RCF TTL6-AS User manual

OWNER MANUAL
TTL6-A ACTIVE THREE-WAY
LINE ARRAY MODULE
TTL6-AS ACTIVE LINE ARRAY
BASS MODULE

4
ENGLISH
1. All the precautions, in particular the safety ones, must be read with special attention, as
they provide important information.
2. Power supply from mains
a. The mains voltage is sufficiently high to involve a risk of electrocution; install and
connect this product before plugging it in.
b. Before powering up, make sure that all the connections have been made correctly and
the voltage of your mains corresponds to the voltage shown on the rating plate on the
unit, if not, please contact your RCF dealer.
c. The metallic parts of the unit are earthed through the power cable.An apparatus with
CLASS I construction shall be connected to a mains socket outlet with a protective
earthing connection.
d. Protect the power cable from damage; make sure it is positioned in a way that it
cannot be stepped on or crushed by objects.
e. To prevent the risk of electric shock, never open this product: there are no parts inside
that the user needs to access.
3. Make sure that no objects or liquids can get into this product, as this may cause a short
circuit.
This apparatus shall not be exposed to dripping or splashing. No objects filled with liquid,
such as vases, shall be placed on this apparatus. No naked sources (such as lighted candles)
should be placed on this apparatus.
4. Never attempt to carry out any operations, modifications or repairs that are not expressly
described in this manual.
Contact your authorized service centre or qualified personnel should any of the following
occur:
- The product does not function (or functions in an anomalous way).
- The power cable has been damaged.
- Objects or liquids have got in the unit.
- The product has been subject to a heavy impact.
5. If this product is not used for a long period, disconnect the power cable.
6. If this product begins emitting any strange odours or smoke, switch it off immediately
and disconnect the power cable.
7. Do not connect this product to any equipment or accessories not foreseen.
For suspended installation, only use the dedicated anchoring points and do not try to hang
this product by using elements that are unsuitable or not specific for this purpose. Also
check the suitability of the support surface to which the product is anchored (wall, ceiling,
structure, etc.), and the components used for attachment (screw anchors, screws, brackets
not supplied by RCF etc.), which must guarantee the security of the system / installation
over time, also considering, for example, the mechanical vibrations normally generated by
transducers.
To prevent the risk of falling equipment, do not stack multiple units of this product unless
this possibility is specified in the user manual.
8. RCF S.p.A. strongly recommends this product is only installed by professional
qualified installers (or specialised firms) who can ensure correct installation
and certify it according to the regulations in force.
The entire audio system must comply with the current standards and regulations
regarding electrical systems.
9. Supports and trolleys.
The equipment should be only used on trolleys or supports, where necessary, that are
recommended by the manufacturer. The equipment / support / trolley assembly must be
SAFETY
PRECAUTIONS
IMPORTANT

5
ENGLISH
moved with extreme caution. Sudden stops, excessive pushing force and uneven floors may
cause the assembly to overturn.
10. There are numerous mechanical and electrical factors to be considered when installing
a professional audio system (in addition to those which are strictly acoustic, such as sound
pressure, angles of coverage, frequency response, etc.).
11. Hearing loss.
Exposure to high sound levels can cause permanent hearing loss.The acoustic pressure level
that leads to hearing loss is different from person to person and depends on the duration
of exposure. To prevent potentially dangerous exposure to high levels of acoustic pressure,
anyone who is exposed to these levels should use adequate protection devices. When a
transducer capable of producing high sound levels is being used, it is therefore necessary
to wear ear plugs or protective earphones. See the manual technical specifications to know
the maximum sound pressure level.
IMPORTANT NOTES
To prevent the occurrence of noise on line signal cables, use screened cables only and avoid
putting them close to:
- Equipment that produces high-intensity electromagnetic fields.
- Power cables.
- Loudspeaker lines.
OPERATING PRECAUTIONS
- Place this product far from any heat sources and always ensure an adequate
air circulation around it.
- Do not overload this product for a long time.
- Never force the control elements (keys, knobs, etc.).
- Do not use solvents, alcohol, benzene or other volatile substances for cleaning
the external parts of this product.
IMPORTANT NOTES
Before connecting and using this product, please read this instruction manual carefully and
keep it on hand for future reference. The manual is to be considered an integral part of
this product and must accompany it when it changes ownership as a reference for correct
installation and use as well as for the safety precautions. RCF S.p.A. will not assume any
responsibility for the incorrect installation and / or use of this product.
WARNING: to prevent the risk of fire or electric shock, never expose this product to rain
or humidity.
CAUTION: to prevent electric shock hazard, do not connect to mains power supply while
grille is removed
OPERATING
PRECAUTIONS
IMPORTANT NOTES
IMPORTANT NOTES
WARNING
CAUTION
Note: This equipment has been tested and found to comply with the limits for a Class A
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when the equipment is operated in a
commercial environment. This equipment generates, uses, and can radiate radio frequency
energy, and if it is not installed and used in accordance with the instruction manual, it
may cause harmful interference to radio communications. Operation of this equipment
in a residential area is likely to cause harmful interference, in which case the user will be
required to correct the interference at his own expense.
Modifications: Any modifications made to this device that are not approved by RCF may
void the authority granted to the user by the FCC to operate this equipment.
FCC NOTES

