RCS RCS-433DT Series User manual

RCS-433DT
IS-T02DSERUK Rev.0 del 23/01/2002
1A - General information
The radiocontrol RCS-433DT has been designed for the control of
automatic closing systems and anti-burglar systems. The operating
frequency is 433,92 MHz.
The receiver which makes the activation, once received the
transmitter code, has to be connected during the installation to the
device to control ( gate, rolling shutters, awnings, anti-burglar
appliances, lighting ).
The transmitter security code is obtained by means of a 9 ways
three-state dip-switch which allows up to 19683 code
combinations. All the receivers of the range RCS-433 can store
into the EEPROM the code of many transmitters.
Each transmitter ( or its different keys ) can be stored into different
receivers and hence can do more functions.
In order to use the unused keys of the transmitter it is enough to
connect the dedicated receiver to the mechanism to drive ( i.e.
electrolock of a pedestrian gate, a buzzer, etc. ).
The product fully complies with the European Directives 99/5/CE,
89/336/CEE, 73/23/CEE and with the Part 15 of FCC
Regulations.
Thank you for choosing a RCS product . You are recommended
to read carefully this manual before using the product.
USER
MANUAL
1A - General information
1B - Technical specifications
1C - Main features
1D - Model types
1 - TRANSMITTER INTRODUCTION
2 - CODING
3 - MEMORISATION
4 - BATTERY AND DIP-SWITCHES ACCESS
5 - TROUBLESHOOTING
CONTENTS
1 - TRANSMITTER INTRODUCTION
1B - Technical specifications
Number of keys : 2 or 4
Supply : 12 Vdc
Battery duration: 12 - 24 months
Battery type: 23A
Current consumption : 25 mA
Operating frequency : 433.92 MHz
Security code combinations number: 19683
Modulation: AM/ASK
E.r.p. : 50 - 100 uW
Range in open space : from 100 to 200 m
Operating temperature : from -10 °C to +55 °C
Dimensions : 83 x 48 x 16 mm
Weight : 40 g
RCS RCS-433DT2
RCS-433DT4

2 - CODING
1D- Model Types
2 buttons dip-switch transmitter : Cod. RCS-433DT2
4 buttons dip-switch transmitter : Cod. RCS-433DT4
GARANZIA
BUTTON 1
CHANNEL A
RED
LED
RED LED
BATTERY
DOOR
1C- Main features
BUTTON 2
CHANNEL B
BUTTON 4
CHANNEL D
BUTTON 3
CHANNEL C
Open the rotating door to access to the battery and the dip-switches.
The dip-position will give the security code.
Warning: each transmitter is set-in-factory with the same code on the dip-
switches; it highly advisable to change this code by moving the dip-switches
on the favourite position ( “+”, “0” , “-”).
The transmitter code has to be stored into the receiver memory. The
memorisation can be done by selflearning. The instructions for this
operation are reported on the receiver installation manual. Your own
installer will perform this operation during the installation or will give you
the necessaries explications during the selling.
Don’t forget that the still free buttons of your transmitter can be used for
further wireless fuctions. Ask your installer the best suitable receiver.
3 - MEMORISATION
4 - BATTERY AND DIP-SWITCH ACCESS
5 - TROUBLESHOOTING
FAULT SOLUTION
The radio signal is not
verifiable
The transmitter led doesn't
switch on
The radio signal is not
verifiable
The transmitter led
switches on
Replace the transmitter
battery
Check the power supply of
the receiver
Replace the transmitter
battery
The guarantee period of all RCS Transmitter batteries is months, beginning
from the manufacturer date. During this period, if the product does not
work correctly, due to a defective component, the product will be repaired
or substituted at the discretion of the producer. The guarantee does not
cover the plastic container integrity. After-sale service is supplied at the
producer's factory.
GUARANTEE
REMOTE CONTROL SOLUTIONS
College Park Commerce Center
2042 N. Rio Grande Ave. Suite A
Orlando - FL 32804
U.S.A.
Office: (407)-426-8687
Fax: [phone]
e-mail: [email protected]
To access the battery slide out the
battery door
Place the 23A alkaline battery between
the 2 contacts.
Respect the right polarity as indicated
on the bottom of the box.
NOTE:Please dispose of the batteries correctly,
they are hazardous waste.
RCS-433DT - Type : SETDS39433
FCC ID : PWJDS433
This device complies with FCC Rules
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept interference received, including
interference that may cause undesired operation.
Part. 15 of the
Notice
Any changes or modification to RCS equipment not expressly approved by RCS could
void the user's authority to operate the equipment.
Battery
Rotating door
Dip-switch
Rotate to open
