are omitted.
CE
Q
Note on Schematic Diagram:
• All capacitors are in µF unless otherwise noted. pF: µµF
50 WV or less are not indicated except for electrolytics
and tantalums.
• All resistors are in Ωand 1/4W or less unless otherwise
specified.
•2: nonflammable resistor.
•C: panel designation.
•U: B+ Line.
•V: B– Line.
• Voltages are dc with respect to ground under no-signal
conditions.
• Voltages are takenwithaVOM(input impedance 10 MΩ).
Voltage variations may be noted due to normal produc-
tion tolerances.
• Signal path.
F: AUDIO
• Circuit Boards Location
SA-WMS215
• IC Block Diagram
IC302 uPC1237HA
1 2 3 4 5 6 7 8
OVER LOAD DET
F/F
OFFSET DET
LATCH/
AUTORESET
VCC ON
MUTE
AC OFF
DET
VCC
CONTROL board
LED board
POWER SWITCH board
POWER IC board
MAIN boar
d
POWER SUPPLY board
Note :
The components identified by
mark 0or dotted line with mark
0are critical for safety.
Replace only with part number
specified.

SA-VE215/WMS215/SS-MS215
44
1-2. SCHEMATIC DIAGRAM (SA-WMS215) • See page 3 for IC block diagram.
The components identified by
mark 0or dotted line with mark
0are critical for safety.
Replace only with part number
specified.

SA-VE215/WMS215/SS-MS215
55
1-3. PRINTEDWIRING BOARD (SA-WMS215) •See page 3 for Circuit Boards Location. There are a few cases that the part printed on
this diagram isn’t mounted in this model.
Ref. No. Location
D301 B-3
D302 B-2
D303 C-6
D304 C-4
D401 B-6
D402 B-4
D403 B-4
IC101 B-1
IC102 C-1
IC103 D-2
IC302 C-4
Q101 C-2
Q102 B-2
Q303 D-4
•Semiconductor
Location

66
NOTE:
• -XX, -X mean standardized parts, so they may
have some differences from the original one.
• Items marked “*” are not stocked since they
are seldom required for routine service. Some
delayshould be anticipatedwhen orderingthese
items.
• Themechanical parts withno reference number
in the exploded views are not supplied.
SECTION 2
EXPLODED VIEWS
2-1. SA-WMS215 (1)
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
2-2. SA-WMS215 (2)
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
1
23
4
5
7
6
9
10
11
12
12
12
12
12
11
11
11
Amplifier
section
SP1
8
#1
#1
#2 #2
#2
#2
#5
supplied
with RV201 #5
#5
not
supplied
not
supplied
51
52
53
54
55
56
T401
58
not supplied
not supplied
not supplied
#4
#4
#4
#4
#3
#5
#3
#4
not
supplied
1 A-4412-320-A PANELASSY, FRONT
2 4-229-516-01 KNOB (VOL)
3 4-220-465-01 WASHER, INSULATING
4 4-229-517-01 KNOB (SW)
5 1-678-476-11 POWER SWITCH BOARD
6 1-678-475-11 CONTROL BOARD
7 1-678-478-11 LED BOARD
8 4-229-518-01 PACKING (D)
9 A-4412-321-A CABINET ASSY
10 4-229-514-01 PANEL, BOTTOM
11 4-229-522-11 FOOT
12 4-229-966-01 SCREW (4X16), +BV TAPPING
SP1 1-529-764-11 SPEAKER (16cm)
#1 7-685-163-01 SCREW +P4X16 TYPE1
#2 7-685-646-79 SCREW +BVTP3X8 TYPE2 N-S
#5 7-685-660-19 SCREW +BVTP4X10 TYPE2 N-S
51 1-678-477-11 POWER IC BOARD
52 A-4473-638-A MAIN BOARD, COMPLETE
53 1-678-474-11 POWER SUPPLY BOARD
54 4-228-899-11 REAR PANEL (AEP,EE,CIS,CH,AUS,UK)
54 4-228-899-21 REAR PANEL (HK,MY,SP)
*55 3-703-244-00 BUSHING (2104), CORD
056 1-777-071-11 CORD, POWER
58 3-710-901-11 SCREW, TAPPING
0T401 1-435-608-11 TRANSFORMER, POWER
#3 7-685-647-79 SCREW +P3X10 TYPE2 NON-SLIT
#4 7-685-648-79 SCREW +P3X12 TYPE2 NON-SLIT
#5 7-685-660-19 SCREW +BVTP4X10 TYPE2 N-S
The components identified by
mark 0or dotted line with mark
0are critical for safety.
Replace only with part number
specified.
The components identified by mark 0or
dotted line with mark 0are critical for safety.
Replace only with part number specified.
•Accessories and packing materials are given in
the last of this parts list.
•Abbreviation
EE : East European model.
AUS : Australian model.
CH : Chinese model.
HK : Hong Kong model.
MY : Malaysia model.
SP : Singapore model.