6
ENGLISH
INNOVATION
TT+ HIGH DEFINITION
TOURING AND THEATRE
INTEGRATION
INTENSITY
TTL6-A, ACTIVE THREE-WAY
LINE ARRAY MODULE
RCF TT+ represents another prominent chapter in the long history of RCF Sound Systems.
Whether a speaker system is designed for live sound or large concert situations as well as permanent
installed theatre sound applications, the paying customer now expects a level of audio fidelity and
intelligibility of such a standard unsurpassed by previous generations.
This requirement has fostered the need for Audio Professionals to be able to offer a range of
speaker systems combined with dedicated transducer and crossover technologies that are superior
in acoustic performance and control.
RCF TT+ offers ready to use solutions and tools in true high definition speaker systems.
Our research and engineering faculty can today offer innovative projects with finite control of
each detail, from the loudspeaker voice coil wire to the highly efficient extended dynamic amplifier
topology. There are many different ingredients that go into creating quality products and systems.
These include computer aided simulation software to assist the understanding of transducer
behaviour and amplifier operation and the relationship of dynamics and transient response.
RCF utilises over thirty state of the art software packages to identify magnetic circuits, voice coil
dynamics, suspension linearity, horn dispersion simulation, crossover filters, amplifier thermal
behaviour etc.
RCF is one of only a few loudspeaker manufacturers worldwide who have the ability to completely
design and manufactures transducers, speaker systems and amplification and control electronics.
Our 60 plus years heritage in Audio combined with our state of the art research and development
and manufacturing processes allows us to seamlessly integrate all the ingredients to design and
build TT+.
The design philosophy for the new TT+ series is based upon offering the sound engineer solutions
and tools that are ready to use. Key factors are the ability to sustain very high power with highly
efficient sound pressure levels. Intense sound levels are created with extremely high definition and
extended dynamic range. Modern construction materials result in mechanical weight ratios that are
light for practical flying and portability.
The TTL6-A is a high power, three way, active line source engineered to deliver high fidelity output
for use indoors and outdoors, for medium to large spaces.
TTL 6-A provides all the advantages of line array technology, such as high direct sound, increased
range and a uniform level distribution, with additional ease of use. It is the preferred sound set-up
for stacked systems and when a wider dispersion is required.
The 3-wayTTL6-A line source is equipped with 2 x 12”low frequencies woofers,4 x 6.5”midranges
and a 3.0” voice coil compression driver with wave-guide for distinctive homogenous directivity.
The integration of four channels of digital amplification and the advanced digital processing set a
new standard for distortion, noise and thermal efficiency.
PRODUCT
INFORMATIONS

7
ENGLISH
REAR
PANEL
FEMALE XLR INPUTS (BAL/UNBAL).The system accept XLR input connectors.
MALE XLR SIGNAL OUTPUT. The output XLR connector provides a loop through for
speakers daisy chaining. The balanced connector is connected in parallel and can be used to
send the audio signal to other amplified speakers, recorders or supplementary amplifiers.
SYSTEM SET UP ENCODER. Push the encoder to select a function (gain reduction, delay,
preset). Rotate the encoder to select a value or a preset.
GAIN REDUCTION LED. Pushing the encoder once the gain reduction indicator lights green.
Then rotate the encoder to reduce the gain to the right level.
POWER LED. This green led is ON when the speaker is connected to the main power supply.
DELAY LED. Pushing the encoder twice the delay indicator lights green. Then rotate the
encoder to delay the speaker. The delay is expressed in meters.
SIGNAL LED. The signal indicator lights green if there is audio signal present on the main
PRESET LED. Pushing the encoder three times the preset indicator lights green.Then rotate
the encoder to load the right preset to the speaker.
LIMITER LED. The amplifier has a built in limiter circuit to prevent clipping of the amplifiers
or overdriving the transducers. When the soft clipping circuit is active the LED blinks RED. It is
okay if the limit LED blinks occasionally. If the LED lights continuously, turn down the signal level.
SYSTEM SET UP DISPLAY. Display the system setting values. In case of RDNet active
connection a rotating segment will light up.
RDNET LOCAL SETUP/BYPASS. When released the local setup is loaded and RDNet can
only monitor the speaker. When switched the RDNet setup is loaded and bypass any speaker
local preset.
RDNET IN/OUT PLUG SECTION. The RDNET IN/OUT PLUG SECTION features etherCON
connectors for the RCF RDNet protocol. This allows the user to completely control the speaker
using the RDNet software.
1
2
3
4
5
6
7
8
9
1
2
8
9
7
3
6
45

