Real Spirit Aqua-Ionizer Pro Deluxe 7.0 User manual

Read Carefully
Before Initial Use.
Retain Manual for
Future Reference.
7.0
AID7000/B

Table of Contents:
•Included with Your Water Ionizer/Parts & Supplies . . . . . . . . . . . . . 01
•Water Ionizer Assembly Overview . . . . . . . . . . . . . . . . . . . . . . . . . 02
•SafetyInstructions&Symbols ............................03
•TechnicalSpecifications .................................11
•Installation Schematic & Instructions . . . . . . . . . . . . . . . . . . . . . . . 13
1. Identify Required Connector/Attach Faucet Diverter Valve. . . . . 14
2. Install the Inner Carbon Filter . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
3.Inlet&OutletHoses .....................17
4.AttachMetalSpout...................................18
5. Connect the Inlet Water Hose to the Faucet Diverter Valve . . . . 18
6.CheckforLeaks .....................................20
A. R/O Systems and Well Water . . . . . . . . . . . . . . . . . . . . . . . . 21
7.PlugIntheWaterIonizer...............................22
•FREEpHKit ..... ................................... 23
•ORPTesters..........................................23
•Understanding the LCD Display . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
•Understanding Your pH Presets . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
•Selecting Your pH Preset & Dispensing Water: . . . . . . . . . . . . . . . 26
•AutomaticCleaningFunction .............................26
•EnhancedCleaningFunction.............................27
•ManualCleaning&Descaling.............................28
•Problems&Solutions...................................30
•WarrantyInformation....................................32
.............
8. SET LIGHT ........................................22
NEED HELP CALL 1-888-601-5886

NEED HELP CALL 1-888-601-5886
Carbon
Water Filter (1) Water Filter (1)
Mineral/Carbon
Standard
Water (City) RO or Low pH
Water
01
Included with Your Water Ionizer/Parts & Supplies:
Inner Tread
Faucet Joint
(1)
3-Bolt Faucet
Connector
(1)
Faucet Diverter
Valve
(1)
Flexible
Metal Spout
(1)
Dual-Tread
Faucet Connector
(1)
Pre-Installed
Inlet and Outlet Hose
Silicone Caps

NEED HELP CALL 1-888-601-5886
02
Water Ionizer Assembly Overview:
Outer Filter Cover
Inner Filter Cover
Carbon Water Filter
Important Note: As a result of minor technical or aesthetic changes some ionizer
parts may appear slightly different in appearence or color than depicted on product
packaging or in this manual. Should this occur, the part(s) remain usable and should
be installed and used in accordance with this product manual.
Water Ionizer
Flexible
Metal Spout
Power Cord
Inlet Water Hose
Acidic Water Outlet Hose
MAKE TEA &
COFFEE
COOKING
DAILY DRINKING
INITIAL DRINKING CLEANING
CLEANING
= 9.5 - 11.0 pH
= 9.5 - 10.0 pH
= 8.5 - 9.5 pH
= 7.5 - 8.5 pH
(Most Municipal Tap Water is 7.0 pH)
= 6.0 - 7.0 pH
= 5.5 - 6.5 pH
PURIFIED WATER Same pH as
Source Water
=
Alkaline Water Presets: Filtered Water Preset:
Acidic Water Presets:

