RCF C 3108-96 User manual

OWNER MANUAL
MANUALE D’USO
C 3108-96 – C 3108-126
C 3110-96 – C 3110-126
-‘COMPACT’ SERIES
LOUDSPEAKERS
-DIFFUSORI ACUSTICI DELLA
SERIE “COMPACT”

4
ENGLISH
IMPORTANT NOTES
Before connecting and using this product, please read this instruction manual
carefully and keep it on hand for future reference. This manual is to be considered an
integral part of this product and must accompany it when it changes ownership
as a reference for correct installation and use as well as for the safety precautions.
RCF S.p.A. will not assume any responsibility for the incorrect installation and / or use of
this product.
WARNING: To prevent the risk of fire or electric shock, never expose this loudspeaker to
rain or humidity and also dust.
SAFETY AND OPERATING PRECAUTIONS
1. All the precautions, in particular the safety ones, must be read with special attention, as
they provide important information.
2. Loudspeaker lines (amplifier outputs) can have a sufficiently high voltage to involve
a risk of electrocution: never install or connect this loudspeaker when amplifiers are
switched on.
3. Make sure all connections have been made correctly and the loudspeaker input
impedance is suitable for the amplifier output.
4. Protect loudspeaker lines from damage; make sure they are positioned in a way that they
cannot be stepped on or crushed by objects.
5. Make sure that no objects or liquids can get into this product, as this may cause a short
circuit.
6. Never attempt to carry out any operations, modifications or repairs that are not expressly
described in this manual.
Contact your authorized service centre or qualified personnel should any of the following
occur:
-The loudspeaker does not function (or works in an anomalous way).
-The cable has been damaged.
-Objects or liquids are inside the loudspeaker.
-The loudspeaker has been damaged due to heavy impacts or fire.
7. Should the loudspeaker emit any strange odours or smoke, remove it from the line after
having immediately switched the amplifier off.
8. Do not connect this product to any equipment or accessories not foreseen.
For suspended installation, only use the dedicated anchoring points and do not try to hang
this loudspeaker by using elements that are unsuitable or not specific for this purpose.
Also check the suitability of the support surface to which the product is anchored (wall,
ceiling, structure, etc.), and the components used for attachment (screw anchors, screws,
brackets not supplied by RCF etc.), which must guarantee the security of the system /
installation over time, also considering, for example, the mechanical vibrations normally
generated by transducers.
9. RCF S.p.A. strongly recommends this product is only installed by professional qualified
installers (or specialised firms) who can ensure a correct installation and certify it according
to the regulations in force.
The entire audio system must comply with the current standards and regulations regarding
electrical systems.
IMPORTANT
WARNING
SAFETY AND OPERATING PRECAUTIONS

5
ENGLISH
10. Mechanical and electrical factors need to be considered when installing a professional
audio system (in addition to those which are strictly acoustic, such as sound pressure,
angles of coverage, frequency response, etc.).
11. Hearing loss
Exposure to high sound levels can cause permanent hearing loss. The acoustic pressure
level that leads to hearing loss is different from person to person and depends on the
duration of exposure.
To prevent potentially dangerous exposure to high levels of acoustic pressure, anyone who
is exposed to these levels should use adequate protection devices.
When a transducer capable of producing high sound levels is being used, it is necessary to
wear ear plugs or protective earphones.
See the technical specifications in the instruction manual for the maximum sound pressure
the loudspeaker is capable of producing.
12. To ensure a correct sound reproduction, loudspeaker phase is to be respected
(loudspeakers are connected respecting the amplifier polarity). This is important when
loudspeakers are installed adjacent one another, for instance, in the same room.
13. To prevent inductive effects from causing hum, noise and a bad system working,
loudspeaker lines should not be laid together with other electric cables (mains), microphone
or line level signal cables connected to amplifier inputs.
14. The loudspeaker cable shall have wires (twisted, if possible, to reduce inductive
effects due to surrounding electro-magnetic fields) with a suitable section and a sufficient
electrical insulation. Refer to local regulations since there may be additional requirements
about cable characteristics.
15. Do NOT connect the loudspeaker low impedance (8 Ω) input to 100 V constant voltage
lines.
16. Install this loudspeaker far from any heat source.
17. Do not overload the loudspeaker with too much power.
18. Do not use solvents, alcohol, benzene or other volatile substances for cleaning the
external parts of this product. Use a dry cloth.

