Redline Engineering RTS3000 User manual

Redline Engineering
RTS3000 - 3000 lb
Capacity Rotisserie
Assembly Manual

Set all like hardware together in matching fashion.

Using 17mm socket wrench, install 10mm bolts, washers, and lock washers to secure all 6 caster wheels
to the bottom of the T shaped frame bases.

Next, use a 24mm socket and wrench to install the 16mm x 110 bolts with corresponding lock washer,
washer, and nuts to secure upright mast heads (part A) to the T-shaped frame bases. Leave all bolts
hand tight during the assembly process. The base on the right depicts this has been done while the base
on the left has not yet completed this step.

Attach the 45 degree angle braces (part B) to the base of the rotisserie at each end. Use four 16mm x
110 bolts across the bottoms and two 16mm x 120 bolts across the tops. Use washer, lock washer, and
nut.The base on the left depicts this has been done while the base on the right has not yet completed
this step.

Next, secure the hydraulic bottle jack (part C) to the frame base with one 16mm x 90 bolt, washer, lock
washer, and nut to the bottom on each side. Leave the bottle jack leaning against the upright as shown
on the left. The base on the left depicts this has been done while the base on the right has not yet
completed this step.

Slide the non-gear drive rotating head assembly (Assembly D) over the masthead making sure the
hydraulic cylinder ram slides into place as shown. You’ll likely need to spin the hydraulic cylinder ram to
align the holes. Once done, use a 16mm x 65 bolt, washer, lock washer, and nut to secure the top of the
hydraulic ram to the bottom of the rotating head assembly (Assembly D).

When the parts below are fully assembled, Bolt A should protrude into the collar shown below. This
keeps the two pieces from separating when the vehicle is spinning. We recommend tightening bolt A so
that it is tight into the collar, and then releasing Bolt A just enough so that the two assemblies spin
freely. Bolt B is a pinch bolt intended to lock the rotisserie angle in place for working on the vehicle.

Using a 19mm socket and wrench, bolt the gear drive (Part E) to its corresponding mounting plate
(Part F) using four M12 bolts, washers, lock washers, and nuts. This step and the next step can be
completed on the rotisserie if lifting this heavy assembly below is problematic for the user.

Using a 19mm socket and wrench, bolt the T carriage mount (Part G) to the rotating gear drive head
(Part E) using four M12 bolts, washers, lock washers, and nuts.

Slide the gear drive assembly (Assembly H) onto the masthead of the rotisserie frame. Rotate the
handle to ensure the assembly is in the proper orientation as shown below. Both right and wrong are
depicted below and labeled accordingly. Use 16mm x 65 bolts, washers, lock washers, and nuts to
secure the top of the hydraulic ram to the gear drive assembly (Assembly H) as shown.

Use the jack handle to raise each end of the rotisserie high enough so that the T carriages can be
installed in the oncoming steps.

Use 24mm bolts and nuts to secure the rotating assembly to the upright.

Use 24mm bolts and nuts to secure the T carriages to the rotating head assembly. Pick whichever hole
you like.

Slide the two mounting arms (Parts L) onto the T-carriage (Part K) at each end and secure the pinch bolts
tightly enough so that they do not fall onto your feet when the T carriage is rotated.

Thread the balancing rods into place as shown. You’ll thread the balancing rod far enough into the
threaded block so that the head of the balancing system aligns with the corresponding mounting holes
as shown in the next step.

Use a 6mm allen tool and 14mm wrench to tighten the four 8mm bolts, washers, lock washers, and nuts
into place. Do this at each end.

Assemble the three telescopic lower frame arms into place as shown below. Tighten the jam bolts into
place at your desired width

Tighten all loose bolts so the rotisserie is extremely rigid. Congrats, you’re done with assembly! Now
you can move onto mounting your vehicle to the rotisserie and aligning the center of gravity of the car
with the center rotating axis of the rotisserie. This step balances the car on the rotisserie and is both
extremely important for safety as well as to avoid damaging your rotisserie and car.

Bolt your car to the rotisserie as you see best fit. It is recommended that you secure your rotisserie
mounting arms to the frame assembly of the car. The following photos depict mounting a 1967 Nova
unibody car to the RTS3000 rotisserie. Redline front unibody brackets and rear leaf spring brackets were
used. Your vehicle is likely to be much different, so these photos are provided for example purposes
only. A full how-to video can be found on our Redline YouTube channel showing this mounting process
as well as the balancing process.
