ReAthlete Cyclo User manual

1
Compact Electric Pedal Exerciser
for Training and Rehabilitation
USER MANUAL
Contact us:
www.reathlete.com
[e-mail]

2
Thank you for purchasing the CYCLO!
We are excited for you to experience the wide range of health and wellness
benefits that come with using our product.
This User Guide is intended to provide you with guidelines to ensure that the
operation of this product is safe and poses no risk to the user. Using this product in
a manner that does not comply with the guidelines described in this manual may
void the product warranty.
Please read all directions before using the product
and retain this guide for reference.
Make sure that you
have all of the pieces:
1Main Frame
2Stabilizer X2
3Right Pedal
4Left Pedal
5Screw X4
6Washer X4
7Right Crank
8Left Crank
9Pedal Straps
2
2
3
9
9
4
1
7 8
Assembly Instructions:
Take the unit out of the box and place it
on the floor as shown in Figure 1.
5
6
Figure 1.

3
Step 1
Attach the STABILIZERS (2) to the front and to the back end
of the MAIN FRAME (1) with SCREWS (5) and WASHERS (6) as shown in Figure 2.
Figure 2.
Figure 3.
Step 2
The LEFT PEDAL (3) is labeled with
an L. The LEFT PEDAL (3) has left
hand threads and is tightened
by turning clockwise. The RIGHT
PEDAL (4) is labeled with an R. The
RIGHT PEDAL (4) has right hand
threads and is tightened by turning
counterclockwise.
Thread the LEFT PEDAL (3) to the
LEFT CRANK (7) as shown in Figure
3. Tighten the pedal securely with
an open-end wrench. Use the same
procedure to attach the RIGHT
PEDAL (4) to the RIGHT CRANK (8).
Snap PEDAL STRAPS (9) onto the
LEFT PEDAL (3) and RIGHT PEDAL (4).
2
5
5
6
6
1 1
2
3
9
9
4
7
8

4
Remote Control
1Change Mode (Manual/Automatic)
2Forward/Reverse (Pedal Direction)
3Decrease Speed (12 intensity levels)
4Increase Speed (12 intensity levels)
5Decrease Resistance
6Increase Resistance
7Start Workout
8Pause/Reset Workout
Manual Mode
Get cardio and aerobic improvements
and exercise different muscle groups
of the lower and upper body. Enjoy
the training!
Press
7
start to use every time
Press
5
or
6
to adjust between
different intensity levels of resistance
Press
8
if you want a break. Within
30 minutes you can press
7
to resume
the training with the same settings.
Press
8
for twice to reset the settings.
Automatic Mode
In the Automatic mode CYCLO turns the
pedals on behalf of the user in order to
therapeutically encourage leg or arm
movements. Enjoy the rehabilitation!
Press
7
start to use every time
Press
2
to switch between forward
and reverse (direction of pedals)
Press
3
or
4
to adjust between
12 different speeds.
Resistance is inactive in this mode.
Press
8
if you want a break. Within
30 minutes you can press
7
to resume
the training with the same settings.
Press
8
for twice to reset the settings.
1
7
3 4
5
6
2
8

5
LED Display
1
In the manual mode, the Manual mode
indicator lights up on the LED screen.
2
In the automatic mode, the Automatic mode
indicator lights up on the LED screen.
3
Displays the time in minutes:seconds.
4
The stopwatch handle rotates as the time
passes to indicate the duration of exercise.
5
The different intensity levels of resistance
range from 0 to 100, with power dots lighting
progressively from bottom to the top
according to the selected resistance level.
6
The speed is displayed in miles per hour.
7
The speed accelerometer grows as
the speed increases.
8
The cycle counter counts up every
completed lap (0.05 mile) and the dots
moving around the running track show how
close you are to completing the next lap.
9
The total distance of the workout is displayed
in miles.
10
The number of calories burnt during the
workout are displayed.
How to Use
Position 1: Seated (Lower Body).
Place the unit on the floor in front of
a chair. Sit in the chair and pedal the
bike with your feet.
Position 2: Lying (Lower Body).
When lying down, place the unit at a
comfortable distance and make sure
that your lower back is supported.
You can use a small cushion at the
base of your back. Pedal the bike
with your feet.
Position 3: Seated (Upper Body).
Place the unit on a table at chest height
and at a comfortable distance and sit
on a stable chair. Pedal the bike with
your hands.
Use the remote control to select the
manual or automatic mode and the
relevant settings.
To turn the massager OFF, press
[PAUSE] button for 3s. To unplug the
machine, first turn it off and then
unplug from the wall socket.
1
3 5
6
7
8
910
4
2

6
Important Safety Notice:
1) Please unplug the device when it is not in use.
2) There are NO user serviceable parts in this product.
3) Ensure that the cable DOES NOT come into contact
with the pedals while in use.
4) DO NOT touch or insert any objects into the moving
parts while the machine is in use.
5) DO NOT submerge product in water or other liquids.
6) Do not touch the power plug with wet hands.
7) Pregnant women and children under 12 years old
MUST NOT use this product.
8) Keep dry: DO NOT operate in a wet or moist condition.
9) DO NOT use this product in a high-temperature or
humid environment. DO NOT leave this product in
direct sunlight for a long time.
10) DO NOT leave this device unattended while turned on.
11) NEVER operate this device if the cord or plug
is damaged.
12) DO NOT operate if the item is malfunctioning
or has been exposed to water.
13) DO NOT crush. DO NOT place heavy objects
on this product.

7
Storage:
Store the device in a safe, dry and cool place. To avoid
breakage, DO NOT wrap the power cord around
the device.
Cleaning And Maintenance:
Turn off and unplug the unit before cleaning. Clean only
with a non-abrasive cleaner or mild detergent with a soft
cloth. Wipe dry the equipment after cleaning.
Caution:
1) Do not use the device to supplement or replace any
medical treatment that you are currently receiving.
Please consult your physician before use if you are
experiencing any unexplained pain.
2) Please contact your physician before using the
REATHLETE CYCLO if you have physical health concerns
or have any of the following conditions:
You have hypertension.
You have undergone a recent surgery.
You have concerns regarding areas of your health.
3) Stop using the product immediately if you feel
uncomfortable or if any abnormalities occur.

8
lf you encounter any other problems,
please contact us at [e-mail]