NEED HELP CALL 1-888-601-5886
03
WARNING
CAUTION
IMPORTANT
Avoid the specified action as it may destroy the unit,
cause serious injury or even death.
Avoid the specified action as it may damage the unit
or cause serios injury.
Do NOT perform the specified action.
The specified action is very important and must be
completed for the unit to function properly.
Safety Instructions & Symbols:
Most City Water in the USA Works Great
Source Water Requirements - Please pay attention to the source
water requirements outlined below prior to installing and operating
your water ionizer...
• The source water entering water ionizer must meet applicable
local standards that make it suitable for drinking. Despite the
unit’s built-in water filter, it should NOT be attached to a water
source not intended for drinking. The purpose of the carbon filter
is to remove residual chlorine, other chemicals, and odors from
water already suitable for human consumption in order to
improve its taste. The filter is NOT intended as the sole
purification source for water that does not meet these standards.
Attempting to use the water ionizer in this manner will void the
warranty, reduce the unit’s performance, shorten its operational
life and could jeopardize the health and life of anyone drinking
water that could potentially still be harmful.
• The water flow entering the water ionizer from the source water
connection must be 0.8 liters per minute or faster for the water
ionizer to operate properly. If the water flow is too slow, the
water ionizer may not be able to induce water flow and therefore
cannot start normally. If your municipal or other water source
flows slower than 0.8 liters per minute, you may need to install a
booster pump.
• The pressure of source water that goes into the unit must be
under 43.5 pounds per square inch (psi) / 0.3 megapascals
(Mpa) for your water ionizer to operate properly and to avoid
damaging the unit. If your water pressure is higher than this, you
should install a water pressure reducer to lower the source water
pressure before it’s fed into your water ionizer.
WARNING
DO NOT

NEED HELP CALL 1-888-601-5886
04
If you have a
R/O
(Reverse Osmosis)System
Do Not install your water ionizer in any of the following locations...
• Near an open flame, in direct sunlight or anywhere temperatures
could exceed 140° F (60° C);
• Near flammable liquids;
• Outdoors or any place where the unit could be directly exposed to
rain, snow, high winds or other weather elements;
• Saunas or other facilities with unusually high levels of humidity
levels; or
• Any spot where water or other liquids might drip on the unit's
exterior.
To avoid electrical shock and fire hazards:
• Be sure the electrical plug is seated fully in the power outlet.
• Do NOT bend, pinch, clamp, place heavy objects upon, modify, or
otherwise damage the unit's power cord or plug.
• Do NOT plug the unit in if the cord, plug or the outlet is damaged.
• Do NOT drag the unit by its power cord or plug.
• Contact a qualified electrician immediately if the cord or plug
becomes damaged.
CAUTION
DO NOT
IMPORTANT
IMPORTANT
WARNING
PLEASE USE the included Mineral filter. This
mineral filter will add back the benifical minerals
the ionizer needs to function properly.
1-888-601-5886
or low pH WELL WATER

NEED HELP CALL 1-888-601-5886
05
CAUTION
PLEASE USE the included Mineral filter.
This mineral filter will add back the beneficiial
minerals the ionizer needs to function properly.
Any questions call
1-888-601-5886
0
If You have a R/O System
(REVERSE OSMOSIS)
or
low pH WELL WATER

NEED HELP CALL 1-888-601-5886
.
06
• Do NOT share the electrical outlet used for your ionizer with other
electrical appliances.
• Use only alternating current 110V power supply. Exceeding the
rated power range may damage the unit and/or cause a fire.
• Do NOT attempt to plug in, unplug, or otherwise operate your
water ionizer if your hands are wet.
• Do NOT submerse the unit in water nor use alcohol, flammable,
toxic or corossive chemicals when cleaning this unit. You should
clean the exterior of your water ionizer by using a slightly damp
cotton cloth with a small amount of dish washing liquid.
• If the unit falls into or is doused by water or any other liquid,
immediately pull its powerplug from the electrical outlet.
• This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities
nor by individuals with otherwise limited knowledge, skills and
abilities regarding the operation of electrical appliances in
general and water ionizers in speciifc unless they have received
supervised and/or written instruction (such as this manual) in
their safe operation.
• Young children should be supervised when attempting to operate
the unit.
• Do NOT place your water ionizer less than 3 feet from your oven,
furnace, space heater or any other active heat source or device.
• Do NOT disassemble, attempt to repair or modify your water
ionizer. This should only be done by a professional service
technician.
• If you have existing water hoses from a previously owned water
ionizer or other water dispensing, filtration or purification devices,
these hoses should be discarded and the new hoses provided
with your new water ionizer should be used instead.
DO NOT
IMPORTANT
WARNING
CAUTION
CAUTION