8
ENGLISH
10
11
WARNING
Pushing the rear encoder it is possible to select the following three functions:
- input gain reduction
- speaker delay setting
- selection of a speaker preset
Pushing once the rear encoder the gain reduction LED will light up. Now rotating the
encoder counter clockwise it will be possible to reduce the input gain. The gain reduction
will be in steps of 0,1 dB for the first 10 dB and than in 1 dB steps.
The maximum reduction is 99 dB.
Pushing a second time the rear encoder the delay LED will light up. Now rotating the
encoder clockwise it will be possible to delay the signal output of the speaker.
The delay is expressed in meter. The delay will be in steps of 0,1 m for the first 10 m and
than in 1 m steps. The maximum delay will be 20 meter.
Pushing a third time the rear encoder the preset LED will light up. Now rotating the encoder
clockwise it will be possible to select a preset.
There are eight presets in three groups:
- CLOSE (C). When the listening distance is less than 4 meter
- LINEAR (L). When the listening distance is from 4 to 11 meter
- FAR (F). When the listening distance is more than 11 meter.
THE REAR ENCODER
CONTROL AND
SPEAKER SETTING
INPUT GAIN REDUCTION
SPEAKER DELAY SETTING
SELECTION OF
A SPEAKER PRESET
WARNING: the Powercon connector is used to disconnect the system from the power supply
network. It shall be easily accessible after the instillation and during the use of the system.
AC INPUT.
Powercon locking 3-pole AC mains.
AC OUTPUT.
Powercon locking 3-pole AC mains output.
TTL6-A PRESETS TTL6-AS PRESETS
10
11

9
ENGLISH
TTL6-A PRESETS
L1. LINEAR. Is the totally linear preset. The speaker curve response is perfectly linear. It is ideal when
listening outdoor or in low reverberation rooms, at medium distance and at a medium or high sound
pressure level.
L2. LINEAR HIGH PASS. This preset is the same as L1 with a 24 dB/oct. high pass filter at 100 Hz. To be
used when the speaker is a part of a bigger system, when is a satellite of a subwoofer system or when the
application is speech reproduction.
L3. LINEAR LOW LEVEL - PLAYBACK. This preset is linear with a gentle +3 dB boost at low frequency. To
be used when playing at low level or for playback music.
L4. LINEAR INDOOR. This preset is linear with a gentle -3 dB shelf at low frequency. It is ideal for a better
sound balance in reverberant rooms and for indoor speech reproduction.
C1. CLOSE. Close listening preset.To be used when the average listener is closer than 3 meter. The preset
shows a gentle -3 dB shelf in high frequencies. The sound balance is natural and never aggressive.
C2. CLOSE HIGH PASS. This preset is the same as C1 with a 24 dB/oct. high pass filter at 100 Hz.
F1. FAR. Far listening preset. To be used when the average listener distance is more than 10 meter.
The preset shows a +3 dB shelf in high frequencies to compensate the air absorption. The clarity and
intelligibility in distance are improved.
F2. FAR HIGH PASS.This is the same as F1 with a 24 dB/oct. high pass filter at 100 Hz.
S1, S2. SIDE COUPLING PRESETS. These presets are linear when the speaker are coupled side to side.
These presets are properly designed for speakers coupled with a horizontal coupling angle from 70°
to 80°. The front of the cabinets shall be split and the rear of the cabinets shall be close. The S2 preset
features the low frequency high pass filter.
U1, U2. VERTICAL COUPLING PRESETS. These presets are linear when the speaker are coupled vertically.
The vertical coupling angle can vary from 0° to 10° in 2° steps. Smaller coupling angles offers a narrower
directivity but a better sound projection and far distance definition. The U2 preset features the low
frequency high pass filter.
TTL6-AS PRESETS
L1 - L2 - L3 - L4. EXTENDED LOW. These presets apply respectively four frequency cut-offs to use this
speaker as subwoofer of other RCF TT+ speakers.
S1 - S2. SIDE POSITIONING. These presets were developed to couple this speaker with TTL6-A when this
is configured with presets S1 e S2.
V1 - V2. VERTICAL POSITIONING.These presets were developed to couple this speaker with TTL6-A when
this is configured with presets V1 e V2.
SE - LE. LOW PASS EXCLUDED. These presets are “free“, full range, developed to freely create cut-offs
and cossing as desired.
After the parameter settings the 2 digits display will flash one time. This represents saving all the preset
values in the speaker memory.
Once saved, all the speaker settings are permanent. It is possible to turn off and turn on, the speaker will
remember the last settings.
To reset the speaker to the original settings :
- turn off the speaker
- keep the encoder pressed
- turn on the speaker
- the status yellow led will be blinking slowly, keep the encoder pressed
- wait until the 2 digits display will turn to show the completed reset procedure
- now release the encoder
- the reset procedure is finished
Using the RDNet IN/OUT connection it is possible to load in the speaker memory a dedicated user
equalisation. The speaker reset procedure will cancel even this equalisation.
The XLR connectors use the following AES standard:
PIN 1 = GROUND (SHIELD)
PIN 2 = HOT (+)
PIN 3 = COLD (-)
70° - 80°
HOT GND
BAL. XLR
COLD
SAVING
A SPEAKER PRESET
SPEAKER RESET
CONNECTIONS