6
ENGLISH
RCF S.P.A. THANKS YOU FOR PURCHASING THIS PRODUCT, WHICH HAS BEEN
DESIGNED TO GUARANTEE RELIABILITY AND HIGH PERFORMANCE.
DESCRIPTION
The new ‘Compact’ series includes a wide range of high quality 2-way passive
loudspeakers for fixed installations. It is based on the RCF exclusive ‘Coverage Matching
Design’ technology, that helps guarantee an optimal transition between the high
frequency horn polar pattern and the low frequency woofer directivity.
The horn can be rotated, allowing to install the loudspeaker either vertically or horizontally.
This manual covers 2models of the new series:
- C 3108 two-way loudspeaker, 8” woofer and 1” driver
- C 3110 two-way loudspeaker, 10” woofer and 1” driver.
Each of the 2models is available with two different horn dispersions, indicated by either
-96 or -126 suffix:
-C 3108-96, C 3108 having 90° (horizontal) x 60° (vertical) dispersion
-C 3108-126, C 3108 having 120° (horizontal) x 60° (vertical) dispersion
-C 3110-96, C 3110 having 90° (horizontal) x 60° (vertical) dispersion
-C 3110-126, C 3110 having 120° (horizontal) x 60° (vertical) dispersion.
All models are carefully assembled in Italy (in our main factory) and include RCF woofers
and drivers that are the best of the most recent technology about transducers.
All loudspeakers are equipped with a high power handling ‘Low Impedance
Compensated Crossover’, having an electronic protection for the driver.
All cabinets are made of Baltic birch (heavy duty painted) and allow different installation
options.
The steel front grilles are protected with a robust double mesh polyester clothing.
The front RCF logo is easily rotatable.
All models are equipped with top and bottom ‘Multiplates’ for either wall or suspended
mounting with chains.
Installation points are available on rear panels.
All models have two Neutrik Speakon NL4 connectors (audio input and parallel link
output).
HOW TO REMOVE THE GRILLE TO HAVE ACCESS TO THE HORN
Rotate the RCF Logo 45°
to show the two screw
heads, then remove the
screws.
Using a hook, pass
through the foam layer
and try to locate a hole on
a side of the metal grille
Once the hook is hanged to
the metal grille, pull gently.
The grille should now lift
and can be removed
Notice the metal grille is located under a
foam layer.
THE HOOK MUST BE HANGED TO THE
METAL GRILLE. DO NOT PULL IF THE
HOOK IS HANGED TO THE FOAM LAYER.

7
ENGLISH
Loudspeakers are to be install by qualified personnel, respecting all safety standards.
Loudspeakers are to be installed securely.
Make sure the support structure (walls / ceilings) has the necessary mechanical
characteristics for the loudspeaker weight, without the risk of a fall that could damage
things or cause an injury.
Use attachments elements suitable for walls / ceilings (e.g. screw anchors for bricks, screw
anchors for concrete, etc.).
a) HORIZONTAL MOUNTING WITH U BRACKET
Necessary optional accessory:
- AC NC08 H-BR (for the C 3108-96 and C 3108-126 models)
- AC NC10 H-BR (for the C 3110-96 and C 3110-126 models).
Fix the U bracket to the wall / ceiling through at least 4 lateral wall plugs (max. M8) plus
a central one (max. M10).
Mount the U bracket to the loudspeaker by tightening the two M10x35 bolts into the two
central holes of the multiplates, as shown in the figure below.
As an alternative, it is possible to install the loudspeaker a bit less prominent, thanks to the
U bracket inner holes. Before tightening the two M10 bolts, adjust the loudspeaker vertical
tilt and then fix it through two M5x20 bolts into one of the 7 small holes of the U bracket.
Note: do Not tilt the loudspeaker upwards!
iNstead of simple m10 bolts, it is possible to use the iNcluded kNobs (haviNg m10 bolts).
INSTALLATION

8
ENGLISH
b) VERTICAL MOUNTING WITH U BRACKET
Necessary optional accessory:
- AC NC08 V-BR (for the C 3108-96 and C 3108-126 models)
- AC NC10 V-BR (for the C 3110-96 and C 3110-126 models).
Fix the U bracket to the wall / ceiling through at least 4 lateral wall plugs (max. M8) plus
a central one (max. M10).
Mount the U bracket to the loudspeaker by tightening the two M10x35 bolts into the two
lateral holes of the loudspeaker, as shown in the figure below.
As an alternative, it is possible to install the loudspeaker a bit less prominent, thanks to
the U bracket inner holes.
Before tightening the two M10 bolts, adjust the loudspeaker vertical tilt and then fix it
through two M4.2x22 self-threading screws (passing through the small hole of the U
bracket) directly into the loudspeaker cabinet wood.
Note: do NOT tilt the loudspeaker upwards!
Instead of simple M10 bolts, it is possible to use the included knobs (having M10 bolts).
c) MOUNTING WITH A SWIVEL BRACKET
Necessary optional accessory: AC WM-C
Mount the fixed part of the AC WM-C accessory (shown in grey in the
respective figure) to the wall through its corners with four M10 wall plugs.
The central hole of the fixed part is useful to let pass the connecting cable
from the wall outlet.
AC WM-C

9
ENGLISH
About the C3108 models, it is possible to fix the moving part of the AC WM-C accessory
directly to the loudspeaker rear panel, through four M8 flat head screws, in one of the 2
possible positions.
Add the two included bars to mount the swivel bracket at the centre (allowing also a
balanced horizontal mounting of the loudspeaker).
The C3110 models have 8 threaded holes (instead of 6), allowing the direct mounting
(without additional bars) of the AC WM-C accessory at the rear panel centre.
Then, put the loudspeaker on the fixed part of the AC WM-C accessory (that is wall-
mounted) and tighten the bolt. The screw below allows vertical tilt adjustments.

