TRENDnet TPE-TG44G User manual

TPP-TG44g
rev: 07.02.2012
PRODUCT OVERVIEW
• 4 x Gigabit PoE / PoE+ ports (up to 30 watts per PoE+ port)
• 4 x Gigabit ports
• Reduces equipment cost by delivering data and power over existing network cables
• 16 Gbps switching capacity
• Sturdy metal case
• Up to 75% GREENnet power savings
8-Port Gigabit GREENnet PoE+ Switch
TPE-TG44g (V1.0R)
TRENDnet’s 8-Port Gigabit GREENnet PoE+ Switch, model
TPE-TG44g, reduces equipment and installation costs by delivering
data and power over existing Ethernet cables. This unmanaged switch
offers four Gigabit PoE+ and four Gigabit non-PoE ports. The PoE+
standard supplies up to 30 watts of power per port for devices such
as high power wireless access points, PTZ (Pan / Tilt / Zoom) internet
cameras, and VoIP telephony systems.
Auto sensing technology delivers 30 watts to 802.3at PoE+ devices
(up to 2 devices), 15 watts to 802.3af PoE devices (up to 4 devices),
and only data to non-PoE devices. GREENnet technology reduces
energy consumption by up to 75% when the switch is not in use. Boost
offi ce effi ciency and reduce network congestion with a total switching
capacity of 16 Gbps. LED indicators display device status for effi cient
troubleshooting. This switch comes in a sturdy metal case and quickly
adds PoE+, PoE, and non-PoE devices to your network.

TPE-TG44g
rev: 07.02.2012
8-Port Gigabit GREENnet PoE+ Switch
TPE-TG44g (v1.0R)
FEATURES
• IEEE 802.3at and IEEE 802.3af Power over Ethernet (PoE) compliant
• Supports PoE Class 2 (7 watts) , 3 (15.4 watts), and 4 (30 watts)
• 4 x Gigabit Auto-MDIX PoE / PoE+ ports
• 4 x Gigabit Auto-MDIX ports
• Provides up to 30 watts for PoE+ (2 ports max.)
• Provides up to 15.4 watts for PoE (4 ports max.)
• Automatically detects the PoE class level of a Powered Device
• 16 Gbps switching fabric
• Forwarding Rate: 1000 Mbps (1,488,000 pps), 100 Mbps (148,800 pps), 10 Mbps (14,880 pps)
• Status LEDs: System Power, PoE, 1000 Mbps, and Link/Activity
• 1K Mac address entries
• 96 Kbyte memory buffer
• Full wire-speed non-blocking reception and transmission
• Store-and-forward switching method
• Back pressure Flow Control for Half-Duplex mode
• IEEE 802.3x Flow Control for Full-Duplex mode
• Power saving technology powers down unused ports and when a connected device is in standby mode
• Jumbo Frame support up to 9K
• Plug and Play
• Sturdy metal case
• 3-year limited warranty

TPE-TG44g
rev: 07.02.2012
8-Port Gigabit GREENnet PoE+ Switch
TPE-TG44g (v1.0R)
SPECIFICATIONS
HARDWARE
Standard • IEEE 802.3 10Base-T
• IEEE 802.3u 100Base-TX
• IEEE 802.3ab 1000Base-T
• IEEE 802.3at Power over Ethernet (PoE+)
• IEEE 802.3af Power over Ethernet (PoE)
• IEEE 802.3x Flow Control
• IEEE 802.3az Energy Effi cient Ethernet
Ports • 4 x Gigabit Auto-MDIX PoE+ ports
• 4 x Gigabit Auto-MDIX ports
Data Transfer Rate • Ethernet: 10/20 Mbps (Half / Full Duplex)
• Fast Ethernet: 100/200 Mbps (Half / Full Duplex)
• Gigabit: 2000 Mbps (Full Duplex)
Forwarding Rate • 1,000 Mbps: 1,488,000pps
• 100 Mbps: 148,800pps
• 10 Mbps: 14,880pps
Data RAM Buffer • 96 Kbytes
Address Table • 1K MAC entries
Switch Fabric • 16 Gbps
Power • Input: 100-240V 47-63 Hz, 2A
• Output: 53V DC, 1.2A External Power Adapter
Diagnostic LEDs • Power, PoE, 1000 Mbps, Link/Activity
Power Consumption • Min: 4 watts (standby)
• Max: 65 watts
• PoE Max: 60 watts
• (4 x 15 watts PoE devices connected or 2 x 30 watts PoE+ devices connected)
Temperature • Operating: 0° ~ 40°C (32° ~ 104°F)
• Storage: -20° ~ 90°C (-4° ~ 194°F)
Humidity • Max 90% (non-condensing)
Dimensions • 142 x 95 x 30 mm (5.6 x 3.7 x 1.2 in.)
Weight • 380 g (13.4 oz.)
Certifi cations • CE, FCC
POE
Power over Ethernet • Up to 15.4 watts for PoE
• Up to 30 watts for PoE+
• PoE: pin 3, 6 for power+ and pin 1, 2 for power- (mode A)

8-Port Gigabit GREENnet PoE+ Switch
TPE-TG44g (v1.0R)
CONTACT INFORMATION
20675 Manhattan Place,Torrance, CA 90501 USA
Tel: [phone]
Fax: [phone]
Web: www.trendnet.com
Email: [email protected]
1-888-326-6061
PACKAGE CONTENTS
TPE-TG44g
Quick Installation Guide
Power adapter (53V DC, 1.2A)
RELATED PRODUCTS
TPE-T88G 16-Port GREENnet 10/100 Mbps PoE+ Switch
TPE-T160 16-Port 30 watt 10/100 Mbps PoE+ Switch
TPE-TG80G 8-Port Gigabit GREENnet PoE+ Switch