10
ENGLISH
At this point you can connect the power supply cable and the signal cable, but before turning
on the speaker make sure that the volume control is at the minimum level (even on the mixer
output). It is important that the mixer is already ON before turning on the speaker.This will avoid
damage to the speakers and noisy “bumps” due to turning on parts on the audio chain. It is a
good practice to always turn on speakers at last and turn them off immediately after the show.
Now you can turn ON the speaker and adjust the volume control to a proper level.
BEFORE TURNING ON
THE SPEAKER
WARNING: daisy chaining speakers always make sure that the maximum current
requirement does not exceed the maximum admitted POWERCON current. In case of doubt
call the closest RCF SERVICE CENTRE.
WARNING
INSTALLATION
WARNING: The powercon connector is used to disconnect the system from the power
supply network. It shall be easily accessible after the installation and during the use of the
system.
The pickup point is asymmetric and can be
fit in two positions (A and B).
Aposition brings the shackle to the front.
Bposition allows an intermediate step
using the same fixing holes.
A B
5. Pickup fixing holes
5
1. Front flying bracket
2. Quick lock pin hole (to be used to lock the
front bracket before installation)
3. Loose pin hole
4. Suspension case pin hole
32
14
Move the pickup bracket to set system with
chosen angle.
The fuse settings/replacement shall be as follow:
FUSE VALUE T 6.30 A H 250 V
VOLTAGE SETUP
(RESERVED TO THE RCF SERVICE CENTRE)
SERVICE NOTE
1. FLYBAR INSTALLATION

11
ENGLISH
Put the first speaker under flybar.
6. Secure both hinge pins on the backside of
speaker (one for each side)
7. Insert pin on flybar bracket ( two for each
side)
8. Set position of hole pin to lock bracket
with speaker
9. Insert the Suspension/Locking Pins
Check that the front and the rear pins are
secured and locked.
7
8
9
6
Fix the pick-up bracket with the two pins
on the holes of flybar brackets and check all
pins are secured and locked
Appoggiare la cassa superiore
a quella inferiore
SIDE VIEW
2. SPEAKER POSITIONING

12
ENGLISH
Move the brackets from the intial position
(figure A) to the locking position (figure B).
Secure the brackets on the locking position
with the quick lock pins (figure C).
Move the front bracket inside the opposite speaker
using the little knob (figure D).
Choose the tilt angle (figure E).
Insert the quick lock pin into the “Suspension Pin“
hole with the help of the litte knob (figure F).
REAR VIEW
SIDE VIEW
A
B
C
D
E
F
3. REAR PINS LOCKING
4. CHOOSING THE TILT ANGLE

13
ENGLISH
Lift the speaker and insert the quick lock pin into
the “Locking Pin” hole.
5. FRONT PINS LOCKING

TTL6-A TTL6-AS
45 - 20.000 Hz
139 dB
90° x 30°
200, 800 Hz
2 x 12” neo, 3.0” v.c.
4 x 6.0” neo, 2.0” v.c.
1.4”, 3.0” v.c.
2200 Watt
1100 Watt
700 Watt
400 Watt
xlr, RDNet Ethercon
Powercon IN/OUT
Close, Linear, Far, 2x Presets
1100 x 378 x 468
53 Kg
35 - 400 Hz
139 dB
-
selectable
3x12”neo,3.0”v.c.
-
-
1650 Watt RMS
1650 Watt RMS
-
-
xlr, RDNet Ethercon
Powercon IN/OUT
Gain, EQ, Preset, Phase
switch, Output Delay Settings
1100 x 378 x 468
45 Kg
ACOUSTICAL
Operating frequency range
Max SPL
Coverage
Crossover frequencies
TRANSDUCERS
Low frequency
Mid frequency
High frequency
AMPLIFIER
Total power
Low section
Mid section
High section
CONNECTIONS
Signal Input/Output
Power Input/Output
CONTROLS
MECHANICAL
Size
Weight
RCF S.p.A.
Via Raffaello Sanzio, 13
42124 Reggio Emilia - Italy
Tel [phone]
Fax [phone]
e-mail: [e-mail]
10307495 RevC
SPECIFICATIONS µ
÷
±