7
2-3. SS-MS215
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
not supplied
SP2
#6
#6
#6
#7
101
103
102
104
101 A-4412-322-A PANEL ASSY, FRONT
102 A-4412-277-A CABINET ASSY
103 1-694-516-11 TERMINAL, SPEAKER
104 A-4461-007-A OVERALL ASSY
SP2 1-529-763-11 SPEAKER (5cm)
#6 4-986-971-11 SCREW (3.5)
#7 3-703-564-81 SCREW (3.5X12), TAPPING
Ver 1.1 2003.05

8
SECTION 3
ELECTRICAL PARTS LIST
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts
specifiedinthe diagrams or the components
used on the set.
• -XX, -X mean standardized parts, so they
may have some difference from the original
one.
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when
ordering these items.
• CAPACITORS:
uF: µF
• RESISTORS
All resistors are in ohms.
METAL: metal-film resistor
METAL OXIDE: Metal Oxide-film resistor
F: nonflammable
• COILS
uH: µH
• SEMICONDUCTORS
In each case, u: µ, for example:
uA...: µA... , uPA... , µPA... ,
uPB... , µPB... , uPC... , µPC... ,
uPD..., µPD...
When indicating parts by reference number,
please include the board name.
The components identified by mark 0or
dotted line with mark 0are critical for safety.
Replace only with part number specified.
CONTROL LED MAIN
1-678-475-11 CONTROL BOARD
**************
< CAPACITOR >
C201 1-126-964-11 ELECT 10uF 20.00% 50V
< CONNECTOR >
*CN202 1-564-519-11 PLUG, CONNECTOR 4P
< VARIABLE RESISTOR >
RV201 1-225-826-11 RES, VAR, CARBON 20K (LEVEL)
**************************************************************
1-678-478-11 LED BOARD
**********
*4-937-336-32 HOLDER, LED
< CONNECTOR >
CN801 1-506-481-11 PIN, CONNECTOR 2P
< DIODE >
D801 8-719-080-25 DIODE SEL6414LF62 (POWER)
**************************************************************
A-4473-638-A MAIN BOARD, COMPLETE
*********************
< CAPACITOR >
C101 1-162-286-31 CERAMIC 220PF 10% 50V
C102 1-126-964-11 ELECT 10uF 20.00% 50V
C103 1-162-286-31 CERAMIC 220PF 10% 50V
C104 1-136-167-00 MYLAR 0.15uF 5.00% 50V
C105 1-136-159-00 MYLAR 0.033uF 5.00% 50V
C106 1-136-169-00 MYLAR 0.22uF 5.00% 50V
C107 1-136-169-00 MYLAR 0.22uF 5.00% 50V
C108 1-136-169-00 MYLAR 0.22uF 5.00% 50V
C109 1-136-169-00 MYLAR 0.22uF 5.00% 50V
C110 1-136-164-00 MYLAR 0.082uF 5.00% 50V
C111 1-136-168-00 MYLAR 0.18uF 5.00% 50V
C112 1-126-964-11 ELECT 10uF 20.00% 50V
C301 1-136-165-00 MYLAR 0.1uF 5.00% 50V
C302 1-126-933-11 ELECT 100uF 20.00% 16V
C305 1-136-169-00 MYLAR 0.22uF 5.00% 50V
C306 1-162-215-31 CERAMIC 47PF 5% 50V
C307 1-126-967-11 ELECT 47uF 20.00% 50V
C308 1-126-967-11 ELECT 47uF 20.00% 50V
C309 1-104-665-11 ELECT 100uF 20.00% 10V
C310 1-126-963-11 ELECT 4.7uF 20.00% 50V
C311 1-104-664-11 ELECT 47uF 20.00% 25V
C401 1-136-165-00 MYLAR 0.1uF 5.00% 50V
C402 1-136-165-00 MYLAR 0.1uF 5.00% 50V
C403 1-119-940-51 ELECT 4700uF 20.00% 50V
C404 1-119-940-51 ELECT 4700uF 20.00% 50V
C405 1-104-665-11 ELECT 100uF 20.00% 25V
C406 1-104-665-11 ELECT 100uF 20.00% 25V
< CONNECTOR >
*CN104 1-564-104-00 PIN, CONNECTOR (B3P-VH) 3P
*CN105 1-568-951-11 PIN, CONNECTOR 2P
CN106 1-691-765-11 PLUG (MICRO CONNECTOR) 3P
CN109 1-564-320-00 PIN, CONNECTOR (B2P-VH) 2P
< DIODE >
D301 8-719-911-19 DIODE 1SS133T-72
D302 8-719-911-19 DIODE 1SS133T-72
D303 8-719-911-19 DIODE 1SS133T-72
D304 8-719-911-19 DIODE 1SS133T-72
D401 8-719-025-03 DIODE RBA-402
D402 8-719-068-44 DIODE HZ15BP-TK
D403 8-719-068-44 DIODE HZ15BP-TK
< IC >
IC101 8-759-634-50 IC M5218AL
IC102 8-759-634-50 IC M5218AL
IC103 8-759-634-50 IC M5218AL
IC302 8-759-111-68 IC uPC1237HA
< JACK >
J101 1-770-377-31 JACK, PIN 1P (LINE)
< TRANSISTOR >
Q101 8-729-119-78 TRANSISTOR 2SC2785TP-E
Q102 8-729-119-78 TRANSISTOR 2SC2785TP-E
Q303 8-729-900-80 TRANSISTOR BA1A4M-TP

