Real-El RS-8F USB Charge User manual

RS-8F USB Charge
SURGE PROTECTOR
with USB Charger
USER’S MANUAL

Technical support: www.real-el.com
1
RS-8F USB
Charge
Congratulations on purchasing the ТМ REAL-EL surge protector!
Please read this User’s Manual before using the unit and retain this User’s
Manual in a safe place for future reference.
COPYRIGHT
© 2015. ENEL GROUP OU.
This Manual and information contained in it are copyrighted. All rights re-
served.
TRADEMARKS
All trademarks are the property of their legal holders.
NOTICE OF RESPONSIBILITY RESTRICTION
Despite the exerted efforts to make this Manual more exact, some discre-
pancies may occur. The information in this Manual is given on “as is” terms.
The author and the publisher do not bear any liability to a person or an orga-
nization for loss or damage which has arisen from the information contained
in this Manual.
PACKAGE CONTENTS
•Surge protector – 1 pc
•User’s manual – 1 pc
•Warranty card – 1 pc
APPLICATION
RS-8F USB Charge surge protector with the built-in USB charger is de-
signed for connection of electrical appliances to the electrical network and
their protection against high-voltage surge pulses and permanent filtration
of high-frequency noises.
User’s Manual
ENG

Technical support: www.real-el.com
2
ENG
RS-8F USB
Charge
FEATURES
•Built-in surge protection
•Double-pole power switch with LED
•Grounded sockets with protection shutters
•Resettable fuse does not require replacement
•2 USB ports to charge two devices simultaneously
•USB charger is suited for most devices
•Pure copper cable without alloys
SAFETY PRECAUTIONS
•Do not connect the surge protector to the electrical network with over-
rating voltage.
•Do not connect the load to the surge protector with the total power, which
exceeds the power indicated in specifications of this device.
•Do not use the surge protector in places with possible ingress of liquid,
moisture, dust and high temperature exposure.
•Do not open and do not make any repairs by yourself.
•Connect the surge protector to the grounded electrical network.
CONNECTION
•Connect equipment to surge protector sockets.
•Connect the surge protector to 230 V electrical network, turn on the
master switch, LED will light.
•If required connect a device to be charged to one of USB ports.
OPERATION
•Do not overload the surge protector by connection of several powerful
devices.
•On operation of the automatic fuse due to the overload, turn on the surge
protector once more in 5-10 minutes after reduction of the total connected
load to a permissible limit. For this purpose, press the on/offbutton on the
fuse.
Surge Protector
with USB Charger

Technical support: www.real-el.com
3
RS-8F USB
Charge
Notes:
• Technical specifications given in this table are supplemental infor-
mation and cannot give occasion to claims.
• Technical specifications and package contents are subject to
change without notice due to improvement of ТМ REAL-EL production.
TECHNICAL SPECIFICATIONS
Parameters and measurement unit
Rated input voltage, V
Operating frequency, Hz
Total power of connected load, kW
Maximum energy absorption of pulse
interference, J
Maximum load current, A
Input plug type
Output socket type
USB charger output voltage
Maximum output current of
USB charger, mAh
Cable length, m
Dimensions (L × H × W), mm
Value
~230
50
≤3.68
200
16
CEE 7/7
8 × CEE 7/3
5 V ± 5 %
2100
3
330 × 40 × 130
User’s Manual
ENG
•If high-voltage impulses or intolerable high voltage occurs at the surge
protector input, the built-in emergency protection can disconnect the surge
protector completely. The surge protector operation with the partial or com-
plete resource loss of the surge protector components is intolerable.

Model: RS-5F CHARGE 4
Manufacturer: ENEL GROUP OU, Katusepapi tn 6, Lasnamäe district, Tallinn city,
Harju county, 11412, Estonia. Made in China.
® Registered Trademark of ENEL GROUP OU. Estonia.
