RACK-UP®SERIES
Model RU-VSQ4
Sequencing Video Switcher
INPUT AND OUTPUT VIDEO SIGNALS MUST BE 75 OHM TERMINATED
AUDIO FOLLOW VIDEO WIRING USING RDL RU-SX4A AUDIO SWITCHER
RDL
1
RESET
MADE IN U.S.A.
24 VDC
4321
CONTROL OUTPUTS
VIDEO OUT
INPUT LOOP OUT
2
34
INPUT LOOP OUT
INPUT LOOP OUT INPUT LOOP OUT
RDL
1
RESET
MADE IN U.S.A.
24 VDC
4321
CONTROL OUTPUTS
VIDEO OUT
INPUT LOOP OUT
2
34
INPUT LOOP OUT
INPUT LOOP OUT INPUT LOOP OUT
RU-SX4A
INPUT
VIDEO
SOURCE
SIGNAL
FROM
VIDEO
75 OHM
OTHER
SIGNAL
TO
WIRING
OPTIONAL
JUMPERS
IF 2 SOURCES USED
IF 3 SOURCES USED
FROM
SIGNAL
VIDEO
SOURCE TERM
75 OHM
JUMPER
POWER
24 VDC
SOURCE
OUTPUT
SIGNAL
75 OHM
TYPICAL PERFORMANCE
Input Impedance: 5 kΩBridging
Gain: Unity, 75 Ωterminated
Load Impedance: 75 Ω
Outputs (5): 4 LOOP OUT from Input Signals;
1 Amplified Output
Operating Signal Level: 0.5 to 1 V p-p
Frequency Response: 10 Hz to 10 MHz (+/- 0.35 dB)
Noise: < -70 dB (below 1 V p-p)
Crosstalk: < -55 dB
Off Attenuation: > 65 dB
Differential Gain: 0.1%
Differential Phase: 0.3 degree
Connector Type: BNC, gold plated
External Control Outputs (4): 50 mA, Open-collector to Ground
Sequencing Rate: Adjustable 1 to 15 seconds
Power Requirement: 24 to 33 Vdc @ 110 mA,
Ground-referenced
Installation/Operation
EN55103-1 E1-E5; EN55103-2 E1-E4
Typical Performance reflects product at publication time
exclusive of EMC data, if any, supplied with product.
Specifications are subject to change without notice.
891-3065I