9
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
MAIN POWER IC
< RESISTOR >
R101 1-249-417-11 CARBON 1K 5% 1/4W F
R102 1-249-441-11 CARBON 100K 5% 1/4W
R103 1-249-441-11 CARBON 100K 5% 1/4W
R104 1-249-429-11 CARBON 10K 5% 1/4W
R105 1-249-429-11 CARBON 10K 5% 1/4W
R106 1-249-424-11 CARBON 3.9K 5% 1/4W F
R107 1-249-436-11 CARBON 39K 5% 1/4W
R108 1-249-424-11 CARBON 3.9K 5% 1/4W F
R109 1-249-417-11 CARBON 1K 5% 1/4W F
R110 1-249-435-11 CARBON 33K 5% 1/4W
R111 1-249-425-11 CARBON 4.7K 5% 1/4W F
R112 1-249-439-11 CARBON 68K 5% 1/4W
R113 1-249-417-11 CARBON 1K 5% 1/4W F
R114 1-249-417-11 CARBON 1K 5% 1/4W F
R115 1-249-435-11 CARBON 33K 5% 1/4W
R116 1-249-438-11 CARBON 56K 5% 1/4W
R117 1-249-427-11 CARBON 6.8K 5% 1/4W F
R118 1-249-427-11 CARBON 6.8K 5% 1/4W F
R119 1-249-427-11 CARBON 6.8K 5% 1/4W F
R303 1-249-427-11 CARBON 6.8K 5% 1/4W F
R304 1-249-433-11 CARBON 22K 5% 1/4W
R305 1-249-412-11 CARBON 390 5% 1/4W F
R307 1-249-478-81 CARBON 2.2 5% 1/2W
R308 1-249-433-11 CARBON 22K 5% 1/4W
R309 1-249-433-11 CARBON 22K 5% 1/4W
R310 1-249-441-11 CARBON 100K 5% 1/4W
R311 1-249-441-11 CARBON 100K 5% 1/4W
R312 1-249-427-11 CARBON 6.8K 5% 1/4W F
R313 1-249-429-11 CARBON 10K 5% 1/4W
R314 1-215-892-11 METAL OXIDE 1K 5% 2W
R315 1-249-439-11 CARBON 68K 5% 1/4W
R316 1-249-430-11 CARBON 12K 5% 1/4W
R318 1-215-868-00 METAL OXIDE 680 5% 1W
R401 1-216-456-00 METAL OXIDE 820 5% 2W
R402 1-216-456-00 METAL OXIDE 820 5% 2W
< RELAY >
RY301 1-515-920-11 RELAY (24V)
**************************************************************
1-678-477-11 POWER IC BOARD
***************
< CAPACITOR >
C304 1-162-286-31 CERAMIC 220PF 10% 50V
< CONNECTOR >
CN108 1-785-088-11 PIN, CONNECTOR 6P
< IC >
IC301 8-759-299-53 IC LM3886T
< RESISTOR >
R306 1-249-435-11 CARBON 33K 5% 1/4W
**************************************************************
1-678-474-11 POWER SUPPLY BOARD
********************
1-533-233-11 HOLDER, FUSE
< CAPACITOR >
0C2 1-113-924-11 CERAMIC 0.0047uF 20.00% 250V
< CONNECTOR >
CN101 1-564-321-00 PIN, CONNECTOR 2P
*CN102 1-580-230-11 PIN, CONNECTOR (PC BOARD) 2P
< FUSE >
0F401 1-532-500-31 FUSE TL 0.63A/250V
**************************************************************
1-678-476-11 POWER SWITCH BOARD
********************
< CAPACITOR >
0C1 1-113-915-11 CERAMIC 0.001uF 20.00% 250V
< CONNECTOR >
*CN201 1-695-044-11 PIN, CONNECTOR 2P
< SWITCH >
0S1 1-554-920-61 SWITCH, PUSH (AC POWER)(1 KEY)(POWER)
**************************************************************
MISCELLANEOUS
**************
056 1-777-071-11 CORD, POWER
103 1-694-516-11 TERMINAL, SPEAKER
SP1 1-529-764-11 SPEAKER (16cm)
SP2 1-529-763-11 SPEAKER (5cm)
0T401 1-435-608-11 TRANSFORMER, POWER
**************************************************************
ACCESSORIES & PACKING MATERIALS
*******************************
01-770-019-11 ADAPTOR, CONVERSION PLUG 3P (UK, HK)
POWER SUPPLY POWER SWITCH
The components identified by
mark 0or dotted line with mark
0are critical for safety.
Replace only with part number
specified.

REVISION HISTORY
Clicking the version allows you to jump to the revised page.
Also, clicking the version at the upper right on the revised page allows you to jump to the next revised
page.
Ver. Date Description of Revision
1.0 2000. 07 New
1.1 2003. 05 Addition of Ref.No.104 (SPM-03032)
SA-VE215/WMS215/SS-MS215