NEED HELP CALL 1-888-601-5886
07
Health Issues: If any of the following apply to you, please consult
your physician before drinking or continuing to drink ionized
alkaline water:
• You have kidney disease, renal failure, and/or have difficulty
discharging/eliminating potassium in which case you should
generally NOT ingest alkaline water.
• You are receiving medical treatment for another disease or
illness;
• You are chronically ill or otherwise in poor health;
• Your health appears to deteriorate after you’ve begun drinking
alkaline water;
• Previously existing health issues do not improve despite
continuously consuming alkaline water.
Beginning to Drink Alkaline Water: Your body may take a while to
get use to alkaline water:
• When drinking alkaline water for the first time, dispense the water
using your unit’s "Initial Drinking" setting and consume only small
amounts, 8 to 16 ounces (0.25 to 0.5 liters) per day.
• Continue this practice for at least 2 weeks prior to advancing to
your unit’s higher pH value "Daily Drinking" setting at which time
you should try to consume 32 to 64 ounces (1 to 2 liters) of
alkaline water per day.
• Attempting to drink higher pH value water before your body
becomes used to alkaline water can result in temporary
digestive, dermatological or other health related problems.
Alkaline Water & Medications: Do NOT drink alkaline water prior to,
with or immediately following taking pills or other medications.
Instead, use your unit's "Purifier Water," i.e., filtered but not
ionized, water setting. As a general rule, you should not consume
alkaline water within 45 mins. to one (1) hour either before or after
taking medication.
IMPORTANT
WARNING
IMPORTANT
CAUTION
DO NOTCAUTION

NEED HELP CALL 1-888-601-5886
Storing Ionized Water: Under normal temperature conditions,
alkaline water stored properly in a sealed, insulated container will
retain its ionized properties for at least 24 hours and up to 48 hours
when refrigerated.
• Do NOT store ionized water in metal containers. It should only be
stored in plastic, glass or ceramic containers.
• Exposing the container to direct sunlight may shorten the period
that alkaline water is able to retain its ionized properties.
Cosmetic Water Use: When using mildly acidic water from your
water ionizer's "Cosmetic" setting for skin care, as an astringent or
for hair care, please discontinue use and consult your physician if
you develop a skin rash or other allergic reaction.
Pets & Ionized Water: Dogs, cats and other mammals may benefit
from drinking ionized water. However, there are a few simple rules:
• Especially if your animals have any preexisting health problems,
consult your local veterinarian before giving them alkaline water
and/or following any negative health reaction to the alkaline
water.
• Start them off slowly on "Initial Drinking" setting and keep them
there for at least 2 weeks prior to moving to the "Daily Drinking"
setting. As a general rule, it's probably best not to exceed 9 pH.
• Do NOT give your pet alkaline water within 45 mins. to an hour
before or after meals. Use the "Purified Water" setting instead.
The higher pH levels can neutralize their stomach acids making it
more difficult for them to absorb nutrients.
• As with humans, Do NOT give your pets ionized water within 45
mins to an hour prior to, with or after taking medication. Doing so
can alter the intended absorption rate of the drug.
• While the "Cosmetic" water setting can be used to treat your pets’
minor wounds and improve its skin and coat. You should check
carefully for any allergic reactions or skin irritation.
IMPORTANT
CAUTION
IMPORTANT
CAUTION
08

