RDL EZ Series User manual

INSTALLATION AND
OPERATION MANUAL
RDL EZ Series products provide the highest level of value to A/V professionals and A/V users who demand professional quality.
For long-term performance, quality and value, you have made the EZ choice. EZ products are made in the USA by RDL, the
inventor of application-specific modules bringing decades of experience as the world’s leading manufacturer of high-reliability
performance products to the A/V industry. Visit the RDL website for hundreds of professional A/V products made in the USA by RDL.
RDL•659 N. 6th Street •Prescott, AZ •USA 86301 •Sales: 800-281-2683 •928-443-9391
Tech Support: 800-933-1780 •928-778-3554 •RDL Europe Sales & Support: (31) 20-6238-983
www.rdlnet.com
Decades of Performance, Quality and Value
EZ-AVX4
Composite Video and Stereo Audio Input Switcher
Model numbers:
EZ-AVX4 includes power supply with North American plug
EZ-AVX4X includes worldwide power supply (specify plug)
INSTALLATION AND
OPERATION MANUAL
RDL EZ Series products provide the highest level of value to A/V professionals and A/V users who demand professional quality.
For long-term performance, quality and value, you have made the EZ choice. EZ products are made in the USA by RDL, the
inventor of application-specific modules bringing decades of experience as the world’s leading manufacturer of high-reliability
performance products to the A/V industry. Visit the RDL website for hundreds of professional A/V products made in the USA by RDL.
RDL•659 N. 6th Street •Prescott, AZ •USA 86301 •Sales: 800-281-2683 •928-443-9391
Tech Support: 800-933-1780 •928-778-3554 •RDL Europe Sales & Support: (31) 20-6238-983
www.rdlnet.com
Decades of Performance, Quality and Value

www.rdlnet.com • ••www.rdlez.com
•
•
•
•
•
•
•
Four Input Source Selection
Video Inputs Accept NTSC or PAL Signals
Unbalanced Stereo Audio Inputs and Output
Simultaneous Audio and Video Switching
Audio and Video on Color-Coded RCA Jacks
Inputs and Outputs on Rear Panel
Full-Size Interlocking Pushbuttons on Front Panel
EZ-AVX4
Composite Video and Stereo Audio Input Switcher
TYPICAL APPLICATION
The EZ-AVX4 is a stereo audio and composite video source selector. Line-level audio and video outputs are provided on RCA
jacks. This unit is ideal as a four input source selector feeding an associated video monitor or recorder. The EZ-AVX4 is used in
stores, houses of worship, restaurants, clubs, security systems and commercial A/V systems.
TV A/V Out
DVR
VCR
DVD Player
TV Monitor
EZ-AVX4
www.rdlnet.com • ••www.rdlez.com

POWER CONNECTION FIXED MOUNTING RUBBER FEET ATTACHMENT
Insert Power Plug
Bottom View
of chassis
Recess
Screw
directly to flat
surface without
installing rubber feet.
Rotate 1/4-turn
clockwise to lock
Rotate 1/4-turn
counter-clockwise
to unlock Peel backing and stick the 4 rubber
feet to chassis in recesses provided.
24 VDC POWER INPUT
Insert plug from power
supply. Rotate 1/4 turn
clockwise to lock.
AUDIO OUTPUT
Connect to the line input of an amplifier, mixer, recorder,
computer or other product with a line-level input.
AUDIO INPUT JACKS
Connect a stereo source to INPUT 1, 2,
3 and/or 4. The source equipment must
provide line-level audio from its line output or
headphone output. Typical sources include
DVD decks, computers and televisions. It is
not necessary that all inputs be connected.
VIDEO INPUT JACKS
Connect a composite video source to VIDEO INPUT 1, 2, 3 and/or 4. The source
equipment must provide NTSC or PAL format video. Typical sources include DVD
players, computers and televisions. It is not necessary that all inputs be connected.
VIDEO OUTPUT
Connect to the composite video
input of a recorder, computer,
television or other product with a
composite video input.
INPUT SELECTOR SWITCHES
Push the button corresponding to the desired INPUT. The button will lock
in position. The selected INPUT switches the audio and video source to the
AUDIO OUT and VIDEO OUT jacks.
POWER INDICATOR
Glows blue when the
product is connected to
a valid power source.
POWER CONNECTION FIXED MOUNTING RUBBER FEET ATTACHMENT
Insert Power Plug
Bottom View
of chassis
Recess
Screw
directly to flat
surface without
installing rubber feet.
Rotate 1/4-turn
clockwise to lock.
Rotate 1/4-turn
counter-clockwise
to unlock. Peel backing and stick the 4 rubber
feet to chassis in recesses provided.

EZ-RA6
EZ-CC6
SELECTED MOUNTING ACCESSORIES
TYPICAL PERFORMANCE
Rack Adapter for 6 Increments of 1/6 Rack Width
Component Chassis for 6 Increments of 1/6 Rack Width
EZ-UCB2
Under-Counter Brackets 1/6 or 1/3 Rack Width
Use In Place of Filler Panel
Holds Adapters and Cables
Mounts in EZ-CC6 and EZ-RA6
Complete accessory listing available at: rdlez.com
Copyright © 2009 Radio Design Labs, Inc. RDL, Radio Design Labs and the RDL logo are registered trademarks of Radio Design Labs, Inc. Data reflects product at publication time, subject to change without notice. “Made in USA” applies to all EZ products except power supplies.
AUDIO SECTION
Inputs (4): Stereo on dual RCA jacks, > 10 kΩ, -10 dBV nominal, +10 dBV max.
Gain: Unity, nominal
Output: Stereo on dual RCA jacks, -10 dBV nominal, +10 dBV max.
Frequency Response: 10 Hz to 20 kHz (±0.01 dB)
THD+N: < 0.02%
Off Attenuation: > 95 dB
Noise: <-95 dB (below -10 dBV output)
24 Vdc power supply current: 85 mA (idle), 100 mA (max.)
Power supply input voltage: 100 to 240 VAC
Warranty: 3 Years; contact RDL technical support department for assistance
Case dimensions: 5.75” (14.6 cm)W x 5” (12.7 cm)D
Mounting size: 1/3 rack width.
VIDEO SECTION
Inputs (4): RCA jack, 1V p-p, 75 Ω
Output: RCA jack, 1V p-p, 75 Ω
Bandwidth: >350 MHz
Differential gain: <0.1%
Differential phase: < 0.1 degree
Off Attenuation: > 40 dB @ 10 MHz
Noise: <-90 dB (1V p-p video, 75 Ω)
891-1555
EZ-DC2
EZ-SMB2
TYPICAL PERFORMANCE
Desktop Chassis 1/3 Rack Width
EZ-UCB2
Under-Counter Brackets 1/6 or 1/3 Rack Width
Surface Mount Bezel for 1/3 Rack Width Products
EZ-SD2
Storage Drawer 1/3 Rack Width
Copyright © 2009 Radio Design Labs, Inc. RDL, Radio Design Labs and the RDL logo are registered trademarks of Radio Design Labs, Inc. Data reflects product at publication time, subject to change without notice. “Made in USA” applies to all EZ products except power supplies.
