Red Panda RASTER User manual

Feedback Description
Initial delay and all repeats are reversed.
Each repeat is shifted higher or lower
than the previous.
Each repeat is shifted higher or lower
than the previous.
The rst repeat is shifted. Subsequent
repeats stay at the same pitch.
Shift Description
Transpose by semitones, +/- 12 semitone
range (25 steps).
Detune from a 4th down to a minor third
up (continuous).
Phase shifter (not available with reverse
feedback).
Bypass
indicator
Thank you for purchasing the Red Panda Raster. The Raster is a digital delay with a pitch shifter integrated into the feed-
back loop. Knob responses are carefully tuned for exploration of self-oscillation and feedback on the verge of blowing
up, but it also works great for clean delays up to 750 ms.
The pitch shifter operates in three modes, with three types of feedback, for a total of 8 dierent combinations:
RASTER
9V DC
Shift pedal/CV
InputOutput
Shift amount
(center o)
Wet/dry blend
Shift indicator
Shift on/o True bypass
Feedback
(100% at 3:00)
Delay time
20-750 ms
WARRANTY
This product is warranted against defects in materials or workmanship for one (1) year from date of original purchase. It
does not cover damages or wear resulting from accident, misuse, abuse, or unauthorized adjustment and/or repair.
Should this product require service (or replacement at our option) while under warranty, please contact
[email protected].
SHIFT
Amount of pitch or phase shift. When the SHIFT footswitch is disengaged (orange LED o), the signal is not shifted.
Plugging in an expression pedal will override the shift knob.
FDBK
Feedback intensity. Innite repeats occur with the knob at approximately 3:00. At settings above 3:00, the repeats gain
in strength for self-oscillation, distorted echoes, and feedback loops.
DELAY
Delay time, from approximately 20 to 750 milliseconds. Short delays with high feedback will create resonance or self-os-
cillation, especially when the shift knob is near zero. The delay knob is tuned for short delays. By carefully adjusting the
delay time and feedback, you can create chaotic self-oscillating drones.
BLEND
Adjusts output from 100% dry to 100% wet.
POWER
Red Panda pedals require a 9V DC center negative, regulated power supply (Boss style). A few examples are the Boss
PSA-120S, Visual Sound One Spot, and the Voodoo Lab Pedal Power series. Using an incorrect power supply may dam-
age your pedal.

SOUNDS
CHORUSED DELAY
Use detune ( ) or phase ( ) mode with small shifts to create chorused repeats.
OCTAVE/HARMONY DELAY
Use transpose ( ) mode with only the rst repeat shifted ( ).
SELF-OSCILLATION
Set the SHIFT knob at or near 12:00, FDBK above 3:00, and DELAY below 10:30. Adjust the delay to change the fre-
quency. Phase shifted ( + ) repeats create bubbling, psychedelic resonant sounds. Unshifted repeats ( ) give distort-
ed self-oscillation.
OVERDRIVEN FEEDBACK
Feedback settings above 3:00 create overdriven feedback and distorted growls. Phase shift ( ) mode with unshifted
repeats ( ) is good for creating squelchy, overdriven feedback sounds.
OLD SCHOOL PITCH SHIFTING
Use transpose ( ) mode with no delay or feedback for discrete semitone shifts. For continuous pitch shifting, use de-
tune ( ) mode. The pitch shifting algorithm adds a slight warble, similar to classic digital pitch shifters.
PLASTIK BASS
Use detune ( ) mode with reverse ( ) repeats. Set SHIFT to approximately 1:30, FDBK to 2:00, DELAY to 8:00, BLEND
at 9:30. Adjust SHIFT, FDBK, and DELAY for squelchy resonance.
REVERSE DELAY
Disable SHIFT and set feedback mode to reverse ( ). The reverse eect is more noticeable at longer delay settings.
At shorter delays, short segments are reversed which gives more of a tremolo sound. With feedback and pitch shifting,
short delays create cascading shifted trails and alien textures.
BARBER POLE FLANGING
Use phase ( ) mode with shifted ( ) repeats. Set FDBK around 2:30 and a short delay to create sounds that seem to
continuously shift up or down in pitch.
ORGAN
Use transpose ( ) mode with repeats shifted ( ), SHIFT at 5:00, FDBK around 2:00, DELAY at 7:00, and BLEND around
3:00. Lowering the blend will bring in more of the guitar attack and adjusting the FDBK knob will change the overtones.
ARPEGGIOS
Use transpose ( ) mode with medium to long delays to shift ( ) each repeat up or down by semitones.
Minor thirds: dissonant intervals that stack to form diminished 7th chords.
Major thirds: augmented chords have a static harmonic characteristic, which can blur tonality.
4ths and 5ths: stack to form quartal and quintal harmonies.
7ths: stacking 7ths will give you nicely spaced tone clusters that sound very dissonant.
Expression Pedals and Control Voltages
Any expression pedal with a 10k-50k ohm linear pot will work. For example, the Roland EV-5, Moog EP-3, M-Audio EX-P,
or Mission Engineering EP-1. You can also use an Electro-Harmonix 8-Step Program to sequence the sampling rate. For
control voltages, 0-3.3V on the tip is the correct range. The Raster has current limiting in case you use a TS cable, but it
is best to use a 1/4” TRS cable with the ring unconnected. The Expert Sleepers “oating ring” cable is an easy way to do
that. We also sell suitable cables at store.redpandalab.com.