NEED HELP CALL 1-888-601-5886
Fish & Aquariums: Unless you are an experienced aquarium owner
or qualified aquatic life professional, Do NOT introduce ionized
water to your aquarium without knowing the precise alkaline or
acidic water settings applicable to your particular fish species. Fish
may become ill or die if their water's pH balance is changed or
changed too quickly.
Exotic Pets: Lizard, snake, turtle, frog and other reptile and
amphibian species vary dramatically in the pH levels to which they
are suited. Please contact your veterinarian or pet shop owner
prior to giving them ionized water.
Plants: Different plants thrive on water of varying pH levels. For
example, some plants prefer more alkaline environments while
others perform better in more acidic ones. Consequently, before
watering your plants with ionized water, you should determine
the pH balance most conducive to the growth of your specific
plants.
Flushing Residual Water: Because a certain amount of water
remains trapped in your water ionizer's filters and tubing, you
should briefly drain this water off prior to each use.
• In order to remove any residual water left in your water ionizer,
you should generally dispense water from the unit for
approximately 1 second before each new period of use.
• If you have not used the unit for at least 2 weeks, you should
dispense water from the unit for at least 3 mins before using it.
Tainted & Leaking Water: If any of the following occurs, stop
drinking water from your ionizer immediately and contact an
authorized service technician. Not doing so could damage your
health...
• Taste or pH testing reveals that water dispensed from the unit
which should be alkaline is coming out acidic;
• Residual water appears to be dripping from the unit and/or is
discovered to be collecting around the electrodes during routine
cleaning and maintenance.
IMPORTANT
CAUTION
IMPORTANT
WARNING
09

NEED HELP CALL 1-888-601-5886
Continuous Operation: Do NOT exceed the following maximum
continuous operational time frames for your water ionizer:
• Do NOT operate the unit in "Initial Drinking," "Daily Drinking" or
"Cosmetic" mode for more than 60 minutes continuously.
• Do NOT operate the unit in "Cleaning," "Cooking" or mode
for more than 30 minutes continuously.
.
Consumable Water Limits: Though extremely high or low pH water
can be used for purposes besides drinking, e.g., cooking food,
cosmetic purposes or household cleaning, etc., humans, unless
directed by their physician for some unusual medical reason,
should not generally drink water higher than 10 pH nor lower than
7 pH on a regular basis.
Grounding: Your water ionizer should only be connected to an
electrical circuit that is protected by a "ground-fault circuit
interrupter," (GFCI)...
• This appliance must be grounded. In the event of a malfunction or
breakdown, grounding will reduce the risk of electric shock by
providing a path of least resistance for electric current.
• This appliance is equipped with a cord having an appliance-
grounding conductor and a grounding plug.
• The plug must be plugged into an appropriate outlet that is
installed and grounded in accordance with all local codes and
ordinances.
• Improper connection of the appliance-grounding conductor can
result in a risk of electric shock.
• Check with a qualified electrician or service representative if you
are in doubt as to whether the appliance is properly grounded.
• Do not modify the plug provided with the appliance; if it will not fit
the outlet, have a proper outlet installed by a qualified electrician.
DO NOTCAUTION
IMPORTANT
WARNING
IMPORTANT
WARNING
10

NEED HELP CALL 1-888-601-5886
Waste Disposal: In compliance with the "Waste Electrical and
Electronic Equipment Directive"...
• This marking indicates that this product should not
be disposed with other household waste through-
out the EU (European Union).
• To prevent possible harm to the environment or
human health from uncontrolled waste disposal
and to conserve material resources, this product
should be recycled responsibly.
• To dispose of your product, please use your local return and
collection systems or contact the retailer where the product was
purchased. They can take this product for safe environmental
recycling.
*R a te d P ow e r C on sum ptio n indicates th e m axim um po w er usage w hen the unit's "C ooking"
se tting is en gaged, ionized w a ter p H outp u t is constant and ra ted inflo w, w ater te m p e ra ture
and to tal disso lve d solid s (T D S ) are at th e ir d e fault valu e . T he actu a l po w e r consum p tion
va rie s to m a in tain a consta n t pH depending on the inflow rate, w ate r tem p e ra ture and TD S
Technical Specifications:
Model..................................................................................
Installation ........................Countertop/Optional Undersink Kit Available
Number of Plates..................................................................................7
Plate Construction.........................................Platinum Coated Titanium
Plate Surface Area ....................................................122 square inches
Plate Technology ........Long-Life/Low Power Consumption RTI Distinct
Constant Electrolysis ....................................................Yes; 60 minutes
Power System.....................................................................Transformer
Voltage........................................................................... AC 110V/60Hz
Wattage............................................................................4W idle/200W
Rated Power................................................................................200W*
IMPORTANT
11
AID7000/B

