Record HA8-LP User manual

Record HA8-LP
Low-Energy Door Operator
Mechanical Setup Quick Start Guide
www.recorddoors.com

Recommended
Tools
Item
No.
Description Item No. Description
1Allen Wrench Set 6Flat Screwdriver, Philip Screwdriver, 5/16” Hex. Nut Driver
2Power Drill and Drill Bits 7Additional Fasteners Depending on Surface
3Level 8Shims
4Tape Measure 9Hand Saw/Power Saw
5Wire Stripper
Record HA8-LP
Low-Energy Swing Door Operator

Record HA8-LP
Handing Chart
left-push-surfacer·ight-push-surface
Ieft-pu11-surfoce right-pulI-surface
•
•

•
•
•
•
•
Installation of the Back Plate

•
•
shims
Figure 6
Figure 5
Figure 4
Installation of the Back Plate

LH RH
Installation of Power and Motor/Gearbox

Figure 11
Installation of Control Board

14”
Installation of Push Arm

Note:
Inspect that arm is not binding or rubbing
on door.
Keep ARMS level during installation.
External door or floor stop is required.
Do not use ARM as door stop.
Installation of Push Arm

Step 17] Pull Arm
1. Toggle hold open button on end cap
2. Verify that pinion output shaft turns in
the right direction
3. When spindle stops, open the door and
connect main arm to spindle output
shaft and tighten. Mark Spot where
Roller touched the door. See Figure 12
4. Turn hold open off and Close door.
Mark where roller touches the door
5. Center track on the two marks. See
Figure 12a
6. Keep track level when mounting to the
door.
Note:
Inspect that arm is not binding or rubbing on door.
Keep TRACK Level during mounting.
External door or floor stop is required.
Do not use track as door stop.
Door Shown Open
Figure 12
MARK THE POSITION WHERE
/THE ROLLER TOUCHES THE DOOR
,r-
MARK THE POSITION WHERE
THE ROLLER TOUCHES THE DOOR
ALIGN SLIDE TRACK WITH
MARKED POSITIONS
\SLIDE TRACK
Installation of Pull Arm

± ±
Signage

Mechanical Installation Complete
Next Step - See Control Board Setup
