Operating Instructions
2 x 50W Bluetooth Amplier
A 4860
A 4860 2 x 50W Bluetooth Amplier
• Class-D 2 x 50W amplier
• Bluetooth 4.2 wireless streaming
• Stereo RCA & 3.5mm jack inputs
• Optical input with high performance DAC
• Automatic signal switching with priority for
Bluetooth audio source
• 240V AC operation
Features

A 4860 2 x 50W Bluetooth Amplier A 4860 2 x 50W Bluetooth Amplier
Specications
Power Output 25WX2 (RMS @ 8Ω)
Power Output 50WX2 (RMS @ 4Ω)
Total Harmonic Distortion (THD) <1%(Rated power: 50W @ 4Ω)
Signal to Noise >92 dB A WTD
Frequency Response 20Hz~20KHz +0/-2dB@ -3dB
Sub Out Frequency 100Hz/1V
Line Level Input Sensitivity 700mV
Channel Separation 50dB
Bluetooth 4.2
Protection Overload , Speaker Short
Dimension 200mm x125mm x 47.5mm (WxDxH),
Weight 0.6kg
• Do not expose this unit to water, mositure, or excessive humidity.
• Do not install or place this unit in a built-in cabinet, or other conned space without adequate
ventilation.
• To prevent risk of electrical shock or re hazard, due to overheating do not obstruct unit’s
ventilation openings.
• Do not install near any source of heat including other units that may produce heat.
• Do not place unit near ames.
• Only clean unit with a dry cloth.
• Unplug unit during lightening storms or when not used for an extended period of time. A
surge protector is strongly recommended.
• Protect the power cord from being walked on or pinched particulary at the plugs.
• Use unit only with accessories specied by the manufacurer.
• Refer all servicing to qualied personal.
Safety Instructions
TO REDUCETHE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SER-
VICEABLE PARTS INSIDE. REFER SERVICINGTO QUALIFIED SERVICE PERSONAL.
CAUTION
This 50W bluetooth stereo amplier provides clean Class D power with compact and a lightweight
design. It features Bluetooth 4.2 streaming with in-built optical input for digital audio sources.The
amplier is also tted with 3.5mm stereo jack and stereo RCA inputs for connection to external
audio sources. Bluetooth takes priority over all other inputs, providing easy wireless streaming
when you need it.The 2 x 50W RMS output is ideal for small retail environments. It is perfectly
paired with the A 4861 subwoofer amplier and C 1065 ceiling mount subwoofer for added musical
performance.
Introduction
Connection Diagram
Connection Diagram - A 4860 to A 4861
A4860 A4861
A4860A4861
SpeakerSubwoofer
SpeakerSubwoofer
B
luetooth or Audio Input
Bluetooth or Audio Input
A4860 A4861
A4860A4861
SpeakerSubwoofer
SpeakerSubwoofer
Bluetooth or Audio Input
Bluetooth or Audio Input
Option 1: Line Level Input Connection
Option 2: Speaker leverl (High Level) Input Connection
A 4860 as a standalone
stereo speaker amplier
2 3

A 4860 2 x 50W Bluetooth Amplier A 4860 2 x 50W Bluetooth Amplier
Rear PanelFront Panel
1. Power Switch:The front panel switch will manually turn the power on or off.
2. Power LED: Red - Standby / Protection. Green - The amplier is in working status.
3. Input Source Indicator: Blue - Bluetooth Red - Optical In Green: Line In (RCA or 3.5mm)
4. Volume: Adjust the output level.
5. Line In: 3.5mm Audio input jack, accepts the audio signal from smartphone, tablet, MP3 player or
other device.
NOTE: When audio device is plugged into this 3.5mm input jack, the RCA input jacks on rear panel
are disconnected.
NOTE: For Bluetooth pairing, turn on the amplier, and ensure your device has Bluetooth enabled.
Connect the device to amplier directly and begin audio playback in your device. The bluetooth
recognition ID is A4860.
1. Antenna: For a wireless Bluetooth connection.
2. RCA inputs: For connecting to audio devices equipped with analog output.
3. Sub Out: For connecting to a subwoofer amplier or active subwoofer speaker.
4. Optical In: For connecting to audio devices equipped with digital optical output.
5. Speaker Output: For connection to speakers.
6. AC Power In: For connecting the power cord.
4 5