10
ENGLISH
d) SUSPENDED MOUNTING WITH A DEDICATED ACCESSORY
Necessary optional accessory: AC NC-FB1
The AC NC-FB1 accessory is a bracket with holes that allows the loudspeaker suspension
with two M10 D-shackles and chains (not included).
Fix the AC NC-FB1 accessory to the loudspeaker top multiplate through four M5 flat
head, as shown in the figure below.
WARNING: loudspeaker connections should be only made by qualified and experienced
personnel having the technical know-how or sufficient specific instructions (to ensure
that connections are made correctly) in order to prevent any electrical danger.
To prevent any risk of electric shock, do not connect loudspeakers when the amplifier is
switched on.
Before turning the system on, check all connections and make sure there are no
accidental short circuits.
The entire sound system shall be designed and installed in compliance with the current
local laws and regulations regarding electrical systems.
‘Compact’ series loudspeakers are designed for indoor use only. If installed outdoor,
loudspeakers shall be protected against water.
The impedance value of each loudspeaker is 8 Ω.
CONNECTIONS

11
ENGLISH
Connect the positive wire (amplifier ‘+’ output) to the pin 1+ of the SPEAKON connector.
Connect the negative wire (amplifier ‘–’ output) to the pin 1– of the SPEAKON connector.
The pins 2+ and 2– are not used.
Two sockets (input and output, linked in parallel) for ‘Neutrik Speakon NL4’ (4-pole) plugs
are available on every rear panel.

12
ENGLISH
NOTES ABOUT LOW IMPEDANCE CONNECTIONS
-The total loudspeaker impedance must not be lower than the amplifier output
impedance. Note: a loudspeaker total impedance equal to the amplifier output one
permits to get the maximum deliverable power (but an higher loudspeaker impedance
entails less power).
-The total loudspeaker power shall be adequate for the maximum deliverable power of
the amplifier.
-The loudspeaker line shall be short (for long distances, it may be necessary to use cables
with large cross-section wires).
-Always use cables having wires with an adequate cross-section, considering the cable
length and the total loudspeaker power.
-Loudspeaker lines must be kept separated from the mains cables, microphone cables or
others, in order to avoid inductive phenomena may cause hum or noises.
-Use loudspeaker cables with twisted wires to reduce hum caused by inductive effects
due to coupling with electromagnetic fields.
-Do NOT connect the low impedance input directly to 70 / 100 V constant voltage lines.
- +
TOTAL IMPEDANCE: 4 Ω
8 Ω
8 Ω
+
+
- +
TOTAL IMPEDANCE: 8 Ω
8 Ω
+

13
ENGLISH
SPECIFICATIONS
MODEL
Impedance
RMS power
Frequency response
(-10 dB)
Sensitivity
(1 W / 1 m)
Sound pressure
300 W / 1 m
Woofer
Driver
Dispersion
(hor. x vert.)
Net weight
C3108-96 C3108-126 C3110-96 C3110-126
8 Ω8 Ω8 Ω8 Ω
300 W 300 W 300 W 300 W
70 Hz ÷ 20 kHz 70 Hz ÷ 20 kHz 60 Hz ÷ 20 kHz 60 Hz ÷ 20 kHz
95 dB 94.5 dB 96 dB 95.5 dB
120 dB 119.5 dB 121 dB 120.5 dB
8” (2” v.c.) 8” (2” v.c.) 10” (2” v.c.) 10” (2” v.c.)
1” (1.5” v.c.) 1” (1.5” v.c.) 1” (1.5” v.c.) 1” (1.5” v.c.)
90° x 60° 120° x 60° 90° x 60° 120° x 60°
12.2 kg 12.2 kg 15.8 kg 15.8 kg
Cabinet birch plywood
Colour black

14
ENGLISH
C 3108 DIMENSIONS mm

15
ENGLISH
C 3110 DIMENSIONS mm

10307299 RevC
www.rcfaudio.com
HEADQUARTERS:
RCF S.p.A. Italy
tel. +39 0522 274 411
e-mail: info@rcf.it
RCF UK
tel. 0844 745 1234
Int. +44 870 626 3142
e-mail: info@rcfaudio.co.uk
RCF France
tel. +33 1 49 01 02 31
e-mail: france@rcf.it
RCF Germany
tel. +49 2203 925370
e-mail: germany@rcf.it
RCF Spain
tel. +34 91 817 42 66
e-mail: info@rcfaudio.es
RCF Belgium
tel. +32 (0) 3 - 3268104
e-mail: belgium@rcf.it
RCF USA Inc.
tel. +1 (603) 926-4604
e-mail: [email protected]
This manual suits for next models
4
Table of contents
Other RCF Speakers manuals