NEED HELP CALL 1-888-601-5886
Technical Specifications: (continued)
Max. Operating Temp ........................................................60°C / 140°F
Source Water Temp...........................................5° - 60°C / 41° - 140° F
Operational Pressure .............................14.5 - 43.5 psa / 0.1 - 0.3 Mpa
Water Flow Rate .........................................4 liters per min (adjustable)
pH Levels ......................................7 total: 4 alkaline, 1 neutral, 2 acidic
Adjustable pH ..................Yes: 3.5 to 11.0, depending on intake source
ORP Range ...........................................................-860mV to +1000mV
Measurements...................................8.25 (W) x 13 (H) x 4.3(D) inches
Weight ..................................................................................8.0 pounds
Filter System .......................................................... Active Carbon Filter
Filter Change Alert ......................................................Yes; LCD display
Filter Life .....................................................................4000-6000 Liters
Approx. 6 months to 1 Yr. with normal usage
Cleaning Cycles...............1. After each use, unit automatically cleans
itself for 10 seconds by reversing positive
and negative plate polarity.
2. Every 40 liters (10.6 gal.), the unit cleans
itself for 30 seconds by reversing positive
and negative plate polarity.
3. After each year of use, the unit should be
cleaned manually following the cleaning and
descaling instructions in this manual.
LCD Size........................6.3 sq in: 3.5 in x 1.8 in: 7 colors,1 per setting
Control Panel......................................Ultra-Responsive Bio-Touch Pad
FDA Approved Plastics.....................................................................Yes
ETL Certified ....................................................................................Yes
Warranty........................................................Limited Lifetime Warranty
12

NEED HELP CALL 1-888-601-5886
Installation Schematic: (Optional Wall Mont)
Flexible
Metal Spout
Power Cord
Inlet Water Hose
Acidic Water
Outlet Hose
Water Ionizer
Video Install Guide ONLINE
Installation Order: There are 7 simple steps to installing your
water ionizer each of which is described in detail beginning on the
next page. Please follow each of the following steps in order.
1. Identify Required Connector(s) & Attach Faucet Diverter Valve
2. Insert the Water Ionizer’s Inner Carbon Filter
4. Install the Flexible Metal Spout
5. Connect the Inlet Water Hose to the Faucet Diverter Valve
7. Check Connections
www.AquaIonizerPro.com/pages/install
13
8. Plug In the Water Ionizer
6. Connect by Product Line to Bottom Diverter.

NEED HELP CALL 1-888-601-5886
www.AquaIonizerPro.com/pages/install
3-Bolt Faucet
Connector
Dual-Thread
Faucet Connector
c. Unthreaded
a. Threaded
on Outside M ay ap pe ar id entica l to a n
inside th rea ded fa uce fro m
the o u tside .
22mm
over 3mm
b. Threaded
on Inside
Th rea d s w ill no t be v isib le from ou tside.
Fe e l inside fa ucet s p ou t fo r th rea d s.
Faucet Diverter
Valve
Inner Thread
Faucet Joint
Installation Step 1 - Identify Required Connectors/Attach Faucet
Diverter Valve: Home faucets typically fall into 1 of 3 categories, a.)
threaded on the outside, b.) threaded on the inside, and c.)
unthreaded, i.e., those without screw on/in connectors.
The type of faucet you have will determine whether you can attached
the Faucet Diverter Valve directly to your faucet or which of the type of
faucet connector(s) you will use to attach the faucet diverter valve to
your faucet. There are three connectors included with your water
ionizer, a 3-bolt faucet connector, an inner thread faucet joint and
a Dual-Thread Faucet Connector.
a) Thread Outside Faucet: You will usually not need to use a
connector. Simply screw the faucet diverter Valve directly onto the
faucet.
14

NEED HELP CALL 1-888-601-5886
www.AquaIonizerPro.com/pages/install
b) Threaded Inside Faucet: Being sure to first insert the washer, screw
the dual-thread faucet connector into the faucet. Then screw the
faucet diverter Valve onto the Dual read Connector.
3-Bolt Faucet
Connector
Dual-Thread
Faucet Connector
24mm
Faucet Diverter
Valve
c) Unthreaded Faucet: If your faucet has neither inside nor outside
threads, loosen the bolts on the 3-bolt faucet connector, slip it over
the end of the faucet pressing upward firmly then tighten bolts
securely locking it on to faucet. Next, screw the inner faucet thread
Joint securely into the bottom of the 3-bolt faucet connector. The
screw the faucet diverter Valve onto inner thread joint which you’ve
just attached to the 3-bolt faucet connector .
22mm
Faucet Diverter
Valve
Inner Thread
Faucet Joint
IMPORTANT
In some instance, either because the threads are
damaged, too wide, or too narrow, you may need to
use the 3-bolt faucet connector assembly method
even on threaded inside or outside faucets.
15

NEED HELP CALL 1-888-601-5886
Installation Step 2 - Insert the Inner Carbon Filter:
Though your water ionizer's Inner Carbon Filter is shipped with your water
ionizer, it is NOT preinstalled in the unit. Simply remove the filter from the
box, remove any packing materials, and install it in the following manner:
A. Remove the water ionizer's Outer Filter Cover by pressing on the arrow
with your thumb, squeezing gently with your finger and pulling up.
B. Firmly grasp the water ionizer's Inner Filter Cover and twist it counter
clockwise to open and gain access to the filter chamber.
C. After unpacking the new Inner
Carbon Filter, hold the end with the
sealing ring on it under running tap
water for 3 minutes to flush away
any loose carbon particles, remove
excess air, and to prime the filter.
Fig. C
Fig. A Fig. B
Inner Filter Cover
Inner Carbon
Water Filter
Outer Filter Cover
16

NEED HELP CALL 1-888-601-5886
www.AquaIonizerPro.com/pages/install
D. Insert the newly flushed Inner Carbon Filter into the open filter
chamber as shown in Fig. D.
E. Reseat the Inner Filter Cover and twist it clockwise to close the
filter in filter chamber.
Fig. D Fig. E
Inner Filter Cover
Inner Carbon
Water Filter
Replacing Filters: The Inner Carbon Filter should be replaced after every 4000-6000 liters / 1280g
gallons of water being dispensed, which means it will last up to a year under normal use
conditions. However, regional, environmental, and other differences in water quality, such as
more polluted municipal water, may require the filter to be replaced more often. If you notice an
unusual odors or taste in your water replace the filter as necessary.
IMPORTANT
VIDEO FOR HELP
-
Installation Step 3
Note: You may need to cut the hoses shorter again to fit your setup if you
have extra, but please wait until you are done with the installation. Once Cut,
each section is about 3 feet long.
A)
B)
OUT IN
Fresh Water Inlet next to power cord.
Your Ionizer will come with two 1/4 inch white hose installed. With
caps on the end.
The Out Hose will have a RED make- that will match up
with the RED dot on the Diverter in the next step.
17
Silicon Caps

NEED HELP CALL 1-888-601-5886
Attach Metal Spout:
REMOVE THE PLASTIC Innner Cover
Screw the flexible Metal Spout clockwise into the outlet connector on top of
the water ionizer.
Connect the Inlet Water Hose to the Faucet
Diverter Valve:
Connect the Inlet Water Hose to the top faucet diverter valve
and the Acidic Water Outlet Hose into the bottom valve.
Inlet Water Hose
On Top
Acidic Water Outlet Tube
On the Bottom
CAUTION: Be sure that the Metal Spout, and the white ¼” hoses for the source
water ('IN') and the acidic ('OUT') are attached correctly to the bottom of the unit as
described in Steps 3 & 4. Remember the Water Inlet is near the Power Cord.
18
The out hose will have a RED
dot that will match up with the
RED dot on the Diverter.
(Red Dot)
Installation Step 5
Installation Step 4
If you a leak unscrew until leak stops. If it persists call 1-888-601-5886
